Chef CG920FGS User manual

RANGEHOOD
User Manual
CG920FGS

USER MANUAL RANGE HOOD C(920FGS
2
3
3
3
4
5

8
9
10
11
1
Adherence to the directions for use in this manual is
extremely important for health and safety. Failure to strictly
adhere to the requirements in this manual may result in
personal injury, property damage and affect your ability
to make a claim under the Westinghouse manufacturer’s
warranty provided with your product. Products must
be used, installed and operated in accordance with
this manual. You may not be able to claim on the
Westinghouse manufacturer’s warranty in the event that
your product fault is due to failure to adhere this manual.
IMPORTANT INFORMATION THAT MAY IMPACT
YOUR MANUFACTURER’S WARRANTY

USER MANUAL RANGE HOOD C(920FGS
2
3
3
3
4
5

8
9
10
11
1
2

DESCRIPTION OF YOUR RANGEHOOD
Technical specifications
Height -113cm
Width 90cm
Depth 50cm
Maximum absorbed power W
Lighting 2 x 50W
Outlet diameter 1 mm
Electrical connection 220-240V, 50Hz
MODEL
1
2
Flexible flue pipe to be sourced locally
3
4
5
6
7Fig.3
Components list
1. Screws x 2
2. Telescopic flue cover set
4. Upper flue cover mounting bracket
5. Lower flue cover mounting bracket
6. Flue transition duct
7. Main body and fan housing assembly
8. Grease filter
Additional items required for installation
to wall.
See Fig. 4 for reccommended working heights, cover
flue mounting bracket locations and telescopic flue cover
fixing points.
3
• Flexible flue pipe.

RANGEHOOD DIMENSIONS
320mm
540mm
543mm
Min 820
Max 1130mm
500mm
500mm
Fig.4
900mm
280mm
4

exhausting fumes from appliances burning gas or other
fuels.
5

Warning: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards.
The warning shall be in the same part of the instructions that include details of how to mount the equipment.
6

Fig. 11
10. Install internal exhaust duct to suit installation type.
Fig. 12
11. Install bottom section of telescopic flue cover.
Fig. 13
12. Install the top section of the telescopic flue cover by
sliding up and securing the top flue to the wall mounting
bracket with the screws provided.
Fig. 14
INSTALLATION
130mm 130mm
7

USING YOUR RANGEHOOD
CONTROL PANEL
s¬"EST¬RESULTS¬ARE¬OBTAINED¬BY¬USING¬A¬LOW¬SPEED¬FOR¬NORMAL¬
conditions and a high speed when odours are more
concentrated.
s¬4URN¬THE¬HOOD¬ON¬A¬FEW¬MINUTES¬BEFORE¬YOU¬START¬COOKING
s¬4HE¬HOOD¬SHOULD¬BE¬LEFT¬ON¬FOR¬ABOUT¬¬MINUTES¬AFTER¬
cooking, or until all odours have disappeared. The control
switches are located on the unit’s front panel (Fig. 15).
s¬4HE¬CONTROL¬PANEL¬COMPRISES¬OF
– T: Indicator lamp
– U: Light button
– V: Off button
– W: Fan speed selection.
1 dot = low speed for light frying/boiling.
2 dots = medium speed for frying/
wok cooking/heavy boiling.
3 dots = high fan speed for grilling/
intensive frying/and wok cooking.
Fig. 15
MAINTAINING YOUR RANGEHOOD
WARNING
IMPORTANT: The hood must always be disconnected from the
electricity supply before beginning any maintenenace work.
Cleaning the hood
s¬ #LEAN¬THE¬OUTSIDE¬OF¬THE¬HOOD¬USING¬A¬DAMP¬CLOTH¬AND¬
a solution of water and mild washing up liquid.
s¬ .EVER¬USE¬CORROSIVE¬ABRASIVE¬OR¬FLAMMABLE¬CLEANING¬
products or products containing bleach.
s¬ .EVER¬INSERT¬POINTED¬OBJECTS¬IN¬THE¬MOTORS¬
protective grid.
s¬ /NLY¬EVER¬CLEAN¬THE¬SWITCH¬PANEL¬AND¬FILTER¬GRILL¬USING¬A¬
damp cloth and mild washing up liquid.
s¬ )T¬IS¬EXTREMELY¬IMPORTANT¬TO¬CLEAN¬THE¬UNIT¬AND¬CHANGE¬THE¬
filters at the recommended intervals. Failure to do so will
cause grease deposits that could cause a fire.
NOTE: The metal grease filters must be removed and
washed, either by hand or in the dishwasher, at least
every four weeks.
Removing the metal grease filters
s¬ 0USH¬THE¬GREASE¬FILTER¬TOWARDS¬THE¬LEFT¬SIDE¬OF¬THE¬UNIT¬AND¬
then pull it down.
Hand washing
Soak grease filters for about one hour in hot water with a
grease-loosening cleaner, then rinse off thoroughly with hot
water. Repeat the process if necessary. Refit the grease filters
when they are dry.
Dishwasher
Place grease filters in the dishwasher. Select the most
powerful washing program and highest temperature, at
least 65°C. Repeat the process. Refit the grease filters when
they are dry. When washing the metal grease filter in the
dishwasher a slight discolouration of the filter can occur, this
does not have any impact on it’s performance.
8

Changing the light bulb
Ensure the appliance is switched off before carrying out
maintenance, to avoid any possibility of electric shock.
Remove grease filter to relace lamp. Replace with 50W
(maximum) GU10 halogen lamps.
Charcoal filter
sThe charcoal filter should only be used if you want to use
the hood in the recirculation function.
sThis filter cannot be cleaned or re-used and as a general
rule, the activated charcoal filter should be changed once
every four months.
Fitting the charcoal filter
Fit one charcoal filter on the left and one on the right so as
to cover the plastic grids that protect the fan wheel.
sAlways specify the hood model code number and
serial number when ordering replacement filters. This
information is shown on the registration plate located on
the inside of this unit.
sReplacement charcoal filters can be ordered from your
local Service Centre.
TROUBLESHOOTING GUIDE
PROBLEM REMEDY
The cooker hood will not start
Check that the hood is connected to an electrical supply
Check that a fan speed has been selected
The cooker hood is not working
Check that the fan speed is set high enough for the task
The grease filter are clean
The kitchen is adequately vented to allow the entry of fresh air
If set up for recirculation, check that the charcoal filter is still effective
If set up for extraction, check that the ducting and outlets are not blocked
The cooker hood has switched off
during operation
The safety cut-out device has been tripped – turn off the hob and wait for the device to reset.
If the hood has been installed below the heights indicated in the installation instructions the
motor will cut out frequently which will damage the hood
MAINTAINING YOUR RANGEHOOD
NOTE: This product is fitted with a safety cutout device.
s If the cooker hood is installed too close to the cooktop, flambe cooking, operating the cooktop without cooking utensils and blocked
filters may activate the safety cutout device. If the hood stops during operation, correct the faults and allow time for the safety cutout
device to reset, the cooker hood will then function correctly.
s Do not operate cooktop without pots/pans.
s Do not flambe under cooktop.
9

OPTIONAL DUCTING ACCESSORIES
AR125RC
AR125F
AR610CF
AR610RK
AR125B
AR1200FS
AR125WV
Part Numbers Description
AR125RC 120mm G/Bond Roof Cowl
AR125F 120mm G/Bond Flue 1200mm
AR125WV 120mm Wall Vent
AR125FD 120mm Flexi Duct
AR610RK Recirculating Kit
AR610CF Replacement carbon mat filter
AR1200FS Stainless steel exhaust cover extension 1200mm
10

notes

notes

This document sets out the terms and conditions of the product
warranties for Chef Appliances. It is an important document. Please
keep it with your proof of purchase documents in a safe place for
future reference should there be a manufacturing defect in your
Appliance. This warranty is in addition to other rights you may have
under the Australian Consumer Law.
1. In this warranty:
(a) ‘ACL’ or ‘Australian Consumer Law’ means Schedule 2 to the
Competition and Consumer Act 2010;
(b) ‘Appliance’ means any Electrolux product purchased by you and
accompanied by this document;
(c) ‘ASC’ means Electrolux’s authorised serviced centres;
(d) ‘Chef’ is the brand controlled by Electrolux Home Products Pty Ltd
of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004 762 341
in respect of Appliances purchased in Australia and Electrolux (NZ)
Limited (collectively “Electrolux”) of 3-5 Niall Burgess Road, Mount
Wellington, in respect of Appliances purchased in New Zealand;
 (e) ‘WarrantyPeriod’meanstheperiodspeciedinclause3ofthis
warranty;
(f) ‘you’ means the purchaser of the Appliance not having purchased
the Appliance for re-sale, and ‘your’ has a corresponding meaning.
2. Application: This warranty only applies to new Appliances, purchased
and used in Australia or New Zealand and is in addition to (and does not
exclude, restrict, or modify in any way) other rights and remedies under
a law to which the Appliances or services relate, including any non-
excludable statutory guarantees in Australia and New Zealand.
3. Warranty Period: Subject to these terms and conditions, this warranty
continues for in Australia for a period of 24 months and in New Zealand
for a period of 24 months, following the date of original purchase of the
Appliance.
4. Repair or replace warranty: During the Warranty Period, Electrolux
or its ASC will, at no extra charge if your Appliance is readily accessible
for service, without special equipment and subject to these terms and
conditions, repair or replace any parts which it considers to be defective.
Electrolux may, in its absolute discretion, choose whether the remedy
oeredforavalidwarrantyclaimisrepairorreplacement.Electroluxorits
ASC may use refurbished parts to repair your Appliance. You agree that
any replaced Appliances or parts become the property of Electrolux.
5. Travel and transportation costs: Subject to clause 7, Electrolux will
bear the reasonable cost of transportation, travel and delivery of the
Appliance to and from Electrolux or its ASC. Travel and transportation will
be arranged by Electrolux as part of any valid warranty claim.
6. Proof of purchase is required before you can make a claim under this
warranty.
7. Exclusions: You may not make a claim under this warranty unless the
defect claimed is due to faulty or defective parts or workmanship. This
warranty does not cover:
 (a) lightglobes,batteries,ltersorsimilarperishableparts;
(b) parts and Appliances not supplied by Electrolux;
 (c) cosmeticdamagewhichdoesnotaecttheoperationofthe
Appliance;
(d) damage to the Appliance caused by:
(i) negligence or accident;
(ii) misuse or abuse, including failure to properly maintain or service;
(iii) improper, negligent or faulty servicing or repair works done by
anyone other than an Electrolux authorised repairer or ASC;
(iv) normal wear and tear;
(v) power surges, electrical storm damage or incorrect power supply;
(vi) incomplete or improper installation;
(vii) incorrect, improper or inappropriate operation;
(viii) insect or vermin infestation;
(ix) failure to comply with any additional instructions supplied with
the Appliance;
In addition, Electrolux is not liable under this warranty if:
(a) the Appliance has been, or Electrolux reasonably believes that the
Appliance has been, used for purposes other than those for which
the Appliance was intended, including where the Appliance has
been used for any non-domestic purpose;
 (b) theApplianceismodiedwithoutauthorityfromElectroluxinwriting;
(c) the Appliance’s serial number or warranty seal has been removed
or defaced
8. How to claim under this warranty: To enquire about claiming under
this warranty, please follow these steps:
(a) carefully check the operating instructions, user manual and the terms
of this warranty;
(b) have the model and serial number of the Appliance available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
9. Australia: For Appliances and services provided by Electrolux in
Australia: Electrolux goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage. You are also entitled to
have the Appliance repaired or replaced if the Appliance fails to be of
acceptable quality and the failure does not amount to a major failure.
‘Acceptable quality’ and ‘major failure’ have the same meaning as
referred to in the ACL.
10. New Zealand: For Appliances and services provided by Electrolux
in New Zealand, the Appliances come with a guarantee by Electrolux
pursuant to the provisions of the Consumer Guarantees Act, the Sale
of Goods Act and the Fair Trading Act. Where the Appliance was
purchased in New Zealand for commercial purposes the Consumer
Guarantee Act does not apply.
11.Condentiality: You accept that if you make a warranty claim, Electrolux
and its agents including ASC may exchange information in relation to you
to enable Electrolux to meet its obligations under this warranty.
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEALAND
APPLIANCE: CHEF RANGEHOODS
CRange_War_Jul19
Important Notice
Before calling for service, please ensure that the steps listed in clause 8 above have been followed.
AUSTRALIA
FOR SERVICE
ortondtheaddressofyournearest
authorised service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call
FOR SPARE PARTS
ortondtheaddressofyournearest
spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call
NEW ZEALAND
FOR SERVICE
ortondtheaddressofyournearest
authorised service centre in New Zealand
PLEASE CALL 0800 10 66 10
FOR SPARE PARTS
ortondtheaddressofyournearest
spare parts centre in New Zealand
PLEASE CALL 0800 10 66 20

Chef. We are part of the Electrolux family.
Share more of our thinking at electrolux.com.au
Part number: 342-1-595 Rev A
© 2020 Electrolux Home Products Pty Ltd
ABN 51 004 762 341
C_MAN_CG920FGS_Apr20
For further information on all Chef appliances, or to obtain
detailed dimension and installation information, call into
your Retailer, phone or email our Customer Care team or
visit our website:
Australia
phone:.......................................................... 13 13 49
email:........................... [email protected]
web:...........................................chefappliances.com.au
New Zealand
phone:................................................. 0800 10 66 10
email:.............................. [email protected]
web:...........................................chefappliances.com.au
LIKE
TO KNOW
MORE?
