installation guide
chef fixed rangehoods
models: RFD602W, RFD602S, RFD902W, RFD902S
All measurements in millimetres.
Current as at Dec 2006.
© 2006 Electrolux Home Products Pty Ltd. CDIMFIXRH page 1 of 2
fixed rangehood dimensions
160mm
598mm/898mm
100mm
60mm
25mm
25mm
30mm
300mm
79mm
25mm
35mm
143mm
ø119mm
500mm
30mm
105mm
Minimum distance
of hood above hob
GAS:
650mm
ELECTRIC:
600mm
Rear Exhaust
t
o atmosphere
Top Exhaust
to atmosphere
Side Exhaust
to atmosphere
Front Recirculating
Exhaust*
fixed rangehood exhaust options
fixed rangehood fixing distance
*In recirculating mode you must use a recirculating kit which includes carbon filters to eliminate cooking smells (model no. ARCFD).

All measurements in millimetres.
Current as at Dec 2006.
© 2006 Electrolux Home Products Pty Ltd. CDIMFIXRH page 2 of 2
fixed rangehood ducting accessories
part numbers description
AR125RC roof cowl
AR125B 90° bend
AR125F flue 1200mm long
AR125FD flexible duct – 1 metre long when expanded
AR125WV wall vent kit
AR125FJ flue joiner without damper
AR125FJD flue joiner with damper
ARCFD (not illustrated) replacement carbon filters
ducting accessories
chef fixed rangehoods
models: RFD602W, RFD602S, RFD902W, RFD902S
AR125RC
AR125F
AR125FD
AR125WV
Alternative flue connection AR125FJ/AR125FJD
Flashing
Not Supplied
AR125B
