Chefman Conical Burr RJ44-SS-TCB User manual

®
Conical Burr
DIGITAL COFFEE
GRINDER
QUICK START GUIDE
• Features
• Before First Use
• How to Adjust the Grind Size
• How to Grind Coffee
• Cleaning and Maintenance
RJ44-SS-TCB
®
©CHEFMAN 2021
FEATURES BEFORE FIRST USE
1. Remove the hopper: Press the release lever on the back of the grind selector ring, rotate
counterclockwise until the unlock icon ( ) aligns with the up arrow ( ) on the lever, then lift up.
2. Wash the ground coffee container, hopper, and their lids with hot soapy water; rinse
and dry thoroughly.
3. Wipe down the base with a damp cloth.
4. Replace the hopper: Set the hopper on the base, aligning the unlock icon ( ) with the up
arrow ( ) on the lever. Rotate clockwise until the lock icon ( ) aligns with the up arrow ( ).
You should hear the hopper click into place. NOTE: If the hopper is not fully attached, the
coffee grinder will not work.
HOW TO ADJUST THE GRIND SIZE
The coffee grinder has 31 grind-size options. To adjust the grind size, rotate the ring just
under the hopper, and select the appropriate grind for the type of coffee you’re making.
• A ner grind exposes more surface to the water and extracts avor more rapidly, which
is appropriate for a quick-brew method like espresso.
• A coarser grind, which exposes little surface, is appropriate for the longer brewing cycle
of French press.
When the beans are ground too nely for a particular brewing method (for instance, an espresso
grind used in a drip coffee machine), the resulting coffee will taste too bitter and strong.
Conversely, when too coarse a grind is selected, the resulting coffee tastes too weak and watery.
Use the chart below to choose your grind size.
Coffee Type French Press/
Cold Brew Pour-Over Drip Coffee Siphon Espresso Turkish Coffee
Grind Size Extra Coarse Coarse Medium
Coarse Medium Fine Fine Extra Fine
Grind Setting 31-26 25-19 18-11 10-6 5-3 2-1
1. Coffee Bean Hopper Lid
2. Coffee Bean Hopper
3. Removable Upper Conical Burr
4. Grind Selector Ring
5. Control Panel
6. LED Display
7. +5 SEC Button
8. MAX TIME Button
9. START/STOP Button
10. Stainless-Steel Base
11. Brush
12. Ground Coffee Container Lid
13. Ground Coffee Container
14. Rubber Mat
1
2
6
5
7
8
9
4
10 12
13
14
3
11

While you should clean the ground coffee container regularly, the rest of the unit requires only
periodic cleaning.
• To clean the ground coffee container, hopper, and lids, wash them in warm, soapy water
and dry with a towel. Do not wash in the dishwasher or use strong detergents or abrasive
pads. The rubber mat is dishwasher-safe.
• Wipe down the outside of the unit with a damp cloth as needed. Never place
the grinder, power supply cord, or plug in water or under running water.
• To clean the burrs and grinding mechanism, follow these steps:
1. Empty the beans from the hopper, then run the grinder until the grinding chamber is
completely empty.
2. Unplug the unit and detach the hopper (see Before First Use).
3. To remove the upper conical burr, hold the upper mill by its handle and turn it
counterclockwise (a), then lift it out of the grinder (b). Brush away any residual coffee
dust and grounds from the upper burr (c). Upper burr is also dishwasher-safe.
1. Put the lid on the ground coffee
container and slide it into place
on top of the rubber mat.
5. Press the START/STOP button.
The timer will count down as
the unit grinds.
2. Fill the hopper with beans and
replace the lid.
3. Select your desired grind size. 6. To end grinding early, press
START/STOP again. To add
more time while the unit is
grinding, press the +5 SEC
button. NOTE: For Pulse mode,
press and hold the START/STOP
button to start grinding; release
the button to stop.
HOW TO GRIND COFFEE HOW TO GRIND COFFEE CLEANING AND MAINTENANCE CLEANING AND MAINTENANCE
4. Brush away coffee grounds and dust from the lower burrs (these are not removable).
Once you’ve loosened particles with the brush, you may need to turn the unit upside
down to completely remove them.
5. Brush away coffee grounds from the grind outlet with the brush.
6. To replace the upper burr, lower it back into place (d), turn the handle clockwise until the
burr clicks into place (e), then push the handle back down (f).
7. Reattach the hopper (see Before First Use).
4. Set desired grind time by
pressing the +5 SEC button up
to 40 seconds. Alternatively,
press the MAX TIME button for
40 seconds.
a
d
b
e
c
f
