Cheminees Philippe RADIANTE 890 3V Instruction Manual
The Original Home Of Cheminées Philippe Australia since 1982
WARMTH FROM FRANCE BY WIGNELLS OF MELBOURNE
RADIANTE 890 3V
INSTALLATION & USER MANUAL
We thank and appreciate your trust in welcoming our Cheminées Philippe Radiante 890 3V
into your space. Living with a Cheminées Philippe is truly a most satisfying and memorably
rewarding experience. You have now joined the family of thousands of proud owners of the
most beautifully hand crafted replaces in the world.
For over six decades Cheminées Philippe have been synonymously known for their quality
French design appeal and admirably, their hand made technique. Manufactured in their
cast iron foundry located in the Pas-de-Calis region of France, they adhere to strict
European requirements, as well as being tested and certied to Australian emissions,
efciency and safety standards.
Please take a moment to read over this manual, including our operations and
maintenance guide to ensure you get the best performance and enjoyment from your new
replace.
We would love to hear your feedback and see some beautiful imagery of your own unique
Cheminées Philippe replace creation. If you would like to help inspire us and others along
their replace design journey, please send a photo of your Philippe to
Wishing you many wonderful years of reside enjoyment,
Warmest regards,
Rick Wignell
Director of Cheminées Philippe Australia
MERCI BEAU COUP
02 CHEMINÉES PHILIPPE RADIANTE 890 3V
“We no longer build replaces for physical warmth,
we build them for the warmth of the soul, we build
them to dream by, to hope by, to home by”
- Edna Ferber 1885-1968
1. PREFACE
1.1 NOTICE 04
1.2 GENERAL SAFETY INFORMATION 05
1.3 PRE-INSTALLATION GUIDELINES 06
1.4 GENERAL FLUE REQUIREMENTS 07
1.5 SUITABLE BASE & HEARTH MATERIALS 08
2. UNIT DIMENSIONS & SPECIFICATIONS
2.1 CHEMINÉES PHILIPPE RADIANTE 890 3V 10
3. FREESTANDING
3.1 STEP BY STEP INSTALL GUIDE 12
3.2 BASE & HEARTH DIMENSIONS 13
3.3 FREESTANDING CLEARANCES 14
3.4 SKAMOTEC WALL GUIDELINES 15
3.5 SKAMTOEC WALL VENTILATION 16
3.6 FLUE COMPONENTS OVERVIEW 17
3.7 FLUE SYSTEM CONFIGURATIONS 18
4. INBUILT
4.1 STEP BY STEP INSTALL GUIDE 20
4.2 BASE, HEARTH & MANTEL SHELF DIMENSIONS 21
4.3 INBUILT CAVITY DIMENSIONS 22
4.4 DEFLECTOR PLATE & GRILLS 23
4.5 FLUE COMPONENTS OVERVIEW 24
5. MECHANISMS & UNIT ASSEMBLY
5.1 MECHANISM GUIDE 26
5.2 PARTS, GATHER & FLUE COLLAR ASSEMBLY 27
5.3 DAMPER, BASE, ASH PAN & GRATE ASSEMBL 28
5.4 BACK PLATE ASSEMBLY 29
5.5 BAFFLE PLATE ASSEMBLY 30
6. OPERATION
6.1 BEFORE FIRST IGNITION 32
6.2 RECOMMENDED FIRE WOOD 33
6.3 HOW TO LIGHT & BURN SAFELY 34 & 35
6.4 WARNINGS LABELS 36
7. MAINTENANCE
7.1 SERVICING GUIDE 38
7.2 TROUBLE SHOOTING 39
7.3 SPARE PARTS 40
8. WARRANTY
8.1 WARRANTY POLICY & EXTENDED WARRANTY 42
8.2 INSTALLER CHECKLIST FORM 43
*Please keep these instructions for future reference. 03
NOTICE 1.1
04 CHEMINÉES PHILIPPE RADIANTE 890 3V
DOCUMENT REVISION 01
This document is valid for Australia & New Zealand as of July 29th 2022 for the installation, operation and
maintenance of the Cheminées Philippe Radiante 890 3V XPPEmSFQMBDF
DISCLAIMER
Cheminées Philippe Australia & Wignells of Melbourne bears no liability for installations that do not meet the
criteria outlined in this manual, alongside the requirements of Australian & New Zealand Standards AS/NZS
2918:2018. The installation techniques, handling and use of the product are beyond our control. Therefore,
Cheminées Philippe Australia & Wignells of Melbourne assumes no responsibility for loss, damage or
expense resulting from improper installation, operation or misuse. In line with our commitment for continuous
improvement, technical parameters are subject to change and we reserve the right to alter the contents of
this manual at any time. For the latest version of this manual please visit, www.chemphilaust.com.au
1.2 GENERAL SAFETY INFORMATION
CHEMINÉES PHILIPPE RADIANTE 890 3V 05
WARNING: THE APPLIANCE AND FLUE SYSTEM SHOULD BE INSTALLED IN ACCORDANCE
WITH AS/NZS 2918:2018 AND THE APPROPRIATE REQUIREMENTS OF THE RELEVANT
BUILDING CODE OR CODES.
WARNING: APPLIANCES INSTALLED IN ACCORDANCE WITH AS/NZS 2918:2018 SHOULD
CONFORM TO THE REQUIREMENTS OF AS/NZS 4013 AND AS/NZS 4012 WHERE REQUIRED
BY THE REGULATORY AUTHORITY, THAT IS. THE APPLIANCE SHOULD BE IDENTIFIABLE BY
A CONFORMANCE PLATE WITH THE MARKING ‘TESTED TO AS/NZS 4013 AND AS/NZS 4012’
AS SPECIFIED IN AS/NZS 4012.
ANY MODIFICATION OF THE APPLIANCE THAT HAS NOT BEEN APPROVED IN WRITING BY
THE TESTING AUTHORITY IS CONSIDERED TO BE IN BREACH OF THE APPROVAL GRANTED
FOR CONFORMANCE TO AS/NZS 4013.
CAUTION: MIXING OF APPLIANCE OR FLUE SYSTEM COMPONENTS FROM DIFFERENT
SOURCES OR MODIFYING THE DIMENSIONAL SPECIFICATION OF COMPONENTS MAY RESULT
IN HAZARDOUS CONDITIONS. WHERE SUCH ACTION IS CONSIDERED THE MANUFACTURER
SHOULD BE CONSULTED IN THE FIRST INSTANCE.
CAUTION: CRACKED AND BROKEN COMPONENTS, FOR EXAMPLE GLASS PANELS, CAST IRON
OR CERAMIC TILES, MAY RENDER THE INSTALLATION UNSAFE.
1MFBTFSFBEUISPVHIUIJTNBOVBMDBSFGVMMZQSJPSUPJOTUBMMJOHPSVTJOHUIJTmSFQMBDF&BDIPGPVS
mSFQMBDFTTIPVMECFJOTUBMMFEJOBDDPSEBODFXJUI"4/;4UIFBQQSPQSJBUFSFRVJSFNFOUT
of the relevant building codes and this manual. All units MUST be installed by a fully licensed and
RVBMJmFEUSBEFTQSPGFTTJPOBMXIPJTSFHJTUFSFEBOEPSMJDFOTFEJONFDIBOJDBMTFSWJDFTXJUIBDMBTT
also restricted to solid fuel heaters (or equivalent in selected states and territories).
WARRANTY:5IFXBSSBOUZPGUIJTmSFQMBDFJTPOMZWBMJEJGUIFVOJUIBTCFFOJOTUBMMFEBTQFSUIF
above requirements and the installer checklist has been completed (page 41 of this manual). An
extended warranty period can also be granted, please see page 40 of this manual for further details
on how to apply for an extended warranty.
CUSTOM INSTALLATIONS: Contact us for approval of any deviation from this document prior to
proceeding. In the event that an installation is undertaken without following this installation manual or
without written approval by Cheminées Philippe Australia, then the sole responsibility of any adverse
outcomes lies with the installer and the unit will be null and void of all warranties.
MUST READ PRIOR TO COMMENCING
PRE-INSTALLATION GUIDELINES 1.3
06 CHEMINÉES PHILIPPE RADIANTE 890 3V
»#FGPSFJOTUBMMJOHUIJTmSFQMBDFUIPSPVHIMZBTTFTTUIFQBDLBHJOHBOEJUTDPOUFOUTJODMVEJOHUIFVOJU
nVFDPNQPOFOUTHSBUFTCBGnFQMBUFTDFJMJOHSJOHFUDUPFOTVSFBMMJUFNTBSFBDDPVOUFEGPSBOEUIBU
any damage or defects caused by transport/handling are immediately reported to your authorised
Cheminées Philippe dealer
»$IFDLUIFJOTUBMMBUJPOTJUFJOBEWBODFBOESFNPWFBMMnBNNBCMFNBUFSJBMTPSUIPTFXIJDIIBWFUIF
QPUFOUJBMUPCFEBNBHFECZIFBUGSPNUIFBSFBXIFSFUIFmSFQMBDFXJMMCFJOTUBMMFE"MMDPNCVTUJCMF
material should be replaced and/or shielded with non-combustible material or maintain a safe clearance
as per pages 11-18 of this manual if installed freestanding or 19-24 if installed inbuilt
»&OTVSFUIFDPSSFDUCBTFVOEFSOFBUIUIFmSFQMBDFJTVTFEJODMVEJOHUIFNJOJNVNTJ[FBOEUIJDLOFTTSFGFS
UPQBHFGPSBMJTUPGSFDPNNFOEFECBTFNBUFSJBMT$IFDLUIBUUIFnPPSJTDBQBCMFPGTBGFMZCFBSJOHUIF
weight and if necessary put in a weight distribution plate or take other necessary measures
»%VF UP UIF XFJHIU PG FBDI mSFQMBDF DBSF NVTU CF UBLFO XIFO NBOFVWFSJOH UIF VOJU 8F TUSPOHMZ
SFDPNNFOENFDIBOJDBMFRVJQNFOUBTXFMMBTNVMUJQMFQSPGFTTJPOBMTBJEJOHXJUINPWJOHUIFVOJUJOUPJUT
intended location
»Familarise yourself with section 5. Mechanisms & Unit Assembly in this manual prior to proceeding. Due
UPUIFTJ[FPGTPNFVOJUTUIFHBUIFSMJGUEPPSNFDIBOJTNTBOEPSEBNQFSTXJMMOFFEUPCFJOTUBMMFEQSJPS
UPUIFJOTUBMMBUJPOPGUIFnVFTZTUFN1MFBTFBMTPSFGFSUPUIJTTFDUJPOGPSUIFmOBMmUUJOHPGUIFCBDLQMBUF
CBGnFQMBUFBTISFUBJOFSBOEHSBUFT
»When installing the unit inbuilt, ventilation grills are required at the top and bottom of the cavity to assist
in natural convection and for the release of heated air into the room. Refer to pages 20-23 for minimum
TJ[FTBOEQMBDFNFOUPGHSJMMFT
»8IFOJOTUBMMJOHUIFmSFQMBDFJOCVJMUBOJOTQFDUJPOIBUDIPSUSBQEPPSJUSFDPNNFOEFE5IJTXJMMBMMPXGPS
easy access to the unit when performing any necessary inspection, maintenance and/or repairs
»Do NOT use combustible material (including Gyprock Fyrechek OR a timber frame) underneath, near or
BSPVOEUIJTmSFQMBDF
PREPARATION OF THE FIREPLACE
BALANCING AIR PRESSURE: TIGHTLY SEALED HOMES, MECHANICAL FANS & DOWNDRAFT
"MMmSFQMBDFTSFRVJSFDPOTUBOUBJSnPXXIFOJOVTFIPXFWFSEVFUPUIFUJHIUMZTFBMFEOBUVSFPG
DFSUBJOIPNFTJUNBZQSPWFEJGmDVMUUPBDIJFWFBDPOUJOVPVTSFQMFOJTINFOUPGGSFTIBJSGPSUIFmSFUP
burn effectively. Mechanical fans (including range hoods, ceiling fans, return air vents including AC
EVDUTBOEPWFSIFBEFYUSBDUPSGBOTXIJDIBSFMPDBUFEXJUIJOUIFTBNFTQBDFBTUIFmSFQMBDFDBO
also create negative pressure and compromise the operation of the unit.
If this occurs, the introduction of fresh air is recommended. This could take the form of a vent
JOTUBMMFEPOBOFYUFSOBMXBMMXIFSFUIFmSFQMBDFXJMMCFTJUVBUFE%FQFOEJOHPOUIFJOTUBMMBUJPOUZQF
JUTIPVMEFJUIFSCFQMBDFEEJSFDUMZJOTJEFUIFJOCVJMUmSFQMBDFDBWJUZPSBTOFBSUPUIFGSFFTUBOEJOH
mSFQMBDFBTQPTTJCMF5IFTVSGBDFBSFBPGUIJTBJSJOUBLFTIPVMECFBNJOJNVNPGDNGPS
FYBNQMFBWFOUNNYNNJOTJ[F
5FSNJOBUJPOPGUIFnVFJOBIJHIQSFTTVSF[POFTVDIBTPOUIFEPXOTUSFBNTJEFPGBOFBSCZPCTUSVDUJPO
UPBJSnPX’PSFYBNQMFUSFFTIJMMTBEKBDFOUCVJMEJOHTPSQBSUTPGUIFCVJMEJOHXIFSFUIFVOJUJTJOTUBMMFE
may also prove to cause downdraught conditions (AS/NZS 2918:2018 extract), in this case refer to page 37
1.4 GENERAL FLUE REQUIREMENTS
CHEMINÉES PHILIPPE RADIANTE 890 3V 07
*Please keep these instructions for future reference.
»Only an approved Cheminées PhilippenVFLJUTIPVMECFJOTUBMMFEXJUIUIJTmSFQMBDF
».JYJOHnVFTZTUFNDPNQPOFOUTBOEPSNPEJGZJOHUIFEJNFOTJPOBMTQFDJmDBUJPOPGUIFnVFBOEDPXMJT
NOT recommended, unless approved by Cheminées Philippe Australia
»A minimum 4.5 metresPGnVFJTSFRVJSFEGSPNUIFUPQPGUIFmSFQMBDFHBUIFSUPUIFDPXM
»"NJOJNVNNNDMFBSBODFBSPVOEUIFUSJQMFTLJOnVFJTUPCFNBJOUBJOFEGSPNUIFPVUFSDBTJOHUPBOZ
combustible surface
»"NJOJNVNNNDMFBSBODFJTUPCFNBJOUBJOFEBSPVOEUIFTJOHMFTLJOnVFUPBOZDPNCVTUJCMFTVSGBDF
»Do NOT JOTUBMMCFOETEJSFDUMZPOUPQPGUIFmSFQMBDFHBUIFS"NJOJNVNNNMFOHUIPGnVFNVTUCF
JOTUBMMFEmSTUCFGPSFUIFmSTUCFOEJTQPTJUJPOFE
»No more than 2 x 45 degree bends are allowed
»90 degree bends are NOT to be used
*All dimensions in mm
FLUE SYSTEM
FLUE BENDS
MINIMUM EXTERNAL FLUE HEIGHTS & COWL CLEARANCES - AS PER AS/NZS 2918:2018
SUITABLE BASE AND HEARTH MATERIALS 1.5
08 CHEMINÉES PHILIPPE RADIANTE 890 3V
»Minimum 150mm hebel blocks, masonry or clay bricks
»A steel bench with any of the above materials installed beneath it
»A minimum 100mm SOLID and supported concrete plinth (without glass, resins or polymer) above a
NJOJNVNNNNBTPOSZnPPS
»For minimum base size refer to page 13
RECOMMENDED FIREPLACE BASE
»Minimum 24mm thick compressed cement sheet is required or a composition of masonry materials at
this thickness or more.
»For minimum hearth size refer to page 13 for freestanding and 21 for inbuilt application
RECOMMENDED FIREPLACE HEARTH
MPORTANT: Please read through this manual carefully prior to installing or using this
mSFQMBDF&BDIPGP
IMPORTANT: Please note that Cheminées Philippe Australia and Wignells of Melbourne can not be
held liable for any thermal expansion cracking of the materials listed above OR for any other type of
NBTPOSZNBUFSJBMJODMVEJOHUJMFTBOETUPOFVTFEGPSUIFmSFQMBDFCBTFBOEIFBSUI
The purchaser should check with the base and hearth supplier that the material being used
VOEFSOFBUIBOEJOGSPOUPGUIFmSFQMBDFJTTVJUBCMFGPSFYUSFNFIFBU5IFCBTFBOEIFBSUITIPVMECFB
IFBUSFTJTUBOUNBUFSJBMXJUIBOBMMPXBCMFTVSGBDFUFNQFSBUVSFPGEFHSFFTPGHSFBUFS
"MMmSFQMBDFCBTFBOEIFBSUINBUFSJBMTNFOUJPOFEBCPWFBSFSFDPNNFOEFEGPSUIFJSUIFSNBM
properties only. It is the responsibility of the purchaser and the installer to ensure that any material
VTFEIBTUIFTUSVDUVBMJOUFHSJUZUPFWFOMZTVQQPSUUIFmSFQMBDFXFJHIUSFGFSUPQBHFBOEnVF
componentry.
»&OHJOFFSFEPSDPNQPTJUFTUPOFJODMVEJOHCVUOPUMJNJUFEUPDBFTBSTUPOFUFSSB[[PFUD
»4LBNPUFDCPBSEBTUIFmSFQMBDFCBTF
»Thin pre-cast concrete
»Timber or any combustible material
»Glass
DO NOT USE
BASE LEVELING:%FQFOEJOHPOUIFUZQFPGCBTFVTFEVOEFSOFBUIUIFmSFQMBDFJUNBZCFOFDFTTBSZUP
level and stablise the unit by using packers underneath for additional support. We recommend using a
strip of lead sheet folded over three times.
MPORTANT: Please read through this manual carefully prior to installing or using this
mSFQMBDF&BDIPGP
2. UNIT DIMENSIONS & SPECIFICATIONS
2.1 CHEMINÉES PHILIPPE RADIANTE 890 3V 10
09
PLEASE NOTE:
%VFUPUIFIBOENBEFOBUVSFPGPVSmSFQMBDFTUIFSFNBZCF
a slight variance factor of 1-2mm across all unit dimensions
and .5kg in unit weight.
CHEMINÉES PHILIPPE RADIANTE 890 3V 2.1
10 CHEMINÉES PHILIPPE RADIANTE 890 3V
HEATING CAPACITY Up to 300sqm*
MAXIMUM AVG. HEAT OUTPUT 13.7kW
FIREBOX MATERIAL Cast Iron
LOG LENGTH Up to 70cm
FLUE SIZE* 10”, 12” & 14”
RECOMMENDED MINIMUM FLUE HEIGHT 4.5m Metres
(From top of spigot)
FIREBOX WEIGHT 305kg
OVERALL AVG. EFFICIENCY
PARTICULATE EMISSIONS FACTOR 1.0g/kg
TEST REPORTS "4’5
ASFT19074-1
CERTIFICATE OF COMPLIANCE #ASFT20C088
* Must use
supplied ue
adaptor
UNIT SPECIFICATIONS & DIMENSIONS
)FBUJOHPVUQVUWBSJFTEFQFOEJOHVQPODFJMJOHIFJHIUGVFMVTFECVJMEJOHJOTVMBUJPOHFPHSBQIJDBM[POFBOE
atmospheric conditions. This unit has been tested and complies with Australian & New Zealand standards
AS/NZS 4012 (2014), AS/NZS 4013 (2014) & AS/NZS2918 (2018), and is recommended to be used with
hardwood only.
515
905 470
3. FREESTANDING
3.1 STEP BY STEP INSTALL GUIDE 12
3.2 BASE & HEARTH DIMENSIONS 13
3.3 FREESTANDING CLEARANCES 14
3.4 SKAMOTEC WALL GUIDELINES 15
3.5 SKAMTOEC WALL VENTILATION 16
3.6 FLUE COMPONENTS OVERVIEW 17
3.7 FLUE SYSTEM CONFIGURATIONS 18
11
* Must use
supplied ue
adaptor
PLEASE NOTE:
All diagrams in this manual are for illustration purposes
only, DO NOT scale from any of these diagrams. All
measurements are in millimetres unless otherwise stated.
STEP BY STEP INSTALL GUIDE 3.1
12 CHEMINÉES PHILIPPE RADIANTE 890 3V
STEP 1: INSPECT THE FIREPLACE & FLUE PENETRATION THEN LAY BASE & HEARTH
»*OTQFDUUIFBSFBUPFOTVSFUIFmSFQMBDFBOEnVFJODMVEJOHDMFBSBODFTCBTFBOEIFBSUIXJMMCF
installed safely and conform to Australian & New Zealand Standards AS/NZS 2918:2018 and the
guides in this manual relative to your type of installation
»-BZUIFCBTFBOEIFBSUISFGFSUPQBHFTGPSNJOJNVNTJ[FTBOESFRVJSFNFOUT
»Additional reinforcement may need to be installed in order to support the weight as outlined on page 8
STEP 2: INSTALL WALL PROTECTION
»If the wall materials are combustible and do not fall within the minimum safety clearances as listed on
page 14, then additional wall protection must be installed
»Protection can include materials such as Skamol Board and bricks/hebel
»8IFOJOTUBMMJOH4LBNPUFDQMFBTFSFGFSUPQBHFTPGUIJTNBOVBMGPSNJOJNVNDMFBSBODFTBOE
installation process
STEP 3: PUT UNIT INTO POSITION & ASSEMBLE THE DAMPER SYSTEM
»%VFUPUIFXFJHIUPGUIJTmSFQMBDFQMFBTFUBLFDBSFXIFOQVUUJOHUIFVOJUJOUPQPTJUJPO
»*UJTBUUIJTTUBHFUIBUXFIJHIMZSFDPNNFOEmUUJOHUIFEBNQFSTZTUFNQSJPSUPmUUJOHUIFnVFQMFBTF
refer to page 27 of this manual
STEP 4: INSTALL THE STARTING COLLAR & FLUE
»5IFnVFBEBQUPSNVTUCFmUUFEJOUPUIFDBTUJSPODPMMBSPGUIFmSFCPYHBUIFS
»8IFOVTJOHBTJOHMFTLJOnVFLJUFOTVSFUIFnVFJTJOTUBMMFEDSJNQFEFOEEPXOJOUPUIFnVFBEBQUPS
»8IFOVTJOHBUSJQMFTLJOnVFLJUVTFUIFTUBSUFSnVFTFDUJPOJOUPUIFnVFBEBQUPS
»4FDVSFUIFnVFUPUIFBEBQUPSVTJOHTUBJOMFTTTUFFMSJWFUTFWFOMZTQBDFE
»"MMTUBJOMFTTTUFFMJOOFSnVFTJODMVEJOHDIBSDPBMQBJOUFETUBJOMFTTTUFFMnVFTNVTUCFKPJOFEVTJOH
stainless steel pop rivets and must be installed crimp end DOWN
»All galvanised second and third outer casing must be installed crimp end UP
»5IFNJOJNVNDMFBSBODFGSPNBTJOHMFTLJOnVFUPBOZDPNCVTUJCMFNBUFSJBMJTNN
»5IFNJOJNVNDMFBSBODFUPUSJQMFTLJOnVFUPBOZDPNCVTUJCMFNBUFSJBMJTNN
»3FGFSUPQBHFnVFSFRVJSFNFOUTBOEGPSnVFDPNQPOFOUTBOEPWFSWJFX
STEP 5: TRIPLE SKIN DROPPER & COWL
»Install non-combustible board to the ceiling
»The triple skin dropper box must be installed to a minimum of 150mm below the ceiling with a 50mm
clearance maintained around the outer skin
»"UUIFUFSNJOBUJPOIFJHIUPGUIFUSJQMFTLJOnVFUIFBDUJWFTUBJOMFTTTUFFMJOOFSNVTUCFBNBYJNVNPG
30mm higher than the middle and outer galvanised casing. The stainless steel skirt is screwed to the
crimp of the outer casing. The stainless steel cowl slides into the neck of the skirt and must locate
JOTJEFUIFBDUJWFnVFCFMPX/PmYJOHJTUPCFEPOFUPUIFDPXM
»3FGFSUPTFDUJPOJO"4/;4GPSJOTUBMMJOHnVFQFOFUSBUJPOT
»1MFBTFBMTPVTFUIFEJBHSBNPOQBHFUPFOTVSFFYUFSOBMnVFIFJHIUTBOEDPXMDMFBSBODFTBSF
maintained
STEP 6: FIT THE BACK PLATE, BAFFLE PLATE, ASH RETAINER, GRATES & ASH PAN
»&OTVSFUIFCBDLQMBUFJTJOTUBMMFEmSTUUIFOVTJOHBMPHUPIPMEUIFCBDLQMBUFJOUPQPTJUJPOUPQSFWFOUJU
GSPNGBMMJOHUIFOJOTUBMMUIFCBGnFQMBUF
»%FUBJMFEJMMVTUSBUJPOTBOEBTTFNCMZJOTUSVDUJPOTDBOCFWJFXFEPOQBHFT
STEP 7: TEST FIRE DRAW
»-JHIUBTNBMMQJFDFPGOFXTQBQFSJOTJEFUIFmSFCPYUPUFTUUIFESBXPGUIFVOJUBOEnVF
»If the draw is adequate, complete the check list on page 43 and return this as well as this entire booklet
UPUIFmSFQMBDFPXOFS
»*GUIFESBXJTJOBEFRVBUFQMFBTFSFGFSUPUIF#BMBODJOH"JS1SFTTVSFTFDUJPOPOQBHF
3.2 BASE & HEARTH DIMENSIONS
CHEMINÉES PHILIPPE RADIANTE 890 3V 13
*Please keep these instructions for future reference.
A
B
MINIMUM BASE SIZE: WIDTH: 946mm x DEPTH: 613mm x THICKNESS: 150mm*
MINIMUM HEARTH SIZE: WIDTH: 2146mm x DEPTH: As per above(B) x THICKNESS: 24mm*
*For a list of recommended materials and thicknesses refer to page 8
MINIMUM HEIGHT OF UNIT A.<149mm A.150mm A.200mm A.300mm A.400mm A.500mm
MINIMUM HEARTH DEPTH B.1000mm B.NN B.578mm B.NN B.422mm B.300mm
BASE
HEARTH
Unless forming an abutment with a wall, the back and side hearth dimensions MUST NOT be altered,
QMFBTFSFGFSUPQBHFGPSNJOJNVNTJ[FT
FREESTANDING CLEARANCES 3.3
14 CHEMINÉES PHILIPPE RADIANTE 890 3V
FREESTANDING
A: CLEARANCES TO 50MM SKAMOL BOARD
CLEARANCES TO A SOLID BRICK/HEBEL VENEER WALL
CLEARANCES TO COMBUSTIBLES
150mm
250mm
600mm
800mm
800mm
Hearth
Combustible Wall
Combustible Wall
50mm Skamotec Board
50mm Skamotec Board
50mm Air Gap
50mm Air Gap
250mm
350mm
600mm
800mm
800mm
Hearth
Combustible Wall
Combustible Wall
50mm Skamotec Board
50mm Skamotec Board
5IF4LBNPMCPBSETTIPVMEFYUFOEUPBNJOJNVNIFJHIUPGNNGSPNUIFIFBSUIXIFOVTJOHBUSJQMFTLJOnVFLJU03BMM
UIFXBZUPUIFDFJMJOHXIFOVTJOHBTJOHMFTLJOnVFLJUSFGFSUPQBHF8IFOVTJOH4LBNPUFDCPBSEXJUIBNNBJS
HBQCFIJOEJUNVTUBMTPCFWFOUJMBUFEGPSOBUVSBMBJSnPXDJSDVMBUJPOSFGFSUPQBHFGPSWFOUJMBUJPOSFRVJSFNFOUT
250mm
950mm
600mm
Hearth
Combustible Wall
Combustible Wall
725mm
150mm
600mm
800mm
800mm
Hearth
Combustible Wall
Combustible Wall
Brick/Hebel
Brick/Hebel
A minimum 110mm solid brick/hebel thick wall should extend a minimum height of 1800mm from the hearth when
VTJOHBUSJQMFTLJOnVFLJUPSUPUIFDFJMJOHXIFOVTJOHBTJOHMFTLJOnVFLJU
GLASS CLEARANCE: A minimum 1500mm from the front
glass to any combustible surfaces must be maintained.
150mm
CORNER CLEARANCES: The same rear clearance
as depicted in these illustrations applies from the two
GVSUIFSFTU CBDL DPSOFS QPJOUT PG UIF mSFQMBDF UP FBDI
DPSOFSXBMM#BTFIFBSUITJ[FSFNBJOTUIFTBNFQBHF
B: CLEARANCES TO 50MM SKAMOL BOARD + AIR GAP
CLEARANCES TO A SOLID BRICK OR HEBEL WALL
600mm
900mm
800mm
Hearth
Brick/Hebel
Brick/Hebel
100mm
600mm
100mm
Combustible
Material
(Refer to page 13)
(Refer to page 13) (Refer to page 13)
(Refer to page 13) (Refer to page 13)
3.4 SKAMOTEC WALL GUIDELINES
CHEMINÉES PHILIPPE RADIANTE 890 3V 15
"MTP LOPXO BT i4LBNPMw CPBSE 4LBNPUFD JT B MJHIUXFJHIU OPODPNCVTUJCMF CPBSE UIBU TJNQMJmFT UIF
construction process to one building material, therefore eliminating the need for a steel or brick frame
construction. It is intended for interior, non-load bearing wall applications and has a maximum service
temperature of 1000 degrees celsius
SKAMOTEC 225
RECOMMENDED FIXING OF SKAMOTEC BOARDS & BATTENS
»MaterialsrequiredincludeconstructionscrewsandSkamotecadhesiveglue.PleaserefertotheSkamotec
Installers Guide for a comprehensive list of materials, as well as the assembly instructions
»It is recommended that the 50mm thick Skamotec battens are spaced to a maximum of 450mm centres,
be a minimum 100mm wide and are placed vertically behind the board as illustrated below
»When using 100mm x 50mm Skamotec batterns behind the Skamotec board, the cavity must be either
ventilated at the top and bottom by using a minimum 25mm air gap that must extend the full width of the
board, or alternatively using metal vents (vermin proof if on an external wall) a minimum surface area of
DNPSYDNBUUIFUPQBOECPUUPNBTJMMVTUSBUFEPOQBHFDBOCFVTFE
»6TFNJOJNVNNNTIFFUTMBJEIPSJ[POUBMMZBDSPTTUIFFOUJSFXJEUIPGUIFmSFQMBDFXJUIOPWFSUJDBM
joins
»All corner and panel joints shall be attached using Skamotec mortar cement or construction adhesive
»%POPUGBTUFOBOZQBSUPGUIF4LBNPUFDCPBSEUPUIFmSFQMBDF
»When applying any adhesive, mortar cement, drywall compound, paint, skim-coat or a scratch coat, all
joining surfaces must be cleaned and moistened with water beforehand (Skamotec branded products
are mandatory). This will prevent these products from drying out too quickly & adhering incorrectly. A
QBJOUFEmOJTITUPOFPSUJMFNBUFSJBMDBOCFVTFEUPmOJTIUIF4LBNPUFDTVSGBDF’PSBDPNQSFIFOTJWF
4LBNPUFDJOTUBMMBOEmOJTIQMFBTFPOMZSFGFSUPUIF4LBNPUFD*OTUBMMFST(VJEF
SKAMOTEC COMPOSITION - PLAN VIEW
SKAMOTEC FINISH
Combustible
Material
SKAMOTEC WALL VENTILATION 3.5
16 CHEMINÉES PHILIPPE RADIANTE 890 3V
OPTION A: 25MM TOP & BOTTOM AIR GAP
OPTION B: CONCEALED EXTERNAL VENTS
OPTION C: CONCEALED INTERNAL VENTS
SKAMOTEC WALL VENTILATION CONFIGURATIONS (WHEN USING 50MM BATTERNS, SEE PAGE 14)
The 25mm top and bottom air gap must extend the full width of the Skamotec cavity and can be left open
to create a shadow line effect, or alternatively can be faced with a metal grill/vent
The minimum concealed surface area of vent is one 720cm2 top (9cm x 80cm) at the top and bottom or 2 x
DNDNYDNUPQBOECPUUPNBTJMMVTUSBUFE
*ALL ILLUSTRATIONS ON THIS PAGE REFERENCE A SINGLE SIDED MODEL ONLY
3.6 FLUE COMPONENTS OVERVIEW
CHEMINÉES PHILIPPE RADIANTE 890 3V 17
SKAMOTEC WALL VENTILATION CONFIGURATIONS (WHEN USING 50MM BATTERNS, SEE PAGE 14)
FREESTANDING INSTALL OVERVIEW*
*SINGLE SKIN FLUE KIT ILLUSTRATION
4.5 METRE 10” SINGLE SKIN FLUE KIT
2
1
3
4
5
10” Flue Adaptor* (Charcoal)
2 x 10” Single Skin Flue 900mm* (Charcoal)
10”-12”-14” Default Triple Skin Flue 900mm* (Charcoal)
2 x 10”-12”-14” Triple Skin Flue 900mm*
14” Split Ring (Charcoal)
6
7
5
1
3
6
7
10”-14” Cover Cone
10” Anti Down Draught Cowl
10” Flue Adaptor* (Charcoal)
10”-12”-14” Default Triple Skin Flue 900mm* (Charcoal)
2 x 10”-12”-14” Triple Skin Flue 900mm* (Charcoal)
2 x 10”-12”-14” Triple Skin Flue 900mm*
14” Split Ring (Charcoal)
10”-14” Cover Cone
10” Anti Down Draught Cowl
1
2
5
6
7
"MMJOUFSOBMwnVFNVTUCFTUBJOMFTTTUFFM
4.5 METRE 10” TRIPLE SKIN FLUE KIT
4
3
2
1
3
4
5
6
7
4
2
(Will vary depending on roof)
MINIMUM FREESTANDING FLUE KIT COMPONENTS
FLUE SYSTEM CONFIGURATIONS 3.7
18 CHEMINÉES PHILIPPE RADIANTE 890 3V
2. Cathedral ceiling 3. ’MBUDFJMJOHnBU
roof 4. .VMUJnPPSXJUI
nBUDFJMJOHBOESPPG
space
5. Flat ceiling with
roof space and
offset
6. Freestanding with
chimney & offset 7. External wall
penetration 8. Double storey
with single storey
penetration
1. Flat ceiling with
roof space
4PNFPGUIFTFnVFTDFOBSJPTNBZSFRVJSFBEEJUJPOBMnVFDPNQPOFOUTPUIFSUIBOUIPTFMJTUFEPOQBHF
FREESTANDING FLUE CONFIGURATIONS
4. INBUILT
4.1 STEP BY STEP INSTALL GUIDE 20
4.2 BASE, HEARTH & MANTEL SHELF DIMENSIONS 21
4.3 INBUILT CAVITY DIMENSIONS 22
4.4 DEFLECTOR PLATE & GRILLS 23
4.5 FLUE COMPONENTS OVERVIEW 24
19
PLEASE NOTE:
All diagrams in this manual are for illustration purposes
only, DO NOT scale from any of these diagrams. All
measurements are in millimetres unless otherwise stated.
*Please keep these instructions for future reference.
STEP BY STEP INSTALL GUIDE 4.1
20 CHEMINÉES PHILIPPE RADIANTE 890 3V
STEP 1: INSPECT THE FIREPLACE & FLUE PENETRATION THEN LAY BASE & HEARTH
»*OTQFDUUIFBSFBUPFOTVSFUIFmSFQMBDFBOEnVFJODMVEJOHDMFBSBODFTCBTFBOEIFBSUIXJMMCF
installed safely and conform to Australian & New Zealan Standards AS/NZS 2918:2018 and the guides
in this manual relative to your type of installation
»-BZUIFCBTFBOEIFBSUISFGFSUPQBHFTGPSNJOJNVNTJ[FTBOESFRVJSFNFOUT
»Additional reinforcement may need to be installed in order to support the weight as outlined on page 8
STEP 2: INSTALL BACK & SIDE WALLS
»Ensure the back and side wall are installed using materials such as Skamol Board, bricks or hebel,
refer to page 22
»Ensure provisions are made for the bottom air inlets and top air outlet on the cavity, please refer to
QBHFGPSNJOJNVNTJ[JOHNFUBMWFOUTBSFUPCFVTFE
STEP 3: PUT UNIT IN POSITION & ASSEMBLE THE DAMPER SYSTEM
»%VFUPUIFXFJHIUPGUIJTmSFQMBDFQMFBTFUBLFDBSFXIFOQVUUJOHUIFVOJUJOUPQPTJUJPO
»*UJTBUUIJTTUBHFUIBUXFIJHIMZSFDPNNFOEmUUJOHUIFEBNQFSTZTUFNQSJPSUPmUUJOHUIFnVFQMFBTF
refer to page 27 of this manual
STEP 4: INSTALL THE STARTING COLLAR, FLUE & DEFLECTOR PLATE
»5IFnVFBEBQUPSNVTUCFmUUFEJOUPUIFDBTUJSPODPMMBSPGUIFmSFCPYHBUIFS
»Drill through adaptor and secure using 3 stainless steel screws evenly spaced
»"MMTUBJOMFTTTUFFMJOOFSnVFTNVTUCFKPJOFEVTJOHTUBJOMFTTTUFFMQPQSJWFUTBOENVTUCFJOTUBMMFE
crimp end DOWN
»%FUFSNJOFUIFIFJHIUPGEFnFDUPSQMBUF$VUUIFTUBSUFSnVFUPTVQQPSUUIFEFnFDUPSQMBUFBUUIFEFTJSFE
height, refer to page 23 for more details
»*OTUBMMUIFEFnFDUPSQMBUFPOUIFUPQPGUIFTUBSUFSnVFHVTTFUT
»1MBDFSPDLXPPMCMBOLFUBMVNJOJVNTJEFEPXOPOUPQPGUIFEFnFDUPSQMBUFFOTVSJOHDPNQMFUFDPWFSBHF
&OTVSFUIFSPDLXPPMCMBOLFUJTJOTUBMMFEmSNMZUPUIFJOOFSTJEFTPGUIFFODMPTVSFBOEBSPVOEUIFUSJQMF
TLJOnVF&OTVSFUIFTMPUTPGUIFTUBSUFSUSJQMFBSFBQQSPYNNBCPWFUIFUPQPGUIFSPDLXPPM
»5IFTUBSUFSUSJQMFXJUITMPUTBOEDBQJTUIFOQMBDFEPOUPQPGUIFEFnFDUPSQMBUF
»All galvanised second and third skins must be installed crimp end UP
»Pick up weight of outer casing in roof space. The weight of the casing must not be supported by the
gussets alone
».JOJNVNDMFBSBODFUPUSJQMFTLJOnVFUPBOZDPNCVTUJCMFNBUFSJBMJTNN
»"UUIFUFSNJOBUJPOIFJHIUPGUIFUSJQMFTLJOnVFUIFBDUJWFTUBJOMFTTTUFFMJOOFSNVTUCFBNBYJNVNPG
30mm higher than the middle and outer galvanised casing. The stainless steel skirt is screwed to the
crimp of the outer casing. The stainless steel cowl slides into the neck of the skirt and must locate
JOTJEFUIFBDUJWFnVFCFMPX/PmYJOHJTUPCFEPOFUPUIFDPXM
»3FGFSUPTFDUJPOJO"4/;4GPSJOTUBMMJOHnVFQFOFUSBUJPOT
»1MFBTFBMTPVTFUIFEJBHSBNPOQBHFUPFOTVSFFYUFSOBMnVFIFJHIUTBOEDPXMDMFBSBODFTBSF
NBJOUBJOFEBMTPSFGFSUPQBHFGPSnVFDPNQPOFOUTPWFSWJFX
STEP 5: FINISH FACADE OF CAVITY
»$PNQMFUFUIFGSPOUPGUIFmSFQMBDFGBDBEFFOTVSFBNJOJNVNDMFBSBODFPGNNCFUXFFOUIFmOJTIFE
mSFQMBDFPQFOJOHBOEBOZQBSUPGUIFmSFCPYJODMVEJOHBOZNFTIHSJMMTBUUBDIFEUPJU
STEP 6: FIT BACK PLATE, BAFFLE PLATE, ASH RETAINER, GRATES & ASHPAN
»&OTVSFUIFCBDLQMBUFJTJOTUBMMFEmSTUUIFOVTJOHBMPHUPIPMEUIFQMBUFJOUPQPTJUJPOUPLFFQJUGSPN
GBMMJOHJOTUBMMUIFCBGnFQMBUF
»’VSUIFSJOTUSVDUJPOTBOEBTTFNCMZJOTUSVDUJPOTDBOCFWJFXFEPOQBHFTPGUIJTNBOVBM
STEP 7: TEST FIRE DRAW
»-JHIUBTNBMMQJFDFPGOFXTQBQFSJOTJEFUIFmSFCPYUPUFTUUIFESBXPGUIFVOJUBOEnVF
»If the draw is adequate, complete the check list on page 43 and return this as well as this entire booklet
UPUIFmSFQMBDFPXOFS
»*GUIFESBXJTJOBEFRVBUFQMFBTFSFGFSUPUIF#BMBODJOH"JS1SFTTVSFTFDUJPOPOQBHF
