Chenbro RM146 Plus Series User manual

RM146 Plus Series
Rackmount Chassis User Manual
January 2020 Version 1.5
A document provides an overview of product features, functions, architecture, and support specifications.

RM146 Plus Series
│ 2
DISCLAIMERS
No license (express or implied, by estoppel or otherwise) to any intellectual property rights is granted by this document.
Chenbro disclaims all express and implied warranties, including without limitation, the implied warranties of merchantability, fitness
for a particular purpose, and non-infringement, as well as any warranty arising from course of performance, course of dealing, or
usage in trade.
This document contains information on products, services and/or processes in development. All information provided here is subject
to change without notice. Contact your Chenbro representative to obtain the latest Configuration Guide.
The products and services described may contain defects or errors known as errata which may cause deviations from published
specifications. Current characterized errata are available on request.
Chenbro, and the Chenbro logo are trademarks of Chenbro Micom Co., Ltd.in the worldwide.
*Other names and brands may be claimed as the property of others
© 2019 Chenbro Micom Co., Ltd.

RM146 Plus Series
│ 3
Table of Contents
List of Figures................................................................................................................................................4
List of Tables .................................................................................................................................................6
1. Product Overview..........................................................................................................................7
1-1 System Features Overview.................................................................................................8
1-2 Front Panel ......................................................................................................................10
1-3 Back Panel .......................................................................................................................11
1-4 Front Control Panel..........................................................................................................12
1-5 Chassis Dimensions..........................................................................................................13
1-6 Available Rack Mounting Kit Options (Refer to “Installation”) ..........................................14
1-7 System Level Environmental Specifications ......................................................................15
1-8 System Packaging ...........................................................................................................16
2. System Components Installation..................................................................................................17
2-1 Top Cover Installation ......................................................................................................18
2-2 HDD Cage Installation ......................................................................................................19
2-3 Hot-swap HDD Assembly Removal and Installation ..........................................................20
2-4 Internal 2.5’’ HDD Installation （RM14604 Plus）........................................................25
2-5 Internal Slim ODD Installation （RM14604 Plus）........................................................26
2-6 Internal 2.5” HDD/SSD Installation （RM14610 Plus）.................................................27
2-7 System Maintenance........................................................................................................28
2-8 Fan Assembly Installation.................................................................................................29
2-9 PCIe Card Installation.......................................................................................................33
2-10 PSU Installation................................................................................................................34
2-11 Slide Rail Installation........................................................................................................36
3. Backplane....................................................................................................................................38
3-1 Storage Backplane Options ..............................................................................................39
3-2 3.5” 4-port 12Gbps Port to Port Backplane ......................................................................40
3-3 3.5” 4-port 12Gbps Mini-SAS HD Passive Backplane.........................................................42
3-4 2.5” 10-port 12Gbps Mini-SAS HD Passive Backplane.......................................................44
4. Maintenance and Service ............................................................................................................46

RM146 Plus Series
│ 4
List of Figures
Figure 1 RM14604 Plus overview .............................................................................................................8
Figure 2 RM14610 Plus overview .............................................................................................................8
Figure 3 RM14604 Plus major components overview...............................................................................9
Figure 4 RM14610 Plus major components overview...............................................................................9
Figure 5 RM14604 Plus front panel ........................................................................................................10
Figure 6 RM14610 Plus front panel ........................................................................................................10
Figure 7 Back panel with redundant PSU................................................................................................11
Figure 8 Back panel with single PSU .......................................................................................................11
Figure 9 RM14604 Plus front control panel ............................................................................................12
Figure 10 RM14610 Plus front control panel ............................................................................................12
Figure 11 Chassis dimensions...................................................................................................................13
Figure 12 Embossed label dimensions......................................................................................................13
Figure 13 Front top cover installation.......................................................................................................18
Figure 14 Rear top cover installation........................................................................................................18
Figure 15 RM14604 Plus HDD cage installation ........................................................................................19
Figure 16 RM14610 Plus HDD cage installation ........................................................................................19
Figure 17 3.5” hot-swap HDD assembly installation .................................................................................20
Figure 18 3.5” hot-swap HDD assembly removal......................................................................................20
Figure 19 3.5” HDD installation (tool-less type)........................................................................................21
Figure 20 3.5” HDD installation (screw type)............................................................................................21
Figure 21 2.5” HDD/SSD installation in 3.5” tray (screw type)...................................................................22
Figure 22 2.5’’ hot-swap HDD/SSD assembly installation..........................................................................23
Figure 23 2.5’’ hot-swap HDD/SSD assembly removal ..............................................................................23
Figure 24 2.5’’ HDD/SSD installation (tool-less type) ................................................................................24
Figure 25 2.5” HDD/SSD installation (screw type).....................................................................................24
Figure 26 RM14604 Plus internal 2.5'' HDD installation............................................................................25
Figure 27 Slim ODD installation (RM14604 Plus) ......................................................................................26
Figure 28 Internal 2.5’’ HDD/SSD bracket assembly (RM14610 Plus) ........................................................27
Figure 29 Internal 2.5” HDD/SSD Installation (RM14610 Plus) ..................................................................27
Figure 30 Installation of whole system into the rack (screw type).............................................................28
Figure 31 Installation of whole system into the rack (tool-less type).........................................................28
Figure 32 Fan assembly installation (4028)...............................................................................................29
Figure 33 Fan module installation (4028) .................................................................................................29
Figure 34 Fan assembly installation (4048)...............................................................................................30
Figure 35 Fan module installation (4048) .................................................................................................30
Figure 36 Fan assembly installation (4056)...............................................................................................31
Figure 37 Fan module installation (4056) .................................................................................................31
Figure 38 Air baffle installation ................................................................................................................32

RM146 Plus Series
│ 5
Figure 39 PCIe card blank removal ...........................................................................................................33
Figure 40 Cards and brackets installation .................................................................................................33
Figure 41 Single 1U PSU installation-1......................................................................................................34
Figure 42 Single 1U PSU installation-2......................................................................................................34
Figure 43 Redundant PSU module installation..........................................................................................35
Figure 44 Redundant PSU module removal..............................................................................................35
Figure 45 Slide rail installation-1 (84H314610-003) ..................................................................................36
Figure 46 Slide rail installation-2 (84H314610-003) ..................................................................................36
Figure 47 Slide rail Installation-3 (84H314610-003)..................................................................................37
Figure 48 Slide rail Installation-4 (84H314610-003)..................................................................................37
Figure 49 Drive tray LED identification .....................................................................................................38
Figure 50 Backplane front view................................................................................................................40
Figure 51 Backplane rear view .................................................................................................................41
Figure 52 Backplane front view................................................................................................................42
Figure 53 Backplane rear view .................................................................................................................43
Figure 54 Backplane front view................................................................................................................44
Figure 55 Backplane rear view .................................................................................................................45

RM146 Plus Series
│ 6
List of Tables
Table 1 Chenbro RM146 Plus series specifications....................................................................................7
Table 2 RM146 Plus series front control panel........................................................................................12
Table 3 Slide rail options ........................................................................................................................14
Table 4 System environmental specifications summary..........................................................................15
Table 5 System packing information.......................................................................................................16
Table 6 Product weight information .......................................................................................................16
Table 7 Drive power LED/activity LED behavior ......................................................................................38
Table 8 Backplane specifications ............................................................................................................40
Table 9 Connector and pin header function description .........................................................................41
Table 10 Backplane specifications ............................................................................................................42
Table 11 Connector and pin header function description .........................................................................43

RM146 Plus Series
│ 7
1. Product Overview
RM146 Plus series is 1U cost effective server chassis, which supports up to ATX motherboard and delivers flexible configurations for
specific applications. This chapter provides a high-level overview of the system features and available options. More details for each
major sub-system, feature, or options are provided in the following chapters.
Table 1 Chenbro RM146 Plus series specifications
Feature
Description
MB Form Factor
ATX (12’’ x 9.6’’) **
Dimension
(D x W x H)
547.6 x 438.5 x 43.5 (mm)
21.56’’ x 17.26’’ x 1.71’’
Drive Bay
RM14604 Plus: 4 x 3.5’’ Hot-swap, 2 x 2.5’’ Internal, 1 x Slim ODD (9.5 mm) ***
RM14610 Plus: 10 x 2.5’’ Hot-swap, 2 x 2.5” Internal (Optional) ***
PSU Form Factor
1U Single or 1+1 Redundant
Indicator
1 x Power Status, 2 x LAN Activity, 1 x UID, 1 x System Alarm, 1 x HDD Status (RM14604
Plus Only)
Front Control
1 x Power On/Off, 1 x UID
Cooling Fan
40 x 28 mm (3, up to 5)
System Security
N/A
Expansion Slot Opening
1 x Full Height & Half Length
Storage Backplane
RM14604 Plus: 3.5“ 4-port 12Gbps, SATA 7-pin
RM14610 Plus: 2.5” 10-port 12Gbps, Mini-SAS HD
Net Weight
7.5 kg/16.52 lb
Gross Weight
10.0 kg/22.03 lb
Front Bezel
Option
Cubic Feet
1.84
Container Loading
20’:480, 40’:960
Note:
** Mounting hole is compatible with ATX & uATX form factor, max board size is up to 12” x 10.5” CEB board when installing 4028 mm
fan only.
*** Internal 2.5” drives and Slim ODD with the thickness for 9.5 mm.

RM146 Plus Series
│ 8
1-1 System Features Overview
Figure 1 RM14604 Plus overview
Figure 2 RM14610 Plus overview

RM146 Plus Series
│ 9
Figure 3 RM14604 Plus major components overview
Figure 4 RM14610 Plus major components overview
A. Front Top Cover
B. Back Top Cover
C. Label Embossment
D. Rear Top Cover Latch
E. Optical Drive Bay
F. Internal 2.5”HDD Bays
G. Fan Assembly
H. Server Board
I. Power Supply Unit

RM146 Plus Series
│ 10
1-2 Front Panel
Figure 5 RM14604 Plus front panel
Figure 6 RM14610 Plus front panel
A. Rack Handles
B. Storage Drive Bay
C. Optical Drive Bay
D. Info Tag
E. Front Control Panel
F. Storage Sticker

RM146 Plus Series
│ 11
1-3 Back Panel
Figure 7 Back panel with redundant PSU
Figure 8 Back panel with single PSU
A. 1U Redundant Power Supply
B. Single 1U Power Supply
C. I/O Gasket
D. Full Height Expansion Slot

RM146 Plus Series
│ 12
1-4 Front Control Panel
Figure 9 RM14604 Plus front control panel
Figure 10 RM14610 Plus front control panel
Table 2 RM146 Plus series front control panel
Label
ICON
Indicator, button or connector
A
PowerButton
B
LAN1,LAN2 Activity LED
C
PowerLED
D
HDD ActivityLED
E
SystemAlarm LED
F
USB3.0
G
UID Button/LED
H
RackHandle (Screw Type)
I
RackHandle (Latch Type)

RM146 Plus Series
│ 13
1-5 Chassis Dimensions
Figure 11 Chassis dimensions
Figure 12 Embossed label dimensions

RM146 Plus Series
│ 14
1-6 Available Rack Mounting Kit Options (Refer to “Installation”)
Advisory Note –Available rack and cabinet mounting kits are not designed to support shipment of the server system while installed
in a rack. If you choose to do so, Chenbro advises you verify your shipping configuration with appropriate shock and vibration testing
before shipment. Chenbro does not perform shipping tests which cover the complex combination of unique rack offerings and custom
packaging options.
Caution: Exceeding the specified maximum weight limit of a given rail kit or misalignment of the server in the rack may result in
failure of the rack rails, causing damage to the system or personal injury. More than one person to operate with mechanical assist
tools to install and align the server into the rack is highly recommended.
Available rack mounting kits:
Table 3 Slide rail options
Part Number
384-14303-3101A0
384-14303-3100A0
84H314610-003
Rail Dimension (mm/inch)
437.0/17.20"
589.0/23.20”
599.0/23.60"
Applicable Cabinet
Post to Post (mm/inch)
580.0~705.0/22.80"~27.70"
600.0~1000.0/23.60”~39.30”
660.0~838.0/26.00"~33.00"
Sliding Mode
Friction
Friction
Ball-bearing, 2 section
Traveling Distance (mm/inch)
289.0/11.30"
234.0/9.20”
560.0/22.00"
Support Chassis Width (mm)
438.5
438.5
438.5
Loading (kg)
20.7
20.7
15.0
Max. Static Loading (kg) for UL
64.6
64.6
61.9
Tool-less
No
No
Yes
Support CMA
No
No
No

RM146 Plus Series
│ 15
1-7 System Level Environmental Specifications
The following table defines the system level specifications under operating and non-operating environments.
Table 4 System environmental specifications summary
Parameter
Specification
Temperature
Operating
5ºC to 35ºC (41ºF to 95ºF)
Temperature
Non-Operating
-40ºC to 70ºC (-40ºF to 158ºF)
Humidity
Non-Operating
50% to 90%, non-condensing with a maximum wet bulb of 28°C (at
temperatures from 25°C to 35°C)
Unpackaged
Shock
Non-Operating
Trapezoidal, 25g, velocity change is based on product weight
Unpackaged
Vibration
Operating
5Hz @ 0.0002g2/Hz to 350Hz @ 0.0002 g2/Hz
Input acceleration is 0.26g RMS
10 minutes per axis for all 3 axes on all samples
Random control limit tolerance is ± 3dB
Sag & Bow
Non-Operating
Tolerance analysis among rack, rail and chassis
Actual on rack test with EIA Go-NoGo fixture
EMI
Pre-Scan
Radiated Emissions
CISPR Class A (under 6dB):
30~1000MHz vertical/horizontal
1G~6GGHz vertical/horizontal
1G~18GGHz vertical/horizontal
ESD
Contact and Air Discharge
Electrostatic Discharge Immunity Test IEC 61000-4-2
RVI
Operating
HDD Class:
Class 1: Highest performance, reliability, and data integrity
Class 2: A second tier of performance, reliability, and data integrity
HDD I/O throughput degradation SPEC
Pass/Fail Criteria
No functional failure during test or post-test diagnostics
Requirement to pass test is based on IOMeter data throughput (in IO’s
per second) expressed as a percent of Test HDD maximum theoretical
baseline performance
Class1: > 90% of baseline for 4K Random Writes and > 80% of baseline
for 128K Sequential Writes
Class2: > 85% of baseline for 4K Random Writes and > 75% of baseline
for 128K Sequential Writes
Mix: > 80% of baseline for 4K Random Writes and > 70% of baseline for
128K Sequential Writes
Packaged
Vibration
Non-Operating
ISTA (weight over 68.0kg, 1B; weight equal or less than 68.0kg, 1A)
Packaged
Drop
Non-Operating
Drop height change is based on product weight
Non-palletized product:
Investigation: Test requirement is 6 face drops, 8 corner drops and 12
edge drops for a total 26 drops
Validation: Test requirement is 6 face drops, 2 corner drops and 3 edge
drops for a total 11 drops
Palletized product: (both investigation and validation)
Perform 2 bottom drops at the specified height, 10 bottom drops at one
half of the specified height
Perform 4 rotational edge drops (one per edge) at the specified height

RM146 Plus Series
│ 16
1-8 System Packaging
The original Chenbro packaging, where the server system is delivered, is designed to provide protection for L3 configuration and
tested to meet ISTA (International Safe Transit Association) Test Procedure 1A (2008). The packaging is also designed to be reused
for shipment after system integration has been completed.
The original packaging includes the shipping box and various protective inner packaging components, which are designed to as a
protective packaging system. When reused, all the original packaging materialsmust be included such as boxes and each inner
packaging component. In addition, all inner packaging components MUST be reinstalled in the proper location to ensure adequate
protection of the system for subsequent shipment.
Table 5 System packing information
Part Number
Single/Bulk
Form Factor
Support Level
87H314604-102
Single
670.0 * 556.0 * 140.0
L3
NOTE: The design of the inner packaging components does not prevent improper placement within the packaging assembly.
There is only one correct packaging assembly that will allow the package to meet the ISTA (International Safe Transit Association)
Test Procedure 1A (2008).
Failure to follow the specified packaging assembly instructions may result in damage to the system during shipment.
Table 6 Product weight information
Product
Unpackaged Net Weight
（kg）
Packaged Gross Weight
（kg）
Unpackaged Net Weight
(lb)
Packaged Gross Weight
(lb)
RM14604 Plus
8.2
10.3
18.10
22.70
RM14610 Plus
8.4
10.5
18.40
23.00
NOTE: An L3 system does not include MB, processors, memory, drives, or add-in cards. It is the system configuration as
shipped from Chenbro. Weights of integrated system (system configurations that include the items above) will vary
depending on the final system configuration. For the 1U product, a fully integrated unpackaged system can weigh up to 40
lb (18.0 +kg).

RM146 Plus Series
│ 17
2. System Components Installation
RM14604/RM14610 Plus support for a variety of different storage options:
Up to 4 x 3.5” hot swap SAS/SATA HDD (RM14604 Plus)
Up to 10 x 2.5” hot swap SAS/SATA HDD or SSD (RM14610 Plus)
2 x 2.5" internal HDD or SSD up to 9.5mm thickness (RM14604/10 Plus)
Support for different storage and peripheral options will vary depending on the system model and/or available accessory options
installed.

RM146 Plus Series
│ 18
2-1 Top Cover Installation
Figure 13 Front top cover installation
1. Align the guide pins of this cover with the grooves on the chassis base, and slide the cover in (two guide pins for both sides).
NOTE: Ensure that arrows on the cover indicating the back of the chassis.
2. Secure it with two screws as shown.
Figure 14 Rear top cover installation
1. Align the guide pins of the cover with the grooves on the chassis base, and slide the cover towards the front panel until it clicks
(three guide pins for both sides).
2. Secure it with one screw as shown.

RM146 Plus Series
│ 19
2-2 HDD Cage Installation
Figure 15 RM14604 Plus HDD cage installation
1. Align the grooves on the HDD cage with the guide pins of the chassis base, and slide the cage toward the back of the chassis.
2. Secure it with two screws as shown.
Figure 16 RM14610 Plus HDD cage installation
1. Align the grooves on the HDD cage with the guide pins of the chassis base, and slide the cage toward the back of the chassis.
2. Secure it with two screws as shown.
NOTE: All cage SKUs follow the same installation guidelines.

RM146 Plus Series
│ 20
2-3 Hot-swap HDD Assembly Removal and Installation
Figure 17 3.5” hot-swap HDD assembly installation
1. With the open lever, insert the HDD assembly into the drive bay until the end of the HDD cage.
2. Push in the lever when it is secured with a click.
Figure 18 3.5” hot-swap HDD assembly removal
1. Press the tray button, and release the lever as shown.
2. Pull the HDD assembly out of the drive bay.
