Chevrolet Tahoe Police and Special Service Packages - 2011
2011 Chevrolet Tahoe Police and Special Service Packages M
Keys, Doors and Windows . . . 1-1
Keys and Locks . . . . . . . . . . . . . . . 1-1
Seats and Restraints . . . . . . . . . 2-1
Airbag System . . . . . . . . . . . . . . . . . 2-1
Instruments and Controls . . . . 4-1
Warning Lights, Gauges, and
Indicators . . . . . . . . . . . . . . . . . . . . 4-2
Information Displays . . . . . . . . . . . 4-3
Lighting . . . . . . . . . . . . . . . . . . . . . . . 5-1
Exterior Lighting . . . . . . . . . . . . . . . 5-1
Driving and Operating . . . . . . . . 8-1
Driving Information . . . . . . . . . . . . . 8-1
Starting and Operating . . . . . . . . . 8-5
Ride Control Systems . . . . . . . . . . 8-5
Towing.........................8-6
Vehicle Care . . . . . . . . . . . . . . . . . . 9-1
Wheels and Tires . . . . . . . . . . . . . . 9-1
Appearance Care . . . . . . . . . . . . . . 9-2
Technical Data . . . . . . . . . . . . . . . 11-1
Vehicle Data . . . . . . . . . . . . . . . . . . 11-2
Special Equipment
Options . . . . . . . . . . . . . . . . . . . . . 15-1
SEO Standard Options . . . . . . . 15-2
SEO Available Options . . . . . . 15-11
Index ..................... i-1

Black plate (2,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
ii Introduction
The names, logos, emblems,
slogans, vehicle model names, and
vehicle body designs appearing in
this manual including, but not limited
to, GM, the GM logo, CHEVROLET,
the CHEVROLET Emblem, and
TAHOE are trademarks and/or
service marks of General Motors
LLC, its subsidiaries, affiliates,
or licensors.
This manual describes features that
may or may not be on your specific
vehicle either because they are
options that you did not purchase or
due to changes subsequent to the
printing of this owner manual.
Please refer to the purchase
documentation relating to your
specific vehicle to confirm each of
the features found on your vehicle.
For vehicles first sold in Canada,
substitute the name “General
Motors of Canada Limited”for
Chevrolet Motor Division wherever
it appears in this manual.
The Tahoe Police Package
(SEO PPV) is designed for police
work up to and including high‐speed
emergency vehicle operations.
The Tahoe Special Service Package
(SEO 5W4) is neither designed nor
intended for use in high‐speed
emergency vehicle operations.
Canadian Vehicle Owners
Propriétaires Canadiens
A French language copy of this
manual can be obtained from your
dealer or from:
On peut obtenir un exemplaire de
ce guide en français auprès du
concessionnaire ou à l'adresse
suivante:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
Numéro de poste 6438 de langue
française
www.helminc.com
Litho in U.S.A.
Part No. 20880110 A First Printing ©2010 General Motors LLC. All Rights Reserved.

Black plate (3,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
Introduction iii
Using this Supplement
This supplement contains
information specific to the unique
components of the vehicle. It does
not explain everything you need to
know about the vehicle. Read this
supplement along with the owner
manual to learn about the vehicle's
features and controls.
Index
A good place to look for what you
need is the Index in back of this
supplement. It is an alphabetical list
of what is in the supplement, and
the page number where you will
find it.

Black plate (4,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
iv Introduction
2NOTES

Black plate (1,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
Keys, Doors and Windows 1-1
Keys, Doors and
Windows
Keys and Locks
Specific Cylinder Unit for Single
Key - Random Code
System . . . . . . . . . . . . . . . . . . . . . . 1-1
Keys and Locks
Specific Cylinder Unit for
Single Key - Random
Code System
If your vehicles are equipped with
one of these options, the entire fleet
of vehicle locks can be operated
with one key.
.SEO 6E2-Specific Fleet
Key Code
.SEO 6E8-Specific Fleet
Key Code
Your vehicle will be equipped with a
standard production random key
code if one of the optional fleet
codes was not ordered.
For specific key code information,
contact your dealer.
Your vehicles will be equipped with
a key cylinder in the ignition lock
and the driver door only. Remote
keyless entry (RKE) is a standard
feature and operates all other doors
and the rear liftgate. Six additional
RKE transmitters may have been
ordered with your vehicle. See your
dealer for additional information
regarding availability of more RKE
units for your vehicle.
The RKE transmitter for your police
vehicle has the vehicle locator/panic
alarm button disabled. The horn will
not sound and the exterior lights will
not flash when the button is
pressed.

Black plate (2,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
1-2 Keys, Doors and Windows
Remote Keyless
Entry Transmitter
Programming ‐SEO
AMF - Fleet Package of 6
Unprogrammed Remote Units
Do not operate or program the
transmitters in the vicinity of other
vehicles that are in the keyless
entry program mode. This prevents
the programming of the transmitters
to the incorrect vehicle.
Up to eight transmitters may be
programmed to the RKE on Police
and Special Service Package
equipped vehicles. The first four
transmitters are given the position
of #1-#4 in the RKE. Any further
transmitters will also be assigned to
position #4.
Verify that the proper transmitters
are learned to the vehicle. Do not
learn a transmitter with a remote
start button to a vehicle that does
not have remote start.
For the proper procedure to be used
for learning transmitters, see your
dealer.

Black plate (1,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
Seats and Restraints 2-1
Seats and
Restraints
Airbag System
Questions and Answers About
Airbags and Specialty Law
Enforcement Vehicles . . . . . . . 2-1
Notices for Customer Installed
Equipment . . . . . . . . . . . . . . . . . . . 2-3
Airbag Deployment
Diagrams . . . . . . . . . . . . . . . . . . . . 2-4
Airbag System
Questions and Answers
About Airbags and
Specialty Law
Enforcement Vehicles
Q: Can equipment such as radar
devices, video cameras, and
radio trees be mounted in a
specialty vehicle equipped
with a right front passenger
frontal airbag?
A: Yes, but care must be taken to
properly mount the equipment
outside of the airbag
“deployment zone.”
Q: What is the airbag
“deployment zone”?
A: The term “deployment zone”
describes the space an airbag
takes up when fully inflated.
Airbags need room to work
properly, and anything in the
“deployment zone” — such
as improperly mounted
equipment —can greatly affect
the performance of the airbag.

Black plate (2,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
2-2 Seats and Restraints
{WARNING
Airbags inflate with great force,
faster than the blink of an eye. No
objects, such as shotguns, should
be placed over or near the airbag
covers. Equipment mounted too
close to an inflating airbag could
break and become a dangerous
projectile in a crash, causing
injury to the vehicle's occupants.
Also, an object too close to an
inflating airbag could prevent the
airbag from operating properly.
If this ever happens, the airbag
would not be able to protect
occupants the way it was
designed to. To help prevent
injury and to allow the airbag to
perform as it was designed, do
not mount equipment inside the
airbag deployment zone.
Q: How can I identify the airbag
“deployment zone”in my
vehicle?
A: See Airbag Deployment
Diagrams on page 2‑4for more
information. The diagrams
provide the approximate
dimensions of the “deployment
zones”for your specialty vehicle.
Before doing any service work,
including the installation of any
equipment, consult the
appropriate service manual.
Q: Is it possible to shield
equipment so it does not
interfere with airbag
deployment?
A: While shielding may protect
certain equipment from being
damaged or dislodged, it may
also negatively affect how an
airbag inflates. Therefore,
we cannot recommend the
placement of any equipment in
the deployment zone, even
when shielding.
Q: Can the installation of push
bumpers on the front end
of the vehicle affect the
deployment of the airbag?
A: It is not likely that installing push
bumpers will affect sensing for
the airbag as long as the vehicle
structure itself is not modified.
GM is not aware of any adverse
defects from the many push
bumpers that have been
installed on current model
GM police vehicles with airbags.
Q: Is there anything I might add
to the front or sides of the
vehicle that could keep the
airbags from working
properly?
A: Yes. If you add things that
change your vehicle's frame,
bumper system, height, front
end or side sheet metal, they
may keep the airbag system
from working properly. Also,
the airbag system may not work

Black plate (3,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
Seats and Restraints 2-3
properly if you relocate any of
the airbag sensors. If you have
any questions about this, you
should contact Customer
Assistance before you modify
your vehicle. The phone
numbers and addresses for
Customer Assistance are in
Step Two of the Customer
Satisfaction Procedures in the
owner manual. See “Customer
Satisfaction Procedure”in the
owner manual Index.
The service manual has information
about the location of the airbag
sensors, sensing and diagnostic
module, and airbag wiring. See
“Service Publications Ordering
Information”in the owner manual.
Notices for Customer
Installed Equipment
Read the following notices before
installing equipment on your
specialty vehicle.
Notice: GM-approved service
procedures must be followed
to remove and reinstall the
instrument panel to the pad in
order to ensure proper airbag
deployment.
Notice: Do not mount equipment
on the passenger side of the
instrument panel top pad
deployment zone. Equipment
should not be mounted on or
around the passenger airbag
opening because of a deploying
airbag. To allow the airbag to
perform as it was designed, do
not mount equipment inside the
airbag deployment zone.
Notice: The police vehicle has
roof-rail airbags. Do not mount a
security barrier such that the
ends of the barrier or brackets
are within the roof-rail
deployment zones.
Notice: The police vehicle has
roof-rail airbags and a rollover
sensor. The rollover sensor is
mounted on the centerline of the
vehicle between the driver and
right front passenger positions.
If the vehicle has bucket seats,
the rollover sensor will be
exposed. Do not mount
equipment within 25 mm (1 in) of
the rollover sensor. This may
affect the performance of the
airbag system. To allow the
airbags to perform as they are
designed, do not mount
equipment near this area.
Notice: Avoid installing wiring for
roof-rail emergency lighting or
radio antennas that may restrict
the proper deployment of the
roof-rail airbags.

Black plate (4,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
2-4 Seats and Restraints
Airbag Deployment Diagrams Top View of Instrument Panel
and Approximate Deployment
Area of the Airbag Zone
A. Passenger Side Instrument
Panel Top Surface Zone
B. Passenger Side Airbag Module
Trim Panel —Rear Edge
C. Passenger Side Door
D. Approximate Dimensions of
Inflated Airbag
E. Passenger Side Airbag
Deployment Zone
F. Passenger Centerline
G. Inside Rearview Mirror
H. Vehicle Centerline
I. Driver Centerline
J. Driver Side Airbag
Deployment Zone

Black plate (5,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
Seats and Restraints 2-5
K. Front of Steering Wheel
L. Driver Side Door
M. Shift Selector Arc
See Notices for Customer Installed
Equipment on page 2‑3for more
information.
Side View of Driver Side Airbag
Deployment Zone
A. Top Edge of Windshield
B. Top of Instrument Panel
C. Inflated Airbag —Steering
Wheel
D. Centerline of Steering Column
at Mid-Tilt
E. Driver Airbag Deployment Zone
F. Front of Steering Wheel
See Notices for Customer Installed
Equipment on page 2‑3for more
information.
Side View of Passenger Side
Airbag Deployment Zone
A. Top Edge of Windshield
B. Inside Rearview Mirror
C. Instrument Panel Top
Surface Zone
D. Passenger Side Airbag Module
Trim Panel —Rear Edge
E. Inflated Airbag —Horizontal
Dimension (Approximate
390 mm (15.4 in))
F. Inflated Airbag —Vertical
Dimension (Approximate
490 mm (19.3 in))
G. Inflated Airbag —Instrument
Panel
H. Passenger Airbag
Deployment Zone
See Notices for Customer Installed
Equipment on page 2‑3for more
information.

Black plate (6,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
2-6 Seats and Restraints
Roof-rail and Seat‐mounted Side Impact Airbag Deployment
Zones - Passenger Side shown, Driver Side similar
A. Front of Deployment Zone at
Front Upper Corner of Front
Door Pad
B. Windshield Pillar Trim with
Grab Handle
C. Visor
D. Deployment Zone
E. Top of Deployment
Zone —Along Roof-rail at
Edge of Headliner
F. Back of Deployment
Zone —At Rear Top Corner
of Rear Door Pad
G. Rear Quarter Window
H. Top Edge of Interior
Quarter Trim
I. Bottom of Airbag Deployment
Zone —Parallel to Outside
Bottom Edge of Rear Quarter
Glass
J. Dimension at Mirror Patch from
Top Edge of Front Door Pad
K. Center of Door Trim Pull Handle
L. Top Surface of Outboard Seat
Cushion
M. Top Edge of Front Door Pad
N. Back Edge of Center Pillar Trim
O. Top Edge of Rear Door Pad
P. Bottom Outside Edge of Rear
Quarter Window
See Notices for Customer Installed
Equipment on page 2‑3for more
information.

Black plate (7,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
Seats and Restraints 2-7
Roof-rail and Seat‐mounted Side Impact Airbag Driver and Passenger
Deployment Zones - View from Rear Cargo Area
A. Roof-rail Airbag
Deployment Zone
B. Underside of Headliner
C. Edge of Headliner
D. Inner Center Pillar Trim
E. Bottom of Door Windows
F. Front Seat Headrest
G. Seat Centerline
H. Inner Door Pad
I. Seat‐mounted Side
Impact Airbag deployment
Zone —Front Seat
J. Top Surface of Outboard Front
Seat Cushion
See Notices for Customer Installed
Equipment on page 2‑3for more
information.

Black plate (8,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
2-8 Seats and Restraints
2NOTES

Black plate (1,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
Instruments and Controls 4-1
Instruments and
Controls
Warning Lights, Gauges, and
Indicators
Instrument Cluster . . . . . . . . . . . . 4-2
Speedometer . . . . . . . . . . . . . . . . . 4-3
Odometer . . . . . . . . . . . . . . . . . . . . . 4-3
Information Displays
Driver Information
Center (DIC) . . . . . . . . . . . . . . . . . 4-3

Black plate (2,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
4-2 Instruments and Controls
Warning Lights, Gauges, and Indicators
Instrument Cluster
Tahoe Police Package 6‐Speed Automatic Transmission (English Shown, Metric Similar)

Black plate (3,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
Instruments and Controls 4-3
The Tahoe Special Service Package
instrument panel cluster is similar
to the Tahoe Police Package
instrument panel cluster, except that
the maximum speed displayed is
lower and additional indicators may
be present. See “Instrument Cluster”
in the Index of your owner manual
for more information.
Speedometer
Your speedometer lets you see your
speed in both miles per hour (mph)
and kilometers per hour (km/h).
The speedometer for the Tahoe
Police Package (SEO PPV) displays
a maximum vehicle speed of
225 km/h (140 mph). The
speedometer for the Tahoe Special
Service Package (SEO 5W4)
displays a maximum vehicle speed
of 193 km/h (120 mph). The Tahoe
Special Service Package is not
designed nor intended for use in
high‐speed emergency vehicle
operations.
Odometer
Your odometer shows how far your
vehicle has been driven, either in
miles (United States) or kilometers
(Canada).
Information Displays
Driver Information
Center (DIC)
The Tahoe Police Package and
Special Service Packages do not
have DIC buttons. You can turn
off or acknowledge the available
DIC messages by using the trip
odometer reset stem located on
the instrument panel cluster.
The DIC will display engine running
hours.
See the owner manual for additional
information on the DIC.

Black plate (4,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
4-4 Instruments and Controls
2NOTES

Black plate (1,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
Lighting 5-1
Lighting
Exterior Lighting
Exterior Lamp Controls . . . . . . . . 5-1
Exterior Lighting
Exterior Lamp Controls
The following exterior lighting
features apply to vehicles first sold
in the United States.
The vehicle has Daytime Running
Lamps (DRL) and an Automatic
Headlamp System (AHS). The DRL
and AHS can be turned to OFF with
the headlamp switch when the
transmission is in P (Park) and the
engine is at idle. If the engine is not
turned off, the DRL and AHS will
remain OFF when the transmission
is placed in gear. The vehicle may
be driven with the lamps off for one
ignition cycle.
The vehicle may have been built
with SEO 9G8, DRL AND AHS
DISABLE. This feature turns off
DRL and AHS and requires manual
control of the exterior lighting. See
your dealer to restore the DRL and
AHS to normal operation.
For vehicles first sold in Canada,
the DRL and AHS can be turned off
if the transmission is in P (Park).
See the owner's manual for more
information.
Special Features
The following standard features are
disabled in the Police Package and
Special Service Package.
.Entry Lighting and Exit Lighting
.Remote Keyless Entry Feedback
(Horn Beep) and (Lamps Flash)
Automatic Door Locking is standard.
If you need it disabled, see your
dealer.

Black plate (2,1)
Chevrolet Tahoe Police and Special Service Packages - 2011
5-2 Lighting
2NOTES
