Chicago Electric 90045 Installation manual

BELT SANDER
3” X 21”
Model 90045
SET UP AND OPERATING INSTRUCTIONS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright©2003 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Manual Revised 10e

Page 2For technical questions, please call 1-800-444-3353.SKU 90045
CONTENTS
IMPORTANT SAFETY
INFORMATION .................................3
GENERAL POWER TOOL SAFETY
WARNINGS........................................... 3
BELT SANDER SAFETY WARNINGS.... 5
VIBRATION SAFETY .............................. 6
GROUNDING ......................................7
DOUBLE INSULATED TOOLS:
TOOLS WITH TWO PRONG PLUGS... 7
EXTENSION CORDS .............................. 7
SYMBOLOGY.......................................... 8
SPECIFICATIONS...............................9
UNPACKING .......................................9
ASSEMBLY.........................................9
TO REMOVE/INSTALL A SANDING
BELT:..................................................... 9
TO ATTACH THE DUST BAG:.............. 10
OPERATING INSTRUCTIONS .........10
TOOL SET UP ....................................... 10
WORK PIECE AND WORK AREA
SET UP ............................................... 10
GENERAL OPERATING
INSTRUCTIONS ................................. 10
MAINTENANCE AND SERVICING...12
CLEANING, MAINTENANCE, AND
LUBRICATION .................................... 12
TROUBLESHOOTING........................... 13
PARTS LIST......................................14
ASSEMBLY DIAGRAM.....................15
LIMITED 1 YEAR / 90 DAY
WARRANTY ...................................16

Page 3For technical questions, please call 1-800-444-3353.SKU 90045
SAVE THIS MANUAL
Keep this manual for the safety warnings
and precautions, assembly, operating,
inspection, maintenance and cleaning
procedures. Write the product’s serial number
in the back of the manual near the assembly
diagram (or month and year of purchase if
product has no number). Keep this manual
and the receipt in a safe and dry place for
future reference.
IMPORTANT SAFETY
INFORMATION
In this manual, on the labeling, and
all other information provided with
this product:
This is the safety alert
symbol. It is used to alert
you to potential personal
injury hazards. Obey all
safety messages that follow
this symbol to avoid possible
injury or death.
DANGER indicates a
hazardous situation
which, if not avoided, will result
in death or serious injury.
WARNING indicates a
hazardous situation
which, if not avoided, could
result in death or serious injury.
CAUTION, used with
the safety alert
symbol, indicates a hazardous
situation which, if not avoided,
could result in minor or moderate
injury.
NOTICE is used to
address practices not
related to personal injury.
CAUTION, without the
safety alert symbol, is
used to address practices not
related to personal injury.
General Power Tool Safety Warnings
WARNING Read all safety warnings
and instructions. Failure to follow the
warnings and instructions may result
in electric shock, re and/or serious
injury.
Save all warnings and instructions
for future reference.
The term ″power tool″ in the warnings
refers to your mains-operated (corded)
power tool.
Work area safety1.
Keep work area clean and well lit.a.
Cluttered or dark areas invite accidents.
Do not operate power tools inb.
explosive atmospheres, such as in
the presence of ammable liquids,
gases or dust. Power tools create
sparks which may ignite the dust or
fumes.
Keep children and bystandersc.
away while operating a power tool.
Distractions can cause you to lose
control.
Electrical safety2.
Power tool plugs must match thea.
outlet. Never modify the plug in
any way. Do not use any adapter
plugs with grounded power tools.
Unmodied plugs and matching outlets
will reduce risk of electric shock.
Avoid body contact with groundedb.
surfaces such as pipes, radiators,
ranges and refrigerators. There is an

Page 4For technical questions, please call 1-800-444-3353.SKU 90045
increased risk of electric shock if your
body is grounded.
Do not expose power tools to rainc.
or wet conditions. Water entering
a power tool will increase the risk of
electric shock.
Do not abuse the cord. Never used.
the cord for carrying, pulling or
unplugging the power tool. Keep
cord away from heat, oil, sharp
edges or moving parts. Damaged
or entangled cords increase the risk of
electric shock.
When operating a power toole.
outdoors, use an extension cord
suitable for outdoor use. Use of a
cord suitable for outdoor use reduces
the risk of electric shock.
If operating a power tool in a dampf.
location is unavoidable, use a
Ground Fault Circuit Interrupter
(GFCI) protected supply. Use of a
GFCI reduces the risk of electric shock.
Personal safety3.
Stay alert, watch what you area.
doing and use common sense when
operating a power tool. Do not use
a power tool while you are tired or
under the inuence of drugs, alcohol
or medication. A moment of inattention
while operating power tools may result
in serious personal injury.
Use personal protective equipment.b.
Always wear eye protection. Safety
equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing
protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting.c.
Ensure the switch is in the off-
position before connecting to power
source, picking up or carrying the
tool. Carrying power tools with your
nger on the switch or energizing power
tools that have the switch on invites
accidents.
Remove any adjusting key or wrenchd.
before turning the power tool on.
A wrench or a key left attached to a
rotating part of the power tool may result
in personal injury.
Do not overreach. Keep propere.
footing and balance at all times. This
enables better control of the power tool
in unexpected situations.
Dress properly. Do not wear loosef.
clothing or jewelry. Keep your hair,
clothing and gloves away from
moving parts. Loose clothes, jewelry
or long hair can be caught in moving
parts.
If devices are provided for theg.
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use of
these devices can reduce dust-related
hazards.
Only use safety equipment that hash.
been approved by an appropriate
standards agency. Unapproved
safety equipment may not provide
adequate protection. Eye protection
must be ANSI-approved and breathing
protection must be NIOSH-approved for
the specic hazards in the work area.
Power tool use and care4.
Do not force the power tool. Usea.
the correct power tool for your
application. The correct power tool will
do the job better and safer at the rate
for which it was designed.
Do not use the power tool if theb.
switch does not turn it on and off.
Any power tool that cannot be controlled
with the switch is dangerous and must
be repaired.

Page 5For technical questions, please call 1-800-444-3353.SKU 90045
Disconnect the plug from thec.
power source before making any
adjustments, changing accessories,
or storing power tools. Such
preventive safety measures reduce
the risk of starting the power tool
accidentally.
Store idle power tools out of thed.
reach of children and do not allow
persons unfamiliar with the power
tool or these instructions to operate
the power tool. Power tools are
dangerous in the hands of untrained
users.
Maintain power tools. Check fore.
misalignment or binding of moving
parts, breakage of parts and any
other condition that may affect the
power tool’s operation. If damaged,
have the power tool repaired before
use. Many accidents are caused by
poorly maintained power tools.
Keep cutting tools sharp and clean.f.
Properly maintained cutting tools with
sharp cutting edges are less likely to
bind and are easier to control.
Use the power tool, accessoriesg.
and tool bits etc. in accordance
with these instructions, taking into
account the working conditions and
the work to be performed. Use of
the power tool for operations different
from those intended could result in a
hazardous situation.
Service5.
Have your power tool serviced by aa.
qualied repair person using only
identical replacement parts. This will
ensure that the safety of the power tool
is maintained.
Belt Sander Safety Warnings
Hold power tools by insulated1.
gripping surfaces when performing
an operation where the cutting tool
may contact hidden wiring or its own
cord. Contact with a ″live″ wire will make
exposed metal parts of the tool ″live″ and
shock the operator.
Maintain labels and nameplates on2.
the tool. These carry important safety
information. If unreadable or missing,
contact Harbor Freight Tools for a
replacement.
Avoid unintentional starting. Prepare to3.
begin work before turning on the tool.
Do not lay the tool down until it has come4.
to a complete stop. Moving parts can
grab the surface and pull the tool out of
your control.
When using a handheld power tool,5.

hands to resist starting torque.
Do not leave the tool unattended when6.
it is plugged into an electrical outlet.
Turn off the tool, and unplug it from its
electrical outlet before leaving.
This product is not a toy. Keep it out of7.
reach of children.
People with pacemakers should8.
consult their physician(s) before use.

to heart pacemaker could cause
pacemaker interference or pacemaker
failure. In addition, people with
pacemakers should:



electrical shock.

grounded. Ground Fault Circuit

Page 6For technical questions, please call 1-800-444-3353.SKU 90045
Interrupter (GFCI) should also be
implemented – it prevents sustained
electrical shock.
WARNING: Some dust created by power9.
sanding, sawing, grinding, drilling, and
other construction activities, contains
chemicals known [to the State of
California] to cause cancer, birth defects
or other reproductive harm. Some
examples of these chemicals are:


cement or other masonry products

treated lumber
Your risk from these exposures varies,
depending on how often you do this type
of work. To reduce your exposure to
these chemicals: work in a well ventilated
area, and work with approved safety
equipment, such as those dust masks

microscopic particles. (California Health
& Safety Code § 25249.5, et seq.)
WARNING: Handling the cord on this10.
product will expose you to lead, a
chemical known to the State of California
to cause cancer, and birth defects or
other reproductive harm. Wash hands
after handling. (California Health &
Safety Code § 25249.5, et seq.)
The warnings, precautions, and11.
instructions discussed in this instruction
manual cannot cover all possible
conditions and situations that may occur.
It must be understood by the operator
that common sense and caution are
factors which cannot be built into this
product, but must be supplied by the
operator.
Vibration Safety
This tool vibrates during use. Repeated

cause temporary or permanent physical
injury, particularly to the hands, arms
and shoulders. To reduce the risk of

Anyone using vibrating tools regularly1.

be examined by a doctor and then have

medical problems are not being caused
or worsened from use. Pregnant
women or people who have impaired
blood circulation to the hand, past hand
injuries, nervous system disorders,
diabetes, or Raynaud’s Disease
should not use this tool. If you feel any
symptoms related to vibration (such as
tingling, numbness, and white or blue

possible.
Do not smoke during use. Nicotine2.
reduces the blood supply to the hands


Wear suitable gloves to reduce the3.
vibration effects on the user.
Use tools with the lowest vibration when4.
there is a choice.
5.
of work.
Grip tool as lightly as possible (while still6.

do the work.
To reduce vibration, maintain the tool7.
as explained in this manual. If any
abnormal vibration occurs, stop use
immediately.
SAVE THESE
INSTRUCTIONS.

Page 7For technical questions, please call 1-800-444-3353.SKU 90045
GROUNDING
TO PREVENT
ELECTRIC SHOCK
AND DEATH FROM INCORRECT
GROUNDING WIRE
CONNECTION:
Check with a qualied electrician
if you are in doubt as to whether
the outlet is properly grounded.
Do not modify the power cord
plug provided with the tool.
Never remove the grounding
prong from the plug. Do not use
the tool if the power cord or plug
is damaged. If damaged, have it
repaired by a service facility
before use. If the plug will not t
the outlet, have a proper outlet
installed by a qualied
electrician.
Double Insulated Tools: Tools with
Two Prong Plugs
Outlets for 2-Prong Plug
Tools marked “Double Insulated” do1.
not require grounding. They have a
special double insulation system which

complies with the applicable standards

Canadian Standard Association, and the
National Electrical Code. (See Outlets
for 2-Prong Plug.)
Double insulated tools may be used in2.
either of the 120 volt outlets shown in the


Extension Cords
Grounded1. tools require a three wire
extension cord. Double Insulated
tools can use either a two or three wire
extension cord.
As the distance from the supply outlet2.
increases, you must use a heavier gauge
extension cord. Using extension cords
with inadequately sized wire causes a
serious drop in voltage, resulting in loss
of power and possible tool damage.
(See Table A.)
The smaller the gauge number of the3.
wire, the greater the capacity of the cord.
For example, a 14 gauge cord can carry
a higher current than a 16 gauge cord.
(See Table A.)
When using more than one extension4.
cord to make up the total length, make
sure each cord contains at least the
minimum wire size required. (See Table
A.)
If you are using one extension cord for5.
more than one tool, add the nameplate
amperes and use the sum to determine
the required minimum cord size. (See
Table A.)
If you are using an extension cord6.
outdoors, make sure it is marked with the

is acceptable for outdoor use.
Make sure the extension cord is properly7.
wired and in good electrical condition.
Always replace a damaged extension

electrician before using it.

Page 8For technical questions, please call 1-800-444-3353.SKU 90045
Protect the extension cords from sharp8.
objects, excessive heat, and damp or
wet areas.
RECOMMENDED MINIMUM WIRE
GAUGE FOR EXTENSION CORDS*
(120/240 VOLT)
NAMEPLATE
AMPERES
(at full load)
EXTENSION CORD
LENGTH
25’ 50’ 75’
100’ 150’
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 
12.1 – 16.0 14 12 10  
16.1 – 20.0 12 10 
TABLE A
* Based on limiting the line
voltage drop to ve volts at
150% of the rated amperes.
Symbology
Double Insulated
Canadian Standards Association

V~ Volts Alternating Current
AAmperes
n0xxxx/min. 
(RPM)

Page 9For technical questions, please call 1-800-444-3353.SKU 90045
SPECIFICATIONS
Electrical Input 120 V~ / 60 Hz / 7.5 A (Rated)
Belt Speed 
Belt Size 3” x 21”
Accessories Dust Bag / 120 Grit Belt
E194601
UNPACKING
When unpacking, make sure that the
item is intact and undamaged. If any parts
are missing or broken, please call Harbor

possible.
ASSEMBLY
Read the ENTIRE IMPORTANT
SAFETY INFORMATION
section at the beginning of this
manual including all text under
subheadings therein before set up
or use of this product.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Turn the Trigger of the tool off
and unplug the tool from its
electrical outlet before
assembling or making any
adjustments to the tool.
Note: For additional information regarding the
parts listed in the following pages, refer
to the Assembly Diagram near the end of
this manual.
To Remove/Install A Sanding Belt:
Figure A
TENSION LEVER OF
FRONT WHEEL FRAME (53)
SANDING
BELT (46)
TRIGGER
(66)
1. 
Wheel Frame (53), and slide the Sanding
Belt (46) out. (See Figure A.)
Slide a new Sanding Belt (46) on. Then,2.

Wheel Frame (53). (See Figure A.)
Plug the Power Cord (14) into the3.
nearest 120 volt, grounded, electrical
outlet.
CAUTION! The machined parts near the
Tension Adjuster (29) may be sharp.
Wear work gloves when adjusting the
tension.
Figure B
TENSION
ADJUSTER
(29)
TRIGGER
(66)
SWITCH LOCK
LEFT
HOUSING
(18)
4. 

Trigger (66). As the Sanding Belt (46)
turns, observe the Sanding Belt to see

to the right or left. If the Sanding Belt
moves to the right or left, while wearing
heavy work gloves, turn the Tension
Adjuster (29) right or left until the

REV 04j; 09k

Page 10For technical questions, please call 1-800-444-3353.SKU 90045
off the Belt Sander.
(See Figures A and B.)
To Attach The Dust Bag:
DUST BAG (69)
Figure C
To attach the Dust Bag (69), simply clip
the opening of the Dust Bag onto the
Dust Port located on the Left Housing
(18). (See Figure C.)
OPERATING INSTRUCTIONS
Read the ENTIRE IMPORTANT
SAFETY INFORMATION
section at the beginning of this
manual including all text under
subheadings therein before set up
or use of this product.
Tool Set Up
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Turn the Trigger of the tool off
and unplug the tool from its
electrical outlet before adjusting
tool or installing accessories.
To start the Belt Sander, depress the1.
Trigger (66). To stop the tool, release
pressure on the Trigger. (See Figure B.)
To lock the Trigger (66) in the2. “ON”
position for continuous operation,
depress the Trigger and push in on the
Switch Lock. The tool will continue to
run. To turn off the tool, squeeze and
release the Trigger once.
(See Figure B.)
WARNING!3. Prior to using the Belt
Sander (each time), make sure the
Switch Lock mechanism is working
properly. Release the Switch Lock
mechanism before disconnecting the Belt
Sander from its electrical outlet. Failure
to do so will cause the tool to start
immediately the next time it is plugged
into an electrical outlet, resulting in
possible injury or property damage.
Work Piece and Work Area Set Up
Designate a work area that is clean and1.

access by children or pets to prevent
distraction and injury.
Route the power cord along a safe2.
route to reach the work area without
creating a tripping hazard or exposing
the power cord to possible damage. The
power cord must reach the work area
with enough extra length to allow free
movement while working.
Secure loose work pieces using a vise3.
or clamps (not included) to prevent
movement while working.
There must not be objects, such as utility4.
lines, nearby that will present a hazard
while working.
Make sure the workpiece is free from5.
nails and any other foreign objects which
could damage the Sanding Belt (46).
General Operating Instructions
Make sure the Trigger is released,1.
then plug the Power Cord (14) into the
nearest 120 volt, grounded, electrical
outlet.

Page 11For technical questions, please call 1-800-444-3353.SKU 90045
WARNING! When sanding a2.
workpiece, always push and pull the
Belt Sander over the workpiece with
both hands rmly gripping the tool.
Do not pass hands or ngers directly
in front of, to the rear, or below the
Sanding Belt (46).
Firmly grip the Belt Sander with both3.
hands. Then, squeeze the Trigger (66)
to turn on the tool. If desired, use the

continuous mode.
Allow the Sanding Belt (46) to turn up to4.
full speed before feeding the Sanding
Belt into the workpiece.
To avoid damaging the workpiece,5.
always sand parallel to the grain of the
wood.
Do not force the Belt Sander to remove6.
material faster than it is designed to
cut. Push and pull the Sanding Belt
(46) gradually along the surface of the
workpiece.
7.
turn off the Belt Sander and wait until
the Sanding Belt (46) stops turning. To
prevent accidents, make sure the trigger
is released and disconnect the power
supply after use. Clean, then store the
tool indoors out of children’s reach.

Page 12For technical questions, please call 1-800-444-3353.SKU 90045
MAINTENANCE AND
SERVICING
Procedures not specically
explained in this manual must
be performed only by a qualied
technician.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Turn the Trigger of the tool off
and unplug the tool from its
electrical outlet before
performing any inspection,
maintenance, or cleaning
procedures.
TO PREVENT SERIOUS INJURY
FROM TOOL FAILURE:
Do not use damaged equipment.
If abnormal noise or vibration
occurs, have the problem
corrected before further use.
Cleaning, Maintenance, and
Lubrication
BEFORE EACH USE,1. inspect the
general condition of the tool. Check
for loose hardware, misalignment or
binding of moving parts, cracked or
broken parts, damaged electrical wiring,
dull or damaged Sanding Belt, and any
other condition that may affect its safe
operation.
TO CLEAN:2. The ventilation openings
should be kept clean and free of sawdust
and debris. The most effective way to
clean the ventilation openings is with
compressed air. The outer body may
be cleaned with a clean cloth and a mild
detergent. Do not use solvents. Do not
immerse the Belt Sander in liquid.
CARBON BRUSH:3. To maintain peak
efficiency of the Belt Sander’s Motor
it is recommended that every two to
six months the Carbon Brush (27) be
examined.
Figure D - FRONT VIEW
BRUSH
HOLDER
COVER (28)
a. To check the Carbon Brush, remove the
Brush Holder Cover (28) located at the
front of the Belt Sander.
(See Figure D.)
Lift out the Carbon Brush to inspect.b.
The Carbon Brush should be free of
dust and dirt. The Carbon Brush should
be replaced when it has worn down to
3/16” in length.
If cleaning is necessary, rub the Carbonc.
Brush thoroughly with a pencil eraser.
Next, clean the Brush Holder opening
with compressed air or a clean cloth.
Then, replace the Carbon Brush. Thed.
Carbon Brush should slide freely in and
out of the Brush Holder (25) without
sticking. Replace the Brush Holder
Cover.
4. WARNING! If the supply cord of
this power tool is damaged, it must be
replaced only by a qualied service
technician.

Page 13For technical questions, please call 1-800-444-3353.SKU 90045
Troubleshooting
Problem Possible Causes Likely Solutions
Tool will not start. Cord not connected.1.
No power at outlet.2.
Tool’s thermal reset breaker3.
tripped (if equipped).
Internal damage or wear.4.
(Carbon brushes or switch, for
example.)
Check that cord is plugged in.1.
Check power at outlet. If outlet is unpowered,2.
turn off tool and check circuit breaker. If breaker
is tripped, make sure circuit is right capacity for
tool and circuit has no other loads.
Turn off tool and allow to cool. Press reset button3.
on tool.
Have technician service tool.4.
Tool operates slowly. Extension cord too long or wire size
too small.
Eliminate use of extension cord. If an extension
cord is needed, use shorter/heavier gauge cord.
See Extension Cords in GROUNDING section.
Performance
decreases over time.
Sanding belt dull or damaged.1.
Carbon brushes worn or2.
damaged.
Replace as needed.1.
2.
Excessive noise or
rattling.
Internal damage or wear. (Carbon
brushes or bearings, for example.)
Have technician service tool.
 Forcing tool to work too fast.1.
Sanding belt dull or damaged.2.
Blocked motor housing vents.3.
Motor being strained by long or4.
small diameter extension cord.
Allow tool to work at its own rate.1.
Replace as needed.2.
3.
approved dust mask/respirator while blowing dust
out of motor using compressed air.
Eliminate use of extension cord. If an extension4.
cord is needed, use one with the proper diameter
for its length and load. See Extension Cords in
GROUNDING section.
Follow all safety precautions whenever diagnosing or servicing the tool.
Disconnect power supply before service.

Page 14For technical questions, please call 1-800-444-3353.SKU 90045
Part Description
1 Close Cover (18)
2 Bearing (626)
3 Shaft Gear
4 Bearing (608)
5 Dust Suction Cover
6 Fan
7 Screw (ST3.8 x 16)
8 Plain Washer (8)
9 Cover Board
10 
11 Belt Cover
14 Power Cord
15 Cable Plug
17 Pressure Cable
18 
19 Bearing (6000)
20 Plain Washer (10)
21 
22 Column Pin (3)
23 Retainer (10)
24 Nameplate
Part Description
25 Carbon Brush Holder
26 Nut (M5)
27 Carbon Brush
28 Brush Holder Cover
29 Tension Adjuster
30 Adjust Spring
31 Plain Washer (16)
32 
33 Screw (ST4.8 x 20)
34 
35 Ring Washer
36 Rear Wheel
37 Needle Bearing
38 Screw (M5 x 10)
40 
41 Spring
42 Screw (M4 x 10)
43 Bearing Seat
44 Front Cover
45 Screw (ST4.8 x 18)
46 Sanding Belt
Part Description
47 Cushion
48 Bottom Plate
49 Belt
52 Front Wheel Drive Axis
53 Front Wheel Frame
54 Front Wheel
55 Small Belt Wheel
56 Stator
58 Rotor
60 Right Housing
62 Nameplate
63 Screw (ST4.8 x 40)
64 Screw (ST4.8 x 25)
65 Screw (M5 x 40)
66 Trigger
67 Soft Grip
68 Adjust Nut
69 Dust Bag (not shown)
70 Roller Bearing
PLEASE READ THE FOLLOWING CAREFULLY









PARTS LIST
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts.
REV 04l, 10e

Page 15For technical questions, please call 1-800-444-3353.SKU 90045
ASSEMBLY DIAGRAM
REV 04l, 10e
65
64
63
62
33
67
4
58
456
48
47
54
37
70
23
52
53
41
32
68 29
30
31
24
28
27
26
25
20 38
49
55
23
22
21
20
19
66
18
40
34
35
36
37
42
43
44
45
46
33 7
17
15
14
13
12
11
109
8
7
6
5
4
3
2
1
69: DUST BAG NOT SHOWN.

Page 16For technical questions, please call 1-800-444-3353.SKU 90045
LIMITED 1 YEAR / 90 DAY
WARRANTY
Harbor Freight Tools Co. makes every
effort to assure that its products meet high
quality and durability standards, and warrants
to the original purchaser that for a period
of ninety days from date of purchase that
the engine/motor, the belts (if so equipped),
and the blades (if so equipped) are free
of defects in materials and workmanship.
Harbor Freight Tools also warrants to the
original purchaser, for a period of one year
from date of purchase, that all other parts
and components of the product are free from
defects in materials and workmanship (90
days if used by a professional contractor or
if used as rental equipment). This warranty
does not apply to damage due directly or
indirectly, to misuse, abuse, negligence or
accidents, repairs or alterations outside
our facilities, normal wear and tear, or to
lack of maintenance. We shall in no event
be liable for death, injuries to persons
or property, or for incidental, contingent,
special or consequential damages arising
from the use of our product. Some states
do not allow the exclusion or limitation of
incidental or consequential damages, so the
above limitation of exclusion may not apply
to you.



FITNESS.
To take advantage of this warranty,
the product or part must be returned to us
with transportation charges prepaid. Proof
of purchase date and an explanation of the
complaint must accompany the merchandise.

will either repair or replace the product at
our election or we may elect to refund the
purchase price if we cannot readily and
quickly provide you with a replacement. We
will return repaired products at our expense,
but if we determine there is no defect, or that
the defect resulted from causes not within the
scope of our warranty, then you must bear the
cost of returning the product.

rights and you may also have other rights
which vary from state to state.
3491 Mission Oaks Blvd. • PO Box 6009 •
Camarillo, CA 93011 • [phone]
