Chicago Electric 4" 93211 User manual

4” TABLE SAW
WITH 2 BLADES
93211
ASSEMBLY AND OPERATING INSTRUCTIONS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright©2005 by Harbor Freight Tools®. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools. Diagrams within this
manual may not be drawn proportionally. Due to continuing improvements, actual
product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Revised Manual 11e

Page 2SKU 93211 For technical questions, please call 1-800-444-3353.
Motor 120 Volts AC /60 Hz / 90 Watts / 1/8HP / 14,000 no load RPM
14,000 RPM Minimum Accessory Rating
Depth of Cut 3/4”
Table Two miter slots, 3/8” each with miter gauge;
7-1/2” L x 5-1/2” W
Arbor Diameter 1/2”
Power Cord 5’, 18 Gauge, 3-prong plug
Blades 4” Dry Diamond Blade
4” x 40 T Manganese Steel Saw Blade
Net Weight 6.8 Lbs.
Save This Manual
You will need the manual for the safety warnings and precautions, assembly instruc-
tions, operating and maintenance procedures, parts list and diagram. Keep your
invoice with this manual. Write the invoice number on the inside of the front cover.
Keep the manual and invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using this tool, basic safety precautions should always be
followed to reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools in damp
or wet locations. Don’t expose to rain. Keep work area well lighted. Do not
use electrically powered tools in the presence of ammable gases or liquids.
3. Keep children away. Children must never be allowed in the work area. Do
not let them handle machines, tools, or extension cords.
4. Store idle equipment. When not in use, tools must be stored in a dry location
to inhibit rust. Always lock up tools and keep out of reach of children.
5. Do not force tool. It will do the job better and more safely at the rate for which
it was intended. Do not use inappropriate attachments in an attempt to exceed
the tool capacity.
6. Use the right tool for the job. Do not attempt to force a small tool or attach-
ment to do the work of a larger industrial tool. There are certain applications
for which this tool was designed. Do not modify this tool and do not use this
tool for a purpose for which it was not intended. REV 06c
Specications

Page 3SKU 93211 For technical questions, please call 1-800-444-3353.
7. Dress properly. Do not wear loose clothing or jewelry as they can be caught
in moving parts. Protective, electrically nonconductive clothes and nonskid
footwear are recommended when working. Wear restrictive hair covering to
contain long hair.
8. Use eye and ear protection. Always wear ANSI-approved impact safety
goggles. Wear a full face shield if you are producing metal lings or wood chips.
Wear an ANSI-approved dust mask or respirator when working around metal,
wood, and chemical dusts and mists. The included eye guard is intended to
supplement eye protection, NOT replace it.
9. Do not overreach. Keep proper footing and balance at all times. Do not reach
over or across running machines.
10. Maintain tools with care. Keep tools sharp and clean for better and safer per-
formance. Follow instructions for lubricating and changing accessories. Inspect
tool cords periodically and, if damaged, have them repaired by an authorized
technician. The handles must be kept clean, dry, and free from oil and grease
at all times.
11. Disconnect power. Unplug tool when not in use.
12. Remove adjusting keys and wrenches. Check that adjusting wrenches are
removed from the tool or machine work surface before plugging it in.
13. Avoid unintentional starting. Be sure the switch is in the Off position when
not in use and before plugging in.
14. Stay alert. Watch what you are doing, use common sense. Do not operate any
tool when you are tired.
15. Check for damaged parts. Before using any tool, any part that appears
damaged should be carefully checked to determine that it will operate properly
and perform its intended function. Check for alignment and binding of moving
parts; any broken parts or mounting xtures; and any other condition that may
affect proper operation. Any part that is damaged should be properly repaired
or replaced by a qualied technician. Do not use the tool if any switch does not
turn On and Off properly.
16. Guard against electric shock. Prevent body contact with grounded surfaces
such as pipes, radiators, ranges, and refrigerator enclosures.
17. Do not operate tool if under the inuence of alcohol or drugs. Read warning
labels on prescriptions to determine if your judgment or reexes are impaired
while taking drugs. If there is any doubt, do not operate the tool.
18. Replacement parts and accessories. When servicing, use only identical
replacement parts. Use of any other parts will void the warranty. Only use ac-

Page 4SKU 93211 For technical questions, please call 1-800-444-3353.
cessories intended for use with this tool. Approved accessories are available
from Harbor Freight Tools.
19. Use proper size and type extension cord. If an extension cord is required,
it must be of the proper size and type to supply the correct current to the tool
without heating up. Otherwise, the extension cord could melt and catch re, or
cause electrical damage to the tool. This tool requires use of an extension cord
of 0 to 10 amps capability (up to 50 feet), with wire size rated at 18 AWG. Longer
extension cords require larger size wire. If you are using the tool outdoors, use
an extension cord rated for outdoor use (signied by “WA” on the jacket).
20. Maintenance. For your safety, service and maintenance should be performed
regularly by a qualied technician.
21. Warning: People with pacemakers should consult their physician(s) before
using this product. Electromagnetic elds in close proximity to a heart pace-
maker could cause interference to or failure of the pacemaker.
22. Take caution as some woods contain preservatives such as copper chro-
mium arsenate (CCA) which can be toxic. When cutting these materials extra
care should be taken to avoid inhalation and minimize skin contact.
23. WARNING: Some dust created by power sanding, sawing, grinding, drilling,
and other construction activities, contains chemicals known [to the State of
California] to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
*Lead from lead-based paints
*Crystalline silica from bricks and cement or other masonry products
*Arsenic and chromium from chemically treated lumber
Your risk from these exposures varies, depending on how often you do this type
of work. To reduce your exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such as those dust masks that
are specially designed to lter out microscopic particles. (California Health &
Safety Code § 25249.5, et seq.)
Note: Performance of this tool (if powered by line voltage) may vary depending on
variations in local line voltage. Extension cord usage may also affect tool perfor-
mance.
Warning: The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions and situations that may occur.
It must be understood by the operator that common sense and caution are
factors which cannot be built into this product, but must be supplied by the
operator.

Page 5SKU 93211 For technical questions, please call 1-800-444-3353.
Important
BEFORE rst use, the Guard (4) and Eye Guard (5) must be properly installed.
1. Remove the Screw (6) at the end of the Guard (4). Align the hole in the center
of the Eye Guard (5) with the hole in the Guard (4).
2. The hole in the Eye Guard (5) is countersunk to accommodate the Screw. Make
sure to install it the right way. Secure using the Screw (6), while being careful
not to overtighten.
3. Swing the Guard Bracket (1) up and remove the top Screw (3). Slide the
Guard (4) over the Bracket, aligning the holes in the Guard with the hole in the
Bracket. Make sure that the Eye Guard is on the top side of the guard and that
the rounded underside of the Guard rests over the blade.
4. Install the Screw (3) to secure the Guard in place.
Changing/Replacing/Installing the Blades
1. Be sure the Table Saw is unplugged before you begin installing or changing the
accessories.
2. You will need two adjustable Wrenches (not included) to install, change or
replace the Blades. Use one wrench to hold the Blade Spindle Lock Nut (14)
in place and the other wrench to turn the Mounting Nut (10). See Assembly
Diagram on Page 7.
3. Remove the Mounting Nut and the Right Blade Bushing (11). Slide the Blade
(12a,b) over the arbor, in line with the Left Blade Bushing (13). Replace the
Right Blade Bushing and the Mounting Nut. Tighten with the wrench.
Unpacking
When unpacking, check to make sure that the product is intact and undamaged. If
any parts are missing or broken, please call Harbor Freight Tools at the number on
the cover of this manual.
REV 06c

Page 6SKU 93211 For technical questions, please call 1-800-444-3353.
Operation
1. Place your Table Saw on a at, level surface capable of supporting weight of
Table Saw and material being cut before use. Always wear ANSI-approved
safety goggles when operating this tool and ensure that all guards are in place
and in proper working order.
2. Mark your work pieces with a pencil or other writing instrument before you be-
gin cutting. Loosen the Knob (7) on the Straight Edge Guide (8) and turn the
Guide to the appropriate angle for your specic cutting requirements. Tighten
the Knob to hold the Guide in place.
3. Plug in the Power Cord (24).
4. Lift the Eye Guard (5) and slide the Straight Edge Guide out far enough to allow
you to lay your work piece at on the Table (32). Lower the Eye Guard onto
your work piece. Never remove the Guard (4) or attempt to operate this
tool without the Eye Guard (5) in place.
5. Flip the Power Switch (18) to the On position.
6. Using the Straight Edge Guide to hold your work piece steady, gently feed your
work piece toward the Blade. Keep your ngers and all other body parts
away from the Blade at all times. If your work piece is particularly small, you
may want to use another small piece of wood or other material to push your
work piece toward the Blade. Do not push forcefully against the Blade, or use
materials that are particularly difcult to cut. If the Blade slows down as you
are feeding your work piece toward it, you are pushing too forcefully, or the
material is too hard for this tool to cut.
REV 06c

Page 7SKU 93211 For technical questions, please call 1-800-444-3353.
Parts List
Part Description Qty. Part Description Qty.
1 Guard Bracket 1 17 Motor Base 1
2 Washer 4 18 Power Switch 1
3 Screw 2 19 Screw 1
4 Guard 1 20 Cover 1
5 Eye Guard 1 21 Screw 4
6 Screw 1 23 Foot 4
7 Knob 1 24 Power Cord 1
8 Straightedge Guide 1 25 Screw 2
9 Straightedge Shaft 1 26 Washer 2
10 Mounting Nut 1 27 Cord Strain Relief 1
11 Rt. Blade Bushing 1 28 Vibration Absorption Pad 4
12a Manganese Steel Blade, 40 T 129 Motor 1
12b Diamond-Coated Blade 1 30 Screw 1
13 Lt. Blade Bushing 1 31 Wing Nut 2
14 Blade Spindle Lock Nut 1 32 Table 1
15 Depth Adjustment Handle 134 Switch Plate 1
16 Washer 1 35 Screw 2
REV 06c; 09e
LIMITED 90 DAY WARRANTY
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and
durability standards, and warrants to the original purchaser that this product is free from defects in materi-
als and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to
damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside
our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance. We
shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special
or consequential damages arising from the use of our product. Some states do not allow the exclusion
or limitation of incidental or consequential damages, so the above limitation of exclusion may not apply
to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transpor-
tation charges prepaid. Proof of purchase date and an explanation of the complaint must accompany
the merchandise. If our inspection veries the defect, we will either repair or replace the product at our
election or we may elect to refund the purchase price if we cannot readily and quickly provide you with
a replacement. We will return repaired products at our expense, but if we determine there is no defect,
or that the defect resulted from causes not within the scope of our warranty, then you must bear the cost
of returning the product.
This warranty gives you specic legal rights and you may also have other rights which vary
from state to state.
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • [phone]

Page 8SKU 93211 For technical questions, please call 1-800-444-3353.
Assembly Drawing
NOTE: Some parts are listed and
shown for illustration purposes
only and are not available
individually as replacement parts.
REV 06c
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS
MANUALAS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR
SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALI-
FIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD
BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS AND NOT BY THE BUYER.
THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO
THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS
OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
