Chip PC Xtreme PC NG6450 User manual


Highlights
Legacy Supported Thin Client - With multi-
session-support and modular plug-in software
Fast – powerful RISC Processor
Video and Audio Support - Separate 8
MB
dedicated video memory and audio support
Resolutions & Widescreen Support -
Resolutions supported up to 1600x1200px @ 64K
(16 bit) colors, widescreen 16:9 support
Manageable - Chip PC’s Xcalibur Global
management software utilizes
Active Directory
(AD) tools and policies across the
AD tree
structure and is scalable to manage hu
ndreds of
thousands of Users and devices via a standard
Active Directory interface
Flexible - Can run a range of applications from
local printing, to various ICA/RDP/VDI and
Terminal Emulation applications
Customizable - Fully customizable de
sktop
interface and
modular operating system and
plugins to fit user needs
Plug-and–Play Connectivity - Fast
, easy
installation and deployment
Data Integrity –
Centralized data storage and
backup insures integrity and security
100% Secured - Against viruses, worms, and
Trojans, requires no security patches needed
Branding - Reflect corporate themes, color and
logo, in software screens and hardware printing
Compact - Weights as little as 180gm (6.35 oz)
and is easily mounted to back of monitor or
underside of desk; eas
y to handle, ship, store, and
install.
Power Saver - 3.5W in full working mode; USB
port powering option via Display (optional, see
Accessories)
NG-6450
The NG 6450 is the highest performance
device of
the Xtreme PC NG series, combining strong
performance with highest security and lowest
power consumption.
Performance is achieved by the uniquely designed
state of the art hardware built especially for thin
client appliances.
It is the perfect workstation for users that require
high-end functionality.
The Xtreme PC Thin Client Family
The Xtreme PC is the smartest, most compact,
family of thin client products on the market today.
These server-centric computing oriented units
function seamlessly with various OS platforms:
Windows (Terminal Server Edition), Citrix, Legacy
and VMware VDI.
The Xtreme PCs, with their small desktop footprint
and low power consumption, coupled with
unequalled management software, truly form the
thin client family of choice.


NG-6450 Hardware Specification Table
CPU •RMI - Alchemy Au 1550, 500 MHz RISC (equivalent to 1.2 GHz x86 TC Processors)
Memory •128 MB DDR
Mass Storage •64 MB Disk-On-Chip with TFS
•Advanced Error Correction and Wear-levelling
Video Memory •128-bit 3D graphics acceleration engine with separate 8 MB display memory SDRAM
Display Support
•Up to 1600X1200 @ 64K (16 bit) colors
Enhanced Display
Support
•Widescreen 16:9 support
Audio Support •Audio Output - 3.5 mm (1/8 inch) Audio-Out Jack; full 16-bit Stereo
•Audio Input - 3.5 mm (1/8 inch) Audio-In Jack
Input/Output •VGA –type video (DB-15)
•3 USB 2.0-compatible ports
•1 Serial port
•1 Parallel port
•PS/2 ports (optional, see Accessories)
•Serial ports (optional, see Accessories)
Status Lights •Power ON - Self-Test passed (Green)
•Power STBY - Self-Test failed (Red)
•LAN Link - Activity (Green/Amber)
Network
•10/100 Fast Ethernet, twisted pair (RJ-45)
•TCP/IP with DNS and DHCP
•Point-to-Point Protocol (PPP)
•SNMP Support - allows remote configuration of device settings, reporting of device configuration and
attached devices
•XG-705A Wireless LAN USB 2.0 Adapter, IEEE 802.11 b/g (optional, see Accessories)
Wireless Support •Support for Wireless USB NIC
Smart Card Support •External PC/SC Smart Card Reader (optional, see Accessories)
Power •Device input: 5V DC 2.4A max.
•Work Mode – 3.5W , Sleep Mode - 0.35W
•Wall-mount power supply input: Universal 90 – 240V AC, 50-60 Hz (included)
•USB port powering option via Display (optional, see Accessories)
Physical Characteristics •Dimensions: 80(W )x158(D)x34(H) mm / 3.15(W )x6.22(D)x1.34(H) inch
•Device weight: 180 gr. (6 oz.)
•Shipping Weight: Per single pack - 0.65 Kg. (1.43 lbs.); Per ten pack - 5.85 Kg. (12.9 lbs.)
Mounting •Special base attachment
•VESA (optional, see Accessories)
•Anti Theft Lock (optional, see Accessories)
Enclosure Color Midnight Gray and Silver
Environmental
•Temperature range: Operating - 0ºC to 40ºC (32ºF to 104ºF); Storage - 0ºC to 60ºC (32ºF to 140ºF)
•Humidity: Operating - 20 to 80% non condensing; Storage – 10 to 90% non condensing
•Altitude: 0 to 20,000 ft
Regulatory Compliance •Safety: UL/cUL60950,EN60 950
•EMI/EMC: FCC Class B, CE Mark, EN55022B, VCCI
•EPA ENERGY STAR
Accessories •Visit our site at www.chippc.com for an updated list
Warranty •1 year automatic Warranty, additional 2 years pending on product registration


Monitor, keyboard and mouse - to be purchased separately
Xcalibur Global & Plugin licenses - to be purchased separately
Above features are supported in latest firmware image version released
Actual display support is dependent on display hardware and cable quality; some of the resolutions and display modes described
above may not be supported by certain displays or cables
Specifications are subjected to change without prior notice
Firmware Specifications Table
Chip PC’s unique Thin Client Operating System architecture provides a fast, secure, customizable and manageable Operating System
fully able to connect to any type of Terminal/Citrix/Legacy/Virtualization server
Operating system •Enhanced Microsoft Windows CE
Integrated
Applications/Clients
•ICA
•RDP
•Internet Explorer
•VDI
•Media Player (model pending)
•VPN Client
•VNC
These Clients are modular and can be added/removed as plugins to save memory and have only needed
applications available on the device
Server OS Compatibility
•Citrix WinFrame, MetaFrame, and Presentation Server 4.5
•Microsoft Windows Server 2000/2003
•Microsoft Windows NT 4.0 – Terminal Server Edition
•VMware Virtual Desktop Interface using RDP
Setup and Configuration
•Configuration is policy-based (stored locally and on server)
•Multi-session support
•Fully customizable PC-like desktop interface
Management •Full policy-based management with Active Directory integration.
•100% remote manageability; upgrades, device configuration and Users & Groups-based management
Security – 100%
immunity to malicious
code
•Full immunity to viruses, Trojans and worms. No malicious code can run on the device
Security - General
•Locked-down desktop that can be changed only by administrator
•Security policy applied from central server
•User cannot change settings
Security - USB Blocking •Full or partial USB blocking as required. The USB ports can be enabled, disabled for all or specified
USB devices such as flash drive, CD-ROM, floppy, and more
User Authentication
Mode
•Provide User-based security and configuration settings. Each user will get unique thin Client
configuration and permissions according to his Group membership in the Active Directory.
Smart Card Access
•A User cannot use the client unless a Smart Card is inserted and the proper PIN code is provided.
Removal of the card will lock the device.
•Devices are available with integrated Smart Card reader or supporting external USB Smart Card
reader
Certificates •Import SSL certificates to the device for connecting to Citrix Secure gateway or websites requiring SSL
Printers; Local and
Network •Full support of both local and network printers: LPD,LPR, SMB, LPT, USB, COM
Wireless Support •Support for wireless USB NIC
Enhanced Display
Support •Widescreen 16:9 support




Since its inception, Chip PC has been a world
leader in server-centric-computing. A public
company with branches in Europe and the U.S.,
Chip PC develops and manufactures, top notch,
thin client technology and management systems.
Chip PC’s team of dedicated researchers and
developers have combined their years of
experience to yield novel ideas and deliver an
outstandingly innovative family of thin client
products.
With the award winning Xcalibur Global
management system and innovative thin client
units, Chip PC maintains a leading market position
with its end-to-end solution.


Chip PC is aimed at solving the thorny problem
of combining intelligent thin client networking
with sophisticated management and control.
Chip PC’s unique solution constructs a ground-
up thin client network from the revolutionary
Jack PC that fits into a standard wall jack,
through the NG Series’, state-of-the art,
powerful, desktop units.
These server-centric, revolutionarily designed,
units are comprehensively managed by Chip
PC’s Xcalibur Global. The Xcalibur Global
Management System simulates an Active
Directory environment with intelligent usage of
its management principles of policies and tools
and offers flexible management that applies
down to the specific needs of every particular
client unit or user.
