Chrysler Uconnect Touch User manual

11CTP-226-AA First Edition
Chrysler Group LLC
86(5ҋ60$18$/
8FRQQHFW7RXFK70
Printed in U.S.A.

TABLE OF CONTENTS
SECTION PAGE
1
INTRODUCTION ............................................................3
2
Uconnect Touch™ 4.3 SYSTEM ..................................................11
3
Uconnect Touch™ 8.4 SYSTEM ..................................................35
4
SAFETY GUIDELINES .......................................................113
1
2
3
4

INTRODUCTION
CONTENTS
䡵Introduction ...........................4
▫Uconnect Touch™ System (4.3) ............4
▫Uconnect Touch™ System (8.4 & 8.4 NAV) ....7
1

INTRODUCTION
Uconnect Touch™ System (4.3)
1 — ON/OFF & Volume Control 5 — Radio hard-key 8 — Screen Off hard-key
2 — Manual Climate Controls 6 — Settings hard-key 9 — Enter/Browse & Tune/Scroll knob
3 — Climate Controls hard-key 7 — More hard-key 10 — CD slot
4 — Player hard-key
4 INTRODUCTION

(1) ON/OFF & VOLUME
Press the ON/OFF button to turn the system ON or OFF.
Rotate the rotary knob to adjust the Volume.
NOTE: If the ignition is switched OFF with the radio in
standby mode, the radio memorizes the standby mode
when the ignition is turned ON again. Press the ON/OFF
VOLUME Control to turn the radio ON. It is possible to
eject the CD and to display the time if the system is off.
(2)(3) CLIMATE CONTROLS
Manual Climate Controls and Climate Control Hard-key.
Refer to Climate Controls in your vehicles Owner’s
Manual on the DVD for further details.
(4) PLAYER
Press the PLAYER hard-key to access media sources such
as: Disc, USB Device and AUX as long as the requested
media is present.
(5) RADIO
Press the RADIO hard-key to enter the Radio Mode. The
different tuner modes; AM, FM and SAT can be selected
by touching the corresponding soft-keys in the Radio
Mode.
(6) SETTINGS
Press the SETTINGS hard-key to access the Settings list.
Clock, Display, Audio, Bluetooth and Sirius Settings are
described in this manual. See your vehicles Owner’s
Manual on the DVD for more details.
(7) MORE
Press the MORE hard-key to access additional options.
Options available such as: Uconnect™ Phone and Com-
pass can be accessed by touching the corresponding
soft-key in the More Menu.
1
INTRODUCTION 5

(8) SCREEN OFF
Press the SCREEN OFF hard-key to turn the touch-screen
OFF. To turn the screen back ON, just touch the screen.
(9) ENTER/BROWSE & TUNE/SCROLL
Press the ENTER/BROWSE button to accept a high-
lighted selection on the screen. Rotate the TUNE/
SCROLL rotary knob to scroll through a list or tune a
radio station.
(10) CD SLOT
When inserting a disc, make sure the label is facing up.
Press the Eject button to eject the disc.
6 INTRODUCTION

Uconnect Touch™ System (8.4 & 8.4 Nav)
1 — ON/OFF & Volume Control 5 — Controls soft-key 9— More soft-key
2 — Manual Climate Control 6 — Climate soft-key 10— Enter/Browse & Tune/Scroll knob
3 — Radio soft-key 7 — Nav soft-key 11 — SD Card slot
4 — Player soft-key 8 — Phone soft-key 12 — CD/DVD slot
1
INTRODUCTION 7

(1) ON/OFF VOLUME
Press the ON/OFF button to turn the unit ON or OFF.
Rotate the rotary knob to adjust the Volume.
NOTE: If the ignition is switched OFF with the radio in
standby mode, the radio memorizes the standby mode
when the ignition is turned ON again. Press the ON/OFF
VOLUME Control to turn the radio ON. It is possible to
eject the CD and to display the time if the system is off.
The navigation software is always working when the
ignition is switched ON, even if the radio is in standby
mode. It is possible to eject the CD and to display the
time if the unit is switched off.
(2) CLIMATE CONTROLS (Manual Controls)
Refer to Climate Controls in your vehicles Owner’s
Manual on the DVD for further details.
(3) RADIO
Press the Radio soft-key to enter the Radio Mode. The
different tuner modes; AM, FM and SAT can be selected
by touching the corresponding soft-keys in the Radio
Mode.
(4) PLAYER
Press the Player soft-key to access media sources such as:
Disc, USB Device and AUX as long as the requested
media is present.
(5) CONTROLS
Press the Controls soft-key to access the Settings list.
Controls such as; Heated Seats, Heated Steering Wheel,
Ventilated Seats, etc. can be selected or turned ON/OFF
by touching the corresponding soft-key.
8 INTRODUCTION

(6) CLIMATE (On-Screen Controls)
Refer to Climate Controls in your vehicles Owner’s
Manual on the DVD for further details.
(7) NAV
Press the Nav soft-key to access the Navigation feature.
Refer to the Navigation section in this manual for further
details.
(8) PHONE
Press the Phone soft-key to access the Uconnect™ Phone
feature. Refer to the Uconnect™ Phone section in the
Owner’s Manual on the DVD for further details.
(9) MORE
Press the More soft-key to access additional options.
Options available such as: Settings and SIRIUS Travel
Link can be accessed by touching the corresponding
soft-key in the More Menu.
(10) ENTER/BROWSE & TUNE/SCROLL
Press the ENTER/BROWSE button to accept a high-
lighted selection on the screen. Rotate the TUNE/
SCROLL rotary knob to scroll through a list or tune a
radio station.
(11) SD CARD SLOT
Insert an SD Card containing audio media in order to
play them through the vehicles sound system.
(12) CD/DVD SLOT
When inserting a disc, make sure the label is facing up.
Press the Eject button to eject the disc.
1
INTRODUCTION 9

Uconnect Touch™ 4.3 SYSTEM
CONTENTS
䡵Operating Instructions – Radio Mode ........ 13
▫Overview ........................... 13
▫Common Radio Functions ............... 13
▫Seek And Direct Tune Functions ........... 14
▫Setting Presets ....................... 16
▫Audio ............................. 18
▫Sirius Satellite Radio Mode .............. 19
䡵Operating Instructions – CD Mode .......... 22
▫Overview ........................... 22
▫Seek Up/Down ...................... 24
▫Browse ............................ 24
▫Source ............................. 24
▫Info ............................... 24
▫Shuffle ............................. 24
▫Audio ............................. 25
䡵Operating Instructions – USB/iPod Mode ..... 25
▫Overview ........................... 25
▫Seek Up/Down ...................... 25
2

▫Browse ............................ 26
▫Source ............................. 26
▫Info ............................... 26
▫Shuffle ............................. 26
▫Audio ............................. 26
䡵Operating Instructions – AUX Mode ......... 26
▫Overview ........................... 26
▫Source ............................. 27
▫Audio ............................. 27
䡵Operating Instructions – Bluetooth Mode ...... 27
▫Overview ........................... 27
▫Seek Up/Down ...................... 28
▫Source ............................. 28
▫Info ............................... 28
▫Repeat ............................. 28
▫Audio ............................. 28
䡵Operating Instructions – More & Settings ..... 29
▫More Main Menu ..................... 29
▫Clock Setting ........................ 30
▫Settings Main Menu ................... 31
▫Display ............................ 32
12 Uconnect Touch™ 4.3 SYSTEM

OPERATING INSTRUCTIONS – RADIO MODE
Overview
The radio is equipped with the following modes:
• FM
• AM
• SAT SIRIUS Satellite Radio (if equipped)
Touch the Radio hard-key, bottom left corner, to enter the
Radio Mode. The different tuner modes; AM, FM, and
SAT, can then, be selected by touching the corresponding
soft-keys on the screen.
Common Radio Functions
The following operations offer the same functionality
across all Radio Modes, and further instructions are
provided where differences exit.
ON/OFF & Volume Control
Push the ON/OFF Volume control knob to turn
on the radio. Push the ON/OFF Volume con-
trol knob a second time to turn off the radio.
The electronic volume control turns continuously (360
degrees) in either direction, without stopping. Turning
the Volume control knob clockwise increases the volume,
and anti-clockwise decreases it.
2
Uconnect Touch™ 4.3 SYSTEM 13

When the audio system is turned on, the sound will be
set at the same volume level as last played.
Enter/Browse & Tune/Scroll Control
Turn the rotary TUNE/SCROLL control knob
clockwise to increase or counterclockwise to
decrease the radio station frequency. Push the
ENTER/BROWSE button to choose a selection.
Info
Touch the info soft-key to display channel number/
frequency, song title, genre and artist. This feature is only
available in FM and SAT modes.
Exit
The Exit soft-key, provides a means to close the Direct
Tune Screen.
Go
Touch the green GO soft-key to allow you to commit an
entry, at which time, the radio will tune to the entered
Channel, and close the Direct Tune Screen. The GO
soft-key is only for SIRIUS Satellite radio mode.
Seek and Direct Tune Functions
The Seek Up and Down functions are activated by
pressing the double arrow soft-keys to the right and left
of the radio station display, or by pressing the left
Steering Wheel Audio Control (if equipped) up or down.
Seek Up
Touching the Seek Up soft-key for less than 2 seconds,
tunes the radio to the next listenable station or channel.
During a Seek Up function, if the radio reaches the
starting station after passing through the entire band two
times, the radio will stop at the station where it began.
14 Uconnect Touch™ 4.3 SYSTEM

Fast Seek Up
Touching and holding the Seek Up soft-key for more than
2 seconds, advances the radio through the available
stations or channels at a faster rate, the radio stops at the
next available station or channel when the soft-key is
released.
Seek Down
Touching the Seek Down soft-key for less than 2 seconds,
tunes the radio to the next listenable station or channel.
During a Seek Down function, if the radio reaches the
starting station after passing through the entire band two
times, the radio will stop at the station where it began.
Fast Seek Down
Touching and holding the Seek Down soft-key for more
than 2 seconds, advances the radio through the available
stations or channel at a faster rate, the radio stops at the
next available station or channel when the soft-key is
released.
Direct Tune
The Direct Tune soft-key screen is available in AM, FM,
and SAT radio modes and can be used to direct tune the
radio to a desired station or channel. Press the Tune
soft-key located at the bottom of the radio screen.
2
Uconnect Touch™ 4.3 SYSTEM 15

Press the available number soft-key to begin selecting a
desired station. Once a number has been entered, any
numbers that are no longer possible (stations that cannot
be reached) will become deactivated / grayed out
If you accidently entered the wrong station number,
touch the CLR soft-key to clear the radio station numbers
and reenter the correct station number.
Once the last digit of a station has been entered, the
DIRECT TUNE screen will close and the system will
automatically tune to that station.
The selected Station or Channel number is displayed in
the Direct Tune text box.
Setting Presets
The Presets are available for all Radio Modes, and are
activated by touching any of the four Preset soft keys,
located at the top of the screen.
16 Uconnect Touch™ 4.3 SYSTEM

When you are receiving a station that you wish to
commit into memory, press and hold the desired num-
bered soft-key for more that 2 seconds or until you hear
a confirmation beep.
The Radio stores up to 12 presets in each of the Radio
modes. A set of 4 presets are visible at the top of the radio
screen.
All Presets Button
Touching the ⬙all⬙soft-key on the radio home screen will
display all of the preset stations for that mode.
Return to Main Radio Screen
You can return to the Main Radio Screen, by either
touching Exit soft-key or pressing the Radio hard-key.
2
Uconnect Touch™ 4.3 SYSTEM 17

Audio
1. Press the SETTINGS hard-key on the right side of the
unit.
2. Then scroll down and press the Audio soft-key to get
to the Audio menu.
3. The Audio Menu shows the following options for you
to customize your audio settings.
• Equalizer
Touch the Equalizer soft-key to adjust the Bass, Mid
and Treble. Use the + or - soft-key to adjust the
equalizer to your desired settings. Press the back
arrow soft-key when done.
• Balance/Fade
Touch the Balance/Fade soft-key to adjust the
sound from the speakers. Use the arrow soft-key to
adjust the sound level from the front and rear or
right and left side speakers. Touch the Center ⬙C⬙
soft-key to reset the balance and fade to the factory
setting. Press the back arrow soft-key when done.
• Speed Adjusted Volume
Touch the Speed Adjusted Volume soft-key to select
between OFF, 1, 2 or 3. This will decrease the radio
volume relative to a decrease in vehicle speed. Press
the back arrow soft-key when done.
4. Touch the Exit soft-key to exit from the Audio Menu.
18 Uconnect Touch™ 4.3 SYSTEM

SIRIUS Satellite Radio Mode
Satellite radio uses direct satellite-to-receiver broadcast-
ing technology to provide clear digital sound, coast to
coast. The subscription service provider is SIRIUS Satel-
lite Radio. This service offers over 130 channels of music,
sports, news, entertainment, and programming for chil-
dren, directly from its satellites and broadcasting studios.
A one-year SIRIUS Satellite Radio subscription is in-
cluded.
SIRIUS XM and all related marks and logos are trade-
marks of SIRIUS XM Radio Inc. and its subsidiaries.
SIRIUS Radio requires a subscription, sold separately
after trial subscription included with vehicle purchase.
Prices and programming are provided by SIRIUS and are
subject to change. Subscriptions governed by Terms &
Conditions available at sirius.com/serviceterms. SIRIUS
Radio U.S. service only available to those at least 18 years
of age in the 48 contiguous United States, D.C., and PR.
Service available in Canada; see www.siriuscanada.ca.
This functionality is only available for radios equipped
with a Satellite receiver. In order to receive satellite radio,
the vehicle needs to be outside with a clear view to the
sky.
If the screen shows Acquiring Signal, you might have to
change the vehicle’s position in order to receive a signal.
In most cases, the satellite radio does not receive a signal
in underground parking garages or tunnels.
No Subscription
Radios equipped with a Satellite receiver, require a
subscription to the Sirius Service. When the Radio does
not have the necessary subscription, the Radio is able to
receive the Traffic/Weather channel only.
2
Uconnect Touch™ 4.3 SYSTEM 19
