Chrysler TOWN & COUNTRY 2009 User manual

301C
Standard Stow ’n Go® or optional Swivel ’n Go,™(1) the highest U.S. Government front and side crash test ratings,(2) optional Flexible
Fuel engine(3) plus standard safety features help Chrysler Town & Country add value, comfort and convenience to your eet.

ICTOY’s • Road & Travel Magazine 2008 Minivan of the Year
Named least expensive vehicle to insure by Insure.com for 2008•
Earned a place in • The Car Book’s 2008 Best Bet Buyer’s Guide
Engine and transmission choices:• 3.3L V6 FFV four-speed
automatic,
(3) 3.8L OHV V6 with six-speed automatic and 4.0L V6
SOHC with six-speed automatic
143.8 cu ft maximum available cargo volume•
Stow ’n Go seating and storage system — Standard•
Swivel ’n Go• (1) with table and storage system — Optional
Sliding Door Alert System —Standard•
Power sliding doors and power liftgate — Available•
Front and rear 12-volt DC power accessory outlets — Standard•
Power adjustable pedals — Available•
Remote Start System — Available•
Power folding 3rd-row seat with one-touch operation — Available•
2nd- and 3rd-row retractable window shades — Available•
Power 2nd-row windows/rear quarter vents — Standard•
YES Essentials• ® Seat Fabric(4) on cloth seats — Standard
Automatic Oil Change Monitoring System — Standard•

Received a U.S. Government • ★★★★★ frontal- and side-impact
crash test rating(2)
Advanced multistage driver and front-passenger air bags• (5) with low
risk deployment — Standard
Supplemental side-curtain air bags• (5) for outboard seating
positions in all three rows — Standard
Electronic Stability Program (ESP)• (6) — Standard
Four-wheel antilock disc brakes — Standard•
Remote Keyless/Illuminated Entry — Standard•
Sentry Key• ® antitheft engine immobilizer — Standard
Tire Pressure Monitoring Warning Lamp — Standard•
Security alarm — Available•
ParkView• ® Rear Back-Up Camera(7) — Available
ParkSense• ® Rear Park Assist System(7) — Available

Smoker’s Group — Available•
Heavy-duty engine cooling — Available•
Manual driver-side lumbar adjust — Available•
Eight-way power driver seat — Available•
Daytime Running Lamps — Available•
UConnect• ® Hands-Free Communication System(8) — Available
2009 chrysler Town & counTry • 2009 chrysler Town & counTry • 2009 chrysler Town & counTry • 2009 chrysler Town & counTry • 2009 chrysler Town

(1) Seat must be locked in forward or rearward mode when vehicle is in motion. Child restraints must only be used
when seats are in forward-facing mode.
(2) Star ratings are a part of the U.S. Department of Transportation's SaferCar.gov program (safercar.gov). 2008 MY.
(3) 3.3L FFV V6 engine not available in CA, MA, ME, NY, and VT. 3.3L gasoline engine will be substituted.
(4) Not compatible with aftermarket fabric-protecting coatings.
(5) Always sit properly in the seat with the seat belt fastened.
(6) Always drive carefully, consistent with conditions. Always wear your seat belt and obey trafc laws.
(7) Always check entire surroundings before backing up.
(8) Requires Bluetooth® enabled mobile phone.


    
3.3L OHV 12V V6 FFV(1)
175 hp @ 5,000 rpm
205 lb-ft of torque @ 4,000 rpm
Four-Speed Automatic S
3.8L OHV 12V V6
197 hp @ 5,200 rpm
230 lb-ft of torque @ 4,000 rpm
Six-Speed Automatic S
4.0L SOHC 24V V6
251 hp @ 6,000 rpm
259 lb-ft of torque @ 4,200 rpm
Six-Speed Automatic S
S = Standard.
(1) 3.3L FFV V6 engine not available in CA, MA, ME, NY and VT. 3.3L gasoline engine will be substituted.

 
Wheelbase 121.2
Overall Length 202.5
Overall Width 76.9
Overall Height 68.9
Track — Front 65.5
— Rear 64.8
Turning Diameter (ft) curb-to-curb 38.0

Head Room — Front 39.8
— Intermediate 39.2
— Rear 37.9
Leg Room — Front 40.6
— Intermediate 36.4
— Rear 37.6
Shoulder Room — Front 63.0
— Intermediate 64.7
— Rear 62.0
Hip Room — Front 57.6
— Intermediate 64.8
— Rear 48.7
Passenger Interior Volume (cu ft) 163.5
Curb Weight (est.) (lb) — LX 4,335
— Touring 4,507
— Limited 4,621
Cargo Capacity(2) (est.) (cu ft) — Behind 3rd-row (cu ft) 32.3
— Behind 2nd-row (cu ft) 82.6
— Maximum (cu ft) 143.8
Fuel Tank Capacity (gal) 20.0
EPA Fuel Economy est(3) (city/highway)
3.3L = 17/24
3.8L = 16/23
4.0L = 16/23
(1) All dimensions are in inches unless otherwise noted.
(2) Does not include seat tub capacity.
(3) Based on 2008 MY.

Bright Silver Metallic
Brilliant Black Crystal Pearl
Inferno Red Crystal Pearl
Deep Crimson Crystal
Modern Blue Pearl
Clearwater Blue Pearl
Stone White
Light Sandstone Metallic
Melbourne Green Pearl

(1) — Advanced multistage driver and front-passenger and supplemental side-curtain
— 160-amp
— 600-amp, maintenance-free

— Four-wheel antilock with vented front and solid rear discs
— Includes mounts for two compatible aftermarket child
seats in the intermediate row
— Overhead, includes interior observation mirror, sunglass bin, switchable on/off
lamps and switches for power doors and liftgate if so equipped
— Rear window
(2) — Includes Brake Assist
— 20-gallon
— Dual located in instrument panel
— Halogen quad and headlamp-off time delay
— 12-volt DC power outlets located in instrument panel and rear
quarter trim and 12-volt auxiliary power outlet in front instrument panel
— Front, bucket
— Headlamp/taillamp ash when sliding doors are in operation
— Open bin, lower instrument panel, driver door sill storage bin and storage/trash bin
— Normal-duty
— Prevents double starts, helps to preserve battery, ignition and battery life
— Compact spare
— Front, variable intermittent mode and rear, wiper/washer with intermittent mode
(1) Always sit properly in the seat with the seat belt fastened.
(2) Always drive carefully, consistent with conditions. Always wear your seat belt and obey trafc laws.
Chrysler, ParkSense, ParkView, Sentry Key, Stow ’n Go and UConnect are registered trademarks and Swivel ’n Go
is a trademark of Chrysler LLC. Chrysler LLC reserves the right to make changes at any time, without notice or
obligation. All product specications and photographs are based on authorized information as of 4/1/08. Fleet
Operations is a division of Chrysler Motors LLC. The Bluetooth word mark and logo are registered trademarks and
are owned by Bluetooth SIG, Inc. YES Essentials is a registered trademark of Milliken & Company.


BFLT09-013

CHRYSLER TOWN & COUNTRY
TRIM COMBINATIONS
Exterior Colors
Medium Slate Gray/
Light Shale
Medium Pebble
Beige/Cream
Bright Silver Metallic •
Brilliant Black Crystal Pearl ••
Clearwater Blue Pearl ••
Deep Crimson Crystal(1) ••
Inferno Red Crystal Pearl ••
Light Sandstone Metallic ••
Melbourne Green Pearl(2) ••
Modern Blue Pearl ••
Stone White ••
(1) N/A on LX.
(2) New for 2009.
POWERTRAINS
Engines Transmissions LX Touring Limited
3.3L OHV 12V V6(1)
175 hp @ 5,000 rpm
205 lb-ft of torque @ 4,000 rpm
Four-Speed Automatic S
3.8L OHV 12V V6
197 hp @ 5,000 rpm
230 lb-ft of torque @ 4,000 rpm
Six-Speed Automatic S
4.0L SOHC 24V V6
251 hp @ 6,000 rpm
259 lb-ft of torque @ 4,200 rpm
Six-Speed Automatic S
S = Standard.
(1) Flex fuel capable. 3.3L Flex Fuel V6 engine not available in CA, NY, ME, MA or VT. 3.3L gas V6 engine will be substituted.
SELECTED FEATURES, OPTIONS AND PACKAGES
Engines Transmissions LX Touring Limited
3.3L V6 OHV FFV(1) Four-Speed Automatic 24F
3.8L V6 OHV Six-Speed Automatic 25K 25L
4.0L V6 SOHC Six-Speed Automatic 28X
Features
Adjustable Pedals — Power adjustable (Includes memory feature on Limited) • • •
Air Bags(2)
— Advanced multistage driver and front-passenger includes low risk deployment • • • •
— Supplemental side-curtain for outboard seating positions in all three rows • • • •
Air Conditioning
— Three-Zone Manual Temperature Control • • •
— Three-Zone Automatic Temperature Control (Included with Premium Group) P •
Alternator — 160 amp • • • •
Assist Handles
— A-pillar of front passenger side • • • •
— Second row B pillar ingress/egress assist • • • •
— Headliner above sliding side doors • • • •
Badge
— Town & Country • • • •
— LX •

CHRYSLER TOWN & COUNTRY
SELECTED FEATURES, OPTIONS AND PACKAGES
LX Touring Limited
Badge (cont.)
— Touring ••
— Limited •
Battery — 600-amp, maintenance-free • • • •
Bezel — Instrument panel, Woodgrain and Satin Silver • • • •
Blind Spot Detection (Included with Safety Group or Security Group) P P P
Brakes — Four-wheel antilock with vented front and solid rear discs • • • •
Brake/Park Interlock • • • •
Brow — License Plate, Bright • • • •
Carpeting — Floor and Cargo area • • • •
Child Seat Anchor System — LATCH-ready, includes mounts for two compatible
aftermarket child seats in the intermediate row • • • •
Clock — Analog, located in upper I/P • • • •
Console
— Overhead, includes interior observation mirror, sunglass bin (bin is deleted with
sunroof), switchable on/off lamps and switches for power doors and liftgate if so
equipped (LED 1st row with SXT, Touring and Limited) • • • •
— Single rear overhead console system includes four storage bins, 2nd and 3rd row
swivel LED lamps, LED halo light ring (replaced by dual mini overhead consoles if
sunroof is ordered) •
Daytime Running Park/Turn Lamps (LMN) LLL L
Defroster — Rear window • • • •
Door Handles
— Body colored • • •
— Bright •
Door Trim Panel
— With map pocket and bin on driver door • • •
— Front, luxury, includes armrest, map pocket, bin on driver door, chrome door
handle, woodgrain applique (1st and 2nd row) •
Door Locks — Power • • • •
Doors
— Dual manual-sliding • •
— Dual power-sliding (Included with Power Convenience Group) P • • •
— Power Liftgate (included with Power Convenience Group) P • • •
Electronic Stability Program (ESP)(3) — Includes Brake Assist and all-speed traction control • • • •
Engine Block Heater (NHK) OOO O
Entertainment Group #1 — Includes six speakers, 2nd-row overhead 9" video screen,
wireless headphones and video remote control, ParkView®Rear Back-Up Camera,
(5)
115V auxiliary power outlet, SIRIUS®Satellite Radio and MyGIG®(4) Multimedia
Entertainment System radio (AT1) O
Entertainment Group #2 — Includes 2nd-row overhead 9" video screen, 3rd-row
overhead 9" video screen (3rd-row screen is swiveling when Swivel ’n Go®seating is
ordered), single-disc DVD player, MyGIG®(4) Multimedia Entertainment System, wireless
headphones and video remote control, ParkView Rear Back-Up Camera(5) and hard
drive (AT2) O•
Entertainment Group #3 — Includes 2nd-row overhead 9" video screen, third-row
overhead 9" video screen (3rd-row screen is swiveling when Swivel ’n Go(6) seating is
ordered), single-disc DVD player, wireless headphones, video remote control, SIRIUS
Backseat TV,
TM auto-dimming rearview mirror with microphone (AT3) O
Family Value Group — Includes remote start, premium removable center console and
2nd- and 3rd-row window shades (AYY) O

CHRYSLER TOWN & COUNTRY
SELECTED FEATURES, OPTIONS AND PACKAGES
LX Touring Limited
Fascia
— Body-color •••
— Body-color with bright insert •
— Rear scuff pad • • • •
Flexible Seating Group — Includes Swivel ’n GoTM Seating System(6) with 2nd-row
swiveling bucket seats, 2nd-row removable/stowable table and Swivel ’n Go badge
(deletes Stow ’n Go®seats and badge) (AGV) OOO O
Floor Mats -— Easy clean mats • • • •
Fog Lamps •• •
Fuel Tank — 20-gallon • • • •
Glass — Sunscreen • • • •
Grille — Bright surround with bright horizontal bars • • • •
Glove Box -— Dual located in I/P • • • •
Grocery Bag Hooks — On back of driver’s seat and rear seatback • • • •
Headlamps
— Halogen quad • • •
— Headlamp-off time delay • • • •
— High Intensity Discharge Headlamps •
— Automatic •• •
— SmartBeamTM (Included with Premium Group) P•
Heated Seat Group — Includes heated front and intermediate seats (ASL) O• •
Heavy Duty Engine Cooling — Includes engine oil cooler, heavy duty transmission oil
cooler, heavy duty radiator (included in Trailer Tow Prep Group) (NMC) L L/P L/P L/P
HomeLink®Universal Transceiver(7) — Programmable, three-function with remote
controls for garage door opener, interior/exterior home lighting or security devices • • •
Instrument Cluster — Four-gauge including tachometer • • • •
Leather Interior Group — Includes leather 1st- and 2nd-row seat trim, power heated
driver and front-passenger seats and heated 2nd-row seats •
Liftgate — Power (Included in Power Convenience Group) P • • •
Lighting
— Map lights located in overhead console •
— Swiveling LED’s (map/reading lights) located in overhead console • • •
— Rear dome located mid cabin between 2nd and 3rd row •
— Rear swiveling reading/courtesy lamps • • •
— Door courtesy •• •
— Portable rechargeable trouble light • • •
— Liftgate, single floodlamp • • • •
— LED, located in overhead that illuminates the front center cupholder and console • • •
— Illuminated front door storage •• •
Load Leveling (packaged with Trailer Tow) (SER) L L/P L/P L/P
Mirrors
Exterior
— Foldaway, power-heated black exterior mirrors •
— Foldaway, power-heated includes body-color exterior mirrors • •
— Foldaway, power heated multi-function includes chrome mirrors, supplemental
signals and driver-side auto-dimming exterior mirror (memory feature on Limited)
(included in Security Group) P•

CHRYSLER TOWN & COUNTRY
SELECTED FEATURES, OPTIONS AND PACKAGES
LX Touring Limited
Mirrors
Interior
— Rearview, day/night • • •
— Rearview, automatic-dimming •
— Visor vanity •
— Illuminated visor vanity •• •
— Rearview auto-dimming mirror with integrated microphone for UConnect®(8)
(included with Safety Group or Navigation radio) (RSP) L/P L/P L/P P
Molding
— Bodyside, body-color •
— Bodyside, bright •• •
— Bright belt molding • • • •
Moonroof — Power, includes mini overhead console and dual rear mini overhead
consoles (GWA) OO O
Mopar Exterior Appearance Group — Includes Mopar bright door sills, Mopar premium
floor mats with logo, Mopar splash guard and body-color running boards (not available
in Deep Crimson Crystal or Dark Carbon Pearl exterior colors) (ALB) OOO O
ParkSense®Rear Park Assist System(5) — Assists while parking (packaged with
Security Group) P•
ParkView®Rear Back-up Camera(5) — Included with MyGIG®(4) radios P P • •
Power Accessory
— 12V DC power outlets located in instrument panel and rear quarter trim • • • •
— 12V auxiliary power outlet in front I/P • • • •
— 115V auxiliary power outlet located on front of driver’s side quarter trim panel
(included with Entertainment Group #1) P • • •
Power Convenience Group — Includes driver’s lumbar support, dual power sliding
doors, power liftgate and power driver’s seat (AJP) O
Premium Group — Includes three zone automatic temperature control, rain sensitive
wipers, power folding third row seats, SmartBeamTM headlamps, UConnect hands free
phone, 17-inch tires and aluminum wheels (ANF) O
Radios
— AM/FM CD MP3 radio • •
— MyGIG®(4) Multimedia Entertainment System — Includes AM/FM radio, DVD/CD/
MP3-compatible player and 20GB hard drive, ParkView Rear Back-Up Camera(5),
six speakers (included with Entertainment Group #1 and Entertainment Group #2) P • •
— MyGIG(4) Multimedia Infotainment System — Includes GPS navigation, UConnect,
(8)
SIRIUS®Satellite Radio, SIRIUS Satellite Traffic, ParkView Rear Back-Up Camera(5)
and rearview auto-dimming mirror with microphone for UConnect (RER) (not
available in all states) L O O O
Remote Keyless/Illuminated Entry System — includes two transmitters, Sentry Key®
anti theft engine immobilizer, headlamp off time delay • • • •
Remote Start System ••
Roof Rack — Black (Limited roof rack side rails are brushed chrome with black
end caps) (MWG) O•• •
Roof Rack Crossbars delete (MW9) LLL L
Safety Group — Includes UConnect and Blind spot detection (AJ1) OO
Seats
— Cloth trimmed with YES Essentials®Seat Fabric(9) ••
— Leather trimmed 1st and 2nd row •
— Leather trimmed 1st and 2nd row with suede micro fiber accents •

CHRYSLER TOWN & COUNTRY
SELECTED FEATURES, OPTIONS AND PACKAGES
LX Touring Limited
Seats, Front
— Buckets ••• •
— Driver’s lumbar support, manual (included with Power Convenience Group) (CDL) L/P L/P • •
— Eight-way power driver seat (included with Power Convenience Group) (JPR) L/P L/P •
— Eight-way power driver seat and eight-way front-passenger seat •
— Eight-way power driver seat and eight-way front-passenger seat with driver’s
side memory •
— Heated front and intermediate seats (Included with Heated Seat Group) P • •
Seats, Rear
— Stow ’n Go®Seating and Storage System — Intermediate bucket seats with
fold-in-floor and rear 60/40 split-folding bench seat with fold-in-floor and tailgate
position features • • • •
— 2nd-row swiveling bucket seats (included with Flexible Seating Group) P P P P
— 2nd-row swiveling bucket seats with Integrated booster seats (CY4) OOO O
— Power folding 3rd-row seat; power rear seat has power recline (included with
Premium Group) (JRJ) PO
Security Alarm (included with Security Group) (LSA) L L L/P •
Security Group — Includes Security alarm, UConnect, ParkSense and Blind spot
detection (AJB) O
Shades — 2nd- and 3rd-row retractable window (included with Family Value Group) P • •
Shift Knob — Leather-wrapped ••
SIRIUS®Satellite Radio — Includes one-year subscription (available only in continental
United States) (Included with Entertainment Group #1 and MyGIG®Multimedia
Infotainment System(4)) (RSC) L/P • • •
SIRIUS Satellite Traffic — Included with MyGIG Multimedia Infotainment System P P P P
SIRIUS Backseat TVTM — included with Entertainment Group #3 (must have
Entertainment Group #2) (RSV) OO P
Sliding Door Alert System — Headlamp/taillamp flash when sliding doors are in
operation, signaling other drivers that passengers could be entering/exiting the vehicle • • • •
SmartBeamTM headlamp control system (Packaged with Premium Group) P •
Smokers Group — Includes front and rear ashtrays and cigar lighter (AWS) LLL L
Sound System
— Four speakers •
— Six speakers (included in Entertainment Group #1 and REN)P••
— ∞Infinity Acoustic 9™ 9 amplified speakers with subwoofer includes 506-watt
amplifier •
Speed Control — Electronic with steering wheel mounted controls • • • •
Speedometer — 220 KPH primary (JDG) LLL L
Steering — Power rack-and-pinion • • • •
Steering Column — Tilt manual • • • •
Steering Wheel
— Luxury •
— Leather-wrapped •• •
— Mounted audio controls •• •

CHRYSLER TOWN & COUNTRY
SELECTED FEATURES, OPTIONS AND PACKAGES
LX Touring Limited
Storage
— Driver door sill storage bin • • • •
— Left rear-quarter trim storage bin (not available with 9 amp speakers) • • •
— Floor console — Tray with four cupholders mounted to floor between 1st-row
seats; low console provides easy access to the rear seat (tray is removable) • •
— Premium console, multi-adjustable for second row use, removable (included with
Family Value Group) ••
Sill Applique
— Black •
— Body-color •• •
Suspension
— Normal duty • • • •
— Load leveling and height control (included in Trailer Tow Group) (SER) LLP P
Tip Start — Quiet start; prevents double starts; helps to preserve battery, ignition and
battery life ••• •
Tire Pressure Monitoring Warning Lamp • • • •
Tire Pressure Monitoring Display ••
Tires
— 225/65 R16 BSW All Season • • •
— 225/65R17 BSW A/S Touring •
— Compact spare • • • •
Trailer Tow Prep Group — Includes engine oil cooling, heavy-duty transmission oil
cooling, heavy-duty engine cooling, heavy-duty radiator, trailer tow wiring harness, and
load-leveling and height-control suspension (AHT) OO
Trip Computer — With temperature and compass display in instrument cluster • • • •
UConnect®Hands-Free Communication System(8) — Includes rearview auto-dimming
mirror with microphone (Included with Safety Group, Security Group and included with
MyGIG®Multimedia Infotainment System(4) (RSP) L L/P L/P O/P
Vehicle Information Center — Display in the instrument cluster; includes steering wheel-
mounted controls ••
Wheels
Wheel Covers
— 16" ••
— 16" aluminum •
— 17" aluminum (packaged with Premium Group) P
— 17" chrome-clad aluminum •
Windows
— Power front one-touch up/down driver and one-touch down front passenger,
power 2nd row • • • •
— Power rear quarter vents • • • •
Wipers
— Front, variable intermittent mode • • • •
— Rear wiper/washer with intermittent mode • • • •
— Rain Sensing (packaged with Premium Group) P•

CHRYSLER TOWN & COUNTRY
• = Included. P = Available within package noted. O = Optional. L = Fleet only limited production option.
(1) Flex fuel capable. 3.3L Flex Fuel V6 engine not available in CA, NY, ME, MA or VT. 3.3L gas V6 engine will be substituted.
(2) Always sit properly in the seat with the seat belt fastened.
(3) Always drive carefully, consistent with conditions. Always wear your seat belt and obey traffic laws.
(4) MyGIG in-dash DVD capability is not available in all states. See your RAE for details.
(5) Always check entire surroundings before backing up.
(6) Seat must be locked in forward or rearward mode while vehicle is in motion. Child restraints must only be used when seats are in forward-facing mode. Children 12 and under should always be
seated in the rear seats properly restrained in a child seat or the vehicle seat belt. Tabletop must be installed in base at all times when in use. When not in use, table and base must be properly
stowed. Never drive with the table installed without properly using your seat belts.
(7) Not compatible with all garage door openers. See your RAE for details.
(8) Requires Bluetooth®mobile phone.
(9) Not compatible with aftermarket fabric-protecting coatings.
Chrysler, Mopar, MyGIG, ParkSense, ParkView, Sentry Key, Stow ’n Go, Swivel ’n Go and UConnect are registered trademarks of Chrysler LLC. Chrysler LLC reserves the right to make changes
at any time, without notice or obligation. All product specifications and photographs are based on authorized information as of 4/1/08. Fleet Operations is a division of Chrysler Motors LLC. The
Bluetooth word mark and logo are registered trademarks and are owned by Bluetooth SIG, Inc. SmartBeam is a trademark of Gentex Corporation. ∞Infinity Acoustic 9 is a trademark of Harman
International Industries, Inc. HomeLink is a registered trademark owned by Johnson Controls, Inc. YES Essentials is a registered trademark of Milliken & Company. “SIRIUS,” the SIRIUS dog logo,
and related marks are registered trademarks of SIRIUS Satellite Radio, Inc. Monthly subscription may apply. Programming is subject to change. Not available in Alaska or Hawaii. For full Terms &
Conditions, visit sirius.com
