Cino eC Manual

cino eC
type: xx
INSTALLATION AND MAINTENANCE MANUAL
Original instructions
MAN1010105 rel. 00 dated 04.11.2011
_________________________________________
www.rheavendors.com
espresso

cino eC by
00 04.11.2011 First issue;
REL. DATED DESCRIPTION
notes
MAN1010105 rel. 00 dated 04.11.2011 page no. 2 of 46 page

cino eC by
general guarantee
conditions
1st
2nd
3rd
4th
5th
6th
7th
these conditions regulate Rheavendors Industries S.p.A.’s
obligations with reference to guarantee and repair; any other term
or condition, either verbal or written, is not applicable, including
those in the purchaser’s purchase orders, if not explicitly accepted
and signed by Rheavendors Industries S.p.A.; if the guarantee
terms here below should be held not to be valid and/or lawful in
the Country where the product is sold, they will not be effective
whereas all the other clauses will remain valid and applicable;
the mechanical and electronic components of the machine are
guaranteed for twelve months, starting from the sales date certified
by the fiscal receipt;
the guarantee shall be understood as the free replacement or
repair of any part of the machine that – at the manufacturer’s
unquestionable discretion – should prove to be originally
defective due to manufacturing defects; the cost of sending the
manufacturer machines, defective pieces and spare parts will be
totally charged to the user’s account; the manufacturer reserves
the right to use new or reconditioned components for repair; if
replaced, original components will be guaranteed for 12 months;
the parts replaced under guarantee will become the property of
RhevVendors Services S.p.A. (request for “Form PO 19.01/2b”
Materials under guarantee – Authorisation to return);
in case of irreparable failure or if a failure of the same origin is
repeated, the manufacturer may – at its unquestionable discretion
– replace the machine with another one, the model of which is
either the same or an equivalent one; the guarantee of the new
machine will be extended up to the original term of guarantee of
the replaced machine;
all the parts that should prove to be defective due to negligence or
carelessness (non-observance of the instructions for the operation
of the machine), incorrect installation or maintenance by
unauthorised personnel, transport damage or any circumstance –
anyway – not due to the manufacturing defects of the machine are
not covered by guarantee; the installation and connection with
supply plants as well as the maintenance operations mentioned by
the installation manual are also excluded from any performance
under guarantee; the guarantee will not cover payment systems
either; whether installed on the machine or supplied as an
accessory, they are subject to their manufacturer’s guarantee
whereas Rheavendors Industries S.p.A. will just act as a broker;
all changes made to the machine and not agreed with the
manufacturer in writing will involve the immediate termination of
the guarantee period and anyway fall under the Customer’s total
responsibility;
the guarantee is excluded in all cases of improper use of the
machine;
Rheavendors Industries S.p.A. will disclaim all responsibility for any
damage that may be directly or indirectly caused to people,
animals or things as a result of:
improper use of the vending machine; incorrect installation;
improper energy or water supply; serious maintenance deficiency;
actions or changes not explicitly authorised; use of non original
spare parts;
in case of failure, Rheavendors Industries S.p.A. is obliged neither
to compensate any economic damage due a forced stop of the
machine nor to extend the guarantee period;
if the machine should be transferred to a centre designated by the
manufacturer for overhaul or repair, the relative transportation
risks and costs will be charged to the user’s account. The freight
charges of machines, defective pieces and spare parts are always
understood as charged to the user’s account;
MAN1010105 rel. 00 dated 04.11.2011 page no. 3 of 46 page

cino eC by
declaration of
conformity
ISO 9001 certification
Rheavendors Industries S.p.A. declares that this drink vending
machine has been designed and manufactured in compliance with
the following directives and safety standards:
Directives :
2004/108/EC; 2006/95/EC; 2006/42EC;
2002/95/EC (RoHS); 2002/96/EC (RAEE); 1907/2006/EC (REACH);
1935/2004/EC;
Standards:
SAFETY part. 2-75: (particular requirements for commercial
dispensing appliances and vending machines) +
CEI EN 60335-2-75/A12;
EN 60335-1: 2002 + A1: 2004 + A2: 2006 + A11: 2004 +
A12:2006 + A13: 2008 + A14: 2010 + 60335-1/EC: 2010;
EN 60335-2-75: 2004 + A1: 2005 + A11: 2006 + A2: 2008 +
A12: 2010;
EMC:
EN 55014-1: 2006 + A1: 2009;
EN 55014-2: 1997 + A1: 2001 + A2: 2008;
EN 61000-3-2: 2006 + A1: 2009 + A2: 2009;
EN 61000-3-3: 2008;
EMF:
EN 62233: 2008;
manufacturer of the machine
Rheavendors Industries S.p.A.
Via Garavaglia, 58
21042 Caronno Pertusella
Varese
Italy The Legal Representative
(A. D. Majer )
MAN1010105 rel. 00 dated 04.11.2011 page no. 4 of 46 page

cino eC by
table of contents
01.
02.
03.
04.
05.
06.
07.
08.
09.
10.
11.
12.
13.
14.
legend
introduction
technical data
configurations
presentation
preliminary actions
connections
first power on
programming
parameters
solution of problems
maintenance
how to do to…
hydraulic diagram
in the listed chapters, the manual describes a cino eC vending
machine in its hardware and software components for a complete
and fully-aware use of all machine functions; due to the large
variety of available options and the constant technical update of
our vending machines, some special device or function might be
indicated and described not in the manner you expect; in this case,
do not hesitate to contact us;
telephone: [phone]
fax: [phone]
e mail: rheaven[email protected]
ATTENTION: this label applied next to the serial number label
inside the vending machine points out that the instructions
supplied by this manual must be carefully read before the
installation and operation of the vending machine;
please, print this manual only if necessary; environmental
protection is our common interest;
page 06
page 07
page 08
page 10
page 12
page 20
page 21
page 22
page 24
page 37
page 39
page 41
page 44
page 46
MAN1010105 rel. 00 dated 04.11.2011 page no. 5 of 46 page

§
cino eC by
01.
legend
01.01. abbreviations and
pictograms E =
A =
R =
=
VSF =
=
=
=
01.02. symbols of
attention
01.03. tools
some general instructions that may be of use for reference to this
manual;
dispensing cycle of drinks based on instant products and coffee
beans;
machines with internal water tank;
machines with external water supply;
mixer for mixing the instant product with water;
worm screw pitch in the product canister;
product shaker for instant canisters;
espresso coffee brewer;
hot water dispenser;
if the text is highlit by this symbol, it is recommended to pay
special attention to the performance of the procedures described; if
not carefully performed on safe conditions, they can be source of
general danger;
if not properly performed, the actions marked by this symbol may
expose to accidental contacts with electric voltage;
if not properly performed, the actions marked by this symbol may
expose to accidental contacts with high-temperature parts;
the same symbols can be found inside the vending machine to
specify the parts on which to act with the outmost care;
the symbol recommends the utmost attention during the actions
described; the use of the service key intended to activate all
machine functions when the door is open is only reserved to the
technical operators who know the operation of the vending
machine, who are aware of potential risks and who make sure they
are operating on totally safe conditions;
the use of the service key shall be strictly limited to the time
necessary to perform the actions requiring the use thereof; users
shall be informed of the prohibition on using and approaching the
vending machine;
the symbol means that it is forbidden to dispose of the equipment
as urban waste and compulsory to provide for separate collection in
order to prevent any potential effect on the environment and
human health; strictly follow the provisions of the European
Parliament’s 2002/96/EC Directive;
some tools commonly used and easy to find are necessary to act
with this vending machine:
- a pair of scissors for electricians;
- a star screwdriver 4/6 mm;
- a set of fixed wrenches up to 13 mm;
- a set of socket head screws from 2 to 8 mm;
it may be of use to procure some expendables, such as disposable
paper, single-use gloves, clean cloths, cups and a bucket for the
collection of waste water;
MAN1010105 rel. 00 dated 04.11.2011 page no. 6 of 46 page

cino eC by
02.
introduction
02.01. copyright
information
02.02. rules
**
**
**
**
**
**
02.03. contacts
02.04. serial number
labels
© Rheavendors Industries S.p.A.; all rights reserved;
this document contains some confidential information of
Rheavendors Industries S.p.A.’s exclusive property; the content of
this document can be neither disclosed in favour of third parties,
nor copied or reproduced in any form whatsoever, either fully or
partially, without Rheavendors Industries S.p.A.’s prior
authorisation in writing; the utilisation, reproduction or disclosure
of the technical information in this document can be protected by
Rheavendors Industries S.p.A. according to the Law;
this manual is intended for the owner of the vending machine; it is
an integral part of the machine and it shall be kept with it;
the information supplied by this manual are intended to achieve
the best performances of the vending machine within the scope of
application established by the Manufacturer; Rheavendors
Industries S.p.A. reserves the right to improve future production
without serving any prior notice and without assuming any
obligation to update the products on the market; the manufacturer
will disclaim all responsibility for any inaccuracy due to misprints;
safety rules for using the vending machine
** pay special attention to the chapters and notes high lit by the
symbols of alert; strictly observe the rules concerning, in
particular, the operators’ and users’ safety;
** under no circumstance may the vending machine be used by
children or by people with poorer physical, sensorial or mental
capacities or who have not been properly informed on correct
use; children shall be supervised to prevent them from playing
with the vending machine;
** if you should find out a water leak or the presence of smoke,
immediately detach the vending machine from the electric and
hydraulic network, never try to restore its operation and apply
to skilled technicians;
** the machine shall be installed according to national rules; pay
special attention to the rules about the machines directly
connected with the hydraulic network;
** the user is not allowed to access the maintaining and servicing
area that shall be properly signalled;
** never remove protections, never override safety devices and
never modify the machine or its components;
Rheavendors Services S.p.A. is at disposal for any kind of
support and information on this vending machine;
telephone: [phone]
fax: [phone]
e mail: rheaven[email protected]
for any reference about our partners all over the world please visit
site: www.rheavendors.com
to be able to identify the vending machine rapidly and univocally as
well as to get the best support, please specify the data of the serial
number label;
code : D12345A67890
s/n: 1234 56 7890
silvery serial number labels are applied inside and outside the case
of the machine;
MAN1010105 rel. 00 dated 04.11.2011 page no. 7 of 46 page
(example)

cino eC by
MAN1010105 rel. 00 dated 04.11.2011 page no. 8 of 46 page
03.
technical data
03.01. dimensions
03.02. weight
03.03. supply
water
energy
03.04. sound pressure
03.05. keyboard
03.06. display
03.07. dispensing cpt.
03.08. drip tray
03.09. dispenser
03.10. safety water
energy
heat
software
03.11. grinder motor
03.12. grinders
03.13. coffee brewer
03.14. air break
03.15. pump
03.16. product motors
03.17. mixing bowl
03.18. mixer motor
03.19. boiler
height:
height (including opened water door):
width:
depth:
- connection by means of a solenoid valve with 3/8“ gas male face:
- supply by a submersible pump:
- connection from internal tank;
- 230 V ac, 50/60 Hz; single-phase and ground;
- cable of the following type: H05VV-F 3G 1 mm² 300/500 V;
anyway refer to label data
A-weighted sound pressure level;
eight selection buttons;
two sixteen-character lines; graphic; three color;
open; folding cup support (useful height 85 mm);
drip tray beneath the cup surface:
a fixed dispensing place;
overflow sensor and pressure relief valve;
water inlet solenoid valve with anti-flood sensor;
a main switch, a door switch;
two 6.3x32 mm fuses;
manually resettable sensors;
time limits for water dispensing cycles;
conical;
made of plastics; the dimension of the brewing chamber can be
mechanically programmed in three volumes;
air break with overflow and level switch;
a vibration pump with bypass;
two;
one;
one;
pressurised boiler;
560mm
625mm
315mm
530mm
26 kg
from 0.1 MPa to 0.8 Mpa;
24 V dc, 1.2 A max.;
3.4 litres capacity;
1,600 W;
less than 70 dB(A);
64 x 128 pixel resolution;
maximum 140 mm;
capacity 750 ml;
220 V ac; 12 A delayed;
88 °C;
220 V dc;
Ø40mm
orange chamber;
Ø36mm
black chamber;
220 V ac; 0,8 Mpa;
95 r.p.m.; 24 V dc;
15,000 r.p.m.; 24 V dc;
0.4 litres, 1,500 W;

cino eC by
MAN1010105 rel. 00 dated 04.11.2011 page no. 9 of 46 page
03.20. product canisters
03.21. miscellaneous
03.22. notes
two; single (55 mm) or double (110 mm) width; dispensing worm
screws 9 mm or 18 mm in pitch; with mixer gear and product
shaker, if arranged by the configuration and with standard or
shorter product slide outlet (see 05.22.);
- coffee beans canister (or hopper) capacity: 0.8 kg
- instant canister capacity:
machine parameters programmable by means of a flash key or
selection keyboard; NRI G13 or similar payment system
compartment; protocols: serial, parallel, executive, MDB; data
collection by means of a flash key (see 09.06.);
the water and energy supply tolerance limits that can ensure a
good and proper operation of the cino eC machine are:
water:
- total hardness:
- recommended conductivity:
(*) if harder, please use anti-limestone filters;
energy:
- nominal voltage:
- nominal frequency:
room (during storage and operation):
- temperature:
- relative humidity:
the power supply cable supplied with the vending machine
shall not be altered under any circumstance; in case of loss
or damage replace it by using an original component only;
make sure that the electric installation can deliver the power
suitable for the machine (see 03.03.);
a good ground connection is not only a legal obligation for the
protection of users and operators, but it can also provide for correct
power supply;
from 10 °F to 25 °F (*)
400 μS @ 20 °C
+10 % /- 25 %
+/- 5 %
5 °C ÷ 35 °C
max 80 %
width 55 mm width 110 mm
capacity 1.7 litres capacity 3.5 litres
coffee 0.33 kg coffee 0.76 kg
milk 0.38 kg milk 0.80 kg
chocolate 0.94 kg chocolate 2.20 kg

04.
configurations
04.01.
a. product canisters
b. water supply
c. numbering
04.02. examples of
configurations
04.03. accessories
cino eC configurations are numerous; they are coded by means of
some categories exemplified here below in the abbreviation of the
machine:
number of instant products and coffee beans:
- external, by means of the inlet solenoid valve:
- internal, from the internal tank to the vending machine:
product canisters, mixing bowls and mixers are numbered in
progression, from the left to the right, as it is shown later on; this
numbering is used in the chapter on how to programme (see 09.)
drinks;
V.M. cino eC E/3 R
V.M. cino eC E/3 A
the configurations above are just some of possible cino eC
configurations, considering the vending machine releases and
programmability; the principles of operation and information are
anyway universal and applicable to all machines of the cino eC
range;
to complete and supplement the vending machines of the cino eC
range, Rheavendors Industries S.p.A. has got a series of
accessories manufactured for these machines, such as cabinets,
autonomous water supply kits, anti-limestone filters, payment
systems, … ;
Rheavendors Services S.p.A. is at disposal for any kind of support
and information on special configurations (see 02.03.);
cino eC E/3
cino eC E/3 R
cino eC E/3 A
keyboard selections
1. Short coffee
2. Long coffee
3. Short white coffee
4. Cappuccino
5. -
6. Milk
7. Latte macchiato
8. Mocaccino
9. Chocolate
10. -
keyboard selections
1. Long coffee
2. Espresso
3. Cappuccino
4. Latte macchiato
5. -
6. Milk
7. Chocolate
8. Mocaccino
9. Hot water
10. -
cino eC by
940
grams
CHOCOLATE
COFFEE BEANS
800
grams
MILK
800
grams
VSF 18
2
VSF18
1

water 1
mixer 1
§
COFFEE BEANS
800
grams

380
grams
MILK
940
grams
CHOCOLATE
VSF 18
2
VSF 18
1
2,2
Litres
WATER
water 1
mixer 1
MAN1010105 rel. 00 dated 04.11.2011 page no. 10 of 46 page

cino eC by
04.04. LM selection cino eC can produce a drink called Latte Macchiato, composed by
milk and coffee and served in the cup in differently coloured bands,
typically milk, coffee and milk;
to get this special drink, refer to a specific package of instructions,
every step of which is called “LM dispensing cycle”; please keep in
mind some general principles to achieve this special drink quality:
- the first milk dispensing cycle shall not be too much mixed;
- the second milk dispensing cycle should occur after 10/15
seconds; mixing shall be extended and performed at the
maximum rotation speed of the impeller;
- the espresso coffee should be dispensed at least 15/20
seconds after the second milk dispensing cycle in the cup;
the data supplied by the table provide for a “latte macchiato”
dispensing cycle and they can be adapted to achieve dispensing
cycles more suitable for the users’ wishes;
parameters values
1st milk
parameters time prod n 24
start delay prod n 5
water time n 60
prod n start delay water n 0
time mixer n 60
water n start delay mixer n 3
speed mixer n low
mixer n
2nd milk
prod LM time prod LM 24
start delay prod LM 200
water LM water LM time 60
start delay water LM 150
mixer LM time mixer LM 80
start delay mixer LM 180
speed mixer LM high
coffee water 2nd delay
es
p
resso coffee star
t
200
selection 1st milk 1st delay 2nd milk 2nd delay
"Latte Macchiato" selection
flow dia
g
ram
time
MAN1010105 rel. 00 dated 04.11.2011 page no. 11 of 46 page

05.
presentation
05.19.
coffee brewer
05.20.
grounds container
05.06.
drip tray
machine cover
05.22.
coffee beans canister
05.15. e 05.37.b.
protection carter
05.05.
door lock
05.26.
mixing bowl
05.33.
coin box
05.28.
mixer motor
05.27.
nozzle support
05.14.
service key
05.15.
internal button (PROG)
05.06.
level sensors
05.16.
flash key housing
05.22.
internal water tank
05.22.
instant product canister
05.23.
water door
05.14.
door switch
cino eC by
05.12.
drain tap
05.08.
power on switch
05.29.
powder aspirator
05.25.
product motor
05.37.a.
CPU
05.31.
air break
05.33.
instant solenoid valves 05.21.
coffee brewer motor
05.31.
switch floater
05.30.
air aspirator
05.18.
grinder motor
05.07.
electric connection
05.36.
pressure boiler
05.09.
fuses
05.11.
water drain plug
05.13. water inlet
solenoid valve
05.28.
mixer motor
05.32.
volumetric counter
05.18.
grinder
MAN1010105 rel. 00 dated 04.11.2011 page no. 12 of 46 page
05.10.
service connectors

05.19. coffee brewer
chamber heating
connection
05.19. coffee brewer
lock lever
05.25.
product motor
05.26. mixer motor
05.21. coffee brewer
presence switch
05.19. coffee brewer
water supply
05.30. powder extraction
drawer housing
05.06.
level sensors
cino eC by
05.19. coffee hopper
presence switch
05.18.
grinding regulation
05.25.
product motor
MAN1010105 rel. 00 dated 04.11.2011 page no. 13 of 46 page
05.06.
waste water discharge
05.22. internal water
tank connector

05.01. general
information
05.02. selection keyboard
05.03. display
05.04. dispenser
05.05. door lock
05.06. drip tray
05.07. electric connection
05.08. power on switch
05.09. fuses
05.10. service connector
05.11. water drain plug
05.12. pressure boiler
drain tap
05.13. water inlet
solenoid valve
05.14. door switch
the Rhea cino eC vending machine is a machine explicitly designed
for being easily used by all users since no specific competence is
required in preparing drinks;
the function consists in dispensing drinks by mixing food products
and water at a proper temperature; the correct operation of the
vending machine occurs in closed rooms in normal environmental
conditions and at a room temperature between 5 °C and 35°C, the
relative humidity below 80%;
use only specific ingredients for vending machines;
dispense by briefly pressing a key of the selection keyboard
(see 05.02.); make sure that the cup has been properly positioned
at the dispensing station, if necessary by using the flap support for
caps (see 03.07.);
after having closed the door, press the buttons to dispense; all
buttons are lighted in standby mode whereas they turn off during
the dispensing cycle and only the selected button turns on; keys
will assume various functions in the programming mode (see 09.)
and enable the user to modify the machine parameters; keys are
numbered progressively from the top: 1, 2, … and from the left;
the display messages inform users and operators about the
operation state of the vending machine;
the cino eC vending machine has got a fixed drink dispenser on
the cup support surface;
the door is closed by means of a lock; the key is mapped and
numbered for identification;
it collects possible residual drops from the dispenser and, if
necessary, the waste water in excess from the air break; it is slided
at the bottom of the machine case, in the front, and it is composed
by a covering drawer and a grilled cover that can be washed by
running water; an electric contact is intended to control the filling
level (see 11. and 13.01.).
a three-terminal socket is arranged at the back of the case for the
connection of the mains cable;
to power on and off the machine;
installed on the mains power supply (see 03.10.);
they provide for electrical connection with an accessory module
that can work in combination with cino eC;
from where to let the silicone tube from the air break come out for
emptying; (see 13.08.);
open it to let water come out of the boiler and empty it; (see
13.08.);
the water inlet solenoid valve on R machines only has got an anti-
flood safety device intended to stop the water inlet in case of
failures; to its electrical pins can be connected in parallel an any
submersible pump (see 03.03.);
to power off the machine when the door is open;
attention
some parts remain anyway network-connected
act extremely carefully;
use the service key to supply the vending machine if it is necessary
to activate the machine when the door is open;
the key is housed in the cover;
02
03
04
05
06
1
2
3
4
6
7
8
9
cino eC by
MAN1010105 rel. 00 dated 04.11.2011 page no. 14 of 46 page
10
14
07
09
08
11
12
13

the button giving access to the machine programming mode is
arranged on the orange protection carter inside the door;
programming flash keys are arranged in the carter inside the door
(see 09.06.);
product labels are arranged inside the door panel, beneath the
orange carter;
insert the labels into the pockets by observing the machine
configuration (see 13.13.);
the grinder grinds the coffee beans in the canister and pours them
directly into the coffee brewer, the coffee powder quantity is
established by a “grinder time” software parameter (see 09.01.a);
you can programme the grinding time necessary to obtain the drink
you wish for each espresso selection;
the selections with coffee beans are inhibited if the coffee canister
presence switch is not pressed (see 05.19.);
there is a lever just beneath the coffee beans canister; move it to
change the grinding degree (move it to the back of the machine to
make powder finer);
after having received and compressed the ground dose from the
grinder, brewing occurs in the coffee brewer by using the water
coming from the pump; the used dose is conveyed to the grounds
container (see 05.20.);
the presence of the brewer is detected by a switch; if it is not
pressed, espresso dispensing cycles are inhibited; there is a version
with a heated metal brewing chamber (see picture on page 13);
it collects over thirty ground doses after having used them in the
coffee brewer; a software option (see 09.01.o.) will show a warning
message as soon as the tray is full;
the coffee brewer motor will rotate some parts of the coffee brewer
to compress ground coffee for brewing; rotation is controlled by a
switch driven by a cam that will inform the CPU on the position of
the coffee brewer;
instant product canisters dispense their content in the underlying
mixing bowls; an internal worm screw driven by the product motor
will push the instant product to the product slide; they can be
equipped with a wheel and a product shaker for constant
dispensing; the outlet, the dimension of which can be either
standard or smaller, has got a closing baffle;
the coffee beans canister (hopper) has a closing blade; pull it
before lifting the container;
to protect the products, containers are closed by a cover; a water
tank is intended for supply in the versions not connected with the
water network (see 01.01.); this tank can be filled through a hatch
of the vending machine cover;
in A machines, a door on the vending machine cover will enable
you to access to the internal water tank and fill it in;
an internal water tank is complete with a float signalling by means
of a red strip if you have filled it in excess;
a single-dose of ground coffee at your choice can be used in some
versions, coming directly to the coffee brewer through a hatch on
the machine cover;
05.15. internal button
(PROG)
05.16. flash key housing
05.17. label slot
05.18. grinder
05.19. coffee brewer
05.20. grounds container
05.21. coffee brewer
motor
05.22. product canisters
05.23. water door
05.24. “Your private
coffee” door
cino eC by
MAN1010105 rel. 00 dated 04.11.2011 page no. 15 of 46 page
16
15
21
23
24
19
20
18
22
17

they are intended to rotate the worm screws inside instant product
canisters to pour the product quantity necessary for selection in the
mixing bowls;
the mixing bowl of the mixer will accommodates the instant
products you have poured to mix them with water; the fan of mixer
motor will act at the bottom and the drink outflow to the dispenser
occurs by means of a silicone tube; mixing bowl and outlet tubes
can be washed with lukewarm running water;
a fixed support on the cup station is intended to house the
dispensers from the coffee brewer, the mixer bowl and the direct
hot water unit;
press the release lever to move it to the right to clean or to remove
the coffee brewer;
the motors of mixers help you mix instant products with water by
means of the rotation of the fan mounted on their axis; the
rotation speed can be adjusted (see 09.01.a.) to the features of the
various products;
an aspirator will eject suspended product residuals from the
vending machine; the aspirator is connected with a drawer beneath
product slides to intercept the residual impalpable powder coming
from selections; the action time of the aspirator is programmable
by means of a software parameter (see 09.01.f.); aspirated air is
ejected through the slots of the rear panel;
to aspirate the air from the internal environment of the machine to
avoid any condensate;
it accumulates water for sending to the pressure boiler; the level is
controlled by a float and – if above the established level – it will
flow back to the inlet solenoid valve safety device, thus preventing
the inlet of new water;
it supplies the CPU the water quantity running through the coffee
brewer to establish its volume; the water quantity of instant
selections is established by the time set in the “water N” parameter
only (see 09.01.a.);
the components intended to support the payment system (not
supplied) are made available in some versions, inside the door; the
coin box is equipped with a lock and the payment system cable
shall be connected with the CPU board; (see 05.37.a.);
- each selection key is lighted by a led mounted on the display
board (see 05.37.b.);
- the front transparent stud, the dispensing compartment and the
door panel are lighted by a led mounted on printed circuits inside
the door;
the dispensing compartment is lighted by four leds in standby
mode and during a dispensing cycle;
leds of different colours turn on alternatively to signal the end of
a dispensing cycle;
05.25. product motors
05.26. mixing bowl
05.27. nozzle support
05.28. mixer motor
05.29. powder aspirator
05.30. air aspirator
05.31. air break
05.32. volumetric counter
05.33. coin box
05.34. door lighting
cino eC by
MAN1010105 rel. 00 dated 04.11.2011 page no. 16 of 46 page
28
26
27
29
30
31
32
33
25
34

05.35. pressure boiler
pump
05.36. pressure boiler
a vibration pump with bypass conveys water to the solenoid valves
block for instant and three-way valve for espresso;
pressure boiler complete with a temperature probe and protection
clicsons; the drain tap may be used to empty the hydraulic circuit
(see 09.01.f.);
attention
these components may be very hot even
if the machine is off
the water quantity of instant selections is established by the time
set in the “water N” parameter (see 09.01.a.);
X2
1
cino eC by
MAN1010105 rel. 00 dated 04.11.2011 page no. 17 of 46 page
EX
E1 E2
water inlet
to the drain tap
to coffee brewer
to mixing bowl 1
hot water 2
temperature probe
three-way valve
clicsons
solenoid valves
solenoid valve name sw outlet
E1 water 1 mixing bowl 1
E2 water 2 hot water 2
EX coffee water coffee brewer
35

05.37. electronics
05.37.a. CPU
05.37.b. display board
05.37.c. RFID
cino eC by
led 24 V dc
grinder motor
fuse 2 A
temperature probe
connector
display board connector
RFID connector
MDB connector
Executive connector
led 5 V dc
IN 220 V ac
grinder motor
connector
internal button
PROG
flash key connector
left keyboard
connector
CPU board
connector
right keyboard
connector
supply connector
dispensing cpt.
led supply
MAN1010105 rel. 00 dated 04.11.2011 page no. 18 of 46 page
USB connector
pressure boiler heating
element led
pressure boiler and pump
heating element
the CPU board governs the operation of the machine, it is the seat
of the machine programmes and it is secured to the frame by
means of turrets;
the temperature probe cable is separated from the machine wiring
to avoid hampering any removal of the probe itself;
it collects and processes the signals necessary to display the
messages for the user and the operator; it receives the signals
from the two selection keyboards and supplies the lighting leds of
the cup compartment;
the RFID card is a hardware option that can equip the machine; it
is housed inside the cover, it enables the operator to programme
the product decounters (see 09.01.n.) and/or it can be used as a
payment system (see 09.01.p.);

05.38. software
05.39. rheAction
the software installed in cino eC can be subdivided into two
different chapters called:
-master:
it is the software determining the machine cycles, the links
between the functions, the order of execution of operations;
this software can not be modified by the operator, but it can be
replaced in the CPU by means of a flash key written at works or
by means of rheAction (see 09.06. and 05.39.);
- configuration:
it is the software determining the times and the
succession of dispensing drinks, the payment system protocol,
the display modes, …; variables may be modified by the operator
either manually aboard the machine or by means of rheAction
(see 09.06. and 05.39.) to adapt the machine behaviour to the
final users’ needs (product quantities and mixtures, warning
messages …) (see 09.);
if it is necessary to update one of the software programmes above
on the machine, the flash key may be of great use; the key can
contain either software or both of them and provide for a rapid and
safe transfer;
please note that the flash key used for these software handlings
must have been previously initialised (with RheAction for example);
in general, the transfer procedure is:
- power off the machine;
- insert the flash key into the corresponding connector (see
05.16.);
- power on the machine by means of the service key (see 05.14.);
- wait for the message on the machine display;
- answer the messages on the display;
- power off the machine and remove the flash key;
please note: if the flash key should contain a master software, the
transfer will certainly occur from the key to the machine, whereas
it will be necessary to follow the steps described by 09.06 in case
of a configuration software;
a system called rheAction is intended to complete and supplement
the programming executable in the machine; it is composed by a
software and hardware, installable in a pc, capable of storing,
modifying and writing the configuration data of Rhea machines;
Rheavendors Services S.p.A. is at disposal for any kind of support
and information on the RheAction system (see 02.03.);
e informazioni riguardanti il sistema RheAction (vedi 02.03.);
cino eC by
MAN1010105 rel. 00 dated 04.11.2011 page no. 19 of 46 page

06.
preliminary actions
06.01. handling
06.02. unpacking
06.03. positioning
06.04. preparation
the vending machine may be transported, handled and positioned
by skilled and trained personnel only; while handling, never
overturn the machine; observe the orientation arrows on the
package;
attention
handle the machine carefully to prevent the authorised personnel
from being injured; considering the weight and overall dimensions
of the vending machine, it is recommended to use a truck at low
speed;
- approach the packed vending machine to its work position;
- cut the two plastic belts;
- lift the external package;
- remove the drip tray;
- extract the protection bag up;
- lift the vending machine and arrange it on the work surface;
attention
the materials composing the package shall never be left within the
reach of people from outside, in particular of children, because they
represent a potential source of danger;
only specialised companies may be charged to provide for the
disposal of package components;
the vending machine shall be arranged for work in a sheltered
room by using a support suitable for the weight of the machine
(see 03.02.); its distance from the walls shall provide for good air
circulation and easy access;
any inclination of the surface shall not exceed 2°;
it is recommended to arrange an easily cleanable impermeable
protection beneath the vending machine to collect any accidental
product fall;
when the machine is in its final working position:
- cut the clamp securing the door key to the drip tray grilled cover;
- insert the door key into the lock (see 05.05.), rotate it and open
the door;
- remove the envelope of documents and labels;
- take the power supply cable and the water union; the water union
can be used for water connection with the network;
- lift the machine cover and remove the guards intended to fasten
product containers for transport;
- insert the labels by observing the order of selections determined
by the machine configuration (see 04.02.);
cino eC by
MAN1010105 rel. 00 dated 04.11.2011 page no. 20 of 46 page
