Circa Enterprises Inc. Guardian Telecom PTR Guide

Ph: 403.258.3100 \ email:[email protected] \ www.guardiantelecom.com
Page/Talk Modules
Models PTR, PTA, PPR & PPA
Installation & Operation
PTR / PPR PTA / PPA
P006207 Rev. C 180117 1/17/2018 10:15 AM

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 2
Table of Contents
Package Contents ..............................................................................2
Overview.............................................................................................3
Page/Talk Replacement Modules .......................................................4
Replacement Parts .............................................................................5
Page/Talk Options and Accessories ...................................................5
Features .............................................................................................6
Installing the Module in a Guardian Enclosure ..................................11
Replacing a Module in a Gaitronics Indoor Enclosure.......................11
Replacing a Module in a Gaitronics Outdoor Enclosure ....................12
Accessing the interior of the Station..................................................12
Ambient Noise Level Adjustment ......................................................13
Group Muting....................................................................................14
Operating the Single Line Station .....................................................15
Operating the Five Line Station.........................................................15
Troubleshooting ................................................................................16
Specifications ...................................................................................17
Warranty ...........................................................................................18
Disclaimer.........................................................................................18
Warning ............................................................................................18
Service Telephone Number ..............................................................18
Feedback..........................................................................................18
Guardian Product Return ..................................................................19
Typical Installation ............................................................................20
Cleaning Tips for Guardian Communication Products.......................20
Table of Figures
Figure 1 - Features (All Options Shown) ..............................................7
Figure 2 - Dimensions PTR & PPR ......................................................7
Figure 3 - Dimensions PTA & PPA ......................................................8
Figure 4 - Harness Connections ..........................................................8
Figure 5 - PTR In Guardian Indoor Housing.........................................9
Figure 6 - PTR in Guardian Outdoor Housing ......................................9
Figure 7 - PPR in Gaitronics Outdoor Housing.....................................9
Figure 8 - PPR in Gaitronics Indoor Housing .......................................9
Figure 9 - Electrical Connections .......................................................10
Figure 10 - Adjustments.....................................................................10
Package Contents
One (1) Page/Talk Module
One (1) Installation & Operation Manual

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 3
Overview
Page/Talk Modules
Guardian's Page/Talk Systems provide reliable and easy to use paging and
communication within industrial environments such as plants, mines, mills
and factories. Individuals can be paged from any station and two or more
persons can communicate on any available line.
The Modules described in this manual are designed for use in harsh,
industrial environments and are identical for single talk line or five talk line
configurations. Modules are available with handsets, connectors for
headsets and as standalone amplifiers. Each Module provides up to twelve
watts of paging power for an external loudspeaker. A page button on the
handset of models with a handset enables one-hand paging operation.
Modules are available for indoor or outdoor use. They may be used along
with appropriate enclosures as a complete station or they may replace
modules in existing stations, either as an upgrade or to replace a
malfunctioning unit. Features of models vary according to their purpose,
however all modules have the same profile and electronic circuitry, and will
fit into any enclosure. For example amplifier modules do not have a
handset. Some models do not have an ambient noise sensor on the
faceplate; these are intended for outdoor use where the door of the
enclosure would prevent the sensor from picking up the ambient noise and
for other applications where an ambient noise sensor is not required. The
models that do have ambient noise sensors on the faceplate can replace
any other module either on a temporary or permanent basis. This is a great
convenience and cost saving feature, since only one spare module needs to
be stocked and a serviceman only has to carry around one module when
testing a system.Modules are secured with four screws for ease of
replacement.
If a PTR (Handset Module) is installed in an indoor housing as a Desk Set
Amplifier the Desk Set and the Wall Station can, at the same time be used
independently of each other. The two can be separated by up to fifty feet.
This feature can save the cost of a complete indoor station if circumstances
permit.
The modular design of the system offers great flexibility in the ways that
components can be combined. For a description of the various
configurations available see Page/Talk Replacement Modules.
In order to avoid acoustical feedback from a loudspeaker receiving a signal
from the station, a jumper on the main circuit board of every station provides
for the associated speaker to be muted when the Page button is pressed.
Group muting is also available for the same purpose. This feature mutes
adjoining speakers when the page button on any station in the group is
pressed.
Guardian's modules, stations and related equipment are compatible with
systems provided by most other manufacturers.

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 4
Note: Some models of Guardian modules include an ambient noise sensor on the faceplate that
controls the output of the associated loudspeaker. Other models do not have an ambient noise
sensor on the faceplate and can be used without the capability of adjusting the loudspeaker
output, or in the case of outdoor stations an ambient noise sensor may be installed in the
enclosure and connected to the circuit board with a harness. Features are included only if they
are specifically mentioned in the description.
Products with descriptions beginning with PT are for Guardian Page/Talk systems; those
beginning with PP are for Gaitronics Page/Party®systems. PT modules can be converted to PP
with the addition of kit P/N P5541 or kit P/N P5542.
Page/Talk Replacement Modules
Part No.
Description
P5500
PTR - Handset module with ambient noise sensor
P5501
PTR - Handset module with ambient noise sensor and headset connector
P5502
PTR - Handset module
P5503
PTR - Handset module with headset connector
P5504
PTA - Amplifier module with ambient noise sensor
P5505
PTA - Amplifier module
P5506 PPR - Handset module with ambient noise sensor and 16 Pin Harness for Gaitronics
enclosure
P5507 PPR - Handset module with ambient noise sensor, headset connector and 16 Pin
Harness for Gaitronics enclosure
P5508
PPR - Handset module with 16 Pin Harness for Gaitronics enclosure
P5509 PPR - Handset module with 16 Pin Harness and ambient noise sensor kit for
Gaitronics outdoor enclosure
P5510 PPR - Handset module with 16 Pin Harness and headset connector for Gaitronics
enclosure
P5511 PPR - Handset module with 16 Pin Harness, headset connector and ambient noise
sensor kit for Gaitronics outdoor enclosure
P5512
PPA - Amplifier module with 16 Pin Harness and ambient noise sensor kit for
Gaitronics enclosure
P5513
PPA - Amplifier module with 16 Pin Harness for Gaitronics enclosure
P5514
PPA - Desk set amplifier module with 24 Pin Harness and ambient noise sensor for
Gaitronics enclosure
P5515
PPA - Desk set amplifier module with 24 Pin Harness, ambient noise sensor and reed
switch kit for Gaitronics enclosure
P5516
PPA - Desk set amplifier module with 24 Pin Harness
P5517
PPA - Desk set amplifier module with 24 Pin Harness and reed switch kit for
Gaitronics enclosure
NOTE: MODELS WITH HEADSET CONNECTORS ARE NOT APPROVED FOR USE IN
HAZARDOUS LOCATIONS

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 5
Replacement Parts
Part No.
Description
P004747
Handset - Push To Page
P002786
Cradle - Handset
P002254
Reed Switch - With Harness
P004371
Handset Retainer
P004593
Microphone - Ambient Noise Sensor
P005925
PCB Guard (Cover)
P005944
Dust Cap - Headset Connector
P005955
PCB - Main Board
P006102
Connector - Headset Panel Jack Harness
P006130
LED - Red Panel With Harness
P005919
Faceplate - Standard Module
P005920
Faceplate - Standard Module With Headset Connector
P005922
Faceplate - Outdoor Module
P006141
Faceplate - Outdoor Module With Headset Connector
P005921
Faceplate - Amplifier Module
P006151
Faceplate - Amplifier Module Without Ambient Noise Sensor
P005794
Connector Harness - 16 Pin
P006070
Connector Harness - 24 Pin
Page/Talk Options and Accessories
Housings
P5520
Indoor standard housing
P5521
Indoor desk amplifier housing
P5522
Outdoor ambient noise housing
P5523
Outdoor housing
Switch And Access Plates
P5530
Five line switch plate
P5531
Single line access plate
Kits And Accessories
P5540
Push to page head set
P5541
16 pin Gaitronics amplifier connector harness kit
P5542
24 pin Gaitronics desk amplifier connector harness kit
P5543
Headset connector panel jack harness kit
P5544
Indoor desk amplifier housing harness kit
P5545
Outdoor housing ambient noise harness kit
P5546
Gaitronics desk set reed switch harness kit
P5547
Indoor housing back plate kit
P5548
Indoor housing flush mount kit

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 6
Features
Faceplate
•
Stainless steel with four screws
Ambient Noise Monitor (Optional)
•
monitors the ambient noise and adjusts speaker volume accordingly
•
initial level adjustment on faceplate
System Indicator LED.
•
indicates if handset is off hook
Handset
•
page switch on handset
•
noise canceling dynamic microphone
•
electronic hook switch provides durability
Headset (optional)
•
plug in headset
Speaker Muting
•a jumper on the circuit board selects muting of the associated
speaker to avoid acoustic feedback
Controls
•
speaker volume – (internally and externally accessible)
•
ambient noise level monitoring
•
microphone gain
•
receiver volume
•
side tone level

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 7
Figure 1 - Features (All Options Shown)
Figure 2 - Dimensions PTR & PPR

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 8
Figure 3 - Dimensions PTA & PPA
Figure 4 - Harness Connections

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 9
Figure 5 - PTR in Guardian Indoor Housing Figure 6 - PTR in Guardian Outdoor Housing
Figure 7 - PPR in Gaitronics Outdoor Housing Figure 8 - PPR in Gaitronics Indoor Housing

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 10
Assignment Designation Description
Jacket
Color
Stripe
Color
Wire
Gauge
System Power
J4A/J5A
HOT
Black
14 AWG
J4A/J5A
COM
White
14 AWG
J4A/J5A
GND
Green
14 AWG
Ambient Noise
J6A
MIC +
n/a
n/a
n/a
Microphone
J6A
MIC -
n/a
n/a
n/a
Speaker
J7A
SPK +
n/a
n/a
n/a
J7A
SPK -
n/a
n/a
n/a
Page Line
J2A/J3A
PA Page Line
Blue
Red
18 AWG
J2A/J3A
PB "
Red
Blue
"
Channel
J2A/J3A
1A Channel 1
Red
18 AWG
J2A/J3A
1B "
L. Brown
Red
"
J2A/J3A
2A Channel 2
Violet
18 AWG
J2A/J3A
2B "
L. Brown
Violet
"
J2A/J3A
3A Channel 3
Blue
18 AWG
J2A/J3A
3B "
L. Brown
Blue
"
J2A/J3A
4A Channel 4
Brown
18 AWG
J2A/J3A
4B "
L. Brown
Brown
"
J2A/J3A
5A Channel 5
Yellow
18 AWG
J2A/J3A
5B "
L. Brown
Yellow
"
Group Muting of
J2A/J3A
Mute
Orange 18 AWG
Loudspeakers
J2A/J3A
Park
Spare Conductor
(Special Order)
n/a Extra Red 12 AWG
Note:
Channels 2 to 5 connections remain empty for single Talk Line hookup.
If this station is in a Group Muting series, but is not to be muted when paging calls are made from
other stations in the group, connect the wires assigned to this function to the Park terminals.
Figure 9 - Electrical Connections
Figure 10 - Adjustments

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 11
Installing the Module in a Guardian Enclosure
WARNING - high voltages are present in this equipment when it is
connected to the power source.
•
Ensure that the module is set up for the correct voltage.
Tip: check the label on
the main circuit board
cover.
•If this is a new installation install the enclosure and switch plate or lower
cover plate, according to the instructions provided.
•
Ensure that none of the electrical connection circuits are live.
•Set the speaker mute jumper on the circuit board to the desired position. See: Group Muting
•Insert the module into the enclosure ensuring that the connector is properly
seated.
•
Tighten the four screws on the faceplate.
•Apply power to the system.
•Wait at least 20 seconds then adjust speaker volume to the desired level
using the potentiometer accessible through the screw hole in the faceplate.
Use a small flat tip screwdriver to make the adjustment.
Note: Adjust speaker
volume while ambient
noise at the station is at
a minimum.
•Test the installation by making a call as described in the operating section.
Replacing a Module in a Gaitronics Indoor Enclosure
WARNING - high voltages are present in this equipment when it is
connected to the power source.
•Disconnect power to the station.
•
Ensure that the module is set up for the correct voltage.
Tip: check the label on
the main circuit board
cover.
•Remove the existing module by undoing the four screws and gently pulling
the module loose from the connector.
•The Guardian replacement module requires an adapter harness to be
compatible with a Gaitronics enclosure. With a 16 pin connector the
harness part no. is P5541 or with 24 pin connector part no. is P5542.If the
module was ordered with the appropriate harness it will already be installed.
If the harness is not already installed refer to the instructions accompanying
the harness kit for installation on the module.
•Set the speaker mute jumper on the circuit board of the replacement
module to the desired position.
See: Group Muting
•Insert the module into the enclosure ensuring that the connector is properly
seated.
•Tighten the four screws on the faceplate.
•Apply power to the system.
•Wait at least 20 seconds then adjust speaker volume to the desired level
using the potentiometer accessible through the screw hole in the faceplate.
Use a small flat tip screwdriver to make the adjustment.
Note: Adjust speaker
volume while ambient
noise at the station is at
a minimum.
•Test the installation by making a call as described in the operating section.

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 12
Replacing a Module in a Gaitronics Outdoor
Enclosure
WARNING - high voltages are present in this equipment when it is
connected to the power source.
•
Disconnect power to the station.
•
Ensure that the module is set up for the correct voltage.
Tip: check the label on
the main circuit board
cover.
•Remove the existing module by undoing the four screws and gently pulling
the module loose from the connector.
•The Guardian replacement module requires an adapter harness to be
compatible with a Gaitronics enclosure, with 16 pin connector harness part
no. P5541 or with 24 pin connector part no. P5542. If the module was
ordered with the appropriate harness it will already be installed. If the
harness is not already installed refer to the instructions accompanying the
harness kit for installation on the module.
•
To provide ambient noise sensing adjustment of the associated loudspeaker
a microphone kit, part no. P5545
must be installed. Refer to the instructions
accompanying the kit.
•Set the speaker mute jumper on the circuit board of the replacement
module to the desired position.
See: Group Muting
•Insert the faceplate ensuring that the connector is properly seated.
•Tighten the four screws.
•Apply power to the system.
•Wait at least 20 seconds then adjust speaker volume to the desired level
using the potentiometer accessible through the screw hole in the faceplate.
Use a small flat tip screwdriver to make the adjustment.
Note: Adjust speaker
volume while ambient
noise at the station is at
a minimum.
•Test the installation by making a call as described in the operating section.
Accessing the interior of the Station
Follow these instructions should it be necessary to access the interior of a
station for adjustments or repairs.
•Remove power from the wall station. Follow local safety guidelines.
•Remove the module as follows:
oRemove the lower access plate/switch plate.
oUndo the four captive screws securing the module.
oGently pull the top of the module faceplate away from the enclosure a
couple of times; then push it back into place.
oUsing two hands pull out the bottom of the module faceplate to release it
from the connector.
Note: Be careful when
removing the module.
The circuit board is on
the faceplate.
•
Perform the necessary adjustments or repairs.
•
Replace the module ensuring that the connector is properly seated.
•
Apply power to the wall station.
•Test the installation by making a call as described in the operating section.

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 13
Ambient Noise Level Adjustment
The Ambient Noise Sensor on Guardian's Page/Talk stations automatically
adjusts the volume of the associated loudspeaker up to 10dB, so that pages
can be heard over the background noise.
There are two controls on the circuit board to adjust the Ambient Noise
Sensor mechanism. The Paging Speaker Volume Control – which is
accessible either from the faceplate or from the back of the module – sets
the volume of the speaker to a comfortable level when the ambient noise is
at a minimum. The Ambient Noise Monitor Adjustment Control determines
how the speaker volume tracks the ambient noise. That is if the speaker is
not loud enough with a high ambient noise the control can be adjusted to
increase the volume. Alternatively if the speaker is too loud with a high
ambient noise the control can be adjusted to decrease the volume. It is
usually not necessary to change the setting of the Ambient Noise Monitor
Adjustment Control since it is set at the factory for average conditions.
Adjustment could be necessary if for some reason the Ambient Noise Sensor
Microphone is shielded from the source of ambient noise or some similar
situation exists.
See: Figure 10 -
Adjustments

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 14
Group Muting
In order to avoid acoustical feedback it may be desirable in certain
circumstances to mute speakers associated with adjoining stations when
making a paging call. This can be accomplished by interconnecting the “Group
Mute” terminals of each station in the group, and setting the speaker mute
jumpers on the circuit boards to the appropriate position.
See: Figure 9 - Electrical
Connections and
Figure 10 - Adjustments
Note: Putting the mute jumper of a station in the on position will mute the
associated speaker when the page button is pressed. If the jumper is in
the off position the speaker will not be muted when the page button is
pressed.
If group muting is used the associated speaker of any station in the group with
its mute jumper in the on position will be muted when a paging call is made
from any station in the group, including the associated station. Any speaker
associated with a station with its mute jumper in the off position will not be
muted when a paging call is made from any station in the group, including the
associated station.
Note: Paging calls
originating from stations
outside the group will be
heard regardless of the
position of the Mute
jumper.
If it is desired to bypass a station in a group, connect the group paging wires to
the PARK terminals of that station.
EXAMPLE OF GROUP MUTING
If the Group Mute Signal Conductors are attached to the Park terminals of station “B” that station will be
bypassed and paging from stations “A” or “C” will have no effect on the output of the loudspeaker
associated with Station “B”.
If the Group Mute Signal Conductors are attached to the Mute terminals of station “B” the condition of
the loudspeaker associated with that station will depend on the setting of the Mute On/Off jumper. If
the jumper is in the ON position the loudspeaker will be muted if a paging call is made from any of the
three stations. If the jumper is in the OFF position the paging call will not be muted if a paging call is
made from any of the three stations.
Paging calls from outside the Group will always be heard, regardless of the position of the mute jumper.

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 15
Operating the Single Line Station
Initiating a Call Note: There is one talk
line on the single line
station.
•Remove the handset.
•Ensure that the line is free.
Broadcasting a Page
•
Press and hold the Page button on the handset.
Note: Continue holding
down the Page button
while broadcasting the
page.
•
Broadcast the page. (e.g. "Joe, I need to talk to you, pick up a handset.")
Connecting with a Second Party
•When the second party picks up their handset, both parties are connected
and can carry on a conversation.
Note: The second party
can be located at any
other station.
Freeing the Line
•Place the handset back on the cradle.
•
Check to ensure that the off-hook detector LED is out.
Operating the Five Line Station
Initiating a Call Note: There are five
talk lines on the five line
station.
•Remove the handset.
•Select a free line using the
Line
selector.
Broadcasting a Page
•
Press and hold the Page button on the handset.
Note: Continue holding
down the Page button
while broadcasting the
page.
•Broadcast the page that includes the number of the line you are using. (e.g.
"Joe, talk to me on line one.")
Connecting with a Second Party
•When the second party selects the appropriate channel and picks up their
handset, both parties are connected and can carry on a conversation.
Note: The second party
can be located at any
other station.
Freeing the Line
•Place the handset back on the cradle.
•
Check to ensure that the off-hook detector LED is out.

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 16
Troubleshooting
Note: If access to the interior of the station is required refer to the appropriate
section.
See: Accessing the
interior of the Station
Station Is Dead but Associated Speaker Is Working
•
No Repair Possible, Return Module for Repair.
See: Warranty and
Product Return
Station Is Dead and Associated Speaker Is Not Working
•
Ensure power is being supplied to the station.
•Check the fuse located on the circuit board and replace if necessary.
Correct the problem that caused the fuse to fail.
See: Specifications for
correct fuse rating
Handset Microphone Volume Too Low
•
Adjust TX level control on circuit board.
Handset Receiver Volume Too Low
•Adjust RX level control on circuit board.
Feedback or Distortion
•Adjust sidetone level control on circuit board.
•Inspect the line and connections for shorts and grounds.
•Ensure that the line balance assembly is loading the lines properly. 33
Ohms for Talk lines and 33 to 133 Ohms for Page lines
Sidetone
•Adjust sidetone level control on circuit board.
Station Stays On or Off Hook (LED Status Indicator On)
1. Ensure power is being supplied to the station.
2. Test the proximity switch in the handset receiver cradle by moving a
small, permanent magnet over the area while listening on the handset for
the line to open and close.
3. If the movement of the magnet switches the on/off hook condition, the
magnet in the receiver cartridge of the handset may be weak – try another
handset. It is not necessary to wire in the new handset to perform this test
– if the new handset switches the on/off hook condition, replace the
existing handset with the new unit.
4. If the movement of the magnet does not appear to switch the on/off
hook condition the handset itself may be defective – try another handset.
5. If these remedies do not correct the problem return the module for
repair.
See: Warranty and
Product Return
Excessive Noise on Line
•Verify no other station's handset is off the hook.
Crosstalk
•Inspect wire terminations for crossed wire pairs.

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 17
Specifications
ELECTRICAL REQUIREMENTS
INPUT VOLTAGE
24 -30VDC, 20 -26 /90-140 /200-260 VAC
AC INPUT FREQUENCY
50/60HZ
INPUT VOLTAGE/CURRENT/FUSE 24VDC/0.5AMP/1A SLOW BLOW
24VAC/0.5AMP/1A SLOW BLOW
120VAC/0.1AMP/0.5A 250V
230VAC/0.05AMP/0.25A 250V
HANDSET AMPLIFIER
OUTPUT LEVEL
1.5VRMS NOMINAL INTO 33 OHM LOAD
OUTPUT LIMITER
1.5VRMS NOMINAL
TRANSMIT GAIN
50dB
FREQUENCY RESPONSE
250 –4000HZ
DISTORTION
1.0% MAXIMUM THD @1000HZ
SPEAKER AMPLIFIER
OUTPUT LEVEL
12 WATTS MAXIMUM WITH NOMINAL VOLTAGE
AMPLIFIER GAIN
0.5VRMS AT RATED OUTPUT
FREQUENCY RESPONSE
250 –4000HZ
DISTORTION
1% MAXIMUM THD @1000HZ 10WATTS
INPUT IMPEDANCE
200K OHMS,NOMINAL
LOAD IMPEDANCE 4 TO 16 OHMS (NOT LESS THAN 8OHMS FOR CONTINUOUS
SERVICE)
ENVIRONMENTAL
WEATHER TIGHT
ENCLOSURE GASKET
DUST TIGHT
ENCLOSURE GASKET
MECHANICAL
FACEPLATE AND SWITCH PLATE
STAINLESS STEEL
PTR (PPR) DIMENSIONS (H X WX D)
8
1
/8X 8
1
/8X 5¼(6 ½)INCHES/206 X 206 X 133 (165) MM
PTA (PPA) DIMENSIONS (H X WX D)
8
1
/8X 8
1
/8X 2¼(3 ½)INCHES/206 X 206 X 58 (89)MM
PTR (PPR) NET WEIGHT
4.5 LBS/2 KG
PTA (PPA) NET WEIGHT
3.7 LBS/1.7 KG
HANDSET MATERIAL HIGH IMPACT ABS
MICROPHONE NOISE CANCELING DYNAMIC
COMPLIANCE
MODELS WITHOUT HEADSET CONNECTORS ARE APPROVED FOR USE IN HAZARDOUS AREAS WHEN
INSTALLED IN CONFORMANCE WITH CSA CERTIFICATE OF COMPLIANCE 1289924 (LR65547). PLEASE
VISIT WWW.GUARDIANTELECOM.COM TO OBTAIN A COPY OF THE PRODUCT COC.

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 18
Warranty
Guardian Telecom warrants your product to be free of defects in material and workmanship for a period
of one year. Guardian Telecom will repair or replace any defective unit that is under warranty free of
charge.
This warranty is null and void if any non-authorized modifications have been made to this product, or if
it has been subjected to misuse, neglect, or accident. This warranty covers bench repairs only; such
repairs must be made at Guardian Telecom or an authorized service depot. Guardian Telecom is not
responsible for costs incurred for on-site service calls, freight, or brokerage.
A return authorization must be obtained prior to warranty claims or repairs.
Disclaimer
The products covered by this manual are designed for use in Industrial Environments and/or Hazardous
Locations. Due to the range of possible applications for these instruments the manufacturer will not be
responsible for damages or losses of any kind suffered as a result of the use of this product, including
consequential damages.
Warning
High voltages may be present in this product, ensure that power is removed before installing,
performing maintenance or making repairs.
Service Telephone Number
1-800-363-8010 Toll Free In North America
Guardian Telecom provides a customer service telephone number which is toll-free within North
America. If you need assistance when installing or operating this product, please call the toll-free
telephone number between regular business hours (7:30AM-5:00PM), Mountain Standard Time. If you
are calling outside of regular business hours, please leave a detailed message, and a member of
Guardian Telecom’s Service Department will return your call as soon as possible. If your product
requires service, Guardian personnel will supply you with an RMA (Return Materials Authorization)
number over the telephone or through our web site product return page. This number must be included
with your return address and the name of the person to contact.
Guardian Telecom
Toll-free 1-800-363-8010
Ph. [phone]
Fax. [phone]
www.guardiantelecom.com
Feedback
Guardian Telecom continually strives to make reliable, durable, and easy to use products. If you, as an
installer or user of our equipment, have any suggestions for improvements to this or any of our products
or documents, including this manual, we would appreciate hearing from you.

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 19
Guardian Product Return
Guardian products have been quality tested and are in full working order when shipped
from the factory, given the rugged nature of these products shipping is not expected to
damage a unit. In the unlikely event of a malfunction, Guardian follows the three step
procedure below.
Step I - On-Site Correction
•The most common source of difficulties with a new product is improper installation in
one of two ways: incorrect wiring connections or connection to an incorrect power
source.
•Product wiring needs to be properly connected to the on-site wiring. Correct wiring
instructions are shown in the user manual included with the product.
Step II - Return Materials Authorization (RMA)
•When a product has been installed following user manual instructions, and the unit
fails to operate, the user must contact Guardian Telecom to obtain authorization to
return the product. This can be done by completing a RMA form online at
www.guardiantelecom.com, or by calling the service telephone number given in this
manual.
•After providing information on the product, the owner and the nature of the problem,
Guardian will issue a RMA number, to be shown on documentation returned with the
product.
•In addition to the RMA number, shipping documents should include name, address
and telephone number of the owner along with contact information for the person
responsible for the repair and/or the user who identified the malfunction.
•(Where a product is being returned for repair from outside of Canada, customs
documentation must show the product’s serial number, date of export [date of
purchase], and a notation that the equipment is: “Canadian goods returning.”)
Step III - Factory Authorized Service
•Once received, each product is carefully inspected and tested. If the product is under
warranty, repairs are completed and the product returned to the owner, generally
within five working days of receipt by the factory.
•A product that has been subjected to misuse, neglect or accident or is beyond the
warranty period will be evaluated. The service department will provide the owner’s
representative with a repair cost estimate. Once approved, repairs are completed
and the product returned, generally within five working days.

Guardian Telecom Installation and Operation
Models PTR, PTA, PPR & PPA
Page 20
Typical Installation
Cleaning Tips for Guardian Communication Products
Guardian Products may occasionally need to be cleaned to maintain appearance. Generally, wiping the
surface with a clean, water dampened cloth will remove most films or residues. If the soiling is too
stubborn for plain water, a mild detergent solution may be used. Be sure to wipe away any detergent
residue with a plain water dampened cloth. The Product may be cleaned with any general-purpose
household glass and surface type cleaner. Do not spray the Product directly! Spray the cleaner on a soft
cloth then wipe the surface. Pre-treated cloths, like those used for eyeglasses or cameras, may be used
to clean the Product. Remoistened novelettes may also be used, however, avoid those containing lanolin
or aloe as they will leave a slippery residue. The handset and surface of the Product may be cleaned
with disinfectants used for general cleaning in a medical environment. Isopropyl alcohol may be used
applied with a cloth. Avoid using alcohol on silicon based keypads, since doing so may significantly
degrade legibility.
•Do not use furniture polishes, waxes or plasticizer-based cleaner (Armor all etc.)
•Do not use lanolin, aloe, glycerin or other skin care type products.
•Do not apply any solvent such as acetone, mineral spirits etc.
