Cirro Eleaf Ipower User manual

*Important notice*
To avoid overheating we recommend to turn off the device while transporting. Always
use compatible chargers provided.
Eleaf Ipower (5000 mAh)
Product Introduction
The IPower comes with an ultra-large battery capacity of 5000mAh in a compact design, which can last you for a
remarkably long time at any power setting. Not only does it apply the new firmware with Smart mode and custom
logo, the IPower also has a fashionable look and comes in many attractive colours to choose from.
How to use?
Power on/off: Press the fire
button 5 times in quick
succession to turn on/off the
device. Keep holding the fire
button to take a puff when the
device is powered on.
Stealth on/off: Press the fire
button and down button simultaneously when the device is powered on to switch between Stealth On and Stealth
Off mode. In Stealth On mode, you can vape with the OLED screen off and you can press the fire button one time to
see current setting.
Adjustment buttons lock/unlock: Keep pressing up button and down button simultaneously for two seconds
when the device is powered on, then the up and down buttons will be locked and the screen will display “Lock”. In
the same way, the up and down buttons can be unlocked and the screen will display “Unlock”. Through this
operation, you can protect the buttons from unintentional presses and prolong their lifespan.
Switch display mode: Keep pressing up button and down button simultaneously for two seconds when the device
is powered off, the screen display will rotate 180 degrees. You can view the screen from two different angles
through this operation.
Switch vaping modes: Long press the mode button to switch among VW, Bypass, Smart, TC-Ni, TC-Ti, TC-SS, TCR-
M1, TCR-M2, TCR-M3 modes.
1) In VW mode: When set in VW mode, the device can support a coil whose resistance is within the range of
0.1ohm-3.5ohm
Adjust wattage: In VW mode, the output wattage can be adjusted from 1W to 80W by pressing the up or
down button, up button to increase and down button to decrease. Keep the button pressed continuously to
rapidly increase or decrease the wattage level.
2) In Bypass mode: Direct output voltage system is applied in Bypass mode. The higher the battery level is,
the higher the output voltage is. When set in this mode, the device can support a coil whose resistance is
within the range of 0.1ohm-3.5ohm.
3) Smart mode: In Smart mode, the wattage can be adjusted from 1W to 80W by pressing up button or down
button only when an atomizer is installed on the device. The Smart mode will save one output power setting
for each resistance value and can totally save ten groups of such profiles. Once you change the output power
setting for a resistance, it will re-save the changed setting automatically. When the Smart mode has already
remembered ten profiles and you want to add another new resistance, the first saved profile will be deleted.
When set in this mode, the device can support a coil whose resistance is within the range of 0.1ohm-
3.5ohm.

The Setting of TCR Mode (M1,M2,M3): For the expert vaper there is the Temperature Coefficient of Resistance
(TCR) mode which allows the devise to support different temperature control coils. These are under the modes M1,
M2 and M3. These modes allow for alternate Coils to be used (includes re-buildable for the more experienced Vaper)
these modes are not needed when using Eleaf coils provided with the kit or the Eleaf temperature control Nickel
coils.
4) In TC-Ni/TC-Ti/TC-SS/TCR(M1, M2, M3) Mode: When set in TC-Ni/TC-Ti/TC-SS mode, the device can
separately support Nickel 200, Titanium, and 316 Stainless Steel coils. In TCR (Temperature Coefficient of
Resistance) mode, the device can support different temperature control coils within different TCR value
ranges and you can set the TCR at different values within proper range. (Resistance range of coil: 0.05ohm-
1.5ohm)
5) When the device is powered off, keep pressing the fire button and the up button simultaneously, then you
will enter into the TCR (M1,M2,M3) set menu:
1. Press the up or down button to choose among M1, M2 and M3;
2. Press the fire button one time to confirm the mode you chose;
3. Press the up or down button to increase or decrease the TCR value according to the material of the coil you used;
4. Keep holding the fire button or stay in the interface for about 10 seconds to confirm your setting.
Following are different TCR value ranges for different coils for your reference:
Adjust wattage: In TC-Ni/TC-Ti/TC-SS/TCR (M1,M2,M3) mode, the output wattage can be adjusted from 1W to
80W. Keep pressing the mode button and up button simultaneously without looseness to increase the wattage level.
On the contrary, keep pressing the mode button and down button simultaneously without looseness to decrease the
wattage level.
Adjust temperature: In TC-Ni/TC-Ti/TC-SS/TCR(M1,M2,M3) mode, temperature can be adjusted from 100-315℃
or 200-600℉by pressing up button or down button, up button to increase and down button to decrease. Each press
of the up or down button will increase or decrease the temperature setting by 5℃or 10℉. Long press up button or
down button can rapidly increase or decrease temperature setting.
Shift between ℃and ℉:If you increase the temperature to 315 ℃, and continue to press the up button, the
temperature reading will automatically change to the lowest Fahrenheit (200℉). Equally, if the temperature is set at
the lowest Fahrenheit (200℉) and you continue to press the down button, the temperature reading will
automatically change to the highest Celsius (315 ℃).
Lock/Unlock resistance: In TC-Ni/TC-Ti/TC-SS/TCR(M1,M2,M3) mode, keep pressing the fire button and up button
simultaneously for two seconds to lock or unlock atomizer “base resistance”. The lock sign will appear when
resistance is locked and “Ω” symbol will come back when unlocked.
Note:
1. Please lock the resistance when the coil is at room temperature so that the device can display the correct “base
resistance”.
2. In resistance lock mode, when you remove the coil and then put it back, the device can maintain the same “base
resistance” although the coil resistance may increase due to the rise of temperature. In resistance unlock mode,
when you remove the coil and then put a coil back, the screen may display “New coil up same down” as the coil
resistance may increase within certain range. If it is the same coil, press the down button and if it is a new coil,
press the up button. But please unlock the resistance when you want to change an atomizer or a coil of
different resistance.

3. When using a common coil or a coil whose resistance is above 1.5ohm in TC-Ni/TC-Ti/TC-SS/TCR (M1,M2,M3)
mode by mistake, the device will automatically switch to VW mode.
How to put custom logo in the device?
Download the file on our official website, plug the device in with USB cable, and double click the EleafUpdate.exe.
Then click “LOGO” and open the image you choose to put it in the device. Finally press the fire button twice in quick
succession when the device is powered on to enter logo on/off interface and press up or down button one time to
turn on/off logo.
Note:
1. Please make sure the image you choose is a monochrome image of 96*16 pixel in the format of bmp.
2. If you fail to put the custom logo in and the device shuts down, press the down button one time to restart the
device.
Firmware Upgrading: The firmware can be upgraded by connecting the device with a computer through the USB
port via a micro USB cable.
Functions of Micro USB Port Charging:
The battery power indicator on the screen of iPower will keep flashing when the remaining power of the device is
less than 10%.
The device can be charged through USB port at the bottom of the device via 1A wall adapter or a computer. It will
take about 6.5 hours to get a full charge via 1A wall adapter.
Properties
Atomizer Protection: Each time when vaping time exceeds ten seconds, the output shuts off automatically with
“Over 10s” display on the screen.
Atomizer Short-circuit & No Atomizer Protection: When atomizer short-circuit occurs, the OLED screen will
display “Atomizer Short”. The screen will display “No Atomizer” when there is no atomizer connected.
Low-voltage Protection: When the voltage of the device is below 3.3V, the OLED screen will display “Lock” and the
output will cut off automatically. Charge the device to reactivate it.
Temperature Protection: In TC-Ni/TC-Ti/TC-SS/TCR(M1,M2,M3) mode, when the actual temperature of coil
reaches the set temperature, the screen will display "Temp Protection".
Temperature Alert: If the temperature of device is over alert temperature, the output will shut off automatically
and the screen will display “Device Too Hot”. You can continue to vape after it cools down.
Precautions
1. Only have your iPower repaired by Eleaf. Do not attempt to repair the unit by yourself as damage or personal
injury may occur.
2. Do not leave the iPower in high temperatures or damp conditions, otherwise it may be damaged. The appropriate
operation temperature is within 0℃to 45℃ while charging and -10℃to 60℃while using.
3. Do not attempt to combine the iPower with parts from other brands of e-cigarettes. If it is damaged in this way,
our company will not take on responsibility and your warranty will be void.
Warnings
1. Please keep out of reach of children.
2. This device is not recommended for use by young people or non-smokers.
Please read the full instruction manual which was provided with this product.
