CIS CL-OPT200T Installation instructions

CL-OPT200T/R Rev.900-759-30-00
©2013 CIS Corporation. All rights reserved.
English
Camera Link⇔Optical Signal Converter
CL-OPT200T/R
Product Specification
& Operation Manual
CIS Corporation

CL-OPT200T/R Rev.900-759-30-00
©2013 CIS Corporation. All rights reserved.
2
Table of Contents
PAGE
1. Scope of Application........................................................................................................................................... 3
2. Handling Precautions.......................................................................................................................................... 3
3. Product Outline.................................................................................................................................................. 5
3.1. Product Configuration................................................................................................................................. 5
3.2. Packaging .................................................................................................................................................. 5
4. Specifications..................................................................................................................................................... 6
4.1. General Specifications................................................................................................................................. 6
4.2. External Input/Output Signals ..................................................................................................................... 7
5. Function Settings ............................................................................................................................................... 8
6. External Connector Interface...............................................................................................................................9
6.1. 6pins circular connector HR10-7R-6PA (HIROSE) or equivalent (for both CL-OPT200T/R).......................... 9
6.2. Camera Link Connector 12226-1100-00PL (SUMITOMO 3M)......................................................................... 9
6.3. Optical Module Connector AFBR-57D9AMZ (AVAGO) (for both CL-OPT200T/R) ............................................ 10
7. LED Status Indication ....................................................................................................................................... 11
8. Selection of Power Feeding Method ................................................................................................................... 11
9. Precautions for Power Over Camera Link (PoCL) ................................................................................................ 12
10. Connection Example......................................................................................................................................... 12
11. Dimensions...................................................................................................................................................... 13
11.1. CL-OPT200T Dimensions........................................................................................................................... 13
11.2. CT-OPT200R Dimensions........................................................................................................................... 14
12. Cases for Indemnity (Limited Warranty)............................................................................................................. 15
13. Product Service................................................................................................................................................ 15

CL-OPT200T/R Rev.900-759-30-00
1. Scope of Application
This is to describe CL-OPT200T/R signal converters enable CIS camera link cameras to connect with
frame grabber boards via optical fiber cables. All specifications contained herein are subject to
change without prior notice. Reproduction in whole or in part is prohibited.
2. Handling Precautions
The signal converters must not be used for any nuclear equipments or aerospace equipments with
which mechanical failure or malfunction could result in serious bodily injury or loss of human life.
Our warranty does not apply to damages or defects caused by irregular and/or abnormal use of the
product. Please observe all warnings and cautions stated below.
Our warranty does not apply to damages or malfunctions caused by neglecting these precautions.
zCL-OPT200T can be used only with CIS camera link cameras. Output CLK of CL-OPT200R is 81MHz
fixed. To capture the images, please use a frame grabber board corresponds to 85MHz.
zPlease use a metallic frame for heat dissipation. (The recommended size of the metallic frame:
larger than H:2mm W:90mm D:90mm) CL-OPT200T/R Main Unit
CL-OPT200Fixing Bracket
zDo not use or store the converter in the following extreme conditions:
¾Extremely dusty or humid places.
¾Extremely hot or cold places (operating temperature –5 to +4℃5)℃
zDo not apply excessive force or static electricity that could damage the converter.
zFollow the instructions in Chapter 6, “External connector interface” for connecting.
Improper connection may cause damages not only to the converter but also to the connected
devices.
©2013 CIS Corporation. All rights reserved.
3

CL-OPT200T/R Rev.900-759-30-00
zConfirm the mutual ground potential carefully and then connect the converter to monitors or
computers. AC leaks from the connected devices may cause damages or destroy the converter.
zDo not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power
supply voltage may cause damages or malfunction of the converter.
zThe voltage ripple of converter input power DC +12V±10% shall be within ±50mV.
zThe rising time of converter input power supply voltage shall be less than +10V, Max 60ms.
Please avoid noises like chattering when rising.
In case of abnormal operation, contact the distributor from whom you purchased the product.
©2013 CIS Corporation. All rights reserved.
4

CL-OPT200T/R Rev.900-759-30-00
©2013 CIS Corporation. All rights reserved.
5
3. Product Outline
CL-OPT200T and CL-OPT200R are signal converters enable CIS camera link cameras to connect with
frame grabber boards via optical fiber cables. With optical fiber cables, data can be transmitted up to
150m length.
Please be noted that only CIS cameras can be connected to CL-OPT200T/R.
Key Features
□ With optical fiber cables, data can be transmitted up to 150m length.
□ Owing to optical fiber cable connection, no radio interference or grand noise would occur.
□ Comply with Camera Link Base/Medium Standard
□ Only CIS camera link non-PoCL and PoCL cameras can be connected.
□ As to PoCL, there are some limitations. (Please refer to page 10 for the details.)
3.1. Product Configuration
□CL-OPT200T (Camera Link → Optical Signal Converter)
□ CL-OPT200R (Optical Signal → Camera Link Converter)
3.2. Packaging
□ Individual Carton
□ Sub Carton (10 pieces/carton)
□ Master Carton (100 pieces/carton)
Note: Master carton may change depends on the quantities to be shipped per delivery.

CL-OPT200T/R Rev.900-759-30-00
©2013 CIS Corporation. All rights reserved.
6
4. Specifications
4.1. General Specifications
(1) Power Requirements DC+12V±10% (Max voltage not to exceed 15V.)
6pins circular connector or PoCL Input (with limitation).
(2) Power Consumption CL-OPT200T : Typ 4.3W / CL-OPT200R : Typ 3.8W
(3) Dimensions
Refer to overall dimension drawing (H:25mm W:60mm D:90mm without protruding portion)
(For both CL-OPT200T/R)
(4) Weight Approx. 200g (For both CL-OPT200T/R)
(5) Camera Link
Input/Output Connector CL-OPT200T/R (For both CL-OPT200T/R) mini Camera Link connector 12226-1100-00PL (SUMITOMO 3M)
CL-OPT200T
Camera Link non-PoCL or PoCL Input
Camera Link input CLK frequency: Driver IC rated 20MHz ～80MHz
Base Configuration/Medium Configuration
CL-OPT200R
Camera Link Output
Camera Link output CLK frequency: 81MHz fixed
(Please connect with a frame grabber board corresponds to 85MHz.)
Base Configuration/Medium Configuration
(6) Optical Connector
LC duplex connector Optical Module Rated: 8 Gb/s
Light wavelength: 850nm
Transmission Bandwidth: 6.125 Gb/s
AFBR-57D9AMZ(AVAGO)
(7) Optical Fiber Cable
Length Max. 150m
(8) Supported Cameras CIS tested Camera Link, non-PoCL, and PoCL cameras.
Base Configuration Camera Series:
VCC-G22/F22 (pixel clk: 49.09MHz) series
VCC-G32/F32 (pixel clk: 72MHz) series
VCC-G60 (pixel clk: 64MHz) series
VCC-GC20/FC20 (pixel clk: 79.99MHz) series
Medium Configuration Camera Series:
VCC-F51/F52 (pixel lk: 72MHz) series
VCC-GC60/FC60 (pixel clk: 72MHz) series
VCC-GC21/FC21 (pixel clk: 80MHz) series
Cannot run the camera at Full Configuration Mode.
(Please contact our sales department regarding connections not listed
above.)
(9) Trigger Delay Referenced Value (measured value with Fujikura
DXLC-2P-PC-(L)M-GC50/125-25R Optical cable)
About 700ns (Circuit Fixed delay) + (5ns x L:Optical cable length (m))
(10) Video Delay Less than 1Line (Refer to the spec of camera to be connected.)
(11) Serial Communications 9600bps fixed
Note: Set the frame grabber at 9600bps.
(12) Safety/Quality Standards UL: Conform to UL Standard including materials and others.
CE: Emission: EN55022:2010 (Class B)
Immunity: EN61000-6-2:2005

CL-OPT200T/R Rev.900-759-30-00
RoHS: Conform to RoHS
FCC: To be applied
(13) Durability Vibration
resistance Acceleration : 98m/s2(10G) Frequency
: 20～200 Hz
Direction : X,Y, and Z, 3 directions
Testing time : 120min for each direction
Shock
resistance No malfunction shall be occurred with 980m/s2(100G) for
±X, ±Y, and ±Z, 6 directions. (without package)
(14) Operation Environment Operation
Temeprature -5 ～+45℃With RH 20～80% With no condensastion
(15) Storage Environment -25 ～+60℃with RH20 ～80% with no condensation
4.2. External Input/Output Signals
(1)GPIO FVAL output :No.3pin 6pins circular connector
(LVTTL output)
External Trigger input :No.4pin
IO Interface of 6 pins circular connector at rear
©2013 CIS Corporation. All rights reserved.
7

CL-OPT200T/R Rev.900-759-30-00
5. Function Settings
With internal dip switch, trigger signals input can be selected.
(1) SW2-1 ・・・ OFF : (Initial Setting)
(1) SW2-2 ・・・ OFF : (Initial Setting)
(2) SW2-3 Trigger input
selection
・・・ ON : 6 pins circular connector input
OFF : Camera Link (CC1) input (Initial Setting)
(3) SW3-1 Camera Link
Configuration
・・・ OFF : Base/Medium (Initial Setting)
ON : Do not use.
(4) SW3-2 ・・・ OFF : Not used (Initial Setting)
(5) SW3-3 ・・・ ON : Not used
・・・ OFF : Not used (Initial Setting)
©2013 CIS Corporation. All rights reserved.
8

CL-OPT200T/R Rev.900-759-30-00
6. External Connector Interface
6.1. 6pins circular connector HR10-7R-6PA (HIROSE) or equivalent (for both CL-OPT200T/R)
©2013 CIS Corporation. All rights reserved.
9
Pin No.
1 Power Input (DC+12V)
2 Power Input (DC+12V)
3 FVAL output
4 External Trigger Input
5 GND
6 GND
6.2. Camera Link Connector 12226-1100-00PL (SUMITOMO 3M)
CL-OPT200T CN1 (Camera Link In: Base side)
Pin No. Pin No.
1 NC/+12V(PoCL) 14 GND
2 X0- 15 X0+
3 X1- 16 X1+
4 X2- 17 X2+
5 Xclk- 18 Xclk+
6 X3- 19 X3+
7 SerTC+ 20 SerTC-
8 SerTFG- 21 SerTFG+
9 CC1- 22 CC1+
10 CC2+ 23 CC2-
11 CC3- 24 CC3+
12 CC4+ 25 CC4-
13 GND 26 NC/+12V(PoCL)
1
14
13
26
CN2 (Camera Link In: Medium Side)
Pin No. Pin No.
1 NC 14 GND
2 Y0- 15 Y0+
3 Y1- 16 Y1+
4 Y2- 17 Y2+
5 Yclk- 18 Yclk+
6 Y3- 19 Y3+
7 100Ω20 Terminated
8 Z0- 21 Z0+
9 Z1- 22 Z1+
10 Z2- 23 Z2+
11 Zclk- 24 Zclk+
12 Z3- 25 Z3+
13 GND 26 NC

CL-OPT200T/R Rev.900-759-30-00
CL-OPT200R CN1 (Camera Link Out: Base side)
Pin No. Pin No.
1 GND/+12V(PoCL) 14 GND
25 X0- 12 X0+
24 X1- 11 X1+
23 X2- 10 X2+
22 Xclk- 9 Xclk+
21 X3- 8 X3+
20 SerTC+ 7 SerTC-
19 SerTFG- 6 SerTFG+
18 CC1- 5 CC1+
17 CC2+ CC2-
16 CC3- CC3+
15 CC4+ CC4-
13 GND 26 GND/+12V(PoCL)
1
14
13
26
CN2 (Camera Link Out: Medium side)
Pin No. Pin No.
1 NC 14 GND
25 Y0- 12 Y0+
24 Y1- 11 Y1+
23 Y2- 10 Y2+
22 Yclk- 9 Yclk+
21 Y3- 8 Y3+
20 100Ω7 Terminated
19 Z0- 6 Z0
18 Z1- 5 Z1+
17 Z2- 4 Z2+
16 Zclk- 3 Zclk+
15 Z3- 2 Z3+
13 GND 26 NC
6.3. Optical Module Connector AFBR-57D9AMZ (AVAGO) (for both CL-OPT200T/R)
LC duplex Connector
©2013 CIS Corporation. All rights reserved.
10

CL-OPT200T/R Rev.900-759-30-00
7. LED Status Indication
LED lights up when the camera, cable, fiber optic cable are linked normally. If it does not light up, please confirm the
followings:
zCamera link cable, camera, and fiber optic cable are not connected.
zNo camera link CLK input
zData transmission failed via optical transmission
zNo power supplied to CL-OPT200T/R
8. Selection of Power Feeding Method
With internal dip switch, power feeding method can be changed.
(1) CL-OPT200T
SW1 ・・・ ON : Feed the power to the converter unit via 6 pins circular
connector. No power is feeded to the camera.
(When non-PoCL camera is connected.)
(Initial Setting)
OFF : Feed the power to both of the converter unit and the
camera via 6pins ciruclar connector.
(When PoCL or PoCL-Lite camera is connected.)
(2) CL-OPT200R
SW1 ・・・ ON : Feed the power to the converter unit via 6 pins circular
connector. (Initial Setting)
OFF : Feed the power to the converter unit via the frame
grabber board.
(When PoCL frame grabber board is connected.)
©2013 CIS Corporation. All rights reserved.
11

CL-OPT200T/R Rev.900-759-30-00
©2013 CIS Corporation. All rights reserved.
12
9. Precautions for Power Over Camera Link (PoCL)
CL-OPT200R (Receiving unit) can operate with power fed via the frame grabber board, but the following
specification does not meet PoCL standard.
When feeding the power via PoCL, please confirm with the power feeding specifications of the frame
grabber board.
(1) The normal output timing of CLK output from the CL-OPT200R to the frame grabber board shall be
maximum 10s after the last power input for the camera, the CL-OPT200T, or the CL-OPT200R.
(2) The intermittent CLK or LVAL/FVAL from the CL-OPT200R may be output to the frame grabber
board, while the camera, the CL-OPT200T, and CL-OPT200R are connected.
10. Connection Example
PoCL Feeder
connection
LC duplex Optical Cable ： Within 150 meters
DXLC-2P-PC-50M-GC50/125-2SR
(ﾌｼﾞｸﾗ社製)
Camera Link
(Base Configuration)
Mini-CL Cable Within
meters
D26-3120-00C-300
友3M社製）
Mini-CL Cable Within
3 meters
1MD26-3560-00C-300
（住友3M社製）
Camera Link
Frame Grabber Bord
CL-OPT200R
CL-OPT200T
3
1S
（住
Circuit
CL IN(M)CL IN(B)
OPT OUTDC IN
CL-OPT200T
CL OUT(M) CL OUT(B)
OPT IN DC IN
CL-OPT200R
Image Data
TriggerSignal
Circuit
Trigger Signal
Power
Supply
(SW2-3)
(SW2-3)
(SW1)
(SW1)

CL-OPT200T/R Rev.900-759-30-00
11. Dimensions
11.1. CL-OPT200T Dimensions
©2013 CIS Corporation. All rights reserved.
13

CL-OPT200T/R Rev.900-759-30-00
11.2. CT-OPT200R Dimensions
©2013 CIS Corporation. All rights reserved.
14

CL-OPT200T/R Rev.900-759-30-00
©2013 CIS Corporation. All rights reserved.
15
12. Cases for Indemnity (Limited Warranty)
We shall be exempted from taking responsibility and held harmless for damage or losses incurred by
the user in the following cases.
zIn case damage or losses are caused by fire, earthquake, or other acts of God, acts by third party,
deliberate or accidental misuse by the user, or use under extreme operating conditions.
zIn case indirect, additional, consequential damages (loss of business interests, suspension of
business activities) are incurred as result of malfunction or non-function of the equipment, we shall
be exempted from responsibility for such damages.
zIn case damage or losses are caused by failure to observe the information contained in the
instructions in this product specification & operation manual.
zIn case damage or losses are caused by use contrary to the instructions in this product specification
& operation manual.
zIn case damage or losses are caused by malfunction or other problems resulting from use of
equipment or software that is not specified.
zIn case damage or losses are caused by repair or modification conducted by the customer or any
unauthorized third party (such as an unauthorized service representative).
zExpenses we bear on this product shall be limited to the individual price of the product.
13. Product Service
In case of abnormal operation, contact the distributor from whom you purchased the product.
