QUICK INSTALLATION GUIDE
Powerline Network
Adapter
Model: PLTE200
Package Contents
Powerline Network Adapter•
Powerline Utility and User Guide•
on CD-ROM
Ethernet Network Cable•
Power Cord•
Quick Installation Guide•
Stand•

Overview
Before you begin, you should have a powerline network already set up, with
your router connected to a Powerline Adapter. The following instructions
describe how to connect the Powerline Network Adapter (model number:
PLTE200) to a computer or other network device.
Internet
Modem
Router
Powerline
Network Adapter Powerline 4-Port
Network Adapter
Gaming Console
Computer
Powerline
Computer
Powerline
Network Adapter
Diagram of a Typical Powerline Network
Installation
A. Connect one end of an Ethernet
network cable to the Ethernet
port of the Adapter.
Connect Ethernet Network Cable

B. Connect the other end to the
Ethernet port of your computer
or other network device.
C. Connect the power cord to the
Power port.
D. Plug the other end into an
electrical outlet.
NOTE: Because the Adapter sends data over the power lines
of your home, Linksys recommends that you plug the Adapter
directly into an electrical outlet. The Adapter has its own power
filter to help protect against surges.
E. The Power, Ethernet, and
Powerline LEDs light up.
NOTE: The Powerline
LED indicates that
the connection between
the Adapter and your
powerline network has
been established.
Hardware installation is complete.
Connect Other End of Network Cable
Connect Power Cord
Plug Power into Outlet
Power, Ethernet, and Powerline LEDs
Light Up

For additional information or troubleshooting help, refer to the User Guide on the CD-ROM.
Additional support is also available by phone or online.
24-Hour Technical Support
800-326-7114
RMA (Return Merchandise Authorization)
http://www.linksys.com/warranty
Website
http://www.linksys.com
FTP Site
ftp://ftp.linksys.com
Support
http://www.linksys.com/support
Sales Information
800-546-5797 (800-LINKSYS)
Linksys, Cisco and the Cisco Logo are registered trademarks or trademarks of Cisco Systems,Inc. and/or its affiliates in the U.S. and certain other
countries. Copyright © 2008 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of
their respective holders.
8070810NC-JL
NOTE: If you want to configure advanced security for your
powerline network, install the Powerline Utility from the included
CD-ROM. For more information, refer to the User Guide on
the CD-ROM.
