Cisco AMP PC3000 Manual

Cisco AMP PC3000 Hardware Installation Guide
First Published: 2019-03-19
Last Modified: 2019-05-03
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: [phone]
800 553-NETS (6387)
Fax: [phone]

THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS,
INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND,
EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.
THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH
THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY,
CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.
The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB's public domain version of
the UNIX operating system. All rights reserved. Copyright ©1981, Regents of the University of California.
NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS" WITH ALL FAULTS.
CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE.
IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT
LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS
HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses and phone numbers. Any examples, command display output, network
topology diagrams, and other figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in illustrative content is unintentional
and coincidental.
All printed copies and duplicate soft copies of this document are considered uncontrolled. See the current online version for the latest version.
Cisco has more than 200 offices worldwide. Addresses and phone numbers are listed on the Cisco website at www.cisco.com/go/offices.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com
go trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any
other company. (1721R)
©2019 Cisco Systems, Inc. All rights reserved.

CONTENTS
Overview 1
CHAPTER 1
Features 1
Package Contents 2
Serial Number Location 3
Front Panel 5
Front Panel LEDs 6
Rear Panel 8
Rear Panel LEDs 9
Power Supply 10
Hardware Specifications 11
Product ID Numbers 12
Power Cord Specifications 12
Installation Preparation 21
CHAPTER 2
Installation Warnings 21
Safety Recommendations 23
Maintain Safety with Electricity 23
Prevent ESD Damage 24
Site Environment 24
Site Considerations 24
Power Supply Considerations 25
Rack Configuration Considerations 25
Mount the Chassis 27
CHAPTER 3
Unpack and Inspect the Chassis 27
Rack-Mount the Chassis 27
Cisco AMP PC3000 Hardware Installation Guide
iii

Connect Cables, Turn on Power, and Verify Connectivity 30
Maintenance and Upgrade 33
CHAPTER 4
Power Button Shut Down 33
Remove and Replace a Drive 34
Remove and Replace a Power Supply 36
Cisco AMP PC3000 Hardware Installation Guide
iv
Contents

CHAPTER 1
Overview
•Features, on page 1
•Package Contents, on page 2
•Serial Number Location, on page 3
•Front Panel, on page 5
•Front Panel LEDs, on page 6
•Rear Panel, on page 8
•Rear Panel LEDs, on page 9
•Power Supply, on page 10
•Hardware Specifications, on page 11
•Product ID Numbers, on page 12
•Power Cord Specifications, on page 12
Features
The Cisco AMP PC3000 appliance supports AMP Private Cloud version 3.0 and later.
The following table lists the features of the Cisco AMP PC3000. See Product ID Numbers, on page 12 for a
list of the spare product IDs (PIDs) associated with the AMP PC3000. You can remove and replace drives
and power supplies. For all other internal component failures, you must send your chassis for RMA.
Table 1: AMP PC3000
DescriptionFeature
2 RUForm factor
Yes
Standard 19-in. (48.3 cm) 4-post EIA rack
Rack mount
Front to rear
Cold aisle to hot aisle
Airflow
Displays the serial number.Pullout asset card
Cisco AMP PC3000 Hardware Installation Guide
1

DescriptionFeature
Yes
Two threaded holes for dual-hole grounding lug.
Use is optional. The supported AC power supplies have internal grounding, so
no additional chassis grounding is required.
Grounding hole
YesLocator beacon
YesPower switch
2 Intel Xeon Gold 6126 processorsProcessor
1.5 TB RAMMemory
Twenty-four 64-GB DDR4-2666-MHz RDIMMsRDIMMs
Two built-in dual 1/10-GB portsManagement ports
2
Version 3.0 Type A
USB ports
One 3-row 15-pin DE-15 connector
Enabled by default.
VGA port
4 fixed SFP+ ports
Supported SFP cables SFP-10G-SR
SFP ports
One 1-GB RJ45 serial port running RS-232 (RS-232D TIA-561)Serial console port
Two 1050-W AC power supplies (hot-swappable and redundant as 1+1)System power
3196 BTU/hrPower consumption
6 fans for front-to-rear coolingFans
Fourteen 800-GB SSDs RAID 6
Ten 1.8-TB SAS HDDs RAID 6
Two 1.2-TB SAS HDDs RAID 1
Hot-swappable
Storage
1RAID controller
Package Contents
The following figure shows the package contents for the AMP PC3000. Note that the contents are subject to
change and your exact contents might contain additional or fewer items.
Cisco AMP PC3000 Hardware Installation Guide
2
Overview
Package Contents

Figure 1: Package Contents
RJ-45 to RJ-45 Cat 5 Ethernet cable,
yellow six feet long (Cisco part number
72-1482-XX)
2Chassis1
Useful Links printed document
The steps in the Useful Links document
send you to the documentation you need
to install, set up, and configure your AMP
PC3000.
4Cisco rail kit (Cisco part number
800-43376-02)
3
SFP+ cables (Optional; in package if
ordered.)
5
Serial Number Location
The serial number (SN) for the AMP PC3000 is printed on the pullout asset card located on the front panel
as shown in the following figure.
Cisco AMP PC3000 Hardware Installation Guide
3
Overview
Serial Number Location

Figure 2: Serial Number on Pullout Asset Card
The serial number is also on the label on the cover of the chassis as shown in the following figure.
The cover latch on the top of the chassis cover is not supported. There are no internal field-replaceable parts
in the AMP PC3000.
Caution
Figure 3: Serial Number Location on Cover
Serial number label1
Cisco AMP PC3000 Hardware Installation Guide
4
Overview
Serial Number Location

Front Panel
The following figure shows the front panel features and disk-drive configuration for the AMP PC3000. See
Front Panel LEDs, on page 6 for a description of the LEDs.
Figure 4: AMP PC3000 Front Panel
Drive bays 15-24 populated with SAS
HDDs for the /other volume.
2Drive bays 1-14 are populated with SSDs
for the /data volume.
1
Unit identification button/LED4Power button/power status LED3
Fan status LED6System status LED5
Power supply status LED8Temperature status LED7
Pullout asset card10Network link activity LED9
-KVM connector
Used with KVM cable that provides one
DB-15 VGA, one DB-9 serial, and two
USB connectors.
11
Cisco AMP PC3000 Hardware Installation Guide
5
Overview
Front Panel

Front Panel LEDs
The following figure shows the front panel LEDs and describes their states.
Figure 5: Front Panel LEDs and Their States
SAS/SATA drive activity LED
• Off—There is no drive in the drive
tray (no access, no fault).
• Green—The drive is ready.
•Green, flashing—The drive is reading
or writing data.
2SAS/SATA drive fault
•Off—The drive is operating properly.
• Amber—Drive fault detected.
• Amber, flashing—The drive is
rebuilding.
• Amber, flashing with one-second
interval—Drive locate function
activated in the software.
1
Unit identification
• Off—The unit identification function
is not in use.
• Blue, flashing—The unit
identification function is activated.
4Power button/LED
• Off—There is no AC power to the
appliance.
• Amber—The appliance is in standby
mode.
• Green—The appliance is in main
power mode. Power is supplied to all
appliance components.
3
Cisco AMP PC3000 Hardware Installation Guide
6
Overview
Front Panel LEDs

Power supply status
• Green—All power supplies are
operating normally.
•Amber—One or more power supplies
are in a degraded operational state.
•Amber, flashing—One or more power
supplies are in a critical fault state.
6System health
• Green—The appliance is running in
normal operating condition.
• Green, flashing—The appliance is
performing system initialization and
memory check.
• Amber—The appliance is in a
degraded operational state (minor
fault). For example:
•Power supply redundancy is lost.
• CPUs are mismatched.
• At least one CPU is faulty.
• At least one DIMM is faulty.
• At least one drive in a RAID
configuration failed.
• Amber, 2 flashes—There is a major
fault with the system board.
• Amber, 3 flashes—There is a major
fault with the memory DIMMs.
• Amber, 4 flashes—There is a major
fault with the CPUs.
5
Network link activity
• Off—The Ethernet Lights Out
Management (LOM) port link is idle.
• Green—One or more Ethernet LOM
ports are link-active, but there is no
activity.
• Green, flashing—One or more
Ethernet LOM ports are link-active,
with activity.
8Fan status
•Green—All fan modules are operating
properly.
• Amber, flashing—One or more fan
modules breached the unrecoverable
threshold.
7
Cisco AMP PC3000 Hardware Installation Guide
7
Overview
Front Panel LEDs

Temperature status
•Green—The appliance is operating at
normal temperature.
• Amber—One or more temperature
sensors breached the critical
threshold.
• Amber, flashing—One or more
temperature sensors breached the
unrecoverable threshold.
9
Rear Panel
The following figure shows the rear panel of the AMP PC3000.
Figure 6: Rear Panel
PCIe riser 2 (PCIe slots 4, 5, 6)
PCIe riser 2 is not supported.
2PCIe riser 1 (PCIe slot 1, 2, 3)
PCIe slot 3 is used for the SFP+ ports.
PCIe slots 1 and 2 are not supported.
1
Power supplies (two, redundant as 1+1)42.5-inch HDD bays containing 1.2-TB SAS
HDDs for the recovery partition
3
Modular LAN-on-motherboard (mLOM)
card slot (x16)
6Threaded holes for dual-hole grounding
lug
5
Dual 1-Gb/10-Gb Ethernet ports (LAN1
and LAN2)
The dual LAN ports can support 1 Gbps
and 10 Gbps depending on the link partner
capability.
82 USB 3.0 Type A ports7
1-Gb Ethernet dedicated Cisco Integrated
Management Controller (CIMC) port
10VGA video port (DB-15 connector)9
Cisco AMP PC3000 Hardware Installation Guide
8
Overview
Rear Panel

Rear unit identification button/LED12Serial port (RJ-45 connector)11
Rear Panel LEDs
The following figure shows the rear panel LEDs and describes their states.
Figure 7: Rear Panel LEDs and Their States
1-Gb/10-Gb Ethernet link status (on both
LAN1 and LAN2)
• Off—No link is present
• Green—Link is active
• Green, flashing—Traffic is present
on the active link
21-Gb/10-Gb Ethernet link speed (on both
LAN1 and LAN2)
• Amber—Link speed is 100 Mbps
• Amber—Link speed is 1 Gbps
• Green—Link speed is 10 Gbps
1
1-Gb Ethernet dedicated management link
status
• Off—No link is present
• Green—Link is active
• Green, flashing—Traffic is present
on the active link
41-Gb Ethernet dedicated management link
speed
• Off—Link speed is 10 Mbps
• Amber—Link speed is 100 Mbps
• Green—Link speed is 1 Gbps
3
Cisco AMP PC3000 Hardware Installation Guide
9
Overview
Rear Panel LEDs

Power supply status (one LED for each
power supply unit)
• Off—No AC input (12 V main power
off, 12 V standby power off)
• Green, flashing—12 V main power
off; 12 V standby power on
• Green—12 V main power on; 12 V
standby power on
• Amber, flashing—Warning threshold
detected but 12 V main power on
•Amber—Critical error detected; 12 V
main power off (for example,
over-current, over-voltage, or
over-temperature failure)
6Rear unit identification
•Off—The unit identification function
is not in use
• Blue, flashing—The unit
identification function is activated
5
SAS/SATA drive activity LED
• Off—There is no drive in the drive
tray (no access, no fault)
• Green—The drive is ready
•Green, flashing—The drive is reading
or writing data
8SAS/SATA drive fault
• Off—The drive is operating properly
• Amber—Drive fault detected
• Amber, flashing—The drive is
rebuilding
• Amber, flashing with one-second
interval—Drive locate function
activated in the software
7
Power Supply
The following table lists the specifications for each 1050-W AC power supply (Cisco part number
UCSC-PSU1-1050W) used in the AMP PC3000.
Table 2: Power Supply Specifications
SpecificationDescription
1313 BTU/hrPower consumption
Nominal range: 100 to 120 V AC, 200 to 240 V AC
Range: 90–132 V AC, 180–264 V AC
AC input voltage range
Nominal range: 50–60 Hz
Range: 47–63 Hz
AC input frequency
Cisco AMP PC3000 Hardware Installation Guide
10
Overview
Power Supply

SpecificationDescription
12.5 A peak at 100 V AC
6.0 A peak at 208 V AC
Maximum AC input current
1250 VA at 100 V ACMaximum input volt amperes
1050 WMaximum output power for each power supply
15 A (subcycle duration)Maximum inrush current
12 ms at 1050 WMaximum hold-up time
12 V DCPower supply output voltage
12 V DCPower supply standby voltage
Climate Savers Platinum Efficiency (80 Plus Platinum
certified)
Efficiency rating
RSP2Form factor
IEC320 C14Input connector
Hardware Specifications
The following table lists the hardware specifications for the AMP PC3000.
Table 3: AMP PC3000 Hardware Specifications
Specification
3.4 x 16.9 x 29.5 in. (8.64 x 42.9 x 74.0 cm)Dimensions (H x W x D)
57.5 lb (26.1 kg)Maximum weight (fully loaded chassis)
Operating: 50 to 95°F (10 to 35°C)
Maximum temperature is derated by 1°F/547 ft
(1°C/300 m) of altitude above 3117 ft (950 m).
Nonoperating: –40 to 149°F (–40 to 65°C) when the
appliance is stored or transported.
Temperature
Operating: 8 to 90% noncondensing
Nonoperating: 5 to 95% noncondensing
Relative humidity
Operating: 0 to 10,000 ft
Nonoperating: 0 to 40,000 ft when the appliance is
stored or transported
Altitude
Cisco AMP PC3000 Hardware Installation Guide
11
Overview
Hardware Specifications

Specification
5.8 Bels (measure A-weighted per ISO7779 LWAd)
Operation at 73°F (23°C)
Sound power level
43 dBa (measure A-weighted per ISO7779 LpAM)
Operation at 73°F (23°C)
Sound pressure level
Product ID Numbers
The following table lists the spare Product IDs (PIDs) associated with the AMP PC3000. The spare components
are ones that you can order and replace yourself. If any internal components fail, you must RMA the entire
chassis including the SFPs and SFP cables. Remove the drives and power supplies before you send the chassis
for RMA. You can view an inventory of PIDs using the Cisco Integrated Management Interface (CIMC). See
Viewing Product ID (PID) Catalog Details for more information.
Table 4: AMP PC3000 PIDs
DescriptionPID
Power supplyAMPPC-AC-1050
Power supply (spare)AMPPC-AC-1050=
1.2-TB hard disk driveAMPPC-HDD-1.2TB
1.2-TB hard disk drive (spare)AMPPC-HDD-1.2TB=
1.8-TB hard disk driveAMPPC-HDD-1.8TB
1.8-TB hard disk drive (spare)AMPPC-HDD-1.8TB=
800-GB solid state driveAMPPC-SSD-800GB
800-GB solid state drive (spare)AMPPC-SSD-800GB=
Rail kitUCSC-RAILB-M4
Rail kit (spare)UCSC-RAILB-M4=
Power Cord Specifications
Each power supply has a separate power cord. Standard power cords or jumper power cords are available for
connection to the AMP PC3000. The jumper power cords for use in racks are available as an optional alternative
to the standard power cords.
If you do not order the optional power cord with the system, you are responsible for selecting the appropriate
power cord for the product. Using a incompatible power cord with this product may result in electrical safety
Cisco AMP PC3000 Hardware Installation Guide
12
Overview
Product ID Numbers

hazard. Orders delivered to Argentina, Brazil, and Japan must have the appropriate power cord ordered with
the system.
Only the approved power cords and jumper cords provided with the AMP PC3000 are supported.
Note
The following power cords and jumper cords are supported.
Figure 8: Argentina CAB-250V-10A-AR
Cord set rating: 10 A, 250 V2Plug: IRAM 20731
Connector: IEC 60320/C133
Figure 9: Australia CAB-9K10A-AU
Cord set rating: 10 A, 250 V2Plug: A.S. 3112-20001
Connector: IEC 60320/C153
Figure 10: Brazil PWR-250V-10A-BZ
Cisco AMP PC3000 Hardware Installation Guide
13
Overview
Power Cord Specifications

Cord set rating: 10 A, 250 V2Plug: NBR 141361
Connector: IEC 60320/C133
Figure 11: Cabinet Jumper CAB-C13-C14-2M
Cord set rating: 10A, 250V2Plug: SS10A1
Connector: HS10S, C-13 to C-143
Figure 12: Cabinet Jumper CAB-C13-C14-AC
Cord set rating: 10 A, 250 V2Plug: SS10A1
Connector: HS10S, C-13 to C-14 (recessed
receptacle)
3
Figure 13: Cabinet Jumper CAB-C13-CBN
Cord set rating: 10 A, 250 V2Plug: SS10A1
Connector: HS10S, C-13 to C-143
Cisco AMP PC3000 Hardware Installation Guide
14
Overview
Power Cord Specifications

Figure 14: China CAB-250V-10A-CH
Cord set rating: 10 A, 250 V2Plug: GB2099.1/20081
Connector: IEC 60320/C133
Figure 15: Europe CAB-9K10A-EU
Cord set rating: 10 A/16 A, 250 V2Plug: CEE 7/7 (M2511)1
Connector: IEC 60320/C15 (VSCC 15)3
Figure 16: India CAB-250V-10A-ID
Cord set rating: 16 A, 250 V2Plug: IS 6538-19711
Connector: IEC 60320-C133
Cisco AMP PC3000 Hardware Installation Guide
15
Overview
Power Cord Specifications

Figure 17: Israel CAB-250V-10A-IS
Cord set rating: 10 A, 250 V2Plug: SI-321
Connector: IEC 60320-C133
Figure 18: Italy CAB-9K10A-IT
Cord set rating: 10 A, 250 V2Plug: CEI 23-16/VII (I/3G)1
Connector: IEC 60320/C15
(EN 60320/C15M)
3
Figure 19: Japan CAB-JPN-3PIN
Cord set rating: 12 A, 125 V2Plug: JIS 83031
Connector: IEC 60320/C133
Cisco AMP PC3000 Hardware Installation Guide
16
Overview
Power Cord Specifications
