Cisco Profile Series User manual

Microphone installation guide for Profile Series with Codec C40 and C20
78-19808-02 Profile C40-C20 Microphone Installation Sheet | September 2011 | © 2010-2011 Cisco Systems, Inc. All rights reserved.
Using one or two microphones
Profile systems with Codec C40 and C20 are shipped with two microphones.
Normally a single microphone should suffice to serve all the participants, as
shown in room setup A to the right.
However, if this is not the case you will need to use two microphones, as
shown in room setup B. You must then make sure the microphones are spaced
sufficiently apart to avoid that the sound of the first microphone suffers from
interference from the second microphone.
How to place the two microphones
As a rule of thumb: The second microphone should be placed three times
or longer away from a participant (MIC 2 - distance 3x) compared to the
microphone closest to that participant (MIC 1 - distance x). This is the case for
all participants.
If you cannot fulfill the requirement you might not need the second microphone
in the first place. Instead, inspect the site to ensure that all participants have
eye contact with the microphone when using the system.
Installing the microphones
Place the microphones on the table and lead the cables toward the rear side
of the Profile system.
Open the rear door in the base module and locate the microphone connectors
on the codec. Connect the microphone cables as shown on the next page.
User documentation
User documentation is available on the Cisco web site.
Go to: http://www.cisco.com/go/telepresence/docs.
Room setup A
A room with four or less participants requires one microphone.
The distance between the video system and the table is 1.5m (5ft).
Profile system
MIC 1
Camera view,
max zoom
Room setup B
A room with more than four participants requires two microphones.
The distance between the video system and the table is 1.5m (5ft).
MIC 1 MIC 2
x3x
Participant
Profile system
Camera view,
max zoom

Microphone installation guide for Profile Series with Codec C40 and C20
78-19808-02 Profile C40-C20 Microphone Installation Sheet | September 2011 | © 2010-2011 Cisco Systems, Inc. All rights reserved.
PC cable (DVI/VGA)
Ethernet cable
Profile system, rear door
Profile system,
front side
Cables
from the
microphones
placed on the
table.
Codec C40
Connect the microphone cables
The codec is in the bottom module
of the Profilesystem.
Power cable
Note: Strap the cables and take care
not to shut the cables in the rear door.
Codec C20
Connect the microphone cables Ethernet cable
PC cable (DVI/VGA)
Profile system, rear door
Profile system,
front side
Cables
from the
microphones
placed on the
table.
The codec is in the bottom module
of the Profilesystem.
Power cable
Note: Strap the cables and take care
not to shut the cables in the rear door.
