Troubleshooting
This chapter provides information and instructions for using the system command line interface (CLI) for
troubleshooting any issues that may arise during system operation.
Refer to the ASR 5500 Installation Guide for comprehensive descriptions of the hardware components addressed
by these troubleshooting procedures.
•Detecting Faulty Hardware, on page 1
•Taking Corrective Action, on page 20
•Verifying Network Connectivity, on page 23
•Using the System Diagnostic Utilities, on page 26
•Generating an SSD, on page 29
•Configuring and Using the Support Data Collector, on page 29
Detecting Faulty Hardware
When power is applied to the chassis, power is sequentially applied to the Management I/O (MIO/UMIO/MIO2)
cards, Data Processing Cards (DPC/UDPC/DPC2/UDPC2s), Fabric and Storage Cards (FSCs), and System
Status Cards (SSCs).
Each PFU and card installed in the system incorporates light emitting diodes (LEDs) that indicate its operating
status. This section describes how to use these status LEDs to verify that all of the installed components are
functioning properly.
As the system progresses through its boot process, some cards will not exhibit immediate LED activity. Allow
several minutes to elapse after a reboot is initiates before checking the LEDs on the various cards to verify
that the boot process has successfully completed.
Important
Licensing Issues
The system boot process is governed by StarOS licenses. During the startup process, each card performs a
series of Power-On Self Tests (POSTs) to ensure that the hardware is operational. These tests also verify that
the card meets all license requirements to operate in this chassis.
Refer to Chassis Universal License Requirements in the ASR 5500 Installation Guide for additional information
on the effect licenses and card types have on the boot process.
Troubleshooting
1

Using the CLI to View Status LEDs
Status LEDs for all cards can be viewed via the CLI by entering the Exec mode show leds all command.
[local]host_name#show leds all
The following displays a sample of this command's output.
Slot 01: Run/Fail: Green | Active: Off | Redundant: Green
Slot 02: Run/Fail: Green | Active: Off | Redundant: Green
Slot 03: Run/Fail: Green | Active: Off | Redundant: Green
Slot 05: Run/Fail: Green | Active: Green | Redundant: Green Master: Green
Slot 06: Run/Fail: Green | Active: Off | Redundant: Green Master:Off
Slot 08: Run/Fail: Green | Active: Off | Redundant: Green
Slot 11: Run/Fail: Green | Active: Green | Redundant: Green Status: Green |
Service: Off
Slot 12: Run/Fail: Green | Active: Green | Redundant: Green Status: Green |
Service: Off
Slot 13: Run/Fail: Green | Active: Green | Redundant: Green
Slot 14: Run/Fail: Green | Active: Green | Redundant: Green
Slot 15: Run/Fail: Green | Active: Green | Redundant: Green
Slot 16: Run/Fail: Green | Active: Green | Redundant: Green
Slot 17: Run/Fail: Green | Active: Green | Redundant: Green
The status of the two Power Filter Units (PFUs) can be viewed by entering the Exec mode show power chassis
command.
Checking the LEDs on the PFU
Each PFU has four LEDs along the top edge of its front panel. You must unsnap the top front cover from the
chassis to view these LEDs. Each LED is associated with one of the four -48 VDC power feeds connected to
the PFU.
Each LED on the PFU should illuminate blue for normal operating conditions.
Figure 1: PFU LEDs
The possible states for these LEDs are described in the following table. If the LED is not blue, use the
troubleshooting information below to diagnose the problem.
Troubleshooting
2
Troubleshooting
Using the CLI to View Status LEDs

Table 1: PFU LED States
TroubleshootingDescriptionColor
None needed.Power feed is supplying -48VDC to this
power plane
Blue
Verify that each circuit breaker is in the ON
position.
PFU is not receiving power to one or more
of its power planes.
None
Verify that the RTN and -48VDC lugs are
attached properly to the posts on the upper
rear of the chassis.
Verify that the ground lug is attached
properly.
Use a voltmeter to verify that the power
distribution panel is supplying the correct
voltage and sufficient current to the
terminals at the rear of the PFU.
Check the cables from the power source to
the rack for continuity.
If a power distribution panel (PDP) is
installed between the power distribution
frame (PDF) and the chassis, verify that its
circuit breakers are set to ON.
If a PDP is installed between the PDF and
the chassis, check the cables from the PDP
to the chassis for continuity.
If all of the above suggestions have been
verified, then it is likely that the PFU is not
functional. Please contact your service
representative.
Checking the LEDs on the MIO Card
Each MIO/UMIO/MIO2 is equipped with the following LEDs:
• Run/Fail
• Active
• Redundancy
• Master
• Busy
Troubleshooting
3
Troubleshooting
Checking the LEDs on the MIO Card

Figure 2: MIO Card Status LEDs
The possible states for all MIO/UMIO/MIO2 LEDs are described in the sections that follow.
MIO Run/Fail LED States
The MIO/UMIO/MIO2 Run/Fail LED indicates the overall status of the card. This LED should be steady
green for normal operation.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 2: MIO Run/Fail LED States
TroubleshootingDescriptionColor
None needed.Card powered with no errors detectedGreen
This is normal operation during boot-up.Card is initializing and/or loading softwareBlinking Green
Errors were detected during the Power On
Self Tests (POSTs). It is likely that the
errors were logged to the system's
command line interface during boot.
Card powered with error(s) detectedRed
Troubleshooting
4
Troubleshooting
MIO Run/Fail LED States

TroubleshootingDescriptionColor
Verify that the LEDs on the PFUs are blue.
If they are not, refer to Checking the LEDs
on the PFU, on page 2 for troubleshooting
information.
Card is not receiving powerNone
Verify that the power source is supplying
ample voltage and current to the chassis.
Verify that the card is properly installed per
the instructions in the ASR 5500 Installation
Guide.
If all of the above suggestions have been
verified, it is possible that the MIO is not
functional. Please contact your service
representative.
MIO Active LED States
The Active LED on the MIO/UMIO/MIO2 indicates that the software is loaded on the card and it is ready for
operation. For the MIO installed in chassis slot 5, this LED should be green for normal operation. For the
MIO installed in slot 6, this LED should be off for normal operation.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 3: Active LED States
TroubleshootingDescriptionColor
None needed for the MIO/UMIO/MIO2 in
slot 5. If green for the MIO/UMIO/MIO2
in slot 6, verify that the MIO/UMIO/MIO2
in slot 5 is installed and licensed properly
according to the instructions in the ASR
5500 Installation Guide.
Card is activeGreen
Refer to Monitoring the System for
information on determining the status of
the MIO/UMIO/MIO2 and system software
processes.
Tasks or processes being migrated from the
active MIO to the standby MIO.
Blinking Green
Verify that the Run/Fail LED is green. If
so, the card is receiving power and POST
results are positive. If it is off, refer to MIO
Run/Fail LED States, on page 4 for
troubleshooting information.
Card is not receiving power.
OR
Card has failed.
None
Troubleshooting
5
Troubleshooting
MIO Active LED States

MIO Redundancy LED States
The Redundancy LED on the MIO/UMIO/MIO2 indicates that software is loaded on the card, but it is serving
as a redundant component. For the MIO/UMIO/MIO2 installed in slot 6, this LED should be green for normal
operation. For the MIO/UMIO installed in slot 8, this LED should be off for normal operation.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 4: MIO Redundancy LED States
TroubleshootingDescriptionColor
None needed. If green for the
MIO/UMIO/MIO2s in slot 5 and slot 6, the
cards and ports are fully backed up.
Card is in redundant modeGreen
Check the status of the other
MIO/UMIO/MIO2. If it has failed or one
or more of its ports are no longer active,
the system can continue to function but
redundancy is compromised.
Card or port on this card is not backed up
by other MIO.
Amber
Refer to Monitoring the System for
information on determining the status of
the MIO/UMIO/MIO2 and system software
processes.
Refer to Monitoring the System for
information on determining the status of
the MIO/UMIO/MIO2 and system software
processes.
Tasks or processes being migrated from the
active MIO to the standby MIO.
Blinking Amber
Verify that the Run/Fail LED is green. If
so, the card is receiving power and POST
results are positive. If it is off, refer to MIO
Run/Fail LED States, on page 4 for
troubleshooting information on.
Card is not receiving power.
OR
Card has failed.
None
MIO Master LED States
The Master LED on the MIO/UMIO/MIO2 indicates whether the card is in Active or Standby mode.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information also provided to diagnose the problem.
Table 5: MIO Master LED States
TroubleshootingDescriptionColor
None needed.This card is the Active MIO.Green
Troubleshooting
6
Troubleshooting
MIO Redundancy LED States

TroubleshootingDescriptionColor
Refer to Monitoring the System for
information on determining the status of
the MIO/UMIO /MIO2and system software
processes.
Tasks or processes being migrated from the
active MIO to the standby MIO.
Blinking Green
Verify that the Run/Fail LED is green. If
so, the card is receiving power and POST
results are positive. If it is off, refer to MIO
Run/Fail LED States, on page 4 for
troubleshooting information.
This card is the Standby MIO.
OR
Card has failed.
None
Refer to Monitoring the System for
information on determining the status of he
MIO/UMIO/MIO2 and system software
processes.
MIO Busy LED States
The Busy LED on the MIO/UMIO/MIO2 indicates that the card is accessing the RAID solid state drives on
the FSCs.
This LED is off when no file storage activity is occurring.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 6: MIO Busy LED States
TroubleshootingDescriptionColor
None required.Files are being transferred to or accessed
from the RAID configuration on the FSCs.
Green
Checking the LEDs on the FSC, on page
12
No RAID activity.
OR
RAID configuration is unavailable.
None
MIO –Interface Link LED States
The Link LED associated with a 1000Base-T (management) or 10 Gigabit Ethernet port on an MIO/UMIO
daughter card (subscriber traffic) indicates the status of the network link. This LED should be green for normal
operation.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Troubleshooting
7
Troubleshooting
MIO Busy LED States

Table 7: MIO –Interface Link LED States
TroubleshootingDescriptionColor
None needed.
NOTE: This LED will not indicate the
presence of a network link until the
interface parameters are set during the
software configuration process.
Link is upGreen
Verify that the Run/Fail LED is green. If
so, the card is receiving power. If it is off,
refer to MIO Run/Fail LED States, on page
4for troubleshooting information.
No power to card.
OR
Link is down.
None
Verify that the interface is cabled properly.
Verify that the device on which the
interface is located is cabled and powered
properly.
MIO –Interface Activity LED States
The Activity LED associated with a 1000Base-T (management) or 10 Gigabit Ethernet port on an
MIO/UMIO/MIO2 daughter card (subscriber traffic) indicates the presence of traffic on the network link.
This LED should be green when data is being transmitted or received over the interface.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 8: MIO –Interface Activity LED States
TroubleshootingDescriptionColor
None needed.Traffic is present on the linkFlashing Green
None needed if there is no activity
on the link. Prior to interface
configuration, this is normal
operation.
No traffic is present on the linkNone
Checking the LEDs on the DPC
Each DPC/UDPC or /DPC2/UDPC2 is equipped with status LEDs as listed below:
• Run/Fail
• Active
• Redundancy
Troubleshooting
8
Troubleshooting
MIO –Interface Activity LED States

Figure 3: DPC Status LEDs
The possible states for all of the DPC/UDPC or /DPC2/UDPC2 LEDs are described in the sections that follow.
DPC Run/Fail LED States
The DPC/UDPC or /DPC2/UDPC2 Run/Fail LED indicates the overall status of the card. This LED should
be green for normal operation.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 9: DPC Run/Fail LED States
TroubleshootingDescriptionColor
None needed.Card powered up with no errors detected.Green
This is normal operation during boot-up.Card is initializing and/or loading software.Blinking Green
Errors were detected during the Power On
Self Tests (POSTs). It is likely that the
errors were logged to the system's
command line interface during boot.
Card powered up with error(s) detected.Red
Troubleshooting
9
Troubleshooting
DPC Run/Fail LED States

TroubleshootingDescriptionColor
Verify that the LEDs on the PFUs are blue.
If they are not, refer to Checking the LEDs
on the PFU, on page 2 for troubleshooting
information.
Card is not receiving power.None
Verify that the power source is supplying
ample voltage and current to the chassis.
Verify that the card is properly installed
and licensed per the instructions in the ASR
5500 Installation Guide.
If all of the above suggestions have been
verified, it is possible that the DPC/UDPC
or /DPC2/UDPC2 is not functional. Please
contact your service representative.
DPC Active LED States
The Active LED on the DDPC/UDPCPC or /DPC2/UDPC2 indicates that the software is loaded on the card
and that the card is ready for operation. When the system first boots up, all installed DPC/UDPCs or
/DPC2/UDPC2s are booted into standby mode. The system must then be configured as to which DPC/UDPCs
or /DPC2/UDPC2s should serve as redundant components (remain in standby mode) and which should function
as active components.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 10: DPC Active LED States
TroubleshootingDescriptionColor
The first time power is applied to the
system, all of the DPC/UDPCs or
/DPC2/UDPC2s should be booted into the
standby mode. Therefore, this LED should
be off.
Card is active.Green
Verify that the Redundancy LED on a
standby DPC/UDPC or /DPC2/UDPC2 is
also blinking green. If so, there is an issue
with the active DPC/UDPC or
/DPC2/UDPC2 and it is transferring its
processes.
Tasks or processes are being migrated from
an active DPC to a standby DPC.
Blinking Green
Refer to Monitoring the System for
information on determining the status of
the DPC/UDPC or /DPC2/UDPC2 and
system software processes and
functionality.
Troubleshooting
10
Troubleshooting
DPC Active LED States

TroubleshootingDescriptionColor
Verify that the Run/Fail LED is green. If
so, the card is receiving power and POST
results are positive. If it is off, refer to DPC
Run/Fail LED States, on page 9 for
troubleshooting information.
Card is not receiving power.
OR
Card is in Standby Mode.
None
Check the state of the Redundancy LED. If
it is green, the card is in standby mode. This
is normal operation for the initial power-up.
If needed, refer to the Configuring DPC
Availability section of System Settings for
information on making the card active.
DPC Redundancy LED States
The Redundancy LED on the DPC/UDPC or /DPC2/UDPC2 indicates that software is loaded on the card, but
it is serving as a standby component. DPC/UDPCs or /DPC2/UDPC2s support n:1 redundancy; the Redundancy
LED should be green on only one DPC/UDPC or /DPC2/UDPC2 for normal system operation.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 11: DPC Redundancy LED States
TroubleshootingDescriptionColor
None needed. There is at least one
DPC/UDPC or /DPC2/UDPC2 in Standby
mode.
Card is in standby mode.Green
Check the status of the other DPC/UDPCs
or /DPC2/UDPC2s. If one DPC/UDPC or
/DPC2/UDPC2 has failed or has been
removed from the chassis, the system can
continue to function but redundancy is
compromised.
Card is not backed up by a standby DPC.Amber
Refer to Monitoring the System for
information on determining the status of
the DPC/UDPC or /DPC2/UDPC2 and
system software processes.
Refer to Monitoring the System for
information on determining the status of
the DPC/UDPC or /DPC2/UDPC2 and
system software processes.
Tasks or processes being migrated from an
active DPC to the standby DPC.
Blinking Amber
Verify that the Run/Fail LED is green. If
so, the card is receiving power and POST
results are positive. If it is off, refer to DPC
Run/Fail LED States, on page 9 for
troubleshooting information.
Card is not receiving power.
OR
Card has failed.
None
Troubleshooting
11
Troubleshooting
DPC Redundancy LED States

Checking the LEDs on the FSC
Each FSC is equipped with the following LEDs as shown in the accompanying figure:
• Run/Fail
• Active
• Redundancy
• Drive 1 Activity
• Drive 2 Activity
Figure 4: FSC Status LEDs
The possible states for all FSC LEDs are described in the sections that follow.
FSC Run/Fail LED States
The FSC Run/Fail LED indicates the overall status of the card. This LED should be green for normal operation.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 12: FSC Run/Fail LED States
TroubleshootingDescriptionColor
None needed.Card powered with no errors detectedGreen
Troubleshooting
12
Troubleshooting
Checking the LEDs on the FSC

TroubleshootingDescriptionColor
This is normal operation during boot-up.Card is initializing and/or loading softwareBlinking Green
Errors were detected during the Power On
Self Tests (POSTs). It is likely that the
errors were logged to the system's
command line interface during boot.
Card powered with error(s) detectedRed
Verify that the LEDs on the PFUs are blue.
If they are not, refer to Checking the LEDs
on the PFU, on page 2 for troubleshooting
information.
Card is not receiving powerNone
Verify that the power source is supplying
ample voltage and current to the chassis.
Verify that the card is properly installed per
the instructions in the ASR 5500 Installation
Guide.
If all of the above suggestions have been
verified, it is possible that the FSC is not
functional. Please contact your service
representative.
FSC Active LED States
The Active LED on the FSC indicates that the software is loaded on the card and that the card is ready for
operation. When the system first boots up, all installed FSCs are booted into ready mode.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 13: FSC Active LED States
TroubleshootingDescriptionColor
The first time power is applied to the
system, all of the FSCs should be booted
into the ready mode. Therefore, this LED
should be on.
Card is active.Green
Verify that the Redundancy LED on a
standby FSC is also blinking green. If so,
there is an issue with the active FSC and it
is transferring its processes.
Tasks or processes being migrated from an
active FSC to a standby FSC.
Blinking Green
Refer to Monitoring the System for
information on determining the status of
the FSC and system software processes and
functionality.
Troubleshooting
13
Troubleshooting
FSC Active LED States

TroubleshootingDescriptionColor
Verify that the Run/Fail LED is green. If
so, the card is receiving power and POST
results are positive. If it is off, refer to FSC
Run/Fail LED States, on page 12 for
troubleshooting information.
Card is not receiving power.
OR
Card is in Standby Mode.
None
Check the state of the Redundancy LED. If
it is green, the card is in standby mode.
FSC Redundancy LED States
The Redundancy LED on the FSC indicates that software is loaded on the card, but it is serving as a redundant
component. FSC support n+1 redundancy; the Redundancy LED should be green on only one FSC for normal
system operation.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 14: FSC Redundancy LED States
TroubleshootingDescriptionColor
None needed. There is at least one FSC in
Standby mode.
Card is in redundant modeGreen
Check the status of the other FSCs. If one
FSC has failed or has been removed from
the chassis, the system can continue to
function but redundancy is compromised.
Card is not backed up by a standby FSC.Amber
Refer to Monitoring the System for
information on determining the status of
the FSC and system software processes.
Refer to Monitoring the System for
information on determining the status of
the FSC and system software processes.
Tasks or processes being migrated from an
active FSC to the standby FSC.
Blinking Amber
Verify that the Run/Fail LED is green. If
so, the card is receiving power and POST
results are positive. If it is off, refer to FSC
Run/Fail LED States, on page 12 for
troubleshooting information.
Card is not receiving power.
OR
Card has failed.
None
FSC Drive n Activity LED States
The Drive 1 Activity and Drive 2 Activity LEDs on the FSC indicate that the RAID solid state drives (SSDs)
are being accessed by the MIO. Drive 1 and Drive 2 on each FSC form a RAID 0 configuration.
Troubleshooting
14
Troubleshooting
FSC Redundancy LED States

The FSC-400GB is equipped with a single 400 GB drive. Only the Drive 1 Activity LED will be active; the
Drive 2 Activity LED will always be off (None).
Important
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information also provided to diagnose the problem.
Table 15: FSC Driven Activity LED States
TroubleshootingDescriptionColor
None required.Files are being transferred to or accessed
from the RAID configuration by the MIO.
Green
Checking the LEDs on the MIO Card, on
page 3
FSC-400GB is not equipped with a second
SDD. Only the Drive 1 Activity LED will
be active.
There is no RAID activity.
OR
RAID configuration is unavailable.
None
Verify that the Run/Fail LED is green. If
so, the card is receiving power and POST
results are positive. If it is off, refer to FSC
Run/Fail LED States, on page 12 for
troubleshooting information.
Card is not receiving powerNone
Checking the LEDs on the SSC
Each SSC is equipped with the following LEDs as shown in the accompanying figure:
• Run/Fail
• Active
• Redundancy
• System Status
• System Service
Troubleshooting
15
Troubleshooting
Checking the LEDs on the SSC

Figure 5: SSC Status LEDs
The possible states for all SSC LEDs are described in the sections that follow.
SSC Run/Fail LED States
The SSC Run/Fail LED indicates the overall status of the card. This LED should be green for normal operation.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 16: SSC Run/Fail LED States
TroubleshootingDescriptionColor
None needed.Card powered with no errors detectedGreen
This is normal operation during boot-up.Card is initializing and/or loading softwareBlinking Green
Errors were detected during the Power On
Self Tests (POSTs). It is likely that the
errors were logged to the system's
command line interface during boot.
Card powered with error(s) detectedRed
Troubleshooting
16
Troubleshooting
SSC Run/Fail LED States

TroubleshootingDescriptionColor
Verify that the LEDs on the PFUs are blue.
If they are not, refer to Checking the LEDs
on the PFU, on page 2 for troubleshooting
information.
Card is not receiving powerNone
Verify that the power source is supplying
ample voltage and current to the chassis.
Verify that the card is properly installed per
the instructions in the ASR 5500 Installation
Guide.
If all of the above suggestions have been
verified, it is possible that the SSC is not
functional. Please contact your service
representative.
SSC Active LED States
The Active LED on the SSC indicates that the software is loaded on the card and that the card is ready for
operation. When the system first boots up, both SSCs are booted into ready mode.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 17: SSC Active LED States
TroubleshootingDescriptionColor
The first time power is applied to the
system, both SSCs should be booted into
the ready mode. Therefore, this LED should
be on.
Card is active.Green
Verify that the Redundancy LED on a
Standby SSC is also blinking green. If so,
there is an issue with the active SSC and it
is transferring its processes.
Tasks or processes being migrated from an
active FSC to a standby FSC.
Blinking Green
Refer to Monitoring the System for
information on determining the status of
the SSC and system software processes and
functionality.
Verify that the Run/Fail LED is green. If
so, the card is receiving power and POST
results are positive. If it is off, refer to the
SSC Run/Fail LED States section for
troubleshooting information.
Card is not receiving power.
OR
Card is in Standby Mode.
None
Check the state of the Redundancy LED. If
it is green, the card is in standby mode.
Troubleshooting
17
Troubleshooting
SSC Active LED States

SSC Redundancy LED States
The Redundancy LED on the SSC indicates that software is loaded on the card, but it is serving as a standby
component. SSC support 1:1 redundancy; the Redundancy LED should be green on the other SSC for normal
system operation.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 18: SSC Redundancy LED States
TroubleshootingDescriptionColor
None needed. The other SSC should be in
Standby mode.
Card is in standby modeGreen
Check the status of the other SSC. If one it
has failed or has been removed from the
chassis, the system can continue to function
but redundancy is compromised.
Card is not backed up by the standby SSC.Amber
Refer to Monitoring the System for
information on determining the status of
the SSC and system software processes.
Refer to Monitoring the System for
information on determining the status of
the SSC and system software processes.
Tasks or processes being migrated from the
active SSC to the standby SSC.
Blinking Amber
Verify that the Run/Fail LED is green. If
so, the card is receiving power and POST
results are positive. If it is off, refer to the
SSC Run/Fail LED States section for
troubleshooting information.
Card is not receiving power.
OR
Card has failed.
None
SSC System Status LED States
The System Status LED on the SSC indicates the that there is a loss of service somewhere in the system. If
this LED is red, the system requires maintenance or service (for example, the system could not locate a a valid
software image at boot-up, or a high temperature condition exists).
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information also provided to diagnose the problem.
Table 19: SSC System Status LED States 11
TroubleshootingDescriptionColor
None required.System is operating normallyGreen
Refer to Monitoring the System for
information on determining the status of
system hardware and software processes.
The system has experienced a loss of
service.
Red
Troubleshooting
18
Troubleshooting
SSC Redundancy LED States

TroubleshootingDescriptionColor
Verify that the Run/Fail LED is green. If
so, the card is receiving power and POST
results are positive. If it is off, refer to the
SSC Run/Fail LED States section for
troubleshooting information.
Card is not receiving powerNone
SSC System Service LED States
The System Service LED on the SSC illuminates amber to indicate that the system has experienced a hardware
component failure.
This LED is off during normal operation.
The possible states for this LED are described in the following table. If the LED is not green, use the
troubleshooting information in the table to diagnose the problem.
Table 20: SSC System Service LED States 12
TroubleshootingDescriptionColor
Monitoring the System for showcommands,
the outputs of which will assist in further
determining the problem.
System requires maintenance (fan filter,
temperature warning, PFU outage etc.).
Amber
Refer to System Logs for information on
how to view logs.
No maintenance needed.No component failures have been detected.
OR
Card is not receiving power.
None
Testing System Alarm Outputs
The system provides the following two physical alarm mechanisms:
•System Audible Alarm: Located on the SSC, the speaker is used to provide an audible indicator that a
minor, major, or critical alarm has occurred.
•CO Alarms Interface: Located on the SSC, this interface provides a DB-15 connector that enables three
dry-contact relays (Form C) for the triggering of external audio and/or visual indicators. These indicators
can be used to alert that either a minor, major, or critical alarm has occurred.
The operation of these alarms can be tested by issuing the following command:
[local]host_name#test alarm { audible | central-office [ critical | major |
minor ] }
When this command is executed, the specified alarm is activated for a period of 10 seconds. After this time,
the alarm will return to its previous condition.
Troubleshooting
19
Troubleshooting
SSC System Service LED States

Taking Corrective Action
In the event that an issue was discovered with an installed application or line card, depending on the severity,
it may be necessary to take corrective action.
The system provides several redundancy and fail-over mechanisms to address issues with application and line
cards in order to minimize system downtime and data loss. These mechanisms are described in the sections
that follow.
Switching MIOs
When the system boots up, the MIO/UMIO/MIO2 installed in chassis slot 5 will boot into the Active mode
and begin booting other system components. The MIO/UMIO/MIO2 installed in chassis slot 6 will automatically
be booted into Standby mode dictating that it will serve as a redundant component. The active
MIO/UMIO/MIO2 automatically synchronizes currently running tasks or processes with the standby
MIO/UMIO/MIO2.
In the event of a critical failure on the MIO/UMIO/MIO2 in slot 5, system control will be automatically
switched to the standby MIO/UMIO/MIO2 in slot 6. This is a relatively seamless transition because the two
are synchronized. The formerly active MIO will then enter the standby mode allowing it to be safely replaced
or restored.
In the event that an issue arises that is not severe enough for the system to perform an automatic switchover,
a manual switchover can be invoked by executing the following commands from the Exec mode prompt.
Step 1 Initiate a manual MIO/UMIO/MIO2 switch over by entering the following command:
[local]host_name#card switch from <5 or 6> to <6 or 5>
You will receive the following prompt:
Are You Sure? [Yes|No]:
Step 2 Press Yto start the switchover.
Step 3 Verify that the switchover was successful by entering the show card table command at the Exec mode prompt:
Check the entry in the Oper State column next to the MIO/UMIO/MIO2 just switched. Its state should be Standby.
Busying Out a DPC
This busy-out command moves processes from the source DPC/UDPC or DPC2/UDPC2 to the destination
DPC/UDPC or DPC2/UDPC2, or disables the DPC/UDPC or DPC2/UDPC2 from accepting any new calls.
When busy-out is enabled, the DPC/UDPC or DPC2/UDPC2 stops receiving new calls but continues to process
calls until they are completed. The command prompt is returned once the command is initiated. The busy-out
procedure is completed in background.
Step 1 Initiate a busy-out by entering the following command:
[local]host_name#card busy-out slot_number
Troubleshooting
20
Troubleshooting
Taking Corrective Action
