CHAPTER
1-1
Cisco ONS 15600 Reference Manual, R8.0
1
Shelf and Backplane Hardware
This chapter provides a description of Cisco ONS 15600 shelf and backplane hardware. Card and cable
descriptions are provided in Chapter 2, “Card Reference.”
To install equipment, refer to the Cisco ONS 15600 Procedure Guide.
Chapter topics include:
•1.1 Installation Overview, page 1-1
•1.2 Bay Installation, page 1-2
•1.3 Front Door, page 1-4
•1.4 Rear Covers, page 1-5
•1.5 Cable Routing, page 1-7
•1.6 Customer Access Panel, page 1-7
•1.7 Alarm, Timing, LAN, and Craft Pin Connections, page 1-10
•1.8 Power Distribution Unit, page 1-13
•1.9 Power and Ground Description, page 1-13
•1.10 Fan-Tray Assembly, page 1-14
•1.11 Cards and Slots, page 1-17
Note The Cisco ONS 15600 assembly is intended for use with telecommunications equipment only.
Note The ONS 15600 is designed to comply with Telcordia GR-1089-CORE Type 2 and Type 4 equipment.
Install and operate the ONS 15600 only in environments that do not expose wiring or cabling to the
outside plant. Acceptable applications include Central Office Environments (COEs), Electronic
Equipment Enclosures (EEEs), Controlled Environment Vaults (CEVs), huts, and Customer Premise
Environments (CPEs).
1.1 Installation Overview
The ONS 15600 is a Network Equipment Building System III (NEBS III)-compliant, environmentally
hardened shelf assembly that ships as a single shelf in a bay assembly for Release 8.0. The ONS 15600
comes with the power distribution unit (PDU), shelf, fans, and backplane already installed. The front

1-2
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.2 Bay Installation
door of the ONS 15600 allows access to the shelf assembly, fan-tray assembly, and cable-management
area. The customer access panel (CAP) or customer access panel version 2 (CAP2) on the back of the
shelf provide access to alarm contacts, external interface contacts, and timing contacts. Power and
ground terminals are located on the top left and right sides of the bay.
Caution Voltage to the alarm circuits should not exceed –48 VDC.
The ONS 15600 comes mounted in a custom, certified NEBS-2000 rack. The bay assembly, including
the rack, fan trays, and PDU weighs approximately 500 pounds (226.8 kg) with no cards installed.
ONS 15600 OC-N cards have OGI connectors on the card faceplate; available connector termination
types are SC, ST, and FC. Fiber optic cables are routed to the front of the OC-N cards.
The ONS 15600 is powered using –48 VDC power but may range from –40.5 to –72 VDC. Input power
is accessible from the sides of the bay, and output power is accessible at the rear of the bay. Cisco
supports dual office-power feeds only.
Install the ONS 15600 in compliance with your local and national electrical codes:
•United States: National Fire Protection Association (NFPA) 70; United States National Electrical
Code
•Canada: Canadian Electrical Code, Part I, CSA C22.1
•Other countries: If local and national electrical codes are not available, refer to IEC 364, Part 1
through Part 7.
1.2 Bay Installation
In this chapter, the terms “ONS 15600” and “bay assembly” are used interchangeably. In the installation
context, these terms have the same meaning. Otherwise, bay assembly refers to the physical steel
enclosure that holds the shelves and power distribution unit (PDU), and ONS 15600 refers to the entire
system, both hardware and software.
To install the ONS 15600, you must first unpack the bay assembly. Two custom ramps and two dollies
are available to assist you with the removal of the bay from the shipping pallet and transportation to the
installation location. Figure 1-1 shows the bay assembly with the dollies installed.

1-3
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.2 Bay Installation
Figure 1-1 ONS 15600 with Dollies Installed
The ONS 15600 shelf measures 25 inches high, 19-9/16 inches wide, and 23 inches deep (63.5 cm H x
49.7 cm W x58.3 cm D). A maximum of three ONS 15600s can fit in a custom seven-foot equipment
rack. The ONS 15600 that ships within a rack is 83-7/8 inches high, 23-5/8 inches wide, and
23-5/8 inches deep (213 cm H x 60 cm W x 60 cm D).
Note Cisco supports only one ONS 15600 shelf per bay.
96607

1-4
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.3 Front Door
1.3 Front Door
The ONS 15600 features a door to the front compartment that you can open by releasing the latches on
the bottom left and right sides of the door. The front door provides access to the shelf, cable-management
tray, and fans (Figure 1-2).
Figure 1-2 ONS 15600 Front Door
You can remove the front door of the ONS 15600 to provide unrestricted access to the front of the shelf.
A label is pasted in a box in the center of the swing-down door that covers the fiber routers (Figure 1-3).
This label designates the position of the rack and shelf in a lineup.
78395
ESD jack
Door pivot point
Door latches

1-5
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.4 Rear Covers
Figure 1-3 Bay Label
The front door also has a Class I laser warning (Figure 1-4).
Figure 1-4 Laser Warning Label
1.4 Rear Covers
The ONS 15600 has an optional plastic rear cover that is held in place with six 6-32 x 3/8 inch Phillips
screws. This plastic cover provides additional protection for the cables and connectors on the backplane
(Figure 1-5).
81219
83121

1-6
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.4 Rear Covers
Figure 1-5 Plastic Rear Cover
Figure 1-6 shows the bus bar covers.
Figure 1-6 PDU Bus Bar Cover
81213
83442

1-7
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.5 Cable Routing
1.5 Cable Routing
The narrow and wide cable routing modules (CRMs) can be installed on the sides of the bay to manage
and contain the optical cables as they are routed away from the bay. You can use both types of fiber
routing systems with overhead or under-floor cabling.
1.6 Customer Access Panel
The Customer Access Panel (CAP or CAP2) is located in the middle on the rear of the shelf. The CAP
and CAP2 provide an alarm pin field, timing, and LAN connections. The CAP or CAP2 plugs into the
backplane using 2mm Hard Metric connectors with 752 pins and is held in place with one large captive
bolt and multiple screws.
The CAP2 has the additional capability of providing provisionable power monitoring.
Figure 1-7 shows the location of the CAP or CAP2 on the back of the shelf.
Note The ONS 15600 supports only T1 (100 ohm) building integrated timing supply (BITS).

1-8
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.6 Customer Access Panel
Figure 1-7 Rear of the ONS 15600, Including the CAP/CAP2
The ONS 15600 CAP and CAP2 provide the following features:
•BITS T1 (100 ohm) interfaces via wire-wrap pins.
•Two Ethernet interfaces via RJ-45 connectors with internal transformer isolation.
•An EIA/TIA-232 craft interface via DB-9 connectors. This interface is surge-protected and provides
EMI filtering. Two interfaces are provided for redundancy.
•Four audio alarm interfaces via a DB-15 connector that is surge-protected and EMI-filtered. The
audio alarm indication is provided by the Timing and Shelf Controller (TSC) card and this interface
can receive a signal to disable the audio alarm.
78398

1-9
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.6 Customer Access Panel
•Four visual alarm interfaces via a DB-15 connector that is surge-protected and EMI-filtered. The
visual alarm indication is provided by the TSC card and the signal is connected to the PDU where
LEDs indicate the alarm status and severity.
•Environmental (external) alarms and controls (16 inputs and 16 outputs) via wire-wrap pins. The
interface is surge-protected and provides isolation by using an opto-isolator for alarm inputs and
relays for alarm outputs. By connecting to different wire-wrap pins on the CAP/CAP2, the alarm
outputs can be configured for either normally open (NO) or normally closed (NC) operation. Alarms
are initiated by shorting these contacts. The alarm input interface provides a pair of positive and
negative wire-wrap pins.
The isolation and termination meet the intra-building lightning surge specification in Telcordia
GR-1089. The CAP and CAP2 have –48 VDC monitoring with an I2C interface and nonvolatile memory
to store the CAP/CAP2 revision information.
Figure 1-8 shows the CAP faceplate.
Figure 1-8 CAP Faceplate and Connections
If the CAP/CAP2 fails, the node raises an EQPT alarm. You can replace the CAP/CAP2 on an in-service
node without affecting traffic. To replace a CAP, refer to the Cisco ONS 15600 Procedure Guide. Always
replace the CAP during a maintenance window.
78485
Wire
wrap
pins
LAN
RJ-45
Craft
DB-9
Audible
Alarm
DB-15
BITS
OUT
BNC
BITS
OUT
BNC
LAN
RJ-45
Craft
DB-9
BITS
IN
BNC
BITS
IN
BNC
Serial Number Label
Part Number Label
Bar Code and
Country of Origin
Labels
Backplane
connectors
Visual
Alarm
DB-15

1-10
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.7 Alarm, Timing, LAN, and Craft Pin Connections
1.7 Alarm, Timing, LAN, and Craft Pin Connections
Caution Always use the supplied ESD wristband when working with a powered ONS 15600 or any ONS 15600
components. Plug the wristband cable into one of the ESD jacks located on the lower-left outside edge
of the bay assembly and at the bottom rear of the shelf.
The ONS 15600 has a backplane pin field located at the bottom rear of the shelf that is part of the
CAP/CAP2. The CAP/CAP2 provides 0.045 square inch (0.290 square centimeter) wire-wrap pins for
enabling alarm inputs and outputs and timing input and output. This section describes the backplane pin
field and pin assignments, as well as timing and LAN connections. See the “1.6 Customer Access
Panel” section on page 1-7 for more information.
1.7.1 External Alarm and Control Contact Installation
The external (environmental) alarm contacts consist of the wire-wrap pin field and two D-Sub 15s. The
alarm pin field supports up to 16 alarm inputs (external alarms) and 16 alarm outputs (external controls).
The two D-Sub 15s support four audible alarms, four visual alarms, one alarm cutoff (ACO), a PDU Fail
A, and a PDU Fail B.
By connecting to different wire-wrap pins on the CAP or CAP2, the alarm outputs can be configured for
either normally open (NO) or normally closed (NC) operation (see Figure 1-9). The alarm inputs consist
of two wire-wrap pins on the CAP or CAP2 and the alarm outputs consist of three wire-wrap pins.
1.7.1.1 Visual and Audible Alarms
Visual and audible alarm contacts are provisioned as Critical, Major, Minor, and Remote. Figure 1-9
shows alarm pin assignments.

1-11
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.7.2 Timing Installation
Figure 1-9 Alarm Pin Assignments on the CAP/CAP2
Visual and audible alarms can be wired to trigger an alarm light at a central alarm collection point when
the corresponding contacts are closed.
1.7.1.2 Alarm Cutoff and PDU Alarms
The PDU Alarm connection controls the visual alarm indicators on the front of the PDU. You can also
activate the alarm cutoff (ACO) function by pressing the ACO button on the TSC card faceplate. The
ACO function extinguishes all audible alarm indications, but the alarm is still raised in Cisco Transport
Controller (CTC).
1.7.2 Timing Installation
The ONS 15600 backplane supports two 100-ohm BITS clock pin fields. Figure 1-10 shows the pin
assignments for the BITS timing pin fields.
Note Refer to Telcordia SR-NWT-002224 for rules about provisioning timing references.
Note 64K and E1 timing are not used with SONET systems. See Chapter 6, “Timing,” for more information.
78510
16 15 14 13 12 11 10 9 87 65 43 21
BITS - B BITS - A
EXTERNAL ALARMS
5
4
3
2
1
10 9 8 7 6 5 4 3 2 1
5
4
3
2
1
Normally open
Common
Normally closed
Short for alarm,
-48 VDC provided
Alarm IN
48 VDC provided
short contacts
FRAME GROUND

1-12
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.7.3 LAN Installation
Figure 1-10 BITS Timing Connections on the CAP/CAP2
1.7.3 LAN Installation
Use a straight-through LAN cable with the LAN port on the CAP or CAP2 to connect the ONS 15600
to a hub, switch, or a LAN modem for remote access to the node. Use a crossover cable when connecting
the CAP or CAP2 to a workstation. You can also use a straight-through or crossover LAN cable with the
LAN port on the active TSC faceplate to connect directly to the local ONS 15600.
Note Do not use the LAN port on the active TSC card for remote monitoring because you will lose
connectivity to the node if the other TSC card in the shelf becomes the active TSC card.
1.7.4 TL1 Craft Interface Installation
To open a TL1 session using the craft interface on a PC, use the RJ-45 port on the active TSC card to
access the system using a standard web browser. If a browser is not available, you can access the system
using one of the two EIA/TIA-232 ports on the CAP and CAP2. Each EIA/TIA-232 port supports VT100
emulation so that you can enter TL1 commands directly without using a web browser. Because the CAP
and CAP2 EIA/TIA-232 port is set up as a data terminal equipment (DTE) interface, you must use a
3-pair swapping null modem adapter when you are working in a UNIX or PC environment so that the
TXD/RXC, DSR/DTR, and CTS/RTS pins are swapped. Use a standard pin D-sub cable when
connecting to a PC. Refer to the Cisco ONS SONET TL1 Command Guide for more information.
Note Do not use the LAN port on the active TSC card for remote monitoring because you will lose
connectivity to the node if the other TSC card in the shelf becomes the active TSC card.
78511
16 15 14 13 12 11 10 9 87 65 43 21
BITS - B BITS - A
EXTERNAL ALARMS
5
4
3
2
1
10 9 8 7 6 5 4 3 2 1
5
4
3
2
1
FRAME GROUND
64k
E1/T1
64k
E1/T1
+
OUT
+
IN
+
OUT
+
IN

1-13
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.8 Power Distribution Unit
1.8 Power Distribution Unit
The PDU consists of a mounting chassis, A- and B-side power modules, an alarm module, and a rear I/O
unit. The ONS 15600 PDU has LEDs that alert you to Critical, Major, Minor, and remote alarms on the
node. Each module can support three 100A input power feeds, 48 VDC power load (based on a fully
loaded ONS 15600 shelf). The PDU supplies six 50A power feeds to the shelves. (The PDU provided
with the ONS 15600 is capable of supplying power to up to three shelves.)
A three-shelf bay at the minimum operational voltage of –36 VDC requires 69-A per feed (207 A total).
A three-shelf bay at the nominal operational voltage of –48 VDC requires 52-A per feed (156 A total).
Each of the three feeds should be protected by its own 100-A breaker. A bus bar system, rather than
wiring, provides a reliable, low resistance path to the ONS 15600 shelf. Figure 1-6 on page 1-6 shows
the PDU output covers found at the top rear of the bay.
Note Cisco supports only one ONS 15600 shelf per bay.
1.9 Power and Ground Description
Ground the equipment according to Telcordia standards or local practices. The ground connection is
located on the front of the bay’s top horizontal rails. The ONS 15600 provides two #12 tapped holes to
accommodate the grounding lug. The lug must be a dual-hole type and rated for at least 125-A capacity.
Figure 1-11 shows the front and rear bay ground holes.

1-14
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.10 Fan-Tray Assembly
Figure 1-11 Front and Rear Bay Ground Holes
The main power connections are made at the PDU side terminals at the top of the bay. To install
redundant power feeds, use four power cables and ground cables. For a single power feed, only two
power cables and one ground cable (all rated for at least 125-A capacity) are required. Use a conductor
with low impedance to ensure circuit overcurrent protection. The ground conductor must have the
capability to safely conduct any faulty current that might be imposed.
Cisco recommends the following wiring conventions, but customer conventions prevail:
•Red wire for battery connections (–48 VDC)
•Black wire for battery return connections (0 VDC)
•The battery return connection is treated as DC-I, as defined in Telcordia GR-1089-CORE, issue 3
The ONS 15600 shelf has redundant –48 VDC power terminals on its backplane. The terminals are
labeled A FEEDS and B FEEDS and are located at the top left and right sides of the shelf behind clear
plastic covers.
1.10 Fan-Tray Assembly
The fan-tray assembly is located at the top of the ONS 15600 shelf front compartment. The fan-tray
assembly has three removable drawers that hold two fans each and fan-control circuitry for the
ONS 15600 (Figure 1-12). You should only need to access the fans if a fan fails.
96611
PDU frame
ground cable
Bay grounding
holes

1-15
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.10.1 Air Filter
Figure 1-12 Fan-Tray Assembly
1.10.1 Air Filter
The ONS 15600 contains a reusable air filter that is made of an open-cell polyurethane foam that is flame
retardant and fungi resistant. The air filter is located above the three fan trays (Figure 1-13). This
disposable filter is designed to be cleaned using only mild detergents. You can order air filter
replacements from Cisco Systems (P/N 700-13116-05). Keep spare filters in stock. Refer to the
Cisco ONS 15600 Procedure Guide for information about replacing the fan-tray air filter.
Caution Inspect the air filter every 30 days, and clean the filter every three to six months. Replace the air filter
every two to three years. Avoid cleaning the air filter with harsh cleaning agents or solvents.
Caution Do not operate an ONS 15600 without a fan-tray air filter. A fan-tray filter is mandatory.
71045

1-16
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.10.2 Fan Speed and Failure
Figure 1-13 Air Filter and one Fan Tray Pulled Out
1.10.2 Fan Speed and Failure
If one or more fans fail on the fan-tray assembly, replace the fan tray where that fan resides. You cannot
replace individual fans. The red FAN LED on the front of the fan tray turns on when one or more fans
fail. For fan-tray replacement instructions, refer to the Cisco ONS 15600 Procedures Guide. The red
FAN LED clears after you install a working fan tray.
Caution If both fans in the center fan tray are inoperative, you must replace the fan tray within five minutes of
failure to avoid affecting traffic because CTC software will shut down one of the single shelf
cross-connect (SSXC) cards.
Caution The ONS 15600 requires at least one working fan in each of the three fan trays. When a single fan in a
tray fails, Cisco recommends replacing the tray with a fully working tray as soon as possible.
Note Each fan tray contains two fans. The FAN LED indicates if one or both fans fail in that fan tray.
Fan speed is determined by card temperature sensors that report temperature data to the active TSC card.
The sensors measure the input and output air temperature for each card. Fan speed options are low,
medium, and high. For example, if a card exceeds permissible operational temperature, the fan speed
increases appropriately. At initial turn-up, the default fan speed is high until the node initializes. If both
78564

1-17
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.11 Cards and Slots
TSC cards fail, the fans automatically shift to high speed. If a single TSC card fails, the active TSC card
will still control the fan speed. Table 1-1 shows the power requirements for an individual fan in a fan
tray.
1.11 Cards and Slots
When a card is inserted in a card slot, it will contact the shelf backplane but is not fully installed until
the ejectors are fully closed.
1.11.1 Card Slot Requirements
The ONS 15600 shelf has 14 card slots numbered sequentially from left to right. Slots 1 to 4 and 11 to 14
are reserved for optical (OC-N) traffic cards. These slots can host any of the ONS 15600 optical cards.
Slots 6/7 and 8/9 are dedicated to SSXC cards, and Slots 5 and 10 house the TSC cards. Each card is
keyed to fit only in an appropriate slot for that card. Unused card slots should be occupied by a filler card
(blank faceplate).
Caution Do not operate the ONS 15600 with a single TSC card or a single SSXC card installed. Always operate
the shelf with one active and one redundant standby TSC card and two SSXC cards.
Shelf assembly slots have symbols indicating the type of cards that you can install in them. Each
ONS 15600 card has a corresponding symbol. The symbol on the card must match the symbol on the slot.
Table 1-2 shows the slot and card symbol definitions.
Refer to Chapter 2, “Card Reference,” for more information about ONS 15600 cards.
All physical connections to the optical cards are made through OGI connectors on the card faceplate.
Table 1-3 lists the number of ports and the line rates for ONS 15600 optical cards.
Table 1-1 Power Requirements for an Individual Fan
Condition Watts Amps BTU/Hr.
Min at 48 V (ambient temperature less than 25 degrees C) 12 0.25 41
Max at 48 V (ambient temperature greater than 25 degrees C) 46 0.95 157
Table 1-2 Slot and Card Symbols
Symbol Color/Shape Definition
Orange/Circle Any traffic card (OC-48, OC-192, ASAP)
Purple/Square TSC slot; only install ONS 15600 cards with a square symbol on the faceplate
Green/Cross SSXC slot; only install ONS 15600 cards with a cross symbol on the faceplate

1-18
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.11.2 ASAP Card Cables
1.11.2 ASAP Card Cables
To allow enough clearance between ASAP card cables and the front door on ONS 15600 shelf assembly,
you must install LC connectors with a connector boot angled downward at 45 or 50 degrees.
Figure 1-14 shows a 45-degree boot with LC connector.
Figure 1-14 Molex 45-Degree Boot with LC Connector
Figure 1-15 shows a 50-degree boot with LC connector.
Table 1-3 Card Ports and Line Rates
Card Ports Line Rate per Port
OC48/STM16 LR/LH 16 Port 1550;
OC48/STM16 SR/SH 16 Port 1310
4 physical interfaces; 4 ports per interface,
totalling 16 OC-48 ports per card
2488.32 Mbps (STS-48, STS-48c)
OC192/STM64 LR/LH 4 Port 1550;
OC192/STM64 SR/SH 4 Port 1310
4 physical interfaces; 1 port per interface,
totalling 4 OC-192 ports per card
9.95 Gbps (STS-192, STS-192c)
Any-Service Any-Port (ASAP) card
(OC-3, OC-12, OC-48, OC-192, or
Gigabit Ethernet)
4 physical interfaces; 1 to 4 ports per interface,
depending on the Pluggable Input/Output
Module used; totalling a maximum of 4
OC-192 ports per card
Up to 9.95 Gbps (STS-192,
STS-192c)
151977

1-19
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.11.3 OGI Cables
Figure 1-15 Tyco 50-Degree Boot with LC Connector
This fiber boot should be part of your fiber-optics cable assembly, along with an LC connector.
You can obtain this boot from the following two vendor. Contact the vendor for specific part numbers:
Molex Incorporated
5224 Katrine Ave.
Downers Grove, IL 605151-800-522-6752
[phone]
[phone]
This fiber boot can also be obtained with part number from the following vendor:
Tyco Electronics (www.tycoelectronics.custhelp.com)
P.O. Box 3608
Harrisburg, PA 17175
1.11.3 OGI Cables
The ONS 15600 faceplate has OGI connectors that terminate in either SC, ST, or FC connectors.
Figure 1-16 shows the OGI to SC cable breakout for the OC-48 card.
151984

1-20
Cisco ONS 15600 Reference Manual, R8.0
Chapter 1 Shelf and Backplane Hardware
1.11.3 OGI Cables
Figure 1-16 OGI Cable Breakout
Figure 1-17 show the OGI pin breakout for the OC-48 card.
Figure 1-17 OGI Pin Breakout
Breakout protection
SC connector
SC key feature
P1
P2
P3
P4
P5
P6
P7
P8
96520
P1 (Blue)
P2 (Orange)
P3 (Green)
P4 (Brown)
P5 (Gray)
P6 (White)
P7 (Red)
P8 (Black)
96521
White ridge
this side
Alignment pins
(male)
