Cisco Prisma EtherLinX User manual

4008226 Rev B 1
Prisma EtherLinX Unit Installation
Instructions
Overview
Introduction
The Prisma®EtherLinX™unit enables service providers to offer differentiated data
networking or virtual private network (VPN) services to multi-tenant building and
business customers. Residing at the customer premises or at the service provider
point of presence (POP), the Prisma EtherLinX unit provides a VLAN-based Layer 2
entry point to the metropolitan area network (MAN) fiber network, trunking,
differentiating and separating customer traffic. Featuring SNMP management,
bandwidth control, quality of service (QoS), traffic prioritization, and multicast
pruning (using IGMP v1, v2), it is an ideal solution for delivering Ethernet-based
services to customers quickly and cost-effectively. The Prisma EtherLinX unit also
features Telnet, and firmware upgrading through serial configuration or Telnet via a
TFTP server.
Purpose
These installation instructions provide product information and instructions for
installing the Prisma EtherLinXunit.
Continued on next page

2 4008226 Rev B
Overview, Continued
Qualified Personnel
Only appropriately qualified and trained personnel should install, operate, maintain,
and service this product.
WARNING:
Allow only qualified personnel to install, operate, maintain, and service this
product. Otherwise, personal injury or equipment damage may occur.
In These Installation Instructions
These installation instructions contain the following topics.
Topic See Page
Important Safety Instructions 3
Laser Safety 13
Product Description 16
Prisma EtherLinX Unit Installation Instructions 17
Software Configurable Features 19
About PrismaView Software 21
SNMP Management 22
Device-Specific Configuration 28
Fiber Optic Cleaning Guidelines 34
Module LED Indicators 36
For Information 37

4008226 Rev B 3
Important Safety Instructions
Read and Retain Instructions
Carefully read all safety and operating instructions before operating this equipment,
and retain them for future reference.
Follow Instructions and Heed Warnings
Follow all operating and use instructions. Pay attention to all warnings and cautions
in the operating instructions, as well as those that are affixed to this equipment.
Explanation of Warning and Caution Icons
Avoid personal injury and product damage! Do not proceed beyond any symbol
until you fully understand the indicated conditions.
The following warning and caution icons alert you to important information about
the safe operation of this product:
You may find this symbol in the document that accompanies this product.
This symbol indicates important operating or maintenance instructions.
You may find this symbol affixed to the product. This symbol indicates a
live terminal where a dangerous voltage may be present; the tip of the
flash points to the terminal device.
You may find this symbol affixed to the product. This symbol indicates a
protective ground terminal.
You may find this symbol affixed to the product. This symbol indicates a
chassis terminal (normally used for equipotential bonding).
You may find this symbol affixed to the product. This symbol warns of a
potentially hot surface.
You may find this symbol affixed to the product and in this document.
This symbol indicates an infrared laser that transmits intensity-
modulated light and emits invisible laser radiation or an LED that
transmits intensity-modulated light.
Continued on next page

4 4008226 Rev B
Important Safety Instructions, Continued
Terminology
The terms defined below are used in this document. The definitions given are based
on those found in safety standards.
Service Personnel - The term service personnel applies to trained and qualified
individuals who are allowed to install, replace, or service electrical equipment. The
service personnel are expected to use their experience and technical skills to avoid
possible injury to themselves and others due to hazards that exist in service and
restricted access areas.
User and Operator - The terms user and operator apply to persons other than service
personnel.
Ground(ing) and Earth(ing) - The terms ground(ing) and earth(ing) are synonymous.
This document uses ground(ing) for clarity, but it can be interpreted as having the
same meaning as earth(ing).
Electric Shock Hazard
Because of the potential for higher humidity, the presence of moisture, the proximity
to ground potential and the possibility that hazardous voltages may be present on
network connected cables, there is a greater risk of electric shock when working with
electronic equipment in the outdoor environment.
To minimize the likelihood and effect of electric shock, follow the instructions in this
warning and the precautions below.
WARNING!
To reduce risk of electric shock, perform only the instructions that are included
in the operating instructions. Refer all servicing to qualified service personnel
only.
•Do not work in rain, fog or snow conditions
•Ensure equipment and cables are dry
•Wear shoes with soles made of insulated material e.g. rubber, vinyl, etc.
•When making electrical connections, work with one hand in your pocket and
avoid accidental contact with grounded surfaces
•Use insulated tools to make electrical connections
•Make all other connections before connecting power to the equipment
Installation
This equipment should be installed by qualified service personnel and should
comply with national and local requirements.
Continued on next page

4008226 Rev B 5
Important Safety Instructions, Continued
Note to the Installer
Equipment Placement
WARNING:
Avoid personal injury and damage to this equipment. An unstable mounting
surface may cause this equipment to fall.
To protect against equipment damage or injury to personnel, comply with the
following:
•Place this equipment close enough to a mains AC outlet to accommodate the
length of this equipment’s power cord.
•Route all power cords so that people cannot walk on, place objects on, or lean
objects against them. This may pinch or damage the power cords. Pay particular
attention to power cords at plugs, outlets, and the points where the power cords
exit this equipment.
•Make sure the mounting surface or rack is stable and can support the size and
weight of this equipment.
Continued on next page

6 4008226 Rev B
Important Safety Instructions, Continued
Ventilation
WARNING:
Avoid electric shock and fire hazard! Never push objects through the openings
in this equipment. Foreign objects can touch dangerous voltage points or cause
electrical shorts that can result in electric shock or fire.
This equipment may have openings for ventilation that protect it from overheating.
To ensure the reliability of this equipment, do not obstruct the openings
•Do not place other equipment, lamps, books, or other objects on top of this
equipment.
•Do not place this equipment in any of the following locations.
−On a bed, sofa, rug, or similar surface
−Over a radiator or a heat register
−In an enclosure, such as a bookcase or equipment rack, unless the installation
provides proper ventilation
Handling Precautions
When moving a cart that contains this equipment, check for any of the following
possible hazards:
WARNING:
Avoid personal injury and damage to this equipment! Move
any equipment and cart combination with care. Quick stops,
excessive force, and uneven surfaces may cause this
equipment and cart to overturn.
Cleaning the Equipment
Before cleaning this equipment, unplug it from the electrical outlet. Use a damp cloth
to clean this equipment. Do not use a liquid cleaner or an aerosol cleaner. Do not use
a magnetic/static cleaning device (dust remover) to clean this equipment.
Continued on next page

4008226 Rev B 7
Important Safety Instructions, Continued
Object and Liquid Entry
Never push objects of any kind into this equipment through openings as they may
touch dangerous voltage points or short out parts that could result in a fire or electric
shock. Do not expose this equipment to liquid or moisture. Do not place this
equipment on a wet surface. Do not spill liquids on or near this equipment.
Overloading
Do not overload electrical outlets, extension cords, or integral convenience
receptacles, as this can result in a risk of fire or electric shock. For equipment that
requires battery power or other sources to operate, refer to the operating instructions
for that equipment.
Lightning and Power Surges
To protect this equipment against damage from lightning storms and power-line
surges, do the following:
•Disconnect the power cord from the grounded mains electrical outlet and
disconnect the antenna or cable system under the following circumstances.
−During lightning storms, or
−When you are not using this equipment for an extended period
•Ground your antenna system to provide some protection against voltage surges
and built-up static charge.
Power Sources
WARNING:
Avoid electric shock and fire hazard! Do not overload electrical outlet and
extension cords. For equipment that requires battery power or other sources to
operate, refer to the operating instructions for that equipment.
•A label on this equipment indicates the correct power source for this equipment.
Operate this equipment only from an electrical outlet with the voltage and
frequency indicated on the equipment label.
•If this equipment plugs into an outlet, the outlet must be near this equipment, and
must be easily accessible.
•This equipment may have two power sources. Be sure to disconnect all power
sources before working on this equipment.
Continued on next page

8 4008226 Rev B
Important Safety Instructions, Continued
•If this equipment does not have a main power switch, the power cord connector
serves as the disconnect device.
•Always pull on the plug or the connector to disconnect a cable. Never pull on the
cable itself.
•Unplug this equipment if it will be unused for long periods of time.
•If you are uncertain of the type of power supply to your home or business, consult
your local power company.
Grounding
This section provides instructions for verifying that the equipment is properly
grounded.
Safety Plugs (USA Only)
This equipment is equipped with either a 3-terminal (grounding-type) safety plug or
a 2-terminal (polarized) safety plug. The wide blade or the third terminal is provided
for safety. Do not defeat the safety purpose of the grounding-type or polarized safety
plug.
To properly ground this equipment, follow these safety guidelines:
•Grounding-Type Plug - For a 3-terminal plug (one terminal on this plug is a
protective grounding pin), insert the plug into a grounded mains, 3-terminal
outlet.
Note: This plug fits only one way. If this plug cannot be fully inserted into the
outlet, contact an electrician to replace the obsolete 3-terminal outlet.
•Polarized Plug - For a 2-terminal plug (a polarized plug with one wide blade and
one narrow blade), insert the plug into a polarized mains, 2-terminal outlet in
which one socket is wider than the other.
Note: If this plug cannot be fully inserted into the outlet, try reversing the plug. If
the plug still fails to fit, contact an electrician to replace the obsolete 2-terminal
outlet.
Continued on next page

4008226 Rev B 9
Important Safety Instructions, Continued
Grounding Terminal
If this equipment is equipped with an external grounding terminal, attach one end of
an 18-gauge wire (or larger) to the grounding terminal; then, attach the other end of
the wire to a ground, such as a grounded equipment rack.
Safety Plugs (European Union)
•Class I Mains Powered Equipment – Provided with a 3-terminal AC inlet and
requires connection to a 3-terminal mains supply outlet via a 3-terminal power
cord for proper connection to the protective ground.
Note: The equipotential bonding terminal provided on some equipment is not
designed to function as a protective ground connection.
•Class II Mains Powered Equipment – Provided with a 2-terminal AC inlet that
may be connected by a 2-terminal power cord to the mains supply outlet. No
connection to the protective ground is required as this class of equipment is
provided with double or reinforced and/or supplementary insulation in addition
to the basic insulation provided in Class I equipment.
Note: Class II equipment, which is subject to EN 50083-1, is provided with a
chassis mounted equipotential bonding terminal. See the section titled
Equipotential Bonding for connection instructions.
Equipotential Bonding
If this equipment is equipped with an external chassis terminal marked with the IEC
60471-5020 chassis icon ( ), the installer should refer to CENELEC standard EN
50083-1 or IEC standard IEC 60728-11 for correct equipotential bonding connection
instructions.
Servicing
WARNING:
Avoid electric shock! Opening or removing the cover may expose you to
dangerous voltages.
Do not open the cover of this equipment. Refer all servicing to qualified personnel
only. Contact us for instructions.
Continued on next page

10 4008226 Rev B
Important Safety Instructions, Continued
Damage that Requires Service
For damage that requires service, unplug this equipment from the electrical outlet.
Refer service to qualified service personnel when any of the following occurs:
•There is damage to the power cord or plug
•Liquid enters the equipment
•A heavy object falls on the equipment
•Operation is not normal (the instructions in this manual describe the proper
operation)
•If you drop this equipment, or damage the cabinet of this equipment
•If this equipment exhibits a distinct change in performance
Upon completion of any service or repairs to this equipment, ask the service
technician to perform safety checks to determine that the equipment is in proper
operating condition.
CAUTION:
Avoid damage to this equipment! Adjust only what the operating instructions
describe. Improper adjustment of controls may result in damage that may
require extensive corrective work by qualified service personnel.
Replacement Parts
When replacement parts are required, be sure the qualified service personnel has
used parts specified by us or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
Safety Check
Upon completion of any service or repairs to this equipment, ask the service
technician to perform safety checks to determine that this equipment is in proper
operating condition.
Continued on next page

4008226 Rev B 11
Important Safety Instructions, Continued
Electromagnetic Compatibility Regulatory Requirements
This equipment meets applicable electromagnetic compatibility (EMC) regulatory
requirements. Refer to this equipment’s data sheet for details about regulatory
compliance approvals. EMC performance is dependent upon the use of correctly
shielded cables of good quality for all external connections, except the power source,
when installing this equipment.
•Ensure compliance with cable/connector specifications and associated installation
instructions where given elsewhere in this manual.
Otherwise, comply with the following good practices:
•Multi-conductor cables should be of single-braided, shielded type and have
conductive connector bodies and backshells with cable clamps that are
conductively bonded to the backshell and capable of making 360° connection to
the cable shielding. Exceptions from this general rule will be clearly stated in the
connector description for the excepted connector in question.
•Ethernet cables should be of single-shielded or double-shielded type.
•Coaxial cables should be of the double-braided shielded type.
EMC
Where this equipment is subject to USA FCC and/or Industry Canada rules, the
following statements apply:
FCC Statement for Class A Equipment
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when this equipment is
operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case users will be required to
correct the interference at their own expense.
Continued on next page

12 4008226 Rev B
Important Safety Instructions, Continued
Industry Canada – Industrie Canadienne Statement
This apparatus complies with Canadian ICES-003.
Cet appareil est confome à la norme NMB-003 du Canada.
CENELEC/CISPR Statement with Respect to Class A Information Technology Equipment
This is a Class A equipment. In a domestic environment this equipment may cause
radio interference in which case the user may be required to take adequate measures.
Modifications
This equipment has been designed and tested to comply with applicable safety, laser
safety, and EMC regulations, codes, and standards to ensure safe operation in its
intended environment. Refer to this equipment’s data sheet for details about
regulatory compliance approvals.
Do not make modifications to this equipment. Any changes or modifications could
void the user’s authority to operate this equipment.
Modifications have the potential to degrade the level of protection built into this
equipment, putting people and property at risk of injury or damage. Those persons
making any modifications expose themselves to the penalties arising from proven
non-compliance with regulatory requirements and to civil litigation for
compensation in respect of consequential damages or injury.
Accessories
Use only attachments or accessories specified by the manufacturer.
CAUTION:
Maintain electrical safety! Power-operated equipment or accessories that you
connect to this equipment should bear the UL listing mark or CSA certification
mark on the accessory itself, and should not be modified so as to defeat the
safety features. This will help avoid any potential for electric shock or fire. If in
doubt, contact qualified service personnel.
Mounting Accessories
CAUTION:
Use this equipment only with a cart, stand, bracket, table, or other mounting
accessories that meet our specifications. Carefully follow all instructions for
proper mounting.

4008226 Rev B 13
Laser Safety
Introduction
This equipment contains an infrared laser that transmits intensity-modulated light
and emits invisible radiation.
Warning: Radiation
WARNINGS:
• Avoid personal injury! Use of controls, adjustments, or performance of
procedures other than those specified herein may result in hazardous
radiation exposure.
• Avoid personal injury! The laser light source on this equipment (if a
transmitter) or the fiber cables connected to this equipment emit invisible
laser radiation. Avoid direct exposure to the laser light source.
• Avoid personal injury! Viewing the laser output (if a transmitter) or fiber
cable with optical instruments (such as eye loupes, magnifiers, or
microscopes) may pose an eye hazard.
•Do not apply power to this equipment if the fiber is unmated or unterminated.
•Do not stare into an unmated fiber or at any mirror-like surface that could reflect
light that is emitted from an unterminated fiber.
•Do not view an activated fiber with optical instruments (e.g., eye loupes,
magnifiers, microscopes).
•Use safety-approved optical fiber cable to maintain compliance with applicable
laser safety requirements.
Warning: Fiber Optic Cables
WARNING:
Avoid personal injury! Qualified service personnel may only perform the
procedures in this document. Wear safety glasses and use extreme caution when
handling fiber optic cables, particularly during splicing or terminating
operations. The thin glass fiber core at the center of the cable is fragile when
exposed by the removal of cladding and buffer material. It easily fragments into
glass splinters. Using tweezers, place splinters immediately in a sealed waste
container and dispose of them safely in accordance with local regulations.
Continued on next page

14 4008226 Rev B
Laser Safety,Continued
Safe Operation For Software Controlling Optical Transmission Equipment
If this document discusses software, the software described is used to monitor
and/or control our and other vendors’ electrical and optical equipment designed to
transmit video, voice, or data signals. Certain safety precautions should be observed
when operating equipment of this nature.
For equipment specific safety requirements, refer to the appropriate section of the
equipment documentation.
For safe operation of this software, refer to the following warnings.
WARNINGS:
• Ensure that all optical connections are complete or terminated before using
this equipment to remotely control a laser device. An optical or laser device
can pose a hazard to remotely located personnel when operated without their
knowledge.
• Allow only personnel trained in laser safety to operate this software.
Otherwise, injuries to personnel may occur.
• Restrict access of this software to authorized personnel only.
• Install this software in equipment that is located in a restricted access area.
Laser Safety Information
This laser based multi-mode transceiver is an IEC 60825-1 Amend. 2 Class 1 laser
product. It complies with FDA performance standards (21 CFR 1040.10 and 1040.11)
for laser products except for deviations pursuant to Laser Notice No. 50, dated July
26, 2001.
Note: All adjustments have been made at the factory prior to shipment of the
module. No maintenance or alteration of this device is required. No adjustments or
controls provided.
Class 1 Laser Product
Avoid possible exposure to hazardous levels of invisible laser radiation; do not view
laser aperture.
Continued on next page

4008226 Rev B 15
Laser Safety,Continued
Product Specific Laser Information
The following illustration displays the location of the laser apertures on this
module’s front panel.
The following label is on the module.
Class 1 Laser product, Luokan 1 Laserlaite,
Laser Klasse 1, Appareil A'Laser de Classe 1

16 4008226 Rev B
Product Description
Prisma EtherLinX Unit
The Prisma EtherLinX unit includes one Uplink port (either 100Base-FX fiber or
10/100 twisted-pair), four 10/100 twisted-pair Ethernet downlink ports (for
connecting users/LANs), and an internal 100 - 240 ±10% AC power supply.
Prisma EtherLinX Unit Illustration
Refer to the following illustration for a view of the Prisma EtherLinX unit.

4008226 Rev B 17
Prisma EtherLinX Unit Installation Instructions
Introduction
The Prisma EtherLinX unit comes ready to install; there is no hardware
configuration required. All features, such as FiberAlert and Auto-Negotiation, are
software configurable. Refer to the Help file for configuration information.
Follow these steps to install the Prisma EtherLinX unit.
1. Place the unit on a suitable flat surface.
2. Attach the cables between the Prisma EtherLinX unit and each device that is
to be interconnected.
3. Plug the unit into a reliable, filtered power source.
Wall-Mount Installation
Follow these steps to wall mount the Prisma EtherLinX unit.
1. Attach the wall-mount bracket to the Prisma EtherLinX unit using the
supplied screws.
Screw holes for
mounting unit to 
wall. Wall-mount 
bracket must be 
attached to the
unit.
Screw holes for mounting 
wall-mount bracket to unit
with supplied screws.
T11389
2. Mount the unit to the wall by tightening the screws (not supplied).
3. Attach the cables between the Prisma EtherLinX unit and each device that is
to be interconnected.
4. Plug the unit into a reliable, filtered power source.
Continued on next page

18 4008226 Rev B
Prisma EtherLinX Unit Installation Instructions,Continued
Rack-Mount Installation
You can rack mount the Prisma EtherLinX unit, by ordering and using the rack
mount kit, which includes two brackets that screw onto either side of the Prisma
EtherLinX unit. Once you attach the brackets to the unit, install the Prisma
EtherLinX unit into the rack.
AutoCross Feature for Twisted-pair Connection
All twisted-pair ports on the Prisma EtherLinX unit include AutoCross, a feature
which automatically selects between a crossover workstation or pass-through
connection depending on the connected device.
Note: Since single-strand fiber products use optics that transmit and receive on two
different wavelengths, you must deploy single-strand fiber products in pairs, or
connect two compatible single-strand fiber products. The two connected products
must also have the same speed and distance capabilities [i.e., both are single-mode
(20 km) or both are single/PLUS (40 km)].

4008226 Rev B 19
Software Configurable Features
Introduction
The FiberAlert, Auto-Negotiation (Selective Advertising), and Bandwidth Control
features are all configurable via the management software or via serial configuration.
Refer to the Prisma EtherLinX unit Help file for software configuration information,
or refer to About Serial Port Configuration later in this document.
About FiberAlert
The Prisma EtherLinX unit includes the advanced troubleshooting feature,
FiberAlert, which minimizes the problems associated with the loss of one strand of
fiber. If a strand is unavailable, the Prisma EtherLinX unit notes the loss of link. The
device then stops transmitting data and the link signal until a signal or link pulse is
received. The result is that the link LED on BOTH sides of the fiber connection goes
out indicating a fault somewhere in the fiber loop. Using FiberAlert, a local site
administrator is notified of a fault and can quickly determine where a cable fault is
located.
Note: FiberAlert is not available/applicable on single-strand fiber products.
Auto-Negotiation, Duplex Mode and Speed
The twisted-pair ports on the Prisma EtherLinX unit auto-negotiate for speed and
duplex mode. This device can also selectively advertise or force the speed and
duplex mode. If the device has a fiber Uplink port, it does not auto-negotiate; it
always operates at 100 Mbps Full-Duplex.
Auto-Negotiation
The Prisma EtherLinX unit ships from the factory with Auto-Negotiation enabled on
the twisted-pair ports. In this mode, the twisted-pair port negotiates for speed and
duplex mode.
Forcing the Speed and Duplex Mode
The twisted-pair downlink ports on the Prisma EtherLinX unit can also be manually
set for 10 Mbps or 100 Mbps operation and for Half- Duplex or Full-Duplex (i.e., 10
Mbps Full-Duplex, 10 Mbps Half-Duplex, 100 Mbps Full-Duplex, or 100 Mbps Half-
Duplex).
Continued on next page

20 4008226 Rev B
Software Configurable Features,Continued
Selective Advertising
Selective Advertising, when used in combination with Auto-Negotiation, advertises
only the configured speed and duplex mode for the twisted-pair port.
Note: If a specific speed and/or duplex mode are desired, it is recommended that
you use Selective Advertising, rather than Force Mode, when connecting to devices
that ONLY auto-negotiate.
Bandwidth Control
The Prisma EtherLinX unit includes bandwidth control functionality. You can
independently set bandwidth, in 32 Kbps increments, on each downlink port, or you
can set the bandwidth for the unit by assigning the uplink port a given amount.
Refer to the Help file for software configuration information.
