Cisco SOHO Series User manual

Cisco Access Routers
For Teleworkers, Small Offices, Small to Medium-Sized
Businesses, and Small to Large Enterprise Branch Offices
Quick Reference Guide: Cisco Access Routers
Cisco SOHO, 800, 1700, 2600, 3600,
3700, 7200, 7300, and 7400 Series
AccessRouter_10.21.02 10/24/02 3:31 PM Page 108

1
Cisco Access Routers
ForTeleworkers, Small Offices, Small to Medium-Sized
Businesses, and Small to Large Enterprise Branch Offices
This is your guide to Cisco access routers, the widest and most
versatile portfolio of products enabling the deployment of full
services to all users, from the home office to the branch office to
the enterprise campus.
Cisco Systems is the worldwide leader in networking for the
Internet, offering solutions that fully support the enterprise-wide
deployment of network-enabled applications. By delivering intelligent
services to the farthest reaches of an organization, Cisco access
routers provide the high availability, enhanced security, easy managea-
bility, and advanced quality of service (QoS) required to support
today’s most sophisticated applications, including videoconferencing,
e-learning, customer relations management, and collaborative
applications.
This guide shows how Cisco access routers also enable you to meet
your future needs, with modular designs that allow incremental
migration as your business and network requirements change.
In the guide, you can see for yourself how Cisco delivers the benefits
beyond access, enabling the full-service branch, from teleworkers,
small offices, and small to medium-sized businesses to small to large
enterprise branch offices.
AccessRouter_10.21.02 10/24/02 3:30 PM Page 1

AccessRouter_10.21.02 10/24/02 3:30 PM Page 2

Cisco Access Routers
ForTeleworkers, Small Offices, Small to Medium-Sized
Businesses, and Small to Large Enterprise Branch Offices
Quick Reference Guide
Series Overview
Cisco SOHO Series and 800 Series . . . . . . . . . . . . . . . . . 7
Cisco 1700 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cisco 2600 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Cisco 3600 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cisco 3700 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Cisco 7200 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Cisco 7300 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Cisco 7400 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Modularity
Network Modules for Cisco
2600, 3600, and 3700 Series . . . . . . . . . . . . . . . . . . . . . . 47
Interface Cards for Cisco
1700, 2600, 3600, and 3700 Series . . . . . . . . . . . . . . . . . 76
Advanced Integration Modules
for Cisco 1700, 2600, 3600, and 3700 Series . . . . . . . . . 88
Compatibility Quicklook . . . . . . . . . . . . . . . . . . . . . . . . . 93
Product Transition Matrix . . . . . . . . . . . . . . . . . . . . . . . 105
AccessRouter_10.21.02 10/24/02 3:30 PM Page 3

Power Branch Solutions
for Small to Medium-Sized
Business and Enterprise Branch Offices
Cisco 2600 Series
Small/Medium-Sized
Enterprise Branch Office
•Built-in Fast Ethernet
(10 /10 0) LAN
•Manageability and
reliability of Cisco
IOS Software
Business-class DSL
•ADSL and G.SHDSL
support
•Enhanced QoS over DSL
Business-class security
•Stateful inspection
firewall
•VPNs: software and
hardware encryption,
Cisco Easy VPN
•Intrusion detection
system (IDS)
• Software compression
Multiservice data/voice
•Low and high-density
analog and digital
voice/fax
•Survivable Remote Site
Telephony (SRST)
Modularity
•Wide array of WAN/voice
interface cards
•Network and advanced
integration module (AIM)
support
•Supports over 50 network
modules, AIMs,
voice/WAN interfaces
•16-port EtherSwitch
Module
•Analog modem
(1 and 2 port)
Cisco SOHO Series
Small Office/Home Office
•Manageability and
reliability of Cisco
IOS®Software
Business-class security
•Stateful inspection
firewall
Fixed configuration
•Somemodels with
integrated 4-port hub
•Dual Ethernet, ADSL,
ADSL over ISDN, and
G.SHDSL
Cisco 800
Teleworker
Small Remote Office
•Manageability and
reliability of Cisco
IOS Software
Business-class security
•Stateful inspection
firewall
•VPN software encryption
• Voice and data
integration
(Cisco 827-4V)
Fixed configuration
•Somemodels with
integrated 4-port hub
•Dual Ethernet, ADSL,
ADSL over ISDN, and
G.SHDSL
Cisco 1700 Series
Small/Medium-Sized
Business, Small Enterprise
Branch Office
•Built-in Fast Ethernet
(10 /10 0) LAN
•Manageability and
reliability of Cisco
IOS Software
Business-class DSL
•ADSL and G.SHDSL
support
•Enhanced QoS over DSL
Business-class security
•Stateful inspection
firewall
•VPNs: software and
hardware encryption,
Cisco Easy VPN
server/remote
•Intrusion detection
system (IDS)
• Software compression
Multiservice data/voice
•Low and high-density
analog and digital voice
•Survivable Remote Site
Telephony (SRST)
Modularity
•WAN/voice modular slots
•Wide array of WAN/voice
interface cards
•T1/E1, ISDN, ADSL,
G.SHDSL, Frame Relay
options
Cisco 3600 Series
Medium-Sized to Large
Enterprise Branch Office
•Built-in Fast Ethernet
(10/100) LAN (Cisco 3660)
•Manageability and
reliability of Cisco
IOS Software
Business-class DSL
•ADSL and G.SHDSL
support
•Enhanced QoS over DSL
Business-class security
•Stateful inspection
firewall
•VPNs: software and
hardware encryption,
Cisco Easy VPN
•Intrusion detection
system (IDS)
• Software compression
Multiservice data/voice
•Analog and digital voice
•Survivable Remote Site
Telephony (SRST)
Modularity
•Wide array of WAN/voice
interface cards
•Networkand advanced
integration module (AIM)
support (Cisco 3660)
•Supports over 80 network
modules, AIMs, and
voice/WAN interfaces
•16-port EtherSwitch
Module (36-port for
Cisco 3660)
AccessRouter_10.21.02 10/24/02 3:30 PM Page 4

Cisco offers the industry’s broadest and most versatile portfolio of
secure, high-performance access routers, enabling the deployment of a
wide array of services to the farthest reaches of an organization, from
the home office to the small office to the large enterprise branch office.
Cisco 3700 Series
Integrated Enterprise
Branch Office
•Built-in Fast Ethernet
(10 /10 0) LAN
•Manageability and
reliability of Cisco
IOS Software
•High-service density in
compact form
•Single platform IP
telephony infrastructure
•Optional integrated
in-line powered
low-density switching
Business-class DSL
•ADSL and G.SHDSL
support
•Enhanced QoS over DSL
Business-class security
•Stateful inspection
firewall
•VPNs: software and
hardware encryption,
Cisco Easy VPN
•Intrusion detection
system (IDS)
• Software compression
Multiservice data/voice
•Analog and digital voice
•Survivable Remote Site
Telephony (SRST)
Modularity
•Wide array of WAN/voice
interface cards
•Networkand advanced
integration module (AIM)
support
•Supports over 70 network
modules, AIMs, and
voice/WAN Interfaces
•16-or 36-port EtherSwitch
Module
Cisco 7200 Series
Large Branch Office
Environments
•RackDensity System
(RDS) allows for up to
nine routers per rack
•Application versatility
—
MPLS, VPN, broadband
aggregation, QoS, and
multiservice
Business-class security/VPN
•Stateful inspection firewall
•VPNs: software and
hardware encryption,
Cisco Easy VPN
•Hardware compression
•Service-level validation
features
•Intrusion detection
system (IDS)
Multiservice data/voice
•Analog and digital voice
•Survivable Remote Site
Telephony (SRST)
•Multiservice interchange
(MIX)-enabled backplane
for service integration
Modularity
• Supports over 70
interfaces, providing a
comprehensive range of
connectivity options
from FE to GE, and DSO
through OC-12 DPT
•Shared interfaces with
Cisco 7400, Cisco 7500,
and Cisco 7600 Series
Internet routers for
common sparing
• FE/GE can be built-in to
system for high-
performance LAN
connectivity
•Flexible processing
options, including
hardware-accelerated IP
services, with Parallel
Express Forwarding
•Comprehensive
management services
through Cisco Element
Manager Framework
(CEMF)
Cisco 7300 Series
Large Branch Office
Environments
•High-performance
connectivity from T3 to
OC-48
•Two GE built-in to system
for high-performance
LAN connectivity
•Hardware-accelerated
services with Parallel
Express Forwarding
•Optional redundant
processor for increased
network availability
•Multiprotocol support
Business-class security/VPN
•Hardware-accelerated
Access Control Lists
•Stateful inspection
firewall
• Software compression
Modularity
•More than 20 network
line cards
•Up to 4 port adaptors
•2fixed GE ports per
NSE-100
•Manageability and
reliability of Cisco IOS
Software
Cisco 7400 Series
Large Branch Office
Environments
•Hardware-accelerated IP
services with Parallel
Express Forwarding
•Compact one-RU form
factor
•Application versatility
—
MPLS, VPN, Broadband
aggregation, QoS, and
multiservice
Business-class security/VPN
•Stateful inspection
firewall
•VPNs: software and
hardware encryption,
Cisco Easy VPN
•Hardware-accelerated
Access Control Lists
•Intrusion detection
system (IDS)
• Software compression
Multiservice data/voice
•Analog and digital voice
•Survivable Remote Site
Telephony (SRST)
Modularity
•Supports over 40
interfaces, providing a
comprehensive range of
connectivity options
from FE to GE, and DSO
through OC-3
•Shared interfaces with
Cisco 7200, Cisco 7500,
and Cisco 7600 Series
Internet routers for
common sparing
•FE/GE built-in to system
for high-performance
LAN connectivity
•Comprehensive
management services
through Cisco Element
Manager Framework
(CEMF)
AccessRouter_10.21.02 10/24/02 3:31 PM Page 5

Cisco SOHO Series
and 800 Series
Cisco SOHO Series and 800 Series routers make it easy and affordable to extend
the power of Cisco IOS®technology to small businesses, small remote offices, and
telecommuters, providing superior security, reliability, and manageability at a low
cost. These routers deliver secure, multiuser access to the Internet or corporate
LAN through a single ADSL, ADSL-over-ISDN, G.SHDSL, ISDN, or serial
connections (up to 512 Kbps), or via an Ethernet WAN port connected to an
external broadband modem.
Business-Class Firewall
Cisco SOHO Series and 800 Series routers
provide the proven security features of Cisco
IOS Software, including stateful firewall
protection. A stateful firewall offers more
intelligent perimeter security by denying or
permitting WAN traffic based on a session’s
state, so requests from users behind the
firewall can be received, while still preventing
unauthorized access.
Virtual Private Networking
Cisco 800 Series routers offer the added
protection of virtual private networks (VPNs),
which use data encryption and secure tunnels
to protect data as it travels from one site to
another, such as a branch office to corporate
headquarters. The Cisco 800 Series supports
IPSec 3DES, the most secure form of data
encryption. With the support of Cisco Easy
VPN Remote, setup, management, and
maintenance of VPN connections is simple using
Cisco 800 Series routers. Users who have PC
VPN software clients can use SOHO Series
routers, with support for IPSec passthrough, to
provide managed firewall protection for remote
offices or home office networks.
Simplified Installation and Set up
Cisco SOHO Series and 800 Series routers come
with color-coded cables and connectors, as well
as default configurations, so even users with
limited technical experience can quickly install
and activate them. The Cisco Router Web Setup
(CRWS) tool, a Web-based installation software
tool, makes configuration just as simple by
providing a graphical user interface (GUI) and
easy-to-follow instructions.
QoS
The Cisco 800 Series routers provide quality of
service (QoS) for traffic management. QoS can
give precedence to mission-critical applications
or delay-sensitive applications such as voice and
video traffic.
Integrated Support for VoIP
The Cisco 827-4V ADSL router provides four
integrated FXS ports to deliver toll-quality
voice for interoffice voice with remote offices
or teleworkers.
7
Benefits and Advantages
AccessRouter_10.21.02 10/24/02 3:31 PM Page 7

When to Deploy
Series Distinctions
Cisco SOHO Series and 800 Series
8
Cisco SOHO Series Cisco 800 Series
WAN Technologies Ethernet, ADSL, ADSL Ethernet, ADSL, ADSL over
over ISDN, G.SHDSL ISDN, G.SHDSL, ISDN, serial
Security Stateful firewall Stateful firewall
VPN IPSec passthrough only Integrated IPSec 3DES,
Easy VPN, IPSec passthrough
QoS DSL ATM QoS only DSL ATM QoS and IP QoS
Upgradability Software updates to Software updates and upgrades
default software image only to new software feature set,
upgradable memory
The Cisco SOHO Series is recommended when
you need to deploy:
•Small office/home office multiuser access
•An easy-to-deploy and setup solution for
nontechnical users
•Firewall protection for users with
PC VPN clients
•The proven reliability and manageability
of Cisco IOS Software
The Cisco 800 Series is recommended when
you need to deploy:
•Managed firewall and VPNs for small
remote offices and teleworkers
•QoS features for voice, video, and
mission-critical applications
•An easy-to-deploy and setup solution
including Cisco Easy VPN
•VoIP with ADSL lines (Cisco 827-4V)
•The proven reliability and manageability
of Cisco IOS Software
Internet
Corporate Teleworker
Cisco 800 Series
Small Remote Office
Cisco 800 Series
Main Office
Small Business
Cisco SOHO Series or
Cisco 800 Series
VPNTunnels
Stateful Firewall
Application Example
AccessRouter_10.21.02 10/24/02 3:31 PM Page 8

Tr ansition Information
Platform Overviews
Cisco SOHO Series and 800 Series
9
Platform Target Key Fixed LAN Fixed WAN Default/Max Default/Max Power
Market Features Connections Connections DRAM Flash Supply
ISDN and Serial Routers
Cisco 801 Small Business, Stateful firewall, 1-port 1-port ISDN 4/12 MB 8/12 MB External
Remote Office, IPSec 3DES, QoS, Ethernet BRI (S/T)
Teleworker IOS Remote (10BASE-T)
Management
Cisco 802 Small Business, Stateful firewall, 1-port 1-port ISDN 4/12 MB 8/12 MB External
Remote Office, IPSec 3DES, QoS, Ethernet BRI (U) NT-1
Teleworker IOS Remote (10BASE-T)
Management
Cisco 803 Small Business, Stateful firewall, 4-port 1-port ISDN 4/12 MB 8/12 MB External
Remote Office, IPSec 3DES, QoS, Ethernet hub BRI (S/T)
Teleworker IOS Remote (10BASE-T) 2 analog
Management telephone ports
Cisco 804 Small Business, Stateful firewall, 4-port 1-port ISDN 4/12 MB 8/12 MB External
Remote Office, IPSec 3DES, QoS, Ethernet hub BRI (U)
Teleworker IOS Remote (10BASE-T) NT-1, 2 analog
Management telephone ports
Cisco 805 Small Business, Stateful firewall, 1-port 1-port serial 4/12 MB 8/16 MB External
Remote Office, IPSec 3DES, QoS, Ethernet (up to
Teleworker IOS Remote (10BASE-T) 512 Kpbs)
Management
Ethernet to Ethernet Routers
Cisco SOHO 71 Small Business, Stateful firewall, 4-port 1-port 16/16 MB 8/8 MB External
Remote Users Web GUI, Ethernet hub Ethernet
with VPN IOS Remote (10BASE-T) (10BASE-T)
PC Clients Management
Cisco 806 Small Business, Stateful firewall, 4-port 1-port 32/32 MB 8/8 MB External
Remote Office, Web GUI, IPSec Ethernet hub Ethernet
Teleworker 3DES, Easy VPN (10BASE-T) (10BASE-T)
QoS, IOS Remote
Management
ADSL over ISDN Routers
Cisco SOHO 76 Small Business, Stateful firewall, 4-port 1-port 16/16 MB 8/8 MB External
Remote Users Web GUI, Ethernet hub ADSL over
with VPN PC IOS Remote (10BASE-T) ISDN
Clients Management
Cisco 826 Small Business Stateful firewall, 4-port 1-port 16/32 MB 8/8 MB External
Remote Office Web GUI, IPSec Ethernet hub ADSL over
Teleworker 3DES, Easy VPN, (10BASE-T) ISDN
QoS, IOS Remote
Management
The new Cisco SOHO 77H routers should be deployed in scenarios that previously called for SOHO
77 routers. Similarly, the new Cisco 827H routers are intended to take the place of Cisco 827 routers
in future deployments. These new models provide additional functionality at no additional cost.
For more information on product transitions, see page 105 of this guide.
AccessRouter_10.21.02 10/24/02 3:31 PM Page 9

Platform Overviews continued
Series Specifications
Cisco SOHO Series and 800 Series
10
Ta r g e t K e y Fixed LAN Fixed WAN Default/Max Default/Max Power
Platform Market Features Connections Connections DRAM Flash Supply
ADSL Routers
Cisco SOHO 77H Small Business, Stateful firewall, 4-port 1-port 16/16 MB 8/8 MB External
Remote Users Web GUI, Ethernet hub ADSL
with VPN PC IOS Remote (10BASE-T)
Clients Management
Cisco 827H Small Business, Stateful firewall, 4-port 1-port 32/32 MB 8/8 MB External
Remote Office, Web GUI, IPSec Ethernet hub ADSL
Teleworker 3DES, Easy VPN, (10BASE-T)
QoS, IOS Remote
Management
Cisco 827-4V Small Business, Stateful firewall, 1-port 1-port 24/32 MB 8/16 MB External
Remote Office, Web GUI, IPSec Ethernet ADSL
Teleworker 3DES, Easy VPN, (10BASE-T)(4 FXS Voice Ports)
QoS, IOS Remote
Management, VoIP
G.SHDSL Routers
Cisco SOHO 78 Small Business, Firewall, Web GUI, 4-port 1-port 16/16 MB 8/8 MB External
Remote Users IOS Remote Ethernet hub G.SHDSL
with VPN PC Management (10BASE-T)
Clients
Cisco 828 Small Business, Stateful firewall, 4-port 1-port 16/32 MB 8/8 MB External
Remote Office, IPSec 3DES, Ethernet hub G.SHDSL
Teleworker Easy VPN, QoS, (10BASE-T)
IOS Remote
Management
Processor RISC CPU
Flash Memory 8-12 MB (Cisco 800 Series expandable to 12-16 MB)
System DRAM Memory 4-32 MB (Cisco 800 Series expandable to 12-32 MB)
Internal Power Supply No
Dimensions (H x W x D) 2.0 x 9.7 x 8.5 in. (5.1 x 24.6 x 21.6 cm)
Performance 9 Mbps Clear Text
Console Port 1 (up to 115.2 Kbps)
Auxiliary Port No Base Configuration: Fixed configuration with single WAN port
Maximum Ethernet Ports 4-port Ethernet LAN hub
(1 Ethernet WAN on Cisco SOHO 71 and Cisco 806)
Maximum High-speed Serial (up to 2 Mbps) 1 (Cisco 805)
Maximum Low-speed Serial (up to 128 Kbps) 0
Voice/Data Support Cisco 827-4V only
Integrated Modems 0
Maximum Number of ISDN BRI Ports 1
Maximum Number of ISDN PRI Ports 0
Integrated CSU/DSU No
AccessRouter_10.21.02 10/24/02 3:31 PM Page 10

Series Specifications continued
Cisco IOS Memory Requirements
Cisco SOHO Series and 800 Series
11
Description DRAM Flash
CISCO 801-804
c800-k8nosy6-mw IP/IPX/Firewall/IPSec 3DES Plus 12 8
c800-k8osy6-mw IP/Firewall/IPSec 3DES Plus 12 8
c800-oy6-mw IP/Firewall 8 8
c800-sy6-mw IP Plus 8 8
c800-y6-mw IP 4 8
Cisco 805
c805-k8nosy6-mw IP/IPX/Firewall/IPSec 3DES Plus 12 8
c805-k8osy6-mw IP/Firewall/IPSec 3DES Plus 12 8
c805-oy6-mw IP/Firewall 8 4
c805-sy6-mw IP Plus 8 8
c805-y6-mw IP 8 4
Description DRAM Flash
Cisco 827 and Cisco 826
c820-k9osv6y6-mz IP/Firewall/Voice/IPSec 3DE 32 8
c820-k9osy6-mz IP/Firewall/IPSec 3DES Plus 24 8
c820-ov6y6-mz IP/Firewall/Voice 24 8
c820-oy6-mz IP/Firewall 20 8
c820-sv6y6-mz IP/Voice Plus 24 8
c820-sy6-mz IP Plus 20 8
c820-v6y6-mz IP/Voice 24 8
c820-y6-mz IP 16 8
Cisco 828
c828-k9osy6-mz IP/Firewall/IPSec 3DES Plus 24 8
c828-oy6-mz IP/Firewall 20 8
c828-sy6-mz IP/Plus 16 8
c828-y6-mz IP 16 8
Compression S/W
Encryption S/W
Redundant Power Supply Support No
Minimum Cisco IOS Software Release Dependent upon model
AccessRouter_10.21.02 10/24/02 3:31 PM Page 11

Cisco IOS Memory Requirements continued
Ordering Information
Cisco SOHO Series and 800 Series
12
Part Number Description
Cisco SOHO Series
Cisco SOHO 71 CISCOSOHO71 Ethernet router, 1E, 4E hub, stateful firewall
Cisco SOHO 76 CISCOSOHO76 Cisco SOHO 76 Router 1 ADSL over ISDN, 4E hub,
stateful firewall
Cisco SOHO 77H CISCOSOHO77H Cisco SOHO 77H router 1 ADSL, 4E hub, stateful firewall
Cisco SOHO 78 CISCOSOHO78 Cisco SOHO 78 router, 1 G.SHDSL, 4E hub
Cisco 800 Series Products
Cisco 801 CISCO801 ISDN/Ethernet Router
Cisco 802 CISCO802 ISDN BRI/Ethernet Router
Cisco 803 CISCO803 ISDN BRI/Ethernet Router, 4-port hub, 2 POTS
Cisco 804 CISCO804 ISDN BRI/Ethernet Router, NT-1, 4-port hub, 2 POTS
Cisco 805 CISCO805 Cisco 805 Ethernet/Serial Router
Cisco 806 CISCO806 Cisco 806 Broadband Router 4E, 1E, stateful firewall
Cisco 811 CISCO811 ISDN Ethernet router with integrated Japan DSU
Cisco 813 CISCO813 ISDN/Ethernet router with integrated 4-port hub, Japan DSU
Cisco 826 CISCO826 Cisco 826 ADSL router (co-existing with ISDN local loops)
Cisco 827H CISCO827H Cisco 827H router, 1 ADSL, 4E hub, stateful firewall
Cisco 827-4V CISCO827-4V Cisco 827-4V ADSL router 1E, 1 ADSL, 4 voice
Cisco 828 CISCO828 Cisco 828 G.SHDSL Router 1E, 1 G.SHDSL
Cisco 828
c806-k9osy6-mz IP/Firewall/IPSec 3DES Plus 20 8
c806-oy6-mz IP/Firewall 16 8
c806-sy6-mz IP Plus 16 8
c806-y6-mz IP 16 8
SOHO Series
soho70-y1-mz IP 16 8
soho78-y1-mz IP 16 8
soho71-oy6-mz IP/FW 16 8
AccessRouter_10.21.02 10/24/02 3:31 PM Page 12

13
Cisco 1700 Series
The Cisco 1700 Series of modular access routers is designed to provide a cost-
effective, integrated routing platform for small and medium-sized businesses and
enterprise small branch offices, ensuring new services can be deployed efficiently as
needs change. These routers provide flexibility and manageability through modular
design to meet demanding and evolving requirements, such as comprehensive security,
multiservice data/voice/video/fax integration, and business-class DSL support.
Flexibility and Investment Protection
The modularity of the Cisco 1700 Series allows
it to easily adapt to evolving needs.
Interchangeable WAN interface cards (WICs) and
voice interface cards (VICs) enable easy
additions or changes, without requiring a forklift
upgrade of an entire platform. The wide range
of available WIC solutions supports WAN
technologies such as broadband DSL, ISDN,
leased lines, and Frame Relay, while VIC
solutions can support Voice over IP and Voice
over Frame Relay. These modules are shared
with Cisco 2600, 3600, and 3700 series routers.
Comprehensive Security
To k eep networks secure and protect sensitive
information, businesses deploy a range of
security technologies, including firewall, VPN,
and IDS. Cisco 1700 Series routers provide
stateful inspection firewall, wire speed VPN with
hardware encryption module, and intrusion
detection capabilities. As new security
technologies are developed, they may simply be
uploaded.
Business-Class DSL Connectivity
The new WIC-1ADSL and WIC-1SHDSL offer
business-class broadband service with scalable
performance, flexibility, and security for branch
offices. The Cisco 1700 Series provides the
perfect solution for a variety of businesses
requiring high-speed business-class DSL
connectivity on a secure, high-performance,
modular platform.
Multiservice Data/Voice/
Video/Fax Integration
In addition to supporting the same security and
business-class DSL features as the entire Cisco
1700 Series, the Cisco 1751 and 1760 offer a
cost-effective way to extend converged
multiservice data/voice networking to branch
offices. They work with existing phones and
other equipment, simplifying deployment of IP
telephony. Service integration using IP protocols
over the Internet enables administrators to
reduce long-distance toll charges between
offices, and support voice-enabled desktop
applications such as integrated messaging and
packet video.
Benefits and Advantages
AccessRouter_10.21.02 10/24/02 3:31 PM Page 13

14
When to Deploy
Cisco 1700 Series
Application Example
The Cisco 1700 Series is ideal for customers
who need:
•The flexibility to add or change WAN services
to support changing needs and applications,
including VPNs, integrated voice/fax/data over
the WAN, broadband DSL and cable access
services
• An integrated access solution that combines a
best-in-class router with firewall, high-speed
encryption, VPN tunnel server, DSU/CSU, and
ISDN NT-1 functions in one platform
•VPN remote aggregation to terminate VPN
software clients at the branch office
•High-speed business-class DSL
connectivity on a secure, high-performance
modular platform
• A secure access solution with VPN (T1/E1
speeds) and firewall for enterprise small
branch offices and small to medium-sized
businesses
•Multiservice voice/video/fax/data integration
•Up to five serial interfaces (including the AUX
port); for example: retail/point-of-sale or small
bank branch office applications
V
PSTN IP Network
Analog Voice
or
ISDN BRI Lines
Analog Phone
Cisco 1760KTS/PBX
Cisco Catalyst®Switch
PC
PC
PC
Fax Cisco IP Phone
IP
Tr ansition Information
The new Cisco 1721 routers should be deployed in scenarios that previously called for Cisco 1720
routers. This new Cisco 1721 model provides higher performance, increased memory, and
additional functionality at no additional cost. For more information on product transitions, see
page 105 of this guide.
AccessRouter_10.21.02 10/24/02 3:31 PM Page 14

Series Specifications
Platform Overview
Cisco 1700 Series
VICs/ Fixed DRAM DRAM FLASH FLASH Power
WICs VICs WICs LAN Ports (default MB) (max MB) (default MB) (max MB) Supply
Cisco 1710 --- 1 32 64 16 16 AC
Cisco 1721 2- - 1 32 96 16 16 AC
Cisco 1751 -12 1 32 96 16 16 AC
Cisco 1751-V -12 1 64 96 32 32 AC
Cisco 1760 -22 1 32 96 16 64 AC
Cisco 1760-V -22 1 64 96 32 64 AC
Processor RISC CPU
Dimensions (H x W x D)
1710,1721, 1751, 1751-V 4.0 x 11.2 x 8.7 in. (10.0 x 28.4 x 22.1 cm)
1760, 1760-V (rack mount) 1.7 x 17.5 x 12.8 in. (4.32 x 44.5 x 32.5 cm)
Flash Memory 16-32 MB (some models expandable to 64 MB)
System DRAM Memory 32-64 MB (some models expandable to 96 MB)
Internal Expansion Slots 1 (e.g., for VPN Module)
Internal Power Supply AC (Cisco 1760 only)
Console Port 1 (up to 115.2 Kbps)
Auxiliary Port 1 (up to 115.2 Kbps)
Maximum Ethernet Connections 3
Maximum 10/100 Ethernet Ports 1
Maximum High-Speed Serial (up to 2 Mbps) 4
Voice/Data Support Cisco 1751 and 1760
Maximum Number of ISDN BRI Ports 4
Maximum Number of ISDN PRI Ports 4
Integrated CSU/DSU Yes (T1/E1, Fractional T1/E1, 56k/64k)
Compression S/W
Encryption S/W + H/W
Redundant Power Supply Support No
Minimum Cisco IOS Release Varies depending on model
15
AccessRouter_10.21.02 10/24/02 3:31 PM Page 15

Cisco IOS Requirements
Cisco 1700 Series
16
Cisco 1700 Series Data and Voice Software Feature Sets for Cisco IOS Release 12.2(4)YB
No. of
images Platform Feature Set
11751 /1760 Cisco 1700 IOS IP/ADSL/IPX/AT/IBM/Voice/FW/IDS Plus IPSec 56
21751 /1760 Cisco 1700 IOS IP/ADSL/IPX/AT/IBM/VOX/FW/IDS Plus IPSec 56
31721 /1751 /1760 Cisco 1700 IOS IP/ADSL/IPX/AT/IBM/FW/IDS Plus IPSec 56
41751 /1760 Cisco 1700 IOS IP/ADSL/IPX/AT/IBM/Voice/FW/IDS Plus IPSec 3DES
51751 /1760 Cisco 1700 IOS IP/ADSL/IPX/AT/IBM/VOX/FW/IDS Plus IPSec 3DES
61721 /1751 /1760 Cisco 1700 IOS IP/ADSL/IPX/AT/IBM/FW/IDS Plus IPSec 3DES
71721 /1751 /1760 Cisco 1700 IOS IP/ADSL/IPX/AT/IBM Plus
81721 /1751 /1760 Cisco 1700 IOS IP/IPX/AT/IBM
91751 /1760 Cisco 1700 IOS IP/ADSL/Voice/FW/IDS Plus IPSec 56
10 1751 /1760 Cisco 1700 IOS IP/ADSL/VOX/FW/IDS Plus IPSec 56
11 1721 /1751 /1760 Cisco 1700 IOS IP/ADSL/FW/IDS Plus IPSec 56
12 1751 /1760 Cisco 1700 IOS IP/ADSL/Voice Plus IPSec 56
13 1751 /1760 Cisco 1700 IOS IP/ADSL/VOX Plus IPSec 56
14 1721 /1751 /1760 Cisco 1700 IOS IP/ADSL Plus IPSec 56
15 1751 /1760 Cisco 1700 IOS IP/ADSL/Voice/FW/IDS Plus IPSec 3DES
16 1751 /1760 Cisco 1700 IOS IP/ADSL/VOX/FW/IDS Plus IPSec 3DES
17 1721 /1751 /1760 Cisco 1700 IOS IP/ADSL/FW/IDS Plus IPSec 3DES
18 1751 /1760 Cisco 1700 IOS IP/ADSL/Voice Plus IPSec 3DES
19 1751 /1760 Cisco 1700 IOS IP/ADSL/VOX Plus IPSec 3DES
20 1721 /1751 /1760 Cisco 1700 IOS IP/ADSL Plus IPSec 3DES
21 1751 /1760 Cisco 1700 IOS IP/ADSL/IPX/Voice/FW/IDS Plus
22 1751 /1760 Cisco 1700 IOS IP/ADSL/IPX/VOX/FW/IDS Plus
23 1721 /1751 /1760 Cisco 1700 IOS IP/ADSL/IPX/FW/IDS Plus
24 1721 /1751 /1760 Cisco 1700 IOS IP/IPX
25 1751 /1760 Cisco 1700 IOS IP/ADSL/Voice/FW/IDS Plus
26 1751 /1760 Cisco 1700 IOS IP/ADSL/VOX/FW/IDS Plus
27 1721 /1751 /1760 Cisco 1700 IOS IP/FW/IDS
28 1751 /1760 Cisco 1700 IOS IP/Voice Plus
29 1751 /1760 Cisco 1700 IOS IP/ADSL/Voice Plus
30 1751 /1760 Cisco 1700 IOS IP/VOX Plus
31 1751 /1760 Cisco 1700 IOS IP/ADSL/VOX Plus
32 1721 /1751 /1760 Cisco 1700 IOS IP Plus
33 1721 /1751 /1760 Cisco 1700 IOS IP/ADSL Plus
34 1721 /1751 /1760 Cisco 1700 IOS IP
35 1721 /1751 /1760 Cisco 1700 IOS IP/ADSL
36 1710 Cisco 1710 IOS IP/IPX/AT/IBM/FW/IDS Plus IPSec 3DES
37 1710 Cisco 1710 IOS IP/FW/IDS Plus IPSec 3DES
AccessRouter_10.21.02 10/24/02 3:31 PM Page 16

17
Recommended
Software Image Product Code Flash DRAM
c1700-bk8no3r2sv3y7-mz S17Q7HVK8-12204YB 32 MB 64 MB
c1700-bk8no3r2sv8y7-mz S17Q7V8K8-12204YB 32 MB 64 MB
c1700-bk8no3r2sy7-mz S17Q7HK8-12204YB 16 MB 64 MB
c1700-bk9no3r2sv3y7-mz S17Q7HVK9-12204YB 32 MB 64 MB
c1700-bk9no3r2sv8y7-mz S17Q7V8K9-12204YB 32 MB 64 MB
c1700-bk9no3r2sy7-mz S17Q7HK9-12204YB 16 MB 64 MB
c1700-bnr2sy7-mz S17Q7P-12204YB 16 MB 48 MB
c1700-bnr2y-mz S17Q-12204YB 8 MB 32 MB
c1700-k8o3sv3y7-mz S17C7HVK8-12204YB 16 MB 64 MB
c1700-k8o3sv8y7-mz S17C7V8K8-12204YB 16 MB 64 MB
c1700-k8o3sy7-mz S17C7HK8-12204YB 16 MB 48 MB
c1700-k8sv3y7-mz S17C7VK8-12204YB 16 MB 64 MB
c1700-k8sv8y7-mz S17CV8K8-12204YB 16 MB 64 MB
c1700-k8sy7-mz S17C7K8-12204YB 16 MB 48 MB
c1700-k9o3sv3y7-mz S17C7HVK9-12204YB 16 MB 64 MB
c1700-k9o3sv8y7-mz S17C7V8K9-12204YB 16 MB 64 MB
c1700-k9o3sy7-mz S17C7HK9-12204YB 16 MB 48 MB
c1700-k9sv3y7-mz S17C7VK9-12204YB 16 MB 64 MB
c1700-k9sv8y7-mz S17CV8K9-12204YB 16 MB 64 MB
c1700-k9sy7-mz S17C7K9-12204YB 16 MB 48 MB
c1700-no3sv3y7-mz S17B7HPV-12204YB 16 MB 64 MB
c1700-no3sv8y7-mz S17B7HPV8-12204YB 16 MB 64 MB
c1700-no3sy7-mz S17B7HP-12204YB 16 MB 48 MB
c1700-ny-mz S17B-12204YB 8 MB 32 MB
c1700-o3sv3y7-mz S17C7HV-12204YB 16 MB 64 MB
c1700-o3sv8y7-mz S17C7HV8-12204YB 16 MB 64 MB
c1700-o3y-mz S17CH-12204YB 8 MB 32 MB
c1700-sv3y-mz S17CVP-12204YB 16 MB 48 MB
c1700-sv3y7-mz S17C7VP-12204YB 16 MB 64 MB
c1700-sv8y-mz S17CV8P-12204YB 16 MB 64 MB
c1700-sv8y7-mz S17C7V8P-12204YB 16 MB 64 MB
c1700-sy-mz S17CP-12204YB 16 MB 32 MB
c1700-sy7-mz S17C7P-12204YB 16 MB 48 MB
c1700-y-mz S17C-12204YB 8 MB 32 MB
c1700-y7-mz S17C7-12204YB 8 MB 32 MB
c1710-bk9no3r2sy-mz S171QHK9-12204YB 16 MB 48 MB
c1710-k9o3sy-mz S171CHK9-12204YB 8 MB 32 MB
AccessRouter_10.21.02 10/24/02 3:31 PM Page 17

Ordering Information
Cisco 1700 Series
18
Product Number Product Description
CISCO1760 10/100 modular router with 2 WIC/VIC, 2 VIC slots,19-inch chassis
CISCO1760-V 10/100 modular touter with voice IP/Voice Plus, 19-inch chassis
CISCO1760-ADSL 10/100BASE-T modular router with ADSL WIC, IP/ADSL
CISCO1760-SHDSL 10/100BASE-T modular G.SHDSL router, 19-inch chassis
CISCO1760-VPN/K9 1760 VPN bundle with VPN module, 48 MB DRAM, IP Plus/FW/3DES
CISCO1760-VPN/K9-A 1760 VPN bundle with ADSL WIC, VPN module, 48 MB DRAM, IP Plus/FW/3DES
CISCO1751 10/100 modular router with 3 slots, IOS IP, 16F/32D
CISCO1751-V 10/100 modular router with voice, IOS IP/Voice Plus, 32F/64D
CISCO1751-VPN/K9 1751 VPN bundle with VPN module, 48 MB DRAM, IP Plus/FW/3DES
CISCO1751-VPN/K9-A 1751 VPN bundle with ADSL WIC, VPN module, 48 MB DRAM, IP Plus/FW/3DES
CISCO1721 10/100BASE-T modular router with 2 WAN slots, 16 MB Flash/32 MB DRAM
CISCO1721-ADSL 10/100BASE-T modular ADSL router, IP/DSL
CISCO1721-SHDSL 10/100BASE-T modular G.SHDSL router, IP/DSL
CISCO1721-VPN/K9 1721 VPN bundle with VPN module, 48 MB DRAM, IP Plus/FW/3DES
CISCO1721-VPN/K9-A 1721 VPN bundle with ADSL WIC, VPN module, 48 MB DRAM, IP Plus/FW/3DES
CISCO1710-VPN-M/K9 Dual-Ethernet security access router, VPN module, IP/FW/3DES
See WAN and Voice Interface Card support for Cisco 1700 Series on pages 88-104 of this guide.
AccessRouter_10.21.02 10/24/02 3:31 PM Page 18

Cisco 2600 Series
Modular Access Routers
Cisco extends enterprise/provider-class versatility, integration, and power to branch
offices with Cisco 2600 Series modular access routers. With more than 1.5 million
2600 Series units installed worldwide, this popular series offers network managers
and service providers flexibility and investment protection in a compact, single-box
solution. The Cisco 2600XM models and the top-of-the-line Cisco 2691 are the
latest additions to the series, providing even more flexibility, performance, and
memory, as well as higher service densities to support today’s and tomorrow’s
branch office needs.
Benefits and Advantages
19
Integrated Flexible Routing
and Low-Density Switching
With the support of an optional 16-port 10/100
EtherSwitch network module, branch offices
can take advantage of the flexibility of integrat-
ed routing and switching functions in one unit
for low port densities. This offers high-speed
connections between individual desktops,
servers, and other network resources in a sin-
gle unit for Layer 2, and allows WAN connec-
tion at Layer 3 through the router. An optional
external power chassis provides power to IP
phones and Cisco Aironet®802.11 base stations.
Versatility/Investment Protection
Thousands of field-upgradable customized
solutions ensure easy migration to future
network requirements. More than 50 WAN
interface cards (WICs) and network modules
(NMs) are shared with the Cisco 1700, 3600,
and 3700 series products. The advanced
integration module (AIM) slot offers
expandability for integration of advanced
services, such as hardware-assisted data
compression, encryption, voice and ATM
hardware-assisted data compression, and
encryption.
Virtual Private Networking/Security
Offers advanced tunneling features, including
L2F and L2TP, standards-based, hardware-
supported IPSec encryption, Cisco IOS Firewall
Feature Set, and diverse WAN and dial
interfaces, ideal for both VPN entry points and
home gateways.
Multiservice Voice/Data Networks
Supports up to 60 simultaneous calls, using
analog and digital connections to phones,
faxes, key systems, PBXs, and PSTN switches,
enabling inter-branch toll charges to be reduced
or eliminated. Using Cisco IOS quality of service
(QoS) features, such as WFQ, CAR, RSVP, and
Custom and Priority Queuing, voice traffic
is digitized and encapsulated in Frame Relay or
IP packets and consolidated with data traffic
AccessRouter_10.21.02 10/24/02 3:31 PM Page 19

20
Benefits & Advantages continuedBenefits and Advantages continued
Cisco 2600 Series
to extend multiservice infrastructure to the
branch office.
Business-Class DSL Connectivity
The new WIC-ADSL and WIC-1SHDSL offer
business-class broadband service with scalable
performance, flexibility, and security for branch
and regional offices. The Cisco 2600 Series pro-
vides the perfect solution for a variety of busi-
nesses requiring high-speed business-class
DSL connectivity on a secure, high-perform-
ance, modular platform.
Power
High-speed routing performance up to
70,000 packets per second, for maximum
scalability to support more concurrent services.
Interoperability/Multiprotocol
Support
Offers a comprehensive set of protocols
and services, including virtual private
networking, firewall protection, encryption,
WAN optimization, and enhanced multimedia
support features.
The new Cisco 2610XM, 2611XM, 2620XM, 2621XM, 2650XM, and 2651XM routers should be
deployed in scenarios that previously called for Cisco 2610, 2611, 2620, 2621, 2650, and 2651
routers, respectively. The new XM models offer improved performance and increased default
memory and maximum memory at no additional cost. For more information on product transitions,
see page 105 of this guide.
Deploy the Cisco 2600 Series when you need:
•Acost-effective solution for the long term
that adapts to evolving network requirements
•Virtual private network (VPN)/extranet access
with firewall protection to reduce costs and
increase security for partners and employees
•Dial concentration with async, ISDN, or
analog modems
•Integrated routing and switching
functionality
•Voice/fax/data multiservice integration
•Serial device concentration of point-of-sale
devices, ATMs, alarm systems, SDLC
controllers with legacy terminals and LAN
devices sharing a single WAN connection
•High-speed business-class DSL
connectivity on a secure, high-performance
modular platform
•Support for advanced QoS features such as
the Resource Reservation Protocol (RSVP),
Weighted Fair Queuing (WFQ), and IP
Precedence to reduce recurring WAN costs
When to Deploy
Tr ansition Information
AccessRouter_10.21.02 10/24/02 3:31 PM Page 20
