Cisco C880 M4 Server Firmware Update Guide
First Published: August 24, 2016
Introduction
This document describes how to update the firmware on a Cisco C880 M4 server. There are two update
procedures:
•Offline Firmware Update Procedure, which should be initiated when the server is powered off.
•Online Firmware Update Procedure, which should be initiated when the server is powered on (in Boot
state).
The procedures are identical except for the state of the system when the procedure is initiated.
Both update procedures instruct you to perform a Unified Firmware Update from the Management Board
(MMB) web UI. The Unified Firmware Update updates the following firmware:
•BIOS firmware
•BMC firmware
•MMB firmware
The BIOS and BMC firmware data are stored in ROM devices on each system board (SB): 0, 1, 2, and 3. The
MMB firmware data are stored in a ROM device on the MMB.
The version of the BIOS firmware on each system board should be the same, and the version of the BMC
firmware on each system board should be the same. When a system board is replaced with a spare system
board, the version of the new system board may not be the same as the version of the firmware on other system
boards. When this situation occurs, perform a Unified Firmware Update to make all firmware versions equal.
Procedure Summary
We recommend performing the Offline Firmware Update Procedure as a part of this overall workflow:
Step 1 Shut down the OS and power off the system (but do not disconnect the power cord).
Step 2 Stop issuing IPMI commands from Cisco UCS Director to the ManageMent Board (MMB) of the C880 M4 Server.
Step 3 Perform the Unified Firmware Update from the MMB web UI to apply the firmware binary so that it starts running.
Step 4 Set the new BMC username and password as described in Changing a Username and Password .
Step 5 Resume issuing IPMI commands from Cisco UCS Director to the C880 M4 Server.
Cisco C880 M4 Server Firmware Update Guide
1

Offline Firmware Update Procedure
Step 1 Log in with administrator privilege to the MMB web UI.
Step 2 From the Navigation bar, choose System.
Step 3 Power off the system (but do not disconnect the AC power).
Step 4 From the Navigation bar, choose Maintenance.
Step 5 Choose Firmware Update >Unified Firmware Update.
Step 6 Choose the firmware file.
Step 7 Click Update.
Wait for the firmware version check window to appear, which takes approximately 5 minutes.
Step 8 Click OK after confirming the firmware version.
The progress bar appears in about 1 minute.
•The time required to update the firmware for a one MMB configuration is about 70 minutes.
•For a one MMB configuration, wait about 5 minutes before logging into the web UI . The web UI is disconnected
during the firmware update.
Online Firmware Update Procedure
Before You Begin
Before starting the update, ensure that the system is in boot state and the OS is not running.
Step 1 Log in with administrator privilege to the MMB web UI.
Step 2 From the Navigation bar, choose Maintenance.
Step 3 Choose Firmware Update >Unified Firmware Update.
Step 4 Choose the firmware file.
Step 5 Click Update.
Wait for the firmware version check window to appear, which takes approximately 5 minutes.
Step 6 Click OK after confirming the firmware version.
The progress bar appears in about 1 minute. The time required to update the firmware for a one MMB configuration is
about 70 minutes.
This online firmware update procedure writes a new version of the firmware to the ROM device. To apply the
new firmware to the system, power off the server and power it on again.
Note
While the new firmware is being applied to the system, the web UI is disconnected. Wait about 5 minutes before logging
into the web UI.
Cisco C880 M4 Server Firmware Update Guide
2
Introduction
Offline Firmware Update Procedure

Changing a Username and Password
For security purposes, the BMC login credentials configuration changed with the revision of C880 M4 Release
Version 1.0.2.
The new BMC login credentials configuration was implemented in an initial firmware revision of C880
M4 with the E7-8800 v3 CPU.
Note
•The username and password are disabled.
•The username and password can be set with a MMB CLI command.
Previously, the default username/password combination was admin/admin, which could not be changed. Once
the new firmware is applied, the BMC username and password are disabled. If you need to log into the BMC
for IPMI processing, you need to set a username and password using the MMB CLI commands listed here:
set bmc user <user id> <password> <password> quiet
user id: a username to be registered
password: a password for the username
password: the confirmation password
Example:
set bmc user admin admin admin quiet
If you enter the IPMI command to BMC without setting a new username, you receive an error message that
indicates that the username is invalid and a LAN connection cannot be established.
Cisco C880 M4 Server Firmware Update Guide
3
Introduction
Changing a Username and Password

Cisco C880 M4 Server Firmware Update Guide
4
Introduction
Changing a Username and Password
