Release Notes for
Cisco Configuration Professional Express 1.0
May 19, 2008
These release notes support Cisco Configuration Professional Express (Cisco CP Express) 1.0. They
should be used with the documents listed in the “Related Documentation” section on page 15 and in
particular, the Release Notes for Cisco Configuration Prefessional.
These release notes are updated as needed. To ensure that you have the latest version of these release
notes, go to http://www.cisco.com/go/ciscocp. In the Support box, click General Information >
Release Notes. Then, find the latest release notes for your release.
Contents
This document contains the following sections:
•Introduction, page 1
•System Requirements, page 2
•Installation Notes, page 8
•Limitations and Restrictions, page 9
•Important Notes, page 9
•Caveats, page 12
•Related Documentation, page 15
Introduction
Cisco CP Express is a graphical configuration tool that enables a user to configure a LAN and WAN
connection, make security settings to protect the router, and, configure a basic firewall, and Network
Address Translation. Cisco CP Express is installed in Flash memory on routers shipped with Cisco
Configuration Professional (Cisco CP).

2
Release Notes for Cisco Configuration Professional Express 1.0
OL-16652-01
System Requirements
System Requirements
This sections describes PC and router system requirements. It contains the following parts:
•PC System Requirements, page 2
•Router System Requirements, page 2
•Cisco IOS Releases, page 6
•Cisco CP Ordering Options, page 7
PC System Requirements
Cisco CP Express can run under the native Java Virtual Machine in the supported browsers, and also
JRE.
Table 1 lists the system requirements for a PC running Cisco CP Express including Web browser
versions and Java runtime environment versions.
Router System Requirements
•Supported Routers, page 2
•Supported Adapters, Cards and Network Modules, page 4
•Cisco IOS Releases, page 6
Supported Routers
This section lists the routers that Cisco CP Express supports, by series.
Table 1 PC System Requirements
System Component Requirement
Operating System Any of the following:
•Microsoft Windows Vista Business Edition. Microsoft
recommends this operating system be installed in administrator
mode.
•Microsoft Windows Vista Ultimate Edition. Microsoft recommends
this operating system be installed in administrator mode.
•Microsoft Windows XP with Service Pack 2
Browser Cisco CP Express can be used with the following browsers:
•Firefox 1.0.6 and later versions
•Internet Explorer 5.5 and later versions
•Netscape 7.1, 7.2, and 9.0
Screen Resolution 1024 X 768
Java Runtime Environment Cisco CP Express can run under the native Java Virtual Machine in the
supported browsers, and also under the Java Runtime Environment.

3
Release Notes for Cisco Configuration Professional Express 1.0
OL-16652-01
System Requirements
Note Cisco CP Express does not support Telco/CO router models.
Cisco 800 Series
Cisco CP Express is supported on the following Cisco 800 series routers:
•Cisco 815
•Cisco 861
•Cisco 881
•Cisco 888
Cisco 1800 Series
Cisco CP Express is supported on the following Cisco 1800 series routers:
•Cisco 1801
•Cisco 1801W
•Cisco 1801W-M
•Cisco 1801M
•Cisco 1802
•Cisco 1802W
•Cisco 1803
•Cisco 1803W
•Cisco 1805
•Cisco 1811
•Cisco 1811W
•Cisco 1812
•Cisco 1812W
•Cisco1812J
•Cisco 1812W-J
•Cisco 1812W-P
•Cisco 1841
•Cisco 1861
Cisco 2800 Series
Cisco CP Express is supported on the following 2800 series routers:
•Cisco 2801
•Cisco 2811
•Cisco 2821
•Cisco 2851

4
Release Notes for Cisco Configuration Professional Express 1.0
OL-16652-01
System Requirements
Cisco 3800 Series
Cisco CP Express is supported on the following Cisco 3800 series routers:
•Cisco 3825
•Cisco 3845
Supported Adapters, Cards and Network Modules
This section contains support information about adapters, cards, and network modules
Network Modules
Cisco CP Express supports the following network modules:
•NM-4T
•NM-1FE2W-V2
•NM-1FE-FX-V2
•NM-2FE2W-V2
•NM-1FE-FX
•NM-4A/S (synchronous only)
•NM-8A/S (synchronous only)
•NM-CIDS-K9
•NM-16ESW
•NM-16ESW-1GIG
•NM-16ESW-PWR
•NM-16ESW-PWR-1GIG
•NMD-36ESW-PWR
•NMD-36ESW-PWR-2GIG
Cisco CP Express supports the following EtherSwitch Service Network Modules:
•NME-16ES-1G-P
•NME-X-23ES-1G-P
•NME-XD-24ES-1S-P
•NME-XD-48ES-2S-P
WAAS Modules
Cisco CP Express supports the following Wide Area Application Services (WAAS) modules:
•NME-WAE-502-K9
•NME-WAE-522-K9
•NME-WAE-302-K9
WAN Interface Cards
Cisco CP Express supports the following WAN interface cards:
•WIC-1T

5
Release Notes for Cisco Configuration Professional Express 1.0
OL-16652-01
System Requirements
•WIC-2T
•WIC-2A/S (Frame Relay, PPP, HDLC, no asynchronous)
•WIC-1ADSL
•WIC-1SHDSL
•WIC-1DSU-T1-V2
•WIC-1B-S/T-V3
•WIC-1AM
•WIC-2AM
•WIC-4ESW
•WIC-1SHDSL-V2
•WIC-1SHDSL-V3
•WIC 1ADSL-DG
•WIC 1ADSL-I-DG
Cisco CP Express supports the following high-speed WAN interface cards (HWICs):
•HWIC-4T
•HWIC-4A/S
•HWIC-4ESW
•HWIC-8A/S-232
•HWICD-9ESW
•HWIC-16A
•HWIC-AP-G-X
•HWIC-AP-AG-X
•HWIC-ADSL-B/ST
•HWIC-ADSLI-B/ST
•HWIC-1ADSL
•HWIC-1ADSLI
•HWIC1-ADSL-M
•HWIC-1CABLE-D
•HWIC-1CABLE-E/J
•HWIC-1FE
•HWIC-2FE
•HWIC-2SHDSL
•HWIC-4SHDSL
AIM Modules
Cisco CP Express supports the following advanced integration modules (AIMs):
•AIM-VPN/BPII-PLUS
•AIM-VPN/HPII-PLUS

6
Release Notes for Cisco Configuration Professional Express 1.0
OL-16652-01
System Requirements
•AIM-VPN/EPII-PLUS
•AIM-VPN/SSL-1
•AIM-VPN/SSL-2
•AIM-VPN/SSL-3
Cisco IOS Releases
Cisco CP Express is compatible with the Cisco IOS releases listed in Table 2.
Determining the Cisco IOS Release
To determine the release of Cisco IOS software currently running on your Cisco router, log in to the
router and enter the show version EXEC command. The following sample output from the show version
command indicates the Cisco IOS release on the second output line:
Router> show version
c3845-1#show version
Cisco IOS Software, 3800 Software (C3845-ADVENTERPRISEK9-M), Version 12.4(11)XW2, RELEASE
SOFTWARE (fc1)
Technical Support: http://www.cisco.com/techsupport
Copyright (c) 1986-2007 by Cisco Systems, Inc.
Compiled Tue 03-Jul-07 00:49 by prod_rel_team
Memory Requirements
Table 3 shows how much memory is required to support Cisco CP Express and related applications.
Table 2 Cisco CP Express-Supported Routers and Cisco IOS Versions
Router Model Earliest Cisco CP Express-Supported Cisco IOS Versions
Cisco 815 •12.4(11)T
Cisco 860 series
Cisco 880 series
•12.4(15)XZ
Cisco 1801
Cisco 1802
Cisco 1803
•12.4(9)T
•12.5(1)M
Cisco 1805 •12.4(15)XY
Cisco 1811
Cisco 1812
•12.4(9)T
•12.5(1)M
Cisco 1841 •12.4(9)T
•12.5(1)M
Cisco 1861 •12.4(11)XW
Cisco 2800 •12.4(9)T
•12.5(1)M
Cisco 3800 •12.4(9)T
•12.5(1)M

7
Release Notes for Cisco Configuration Professional Express 1.0
OL-16652-01
System Requirements
Cisco CP Ordering Options
Cisco CP Express is shipped with every ordering option under which Cisco CP can be ordered. Table 4
on page 7 describes the Cisco CP ordering option. Ordering options are also referred to as SKUs.
Table 3 Cisco CP Express File List
Filename Size Description
cpexpress.tar 2.17 MB
2,281,472 bytes
Cisco CP Express application file
home.shtml 1.01 KB
(1,038 bytes)
Cisco CP Express support file
home.tar 110 KB Cisco CP Express support file
cpconfig-modelnum.
For example:
cpconfig-180x.cfg
2.82 to 3.33 KB Default Configuration File
securedesktop-ios-3.1.1.45-
k9.pkg
1.61 MB
(1,697, 952 bytes)
Cisco Secure Desktop client software for SSL VPN
clients.
sslclient-win-1.1.4.176.pkg 406 KB
(415,956 bytes)
Full tunnel client software for SSL VPN clients
wlanui.tar 2.13 MB
(2, 242, 560 bytes)
Wireless Application
128MB.sdf 515 KB
(527, 849 bytes)
Signature Definition File (SDF) used by Cisco IOS
IPS
256MB.sdf 775 KB
(793, 739 bytes
Signature Definition File (SDF) used by Cisco IOS
IPS
Table 4 Cisco CP Ordering Options
Ordering Option (SKU) Description
CCP-CD Cisco CP: Shipped on CD
Cisco CP Express: Shipped in router flash memory
SSL Signature File: Shipped in router flash memory
Default Configuration File: Shipped in router flash memory and in NVRAM
CCP-CD-NOCF Cisco CP: Shipped on CD
Cisco CP Express: Shipped in router flash memory
SSL Signature File: Shipped in router flash memory
Default Configuration File: Shipped in router flash memory.
Note This ordering option does not provide the default configuration file
for Cisco 800 series routers.

8
Release Notes for Cisco Configuration Professional Express 1.0
OL-16652-01
Installation Notes
Installation Notes
This section contains important information regarding installation of Cisco CP Express.
Downloading Cisco CP Express From Cisco.com and Installing It On the Router
If Cisco CP Express is not currently installed on the router, and you want to install it, complete the
following steps:
Step 1 Go to http://www.cisco.com/go/ciscocp, and click Download Software in the Support box.
Step 2 If a login page appears, enter your login credentials. In the Software Download page, click Cisco
Configuration Professional.
Step 3 In the next download page that appears, click the release number that you want to download.
Step 4 Click on the Cisco Configuration Professional package link. The zip file contains the Cisco CP, and
Cisco CP Express installation files.
Uninstalling Cisco CP Express Files
If you want to remove Cisco CP Express from flash memory or from a router disk file system, you can
do so by logging onto the router and completing the following steps in EXEC mode:
Step 1 Change to the directory in which the Cisco CP Express files are located.
If the router has a flash file system, use the following command:
router# cd flash:
CCP-EXPRESS Cisco CP: Not shipped
Cisco CP Express: Shipped in router flash memory
SSL Signature File: Shipped in router flash memory
Default Configuration File: Shipped in router flash memory and in NVRAM
CCP-EXPRESS-NOCF Cisco CP: Not shipped
Cisco CP Express: Shipped in router flash memory
SSL Signature File: Shipped in router flash memory
Default Configuration File: Shipped in router flash memory.
Note This ordering option does not provide the default configuration file
for Cisco 800 series routers.
Table 4 Cisco CP Ordering Options
Ordering Option (SKU) Description

9
Release Notes for Cisco Configuration Professional Express 1.0
OL-16652-01
Limitations and Restrictions
If the router has a disk file system, use the following command:
router# cd diskN
Replace Nwith the actual number of the disk. Use the slot keyword instead of the disk keyword if
necessary.
Step 2 Use the delete command to remove the Cisco CP Express files. The example below deletes the file
cpexpress.tar:
router# delete cpexpress.tar
Delete filename [cpexpress.tar]?
Delete flash:cpexpress.tar? [confirm]
Press Return to confirm the deletion.
Step 3 Use the delete command to remove the remaining Cisco CP Express files.
Step 4 Reclaim memory space by using the squeeze flash: command:
router# squeeze flash:
It is not necessary to use the squeeze flash: command on DOS-based file systems.
Limitations and Restrictions
This section describes the following restrictions and limitations that may apply to Cisco CP Express:
•Cisco CP Express Does Not Support Cisco 7000 Series Routers, page 9
Cisco CP Express Does Not Support Cisco 7000 Series Routers
Cisco CP Express does not support the Cisco 7204VXR, Cisco 7206VXR, and Cisco 7301 Routers and
is not shipped with those routers.
Important Notes
This section contains important information for Cisco CP Express. It contains the following sections:
•Cisco IOS Enforces One-Time Use of Default Credentials
•Cisco CP Express May Not Operate with Custom Configuration File
•Popup Blockers Disable Cisco CP Express Online Help
•Disable Proxy Settings
•Security Alert Dialog May Remain After Cisco CP Express Launches
Cisco IOS Enforces One-Time Use of Default Credentials
To address CSCsm25466, Cisco IOS images included with recent shipments of Cisco 800, Cisco 1800,
Cisco 2800, and Cisco 3800 routers, enforce the one-time use of the default username and password
provided in the default configuration file shipped with Cisco CP Express and Cisco CP. If you bypass

10
Release Notes for Cisco Configuration Professional Express 1.0
OL-16652-01
Important Notes
Cisco CP Express and use a console or Telnet connection to log into the router, the login and exec
banners warn you that you must change the username “cisco” and password “cisco” before you log off
of the router. If you do not change the credentials as directed, you will not be able to log on to the router
the next time that you attempt to do so.
The following Cisco IOS releases enforce the one-time use of the default credentials:
•12.4(11)T or later
•12.4(11)SW, 12.4(11)SW1, 12.4(11)XV, 12.4(11)XJ
•12.4(9)T5, 12.4(9)T6
•12.3(21), 12.3(22)
Follow the procedure in this section to secure the router by creating a new username and password, to
remove the login banner and exec banner warnings, and to save the configuration changes to the router
startup configuration.
Note If you login to the router using a Telnet or a console connection but do not complete the steps in this
procedure, be aware of the following:
•If you do not change the default username and password, and then log off the router, you will not be
able to log into the router again without entering the reload command. No additional warning is
given before you log off.
•If you do not change the default username and password, but do enter the write memory command
before ending the session, future logins will be disabled. In this case, you will need to follow the
password recovery procedure at the following link:
http://www.cisco.com/en/US/products/sw/iosswrel/ps1831/products_tech_note09186a00801746e6.sht
ml
To secure the router, remove the banner warnings and save the changes to the router startup config,
complete the following steps:
Step 1 Connect the light blue console cable, included with your router, from the blue console port on your router
to a serial port on your PC. Refer to your router’s hardware installation guide for instructions.
Step 2 Connect the power supply to your router, plug the power supply into a power outlet, and turn on your
router. Refer to your router’s quick start guide for instructions.
Step 3 Use HyperTerminal or a similar terminal emulation program on your PC, with the terminal emulation
settings of 9600 baud, 8 data bits, no parity, 1 stop bit, and no flow control, to connect to your router.
Step 4 When prompted, enter the username cisco, and password cisco.
Step 5 Enter configuration mode by entering the following command:
yourname# configure terminal
Step 6 Create a new username and password by entering the following command:
yourname(config)# username username privilege 15 secret 0password
Replace username and password with the username and password that you want to use.
Step 7 Remove the default username and password by entering the following command:
yourname(config)# no username cisco
