Cisco Catalyst WS-C2960L-8TS-LL Quick start guide

Cisco Catalyst 2960-L Series
Easy Setup Guide
1 Connecting PC to Switch
2 Configuring Switch
You can easily set up your switch
in this step-by-step guide.

1-1 Before You Begin
Before you begin the installation, make sure that you have the following equipment:
●Catalyst 2960-L (the switch) ●AC Power Cord
●Ethernet Cable ●PC
Make sure that nothing is connected to the switch and your PC settings are
configured to use DHCP.
1-2 Connecting PC to Switch
ConnectingPCtoSwitch
1
1Connect the AC power cord to the
AC power connector of the switch
and a grounded AC outlet.
Power the switch.
2Confirm that the SYST LED and
STAT LED are solid green.
After the switch powers on, it begins
the power-on self-test (POST). During
POST, the each LED blinks. When POST is
completed, the SYST LED and STAT LED
turn solid green.
2
3Press and hold the Mode button.
4Confirm that all the LEDs turn
green.
Press the Mode button when the SYST
and STAT LED turn green, hold the Mode
button until all the LEDs next to the Mode
button turn green.
5Connect the Ethernet cable to the
Ethernet port of the switch, and
the other end of the cable to the
Ethernet port on your PC.
Wait until the port LEDs on the switch and
your PC are green or blinking green. Green
LEDs indicate a successful connection.
Caution
At step ❷, if the SYST LED does not turn solid green, or turns amber, the switch failed the
POST, reconnect the AC power cord to the switch AC power connector and a grounded AC
outlet. Nevertheless the SYST LED does not turn solid green, or turns amber, contact your
Cisco representative or reseller.
At step ❹, if the LEDs next to the Mode button blink when you press the button, release it.
Blinking LEDs indicate that the switch is already configured and cannot go into Express Setup
mode.
At step ❺, the switch port to connect an Ethernet cable is the RJ-45 Ethernet port, not the
RJ-45 console port. The RJ-45 Ethernet ports are numbered 1 to 8 on the 8-port model, 1 to
16 on the 16-port model, 1 to 24 on the 24-port model, 1 to 48 on the 48-port model.
34
MEMO
You can confirm the connection by the
"ping 10.0.0.1" command from your PC
to the switch.
Cisco Catalyst 2960-L Series Easy Setup Guide
1Connecting PC to Switch

2-1 Before You Begin
Before you begin the configuration, make sure that you have the following information.
●IP Address of the Default Gateway (Router)
●IP Address and Subnet Mask for the Switch
2-2 Logging in to Configuration Setup Wizard
When you first set up the switch, use the Configuration Setup Wizard to enter the
initial IP information. Launch a Web browser on your PC, and log in to the Web UI.
1
1Enter the IP address
"10.0.0.1" into a web
browser address bar, and
press Enter key.
The authentication dialog box
appears.
Configuring Switch
2
Caution
If the authentication dialog box does not appear, make sure that:
・All the LEDs next to the Mode button turn green.
・You connect a straight-through cable to an Ethernet port on the switch and the PC.
・Any pop-up blockers or proxy settings on your browser are disabled and that any
wireless client is disabled on your PC or laptop.
・Your PC settings use DHCP. During the Express Setup mode, the switch acts as a DHCP
server. If your PC has a static IP address, temporarily configure your PC settings to use DHCP.
3
2-3 Basic Configuration
After logging in to the Web UI, the Configuration Setup Wizard automatically appears
to help you perform initial configuration.
2Enter the default
username "cisco" in the
[Username].
3Enter the default
password "cisco" in the
[Password].
4Click [OK].
The Configuration Setup Wizard
window appears.
1Click [GO TO WIZARD].
The BASIC CONFIGURATION
window appears.
4
1
MEMO
The switch has a default IP address "10.0.0.1" and a secondary IP address "10.0.0.3".
2
Cisco Catalyst 2960-L Series Easy Setup Guide
2Configuring Switch

2
2Enter a Hostname.
3Enter a Username.
4Enter a Password.
5Enter a Enable Password.
6Select the time and date.
7Click [Interface
Configuration].
The INTERFACE
CONFIGURATION window
appears.
MEMO
The ❺[Enable Password] controls access to the privileged EXEC mode in the CLI (Command
Line Interface).
4
3
5
7
6
2-4 Interface Configuration
Configure the interface information. As a minimum information in order to connect the
switch to the network, the [Data Vlan] field is required.
1Enter a Data VLAN ID.
By default, the VLAN ID assigned
to the management interface for
your switch is 1.
2Enter a Voice VLAN ID.
You can skip this step if your
network does not use a VLAN
for voice traffic.
1
2
Cisco Catalyst 2960-L Series Easy Setup Guide
2Configuring Switch

3Select Access Ports.
You can skip this step if you want
to use all the RJ-45 Ethernet
ports as access ports.
4Click [PortFast Enable].
You can skip this step.
5Select Uplink Ports.
The uplink port functions as a
trunk port connecting to a switch
or router. You can skip this step.
6Click [Layer 3
Configurations]
The LAYER 3 CONFIGURATION
window appears.
3
5
4
6
MEMO
You can configure each ports in the Web UI or CLI (Command Line Interface) after
completing the Configuration Setup Wizard.
MEMO
The PortFast immediately
brings ports to the forwarding
state from a blocking state,
bypassing the listening and
learning states.
2-5 Layer 3 Configuration
Configure the Layer 3 information. As a minimum information in order to connect the
switch to the network, the [Default Gateway] field is required.
1
1Enter the IP address of
the Default Gateway.
2Enter the IP address
and subnet mask for
the switch in the [New
IP] and [Subnet] of
[VlanX] row.
You can configure only one L3
interface on the switch.
3Click
［Advanced
Configuration］.
The ADVANCED
CONFIGURATION window
appears.
2
3
MEMO
The step ❷is not required, but recommended. By assigning an IP address to the
switch here, you can easily access to the Web UI by entering the IP address into a web
browser address bar, after completing the Configuration Setup Wizard.
Cisco Catalyst 2960-L Series Easy Setup Guide
2Configuring Switch

2-6 Advanced Configuration
Configure the advanced information.
1
2-7 Confirming Settings
Review the settings that you configured, save and enable them on the switch.
1Click [Enable Telnet].
2Click [Summary].
The SUMMARY window
appears.
2
1
1Click [Submit].
The Redirecting pop-up window
appears. Connect the switch to
your network.
MEMO
If you want to reconfigure the siwtch, you must return the switch to the factory default
settings. You can reset the switch in the CLI (Command Line Interface). In order to
access to the CLI, the following environments are required.
・The terminal-emulation program such as Tera Term, PuTTY, Windows Command
Prompt.
・Connecting the switch and PC directly by the console cable or remotely through
network.
The example below is the commands to reset in case of using Windows Command
Prompt to connect to the switch with Telnet. Bold text indicates commands entered.
C:\Windows\system32>telnet 10.10.10.2 *Enter the IP address of the step 2-5 ❷
Username: cisco *Enter the username of the step 2-3 ❸
Password: cisco *Enter the password of the step 2-3 ❹
cisco#erase startup-config
Erasing the nvram filesystem will remove all configuration files! Continue? [confirm]
[OK]
Erase of nvram: complete
The example below is the commands to reset in case of connecting to the switch by
the console cable and using Tera Term. Bold text indicates commands entered.
cisco>enable
Password: cisco1234 *Enter the enable password of the step 2-3 ❺
cisco#erase startup-config
Erasing the nvram filesystem will remove all configuration files! Continue? [confirm]
[OK]
Erase of nvram: complete
When the "Erase of nvram: completemessage is shown, reboot the switch by
entering the "reload" command or reconnecting the AC power cord.
MEMO
The switch has a new IP address after configuration (the IP address of the step 2-5 ❷).
Your PC still has an IP address which was assigned by the switch during the Express
Setup mode and needs to have an appropriate IP address to reach the new IP address
of the switch. To do so, simply restart your PC.
Cisco Catalyst 2960-L Series Easy Setup Guide
2Configuring Switch

© 2016 Cisco and/or its affiliates. All rights reserved. Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To
view a list of Cisco trademarks, go to this URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word
partner does not imply a partnership relationship between Cisco and any other company. (1110R)
Appendix Transition Guide Settings
The Cisco Catalyst 2960-L Series Switches are ideal for the replacement of the existing Cisco Catalyst Switches, especially Cisco Catalyst 2960-C/SF/S/Plus Series LAN Lite models.
You can upgrade these Fast Ethernet switches to Gigabit Ethernet switches without impairing their functions.
Legacy Models Current Models
Catalyst 2960-C Catalyst 2960-SF Catalyst 2960-S Catalyst 2960-Plus Catalyst 2960-X Catalyst 2960-L
WS-C2960C-8TC-S - - - - WS-C2960L-8TS-LL
-----WS-C2960L-8PS-LL
-----WS-C2960L-16TS-LL
-----WS-C2960L-16PS-LL
- WS-C2960S-F24TS-S WS-C2960S-24TS-S WS-C2960+24TC-S WS-C2960X-24TS-LL WS-C2960L-24TS-AP
---WS-C2960+24LC-S
WS-C2960+24PC-S -WS-C2960L-24PS-AP
- WS-C2960S-F48TS-S WS-C2960S-48TS-S WS-C2960+48TC-S WS-C2960X-48TS-LL WS-C2960L-48TS-AP
- - - WS-C2960+48PST-S - WS-C2960L-48PS-AP
