Cisco Catalyst 2960S-48FPD-L User manual

A-1
Catalyst 2960-S Switch Hardware Installation Guide
OL-19732-01
APPENDIX
A
Technical Specifications
Table A-1 Environmental Specifications for All Catalyst 2960-S Switches
Environmental Ranges
Operating temperature 0 to 113°F (–5 to 45°C) up to 5,000 ft (1500 m)
23 to 104°F (–5 to 40°C) up to 10,000 ft (3000 m)
Storage temperature –13 to 158°F (–25 to 70°C)
Relative humidity 10 to 85% (noncondensing)
Storage altitude Up to 15,000 ft (4573 m)

A-2
Catalyst 2960-S Switch Hardware Installation Guide
OL-19732-01
Appendix A Technical Specifications
Table A-2 Catalyst 2960S-48FPD-L, 2960S-48LPD-L, 2960S-24PD-L, 2960S-48FPS-L,
2960S-48LPS-L, and 2960S-24PS-L Switch Specifications
Power Requirements
AC input voltage 100 to 240 VAC (autoranging)
9 to 4 A, 50 to 60 Hz (Catalyst 2960S-48FPD-L)
5 to 2 A, 50 to 60 Hz (Catalyst 2960S-48LPD-L)
5 to 2 A, 50 to 60 Hz (Catalyst 2960S-24PD-L)
9 to 4 A, 50 to 60 Hz (Catalyst 2960S-48FPS-L)
5 to 2 A, 50 to 60 Hz (Catalyst 2960S-48LPS-L)
5 to 2 A, 50 to 60 Hz (Catalyst 2960S-24PS-L)
DC input voltage for
RPS 2300
+12 V @ 4 A, –52 V @ 15A (Catalyst 2960S-48FPD-L)
+12 V @ 4 A, –52 V @ 8 A (Catalyst 2960S-48LPD-L)
+12 V @ 3 A, –52 V @ 8 A (Catalyst 2960S-24PD-L)
+12 V @ 4 A, –52 V @ 15 A (Catalyst 2960S-48FPS-L)
+12 V @ 4 A, –52 V @ 8 A (Catalyst 2960S-48LPS-L)
+12 V @ 3 A, –52 V @ 8 A (Catalyst 2960S-24PS-L)
Power consumption1
1. Power consumption values for the power consumed internally by the switch at 120 VAC 60 Hz.
129 W, 440 BTUs per hour (Catalyst 2960S-48FPD-L)
100 W, 341 BTUs per hour (Catalyst 2960S-48LPD-L)
84 W, 286 BTUs per hour (Catalyst 2960S-24PD-L)
131 W, 447 BTUs per hour (Catalyst 2960S-48FPS-L)
100 W, 341 BTUs per hour (Catalyst 2960S-48LPS-L)
84 W, 286 BTUs per hour (Catalyst 2960S-24PS-L)
Power rating2
2. Power rating values for the switch input power.
0.89 KVA (Catalyst 2960S-48FPD-L)
0.48 KVA (Catalyst 2960S-48LPD-L)
0.46 KVA (Catalyst 2960S-24PD-L)
0.89 KVA (Catalyst 2960S-48FPS-L)
0.48 KVA (Catalyst 2960S-48LPS-L)
0.46 KVA (Catalyst 2960S-24PS-L)
PoE+
15.4 W-per-port maximum, 740-W switch maximum
(Catalyst 2960S-48FPD-L and 2960S-48FPS-L switches)
15.4-W-per-port maximum, 370-W switch maximum
(Catalyst 2960S-48LPD-L, 2960S-24PD-L, 2960S-48LPS-L, and 2960S-24PS-L switches)
Physical Dimensions
Weight 13 lb (5.89 kg) (Catalyst 2960S-48FPD-L)
12.5 lb (5.66 kg) (Catalyst 2960S-48LPD-L)
12.5 lb (5.66 kg) (Catalyst 2960S-24PD-L)
13 lb (5.89 kg) (Catalyst 2960S-48FPS-L)
12.5 lb (5.66 kg) (Catalyst 2960S-48LPS-L)
12.5 lb (5.66 kg) (Catalyst 2960S-24PS-L)
Dimensions (H x D x W) 1.75 x 15.19 x 17.5 in. (4.45 x 38.6 x 44.5 cm). Applies to all PoE
switches.

A-3
Catalyst 2960-S Switch Hardware Installation Guide
OL-19732-01
Appendix A Technical Specifications
Table A-3 Catalyst 2960S-48TD-L, 2960S-24TD-L, 2960S-48TS-L, 2960S-24TS-L, 2960S-48TS-S,
and 2960S-24TS-S Switch Specifications
Power Requirements
AC input voltage 100 to 240 VAC (autoranging)
1 to 0.5 A, 50 to 60 Hz (Catalyst 2960S-48TD-L)
1 to 0.5 A, 50 to 60 Hz (Catalyst 2960S-24TD-L)
1 to 0.5 A, 50 to 60 Hz (Catalyst 2960S-48TS-L)
1 to 0.5 A, 50 to 60 Hz (Catalyst 2960S-24TS-L)
1 to 0.5 A, 50 to 60 Hz (Catalyst 2960S-48TS-S)
1 to 0.5 A, 50 to 60 Hz (Catalyst 2960S-24TS-S)
DC input voltage for
RPS 2300
+12 V @ 4 A, (Catalyst 2960S-48TD-L)
+12 V @ 3 A, (Catalyst 2960S-24TD-L)
+12 V @ 4 A, (Catalyst 2960S-48TS-L)
+12 V @ 4 A, (Catalyst 2960S-24TS-L)
+12 V @ 4 A, (Catalyst 2960S-48TS-S)
+12 V @ 3 A, (Catalyst 2960S-24TS-S)
Power consumption1
1. Power consumption values for the power consumed internally by the switch at 120 VAC 60 Hz.
55 W, 188 BTUs per hour (Catalyst 2960S-48TD-L)
40 W, 136 BTUs per hour (Catalyst 2960S-24TD-L)
52 W, 177 BTUs per hour (Catalyst 2960S-48TS-L)
40 W, 136 BTUs per hour (Catalyst 2960S-24TS-L)
53 W, 181 BTUs per hour (Catalyst 2960S-48TS-S)
36 W, 123 BTUs per hour (Catalyst 2960S-24TS-S)
Power rating2
2. Power rating values for the switch input power.
0.09 KVA (Catalyst 2960S-48TD-L)
0.09 KVA (Catalyst 2960S-24TD-L)
0.13 KVA (Catalyst 2960S-48TS-L)
0.09 KVA (Catalyst 2960S-24TS-L)
0.10 KVA (Catalyst 2960S-48TS-S)
0.08 KVA (Catalyst 2960S-24TS-S)
Physical Dimensions
Weight
Dimensions (H x D x W)
9.5 lb (4.30 kg) (Catalyst 2960S-48TD-L,
Catalyst 2960S-24TD-L, and 2960S-48TS-S)
10.5 lb (4.76 kg) (Catalyst 2960S-48TS-L)
10 lb (4.53 kg) (Catalyst 2960S-24TS-L and
2960S-24TS-S)
1.75 x 11.77 x 17.50 in. (4.45 x 29.9 x 44.5 cm). All non-PoE
switches.
