Cisco SG350X-24P User manual

Quick Start Guide
Cisco 350X Series Managed Switches

2 Cisco 350X Series Managed Switches
Welcome
Thank you for choosing the Cisco 350X Series Managed Switches. The
switches are designed to be operational right out-of-the-box as standard
layer 2 and 3 switches. Using the default configuration, your switch
forwards packets between the connecting devices after power up.
This guide familiarizes you with the switch layout and describes how to
deploy the switch in your network. For additional information, see
www.cisco.com/go/350xswitches.
Package Contents
•Your Cisco 350X Series Managed Switch
•Power Cord
•Rack-Mount Kit and Rubber Feet
•DB-9 to RJ45 Serial Cable
•Quick Start Guide
•Pointer Card with China RoHS
•Technical Support Contacts
•EU Directives 1999/5/EC Compliance Information (for EU SKU only)
Before You Begin
Before you begin the installation, make sure that you have the following:
•RJ-45 Ethernet cables for connecting network devices. A category 6a
and higher cable is required for 10G ports; a category 5e and higher
cable is required for all other ports.
•Console cable for using the console port to manage your switch.
•Tools for installing the hardware. The rack-mount kit packed with the
switch contains four rubber feet for desktop placement, and two
brackets and twelve screws for rack-mounting. If the supplied screws
are lost, use replacement screws in the following size:
– Diameter of the screw head: 6.9 mm
– Length of face of screw head to base of screw: 5.9 mm
– Shaft diameter: 3.94 mm
1

Cisco 350X Series Managed Switches 3
•Computer with Internet Explorer (version 9.0, 10.0, 11.0), or Firefox
(version 36.0, 37.0 or higher), or Chrome (version 40,41,42 or higher) for
using the web-based interface or the console port to manage your
switch.
Mounting the Cisco 350X Series Switches
Your switch can be installed in the following ways:
•Place the switch on a flat surface. To place the switch on a desktop,
install the four rubber feet (included) on the bottom of the switch.
•Mount the switch in a standard rack (1 rack unit high).
Placement Tips
Do not deploy the switch in a location where any of the following
conditions exist:
•AmbientTemperature—To prevent the switch from overheating, do not
operate it in an area that exceeds an ambient temperature of 122°F
(50°C).
•AirFlow—Be sure that there is adequate air flow around the switch.
• Mechanical Loading—Be sure that the switch is level and stable to
avoid any hazardous conditions.
• Circuit Overloading—Adding the switch to the power outlet must not
overload that circuit.
Rack Mounting
You can mount the switches in any standard size, 19-inch (about 48 cm)
wide rack. The switch requires 1 rack unit (RU) of space, which is 1.75
inches (44.45 mm) high.
CAUTION For stability, load the rack from the bottom to the top, with the
heaviest devices on the bottom. A top-heavy rack is likely to
be unstable and might tip over.
2

4 Cisco 350X Series Managed Switches
To install the switch into a 19-inch standard chassis:
STEP 1Place one of the supplied brackets on the side of the switch so that
the four holes of the brackets align to the screw holes, and then use
the four supplied screws to secure it.
STEP 2Repeat the previous step to attach the other bracket to the opposite
side of the switch.
STEP 3After the brackets are securely attached, the switch is now ready
to be installed into a standard 19-inch rack.
Connecting Network Devices
To connect the switch to the network:
STEP 1Connect an Ethernet cable to the Ethernet port of a computer,
printer, network storage, or other network devices.
STEP 2Connect the other end of the Ethernet cable to one of the
numbered Ethernet ports of the switch.
The Ethernet port light turns green when the connection is active.
Refer to Cisco 350X Series Switch Features for details about the
different ports and LEDs on each switch.
400925
3

Cisco 350X Series Managed Switches 5
STEP 3Repeat Step 1 and Step 2 for each device that you want to
connect to the switch.
NOTE A category 6a and higher cable is required for 10G ports; a category
5e or higher cable is required for all other ports. When you connect your
network devices, do not exceed the maximum cabling distance of 100
meters (328 feet). It can take up to one minute for the attached devices
or the LAN to be operational after it is connected. This is normal behavior.
Power over Ethernet Considerations
WARNING The switch is to be connected only to PoE networks without
routing to the outside plant.
If your switch is one of the Power over Ethernet (PoE) models, consider the
following power requirement:
*60-Watt PoE extends the IEEE Power of Ethernet Plus standard to double
the power per port to 60 Watts.
350 Switches with Power Over Ethernet
Model Power
Dedicated
to Poe
Number of Ports
Supporting Poe
Poe Standard
Supported
SG350X-24P 195 Watts 1–24
*60-Watt UPoE: ports
1, 2, 13, 14
802.3af/at
60 -Watt PoE
802.3af/at, 4 pair
PoE, Rest af/at
SG350X-24MP 382 Watts
SG350X-48P 382 Watts 1–48
*60-Watt UPoE: ports
1, 2, 3, 4, 25, 26, 27, 28
SG350X-48MP 740 Watts
SG350X-8PMD 240 Watts 1–24
*60-Watt UPoE: ports
5, 6, 7, 8
SG350X-24PD 375 Watts 1–24
*60-Watt UPoE: ports
11, 12, 23, 24

6 Cisco 350X Series Managed Switches
CAUTION Consider the following when connecting switches capable of
supplying PoE:
The PoE models of the switches are PSE (Power Sourcing
Equipment) that are capable of supplying DC power to
attaching PD (Powered Devices). These devices include VoIP
phones, IP cameras, and wireless access points. The PoE
switches can detect and supply power to pre-standard
legacy PoE Powered Devices. Due to the support of legacy
PoE, it is possible that a PoE switch acting as a PSE may
mistakenly detect and supply power to an attaching PSE,
including other PoE switches, as a legacy PD.
Even though PoE switches are PSE, and as such should be
powered by AC, they could be powered up as a legacy PD
by another PSE due to false detection. When this happens,
the PoE switch may not operate properly and may not be
able to properly supply power to its attaching PDs.
To prevent false detection, you should disable PoE on the
ports on the PoE switches that are used to connect to PSEs.
You should also first power up a PSE device before
connecting it to a PoE switch. When a device is being falsely
detected as a PD, you should disconnect the device from the
PoE port and power recycle the device with AC power
before reconnecting its PoE ports.
Configuring the 350X Series Switches
Before You Begin
The switch can be accessed and managed by two different methods; over
your IP network using the web-based interface, or by using the switch’s
command-line interface through the console port. Using the console port
requires advanced user skills.
These are the default settings used when configuring your switch for the
first time.
Parameter Default Value
Username cisco
Password cisco
LAN IP 192.168.1.254
454

Cisco 350X Series Managed Switches 7
Configuring Your Switch Using the Web-based Interface
To access the switch with a web-based interface, you must know the IP
address that the switch is using. The switch uses the factory default IP
address of 192.168.1.254, with a subnet of /24.
When the switch is using the factory default IP address, the System LED
flashes continuously. When the switch is using a DHCP server-assigned IP
address or an administrator has configured a static IP address, the System
LED is a steady green (DHCP is enabled by default).
NOTE If you are managing the switch through a network connection and
the switch IP address is changed, either by a DHCP server or manually,
your access to the switch will be lost. You must enter the new IP address
that the switch is using into your browser to use the web-based
interface. If you are managing the switch through a console port
connection, the link is retained.
To configure the switch using the web-based interface:
STEP 1Power on the computer and your switch.
STEP 2For Cisco 350XG switches, connect the computer to the OOB port
found on the front panel. For Cisco 350X switches, connect the
computer to any network port.
STEP 3Set up the IP configuration on your computer.
a. If the switch is using the default static IP address of
192.168.1.254/24, you must choose an IP address for the
computer in the range of 192.168.1.2 to 192.168.1.253 that is
not already in use.
b. If the IP addresses will be assigned by DHCP, make sure that
your DHCP server is running and can be reached from the
switch and the computer. You may need to disconnect and
reconnect the devices for them to discover their new IP
addresses from the DHCP server.
NOTE Details on how to change the IP address on your computer
depend upon the type of architecture and operating system that
you are using. Use your computers local Help and Support
functionality and search for “IP Addressing.”
STEP 4Open a web browser window. If you are prompted to install an
ActiveX plug-in when connecting to the device, follow the prompts
to accept the plug-in.
STEP 5Enter the switch IP address in the address bar and press Enter. For
example, http://192.168.1.254.

8 Cisco 350X Series Managed Switches
STEP 6When the login page appears, choose the language that you prefer
to use in the web-based interface and enter the username and
password.
The default username is cisco. The default password is cisco.
Usernames and passwords are both case sensitive.
STEP 7Click Log In.
If this is the first time that you have logged on with the default
username and password, the Change Password page opens. The
rules for constructing a new password are displayed on the page.
STEP 8Enter a new password and confirm the password.
NOTE Password complexity is enabled by default. The password
must comply with the default complexity rules or it can be disabled
temporarily by checking Disable next to the Password Strength
Enforcement option.
STEP 9Click Apply.
CAUTION Make sure that any configuration changes made are saved
before exiting from the web-based interface by clicking on
the Save icon. Exiting before you save your configuration
results in all changes being lost.
The Getting Started page opens. You are now ready to configure
the switch. Refer to the Administration Guide or see the help pages
for further information.

Cisco 350X Series Managed Switches 9
Configuring Your Switch Using the Console Port
To configure the switch using the console port:
STEP 1Connect a computer to the switch console port using the supplied
console cable.
STEP 2Start a console port utility such as HyperTerminal on the computer.
STEP 3Configure the utility with the following parameters:
•115200 bits per second
•8 data bits
•no parity
•1 stop bit
•no flow control
STEP 4Enter a username and password. The default username is cisco,
and the default password is cisco. Usernames and passwords are
both case sensitive.
If this is the first time that you have logged on with the default
username and password, the following message appears:
Please change your password from the default
settings. Please change the password for better
protection of your network. Do you want to change
the password (Y/N) [Y]?
STEP 5Enter Y, and set a new administrator password.
NOTE Password complexity is enabled by default. The password
must comply with the default complexity rules.
CAUTION Make sure that any configuration changes made are saved
before exiting.
You are now ready to configure the switch. Refer to www.cisco.com/go/
350xswitches to locate the CLI Guide for your switch.
NOTE If you are not using DHCP on your network, set the IP address type
on the switch to Static and change the static IP address and subnet
mask to match your network topology. Failure to do so may result in
multiple switches using the same factory default IP address of
192.168.1.254.

10 Cisco 350X Series Managed Switches
Stacking the Cisco 350XG Series Switches
Before configuring the switches as a stack, refer to the Administration
Guide for additional details. Refer to the front panel graphics in Cisco
350X Series Switch Features to help with the stack port descriptions and
supported modules.
By default, the ports on a switch function as regular Ethernet ports, except
if you configure them to do stacking. You cannot mix the stack speeds
between the switches or ports.
WARNING Stack ports must be either configured with the same port
speed or have the same speed capability on the module or
cable plug in. If the port speed is configured as auto, then the
module plugged into these two ports will need to have the
same speed capability, otherwise the switch will not be able to
form as a stack with multiple units.
A stack can have up to four Cisco 350XG series switches in it. Any 10G
port of the switch can be used for stacking. The switch can only be
stacked without Mesh topology.
The switches in the same stack are connected together through their stack
ports. Depending on the type of stack ports and the desired speed, you
may need Cat6a Ethernet cables and/or Cisco approved modules or
cables for the Cisco 350XG switches.

Cisco 350X Series Managed Switches 11
Cisco 350X Series Switch Features
This section describes the exterior of the switch to help familiarize you
with your switch.
Product Models
Front Panel
The ports, LEDs, and Reset button are located on the front panel of the
switch as represented in the following illustrations.
SG350X-8PMD
SG350X-48
Model Description
SG350X-24 24-Port Gigabit Stackable Managed Switch
SG350X-24P 24-Port Gigabit PoE Stackable Managed Switch
SG350X-24MP 24-Port Gigabit PoE Stackable Managed Switch
SG350X-48 48-Port Gigabit Stackable Managed Switch
SG350X-48P 48-Port Gigabit PoE Stackable Managed Switch
SG350X-48MP 48-Port Gigabit PoE Stackable Managed Switch
SG350XG-24F 24-Port 10G SFP+ Stackable Managed Switch
SG350XG-24T 24-Port 10GBase-T Stackable Managed Switch
SG350XG-2F10 12-Port 10G Stackable Managed Switch
SG350XG-48T 48-Port 10GBase-T Stackable Managed Switch
SG350X-8PMD 8-Port 2.5G PoE Stackable Managed Switch
SG350X-24PD 24-Port 2.5G PoE Stackable Managed Switch
5
SG350XG-48T

12 Cisco 350X Series Managed Switches
SG350X-24
SG350X-24PD
Front Panel Ports
USB Port—The USB port connects the switch to a USB device so that you
can save and restore the configuration files, firmware images, and
SYSLOG files through the connected USB device.
RJ-45 Ethernet Ports—The RJ-45 Ethernet ports connect network devices,
such as computers, printers, and access points, to the switch.
Multigigabit Ethernet Ports—Highlighted in blue, these ports support
speeds of 100 Mbps, 1 Gbps, and 2.5 Gbps, on Cat 5e cables. Much of the
cabling deployed worldwide is limited to 1 Gbps at 100 meters. Cisco
Multigigabit Ethernet enables speeds up to 2.5 Gbps on the same
infrastructure without replacing a cable.
60-Watt PoE Ports—Highlighted in yellow, the 60-Watt PoE ports double
the PoE power to 60W.
SFP+ Port (if present)—The small form-factor pluggable plus (SFP+) are
connection points for modules so that the switch can link to other switches.
These ports are also commonly referred to as mini 10GigaBit Interface
Converter ports. The term SFP+ will be used in this guide.
•The SFP+ ports are compatible with Cisco modules MGBSX1, MGBLH1,
MGBT1, MGBLX1, MGBBX1, as well as other brands of modules.
•The Cisco SFP+ 10G optical modules that are supported in the Cisco
switches are: SFP-10G-SR, and SFP-10G-LR.
•The Cisco SFP+ Copper Cable modules for stacking that are supported
in the Cisco switches are: SFP-H10GB-CU1M, SFP-H10GB-CU3M, and
SFP-H10GB-CU5M.
•The SFP+ port is a combination port, shared with one other RJ-45 port.
When the SFP+ is active, the adjacent RJ-45 port is disabled.
•The LEDs of the corresponding RJ-45 port flash green to respond to the
SFP interface traffic.

Cisco 350X Series Managed Switches 13
SFP Port (if present)—The small form-factor pluggable (SFP) ports are
connection points for modules, so the switch can link to other switches.
These ports are also commonly referred to as miniGigaBit Interface
Converter (miniGBIC) ports. The term SFP is used in this guide.
•SFP ports are compatible with Cisco modules MGBT1, MGBSX1,
MGBLH1, MGBLX1, MGBBX1, MFELX1, MFEFX1, and MFEBX1, as well as
other brands of modules.
• Some SFP interfaces are shared with one other RJ-45 port, called a
combo port. When the SFP is active, the adjacent RJ-45 port is
disabled.
•The LEDs of the corresponding RJ-45 port flash green to respond to the
SFP interface traffic.
OOB Port (if present)—The Out of Band (OOB) port is a CPU’s Ethernet
port that can be used only as a management interface. Bridging between
the OOB port and the in-band Layer 2 interface is not supported.
Front Panel LEDs
PoE (if present)—(Amber) Located on the right of the port. The LED lights
steady when power is being supplied to a device attached to the
corresponding port.
Master—(Green) The LED lights steady when the switch is a stack master.
System—(Green) The LED lights steady when the switch is powered on,
and flashes when booting, performing self-tests, or acquiring an IP
address. If the LED flashes Amber, the switch has detected a hardware
failure, a firmware failure, and/or a configuration file error.
Stack ID—(Green) The LED lights steady when the switch is stacked and
the corresponding number indicates its Stack ID.
LINK/ACT—(Green) Located on the left of each port. The LED lights steady
when a link between the corresponding port and another device is
detected, and flashes when the port is passing traffic.
XG—(Green) Located on the right of a 10G port. The LED lights steady
when another device is connected to the port, is powered on, and a 10
Gbps link is established between the devices. When the LED is off, the
connection speed is under 10 Gbps or nothing is cabled to the port.
Gigabit—(Green) Located on the right of the OOB port. The LED lights
steady when another device is connected to the port, is powered on, and a
1000 Mbps link is established between the devices. When the LED is off,
the connection speed is under 1000 Mbps or nothing is cabled to the port.

14 Cisco 350X Series Managed Switches
SFP+ (if present)—(Green) Located on the right of a 10G port. The LED
lights steady when a connection is made through the shared port, and
flashes when the port is passing traffic.
Reset Button
The switch can be reset by inserting a pin or paper clip into the Reset
button opening on the front panel of the switch. See Returning the
Switches to the Factory Default Settings for details.
Back Panel
The power port and console port are located on the back panel of the
switch. The back panel of your particular switch may look different, and if
your model has a fan, allow for adequate air circulation.
Power—Connects the switch to AC power.
Console—Connects a serial cable to a computer serial port so that it can
be configured by using a terminal emulation program.
Returning the Switches to the Factory
Default Settings
To use the Reset button to reboot or reset the switch, do the following:
•To reboot the switch, press and hold the Reset button for less than ten
seconds.
•To restore the switch to its factory default settings:
– Disconnect the switch from the network or disable all DHCP
servers on your network.
– With the power on, press and hold the Reset button for more than
ten seconds.
400924
6

Cisco 350X Series Managed Switches 15
Troubleshoot Your Connection
If you cannot access your switch from the web-based interface, the switch
may not be reachable from your computer. You can test network
connections by using ping on a computer running Windows:
STEP 1Open a command window by selecting Start > Run and enter cmd.
STEP 2At the Command window prompt, enter ping and the switch IP
address. For example, ping 192.168.1.254 (the default static IP
address of the switch).
If you can reach the switch, you should get a reply similar to the
following:
Pinging 192.168.1.254 with 32 bytes of data:
Reply from 192.168.1.254:bytes=32 time<1ms TTL=128
If you cannot reach the switch, you should get a reply similar to the
following:
Pinging 192.168.1.254 with 32 bytes of data:
Request timed out.
Possible Causes and Resolutions
The Switch is not Powering on
•Verify the power cord is plugged firmly into the switch and into the
power outlet.
•Verify that the power outlet is active.
•Verify that the computer is on.
•Replace the power adapter, before replacing the switch, if the situation
continues.
Bad Ethernet connection
•Check the LEDs for proper indications. See Front Panel for details.
•Check the connectors of the Ethernet cable to ensure that they are
firmly plugged into the switch and your computer.
•Use a different Ethernet cable or port.
Bad Console port connection
•Verify the console cable connectors are firmly plugged into the switch
and your computer.
•Verify the console port utility is configured with the correct parameters.

16 Cisco 350X Series Managed Switches
IP Addressing Issues
•The Cisco switches can also be accessed by the Cisco FindIT Network
Discovery Utility that automatically discovers all Cisco Small
Business devices in the same local network segment as your computer.
You can view device information including the current IP address,
download the latest firmware for the device, or launch the product
configuration utility to view and configure the settings. For more
information, see www.cisco.com/go/findit.
•Verify that you are using the correct IP address of the switch. Determine
the current IP address of the switch from the CLI through the console
port, Cisco FindIT, or from your network administrator. The System LED
provides an indication of where the switch received the IP address (See
Front Panel for details.)
•Make sure that no other device is using the same IP address as the
switch.
No IP route
If the switch and your computer are in different IP subnets, you need
one or more routers to route the packets between the two subnets.
Unusually long access time
Due to the standard spanning tree loop detection logic, adding new
connections may take 30 to 60 seconds for the affected interfaces
and/or LAN to become operational.

Cisco 350X Series Managed Switches 17
Where to Go From Here
WARNING This is a class A product. In a domestic environment this
product may cause radio interference in which case the user
may be required to take adequate measures.
Cisco Support Community www.cisco.com/go/smallbizsupport
Cisco Support and
Resources
www.cisco.com/go/smallbizhelp
Phone Support Contacts www.cisco.com/en/US/support/
tsd_cisco_small_business
_support_center_contacts.html
Cisco Firmware Downloads www.cisco.com/go/smallbizfirmware
Select a link to download firmware for
Cisco Products. No login is required.
Cisco Open Source
Requests
To receive a copy of the source code to
which you are entitled under the applicable
free/open source license(s) (such as the
GNU Lesser/General Public License),
please send your request to:
externalopensource-request[email protected]
In your requests please include the Cisco
product name, version, and the 18 digit
reference number (for example:
7XEEX17D99-3X49X081) found in the
product open source documentation.
Cisco Partner Central
(Partner Login Required)
www.cisco.com/web/partners/sell/smb
Product Documentation
350X Series www.cisco.com/go/350xswitches
Regulatory Compliance
and Safety Information
www.cisco.com/en/US/docs/switches/lan/
csb_switching_general/rcsi/
Switch_RCSI.pdf
Warranty Information www.cisco-warrantyfinder.com
7

Americas Headquarters
Cisco Systems, Inc.
www.cisco.com
Cisco has more than 200 offices worldwide.
Addresses, phone numbers, and fax numbers
are listed on the Cisco website at
www.cisco.com/go/offices.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates
in the U.S. and other countries. To view a list of Ciscotrademarks, go to this URL:
www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their
respective owners. The use of the word partner does not imply a partnership relationship
between Cisco and any other company. (1110R)
© 2017 Cisco Systems, Inc. All rights reserved.
