APPENDIX
Cisco Cabinet Dimensions A-1
Cisco Cabinet Dimensions
A
This appendix illustrates the space requirements for various system configurations in the Cisco
cabinet and a typical cable management setup. It also contains a table with the height of Cisco WAN
switching components in inches, centimeters, and rack-mount units (RMUs). This can help in the
calculation of height requirements for individual system configurations. The last illustration shows
the bracket installation in the Cisco cabinet (for a BPX 8620 node, in this case). The illustrated
components are the:
•BPX 8620
•IGX 8410, 8420, and 8430 switches
•Cisco MGX 8220 edge concentrator
The sequence of illustrations in this chapter is as follows:
•Cisco Cabinet
•Cable Management
•Examples of System Configurations
•Table of Component Heights

A-2 BPX 8600 Series Installation
Figure A-1 Back View of Cisco Cabinet
Frame
bonding
connection
Frame
bonding
connection
H8215

Cisco Cabinet Dimensions A-3
Figure A-2 Cable Management
Frame
bonding
connection
Cable
manager
Cable
manager
H7963

A-4 BPX 8600 Series Installation
Figure A-3 IGX 8430 Switch, AC and DC-Powered
3.50
8.75
IGX switch
(lower shelf)
H8220
IGX switch
(upper shelf)
IGX switch
(lower shelf)
IGX switch
(upper shelf)
DC-powered
IGX 8430 switch AC-powered IGX 8430 switch
AC power supply
Exhaust plenum
Cooling unit
Cooling unit
Exhaust plenum
Cooling unit
Cooling unit

Cisco Cabinet Dimensions A-5
Figure A-4 IGX 8420 Swtch, DC-Powered and AC-Powered
8.75
IGX switch
AC power supply
Cooling unit
Exhaust plenum
DC-powered
IGX 8420 switch AC-powered IGX 8420 switch
8.75
IGX switch
Cooling unit
Exhaust plenum
H8364

A-6 BPX 8600 Series Installation
Figure A-5 IGX 8410 Switch, AC or DC-Powered
AC or DC-powered
IGX 8410 switch
8.75
IGX 8410 switch
H8365

Cisco Cabinet Dimensions A-7
Figure A-6 Single BPX Switch, AC and DC-Powered
DC-powered BPX 8620 node AC-powered BPX 8620 node
H8217
AC power supply
3.50
BPX 8620 switch BPX 8620 switch
8.75

A-8 BPX 8600 Series Installation
Figure A-7 Single BPX Node and MGX 8220 Edge Concentrator, AC and DC-Powered
AC power supply
AC power supply
H8218
3.50
8.75
BPX 8620 switch BPX 8620 switch
MGX 8220
MGX 8220
Exhaust plenum
Exhaust plenum
Cooling unit
Cooling unit
DC-powered BPX 8620
and MGX 8220 units AC-powered BPX 8620 and MGX 8220 units

Cisco Cabinet Dimensions A-9
Figure A-8 BPX Node, MGX 8220 Edge Concentrator, and ESP, AC and DC-Powered
AC power supply
AC power supply
H8219
3.50
8.75
BPX 8620 switch BPX 8620 switch
MGX 8220
MGX 8220
Exhaust plenum
Exhaust plenum
Cooling unit
Cooling unit
WAN service node
BPX 8620/MGX 8220/ESP
DC power
WAN service node
BPX 8620/MGX 8220/ESP
AC power

A-10 BPX 8600 Series Installation
Figure A-9 BPX Node With 2 ESP Systems and 3 MGX 8220 Shelves, DC-Powered
MGX 8220 booster
MGX 8220
MGX 8220
MGX 8220
ESP
ESP
BPX 8620
H8221
Exhaust plenum
Cooling unit
WAN Service Node
BPX 8620/MGX 8220/ESP
DC power
