OWNER'S MANUAL
75 lb. HD STACK LAUNDRY DRYER
Cissell Manufacturing Co.
831 S. First St. - P.O.Box 32270 - Louisville, Ky. - 40232-2270
Tel: [phone] - Fax: [phone] -
Sales Fax: [phone] - Service/Parts Fax: [phone]
THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER
MANHD75ST 05/02
HD75ST
Gas: Natural and LP
Steam

Page 2
IMPORTANTNOTICES—PLEASEREAD
For optimum efficiency and safety, we recommend that you read the manual before operating the equipment. Store this manual in a
file or binder and keep for future reference.
WARNING: For your safety, the information in this manual must be followed to minimize
the risk of fire or explosion or to prevent property damage, personal injury or loss of life.
- Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or
any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Clear the room, building or area of all occupants.
• Immediately call your gas supplier from a neighbor's phone. Follow thegas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
WARNING: In the event the user smells gas odor, instructions on what to do must be posted in a
prominent location. This information can be obtained from the local gas supplier.
WARNING: Wear safety shoes to prevent injuries.
WARNING: Purchaser must post the following notice in a prominent location:
FOR YOURSAFETY
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WARNING: A clothes dryer produces combustible lint and should be exhausted outside the
building. The dryer and the area around the dryer should be kept free of lint.
WARNING: Be safe, before servicing machine, the main power should be shut off.

Page 3
WARNING: To avoid fire hazard, do not dry articles containing foam rubber or similar texture materials.
Do not put into this dryer flammable items such as baby bed mattresses, throw rugs,undergarments
(brassieres, etc.) and other items which use rubber as padding or backing. Rubber easily oxidizes causing
excessive heat and possible fire. These items should be air dried.
WARNING: Synthetic solvent fumes from drycleaning machines create acids when drawn through the
dryer. These fumes cause rusting of painted parts, pitting of bright or plated parts, and completely
removes the zinc from galvanized parts, such as the tumbler basket. If drycleaning machines are in the
same area as the tumbler, the tumbler's make-up air must come from a source free of solvent fumes.
WARNING: Do not operate without guards in place.
WARNING: Check the lint trap often and clean as needed but at least a minimum of once per day.
WARNING: Alterations to equipment may not be carried out without consulting with the factory and
only by a qualified engineer or technician. Only Manufacturer parts may be used.
WARNING: Remove clothes from dryer as soon as it stops. This keeps wrinkles from setting in and
reduces the possibility of spontaneous combustion.
WARNING: Be safe - shut main electrical power and gas supply off externally before attempting
service.
WARNING: Never use drycleaning solvents, gasoline, kerosene, or other flammable liquids in the dryer.
FIREAND EXPLOSION WILLOCCUR. NEVER PUT FABRICSTREATED WITH THESELIQUIDS
INTO THE DRYER. NEVER USE THESE LIQUIDS NEAR THE DRYER..
WARNING:Do not place items exposed to cooking oils in your dryer. Items contaminated with cooking
oils may contribute to a chemical reaction that could cause a load to catch fire.
WARNING: Never let children play near or operate the dryer. Serious injury could occur if a child
should crawl inside and the dryer is turned on.
WARNING: Never tumble fiberglass materials in the dryer unless the labels say they are machine
dryable. Glass fibers break and can remain in the dryer. These fibers cause skin irritation if they
become mixed with other fabrics.
WARNING: Before operating gas ignition system - purge air from natural gas or propane gas lines
per manufacturer’s instructions.
WARNING: To reduce the risk of electric shock, disconnect this appliance from the power supply
before attempting any user maintenance other than cleaning the lint trap. Turning the controls to the
OFF position does not disconnect this appliance from the power supply.

Page 4
AVERTISSEMENT. Assurez-vousdebien
suivre les instructions donnees dans cette
notice pour reduire au minimum le risque
d’incendie ou d’explosion ou pour eviter tuot
dommage materiel, toute blessure ou la mort.
__ Ne pas entreposer ni utiliser d’essence ni
d’autres vapeurs ou liquides inflammables dans
le voisinage de cet appareil ou de tout autre
apparell.
__ QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ:
•Ne pas tenter d’allumer d’apparell.
• Ne touchez a aucun interrupteur. Ne pas
vous servir des telephones se trouvant dans
le batiment ou vous vous trouvez.
• Evacuez la piece, le batiment ou la zone.
•Appelez immediatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
du fournisseur.
•Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
__ l’installation et l’entretien doivent etre assures
par un installateur ou un service d’entretien
qualifie ou par le fournisseur de gaz.
ATTENTION:L’ACHETEUR DOIT PLACER L’AVERTISSEMENT
SUIVANT DANS UN ENDROIT CLAIR ET VISIBLE:
ATTENTION:L’ACHETEUR DOIT PLACER L’AVERTISSEMENT
SUIVANT DANS UN ENDROIT CLAIR ET VISIBLE:
POUR VOTRE SECURITE
Ne pas entreposer ni utiliser d’ essence
ni d’autres vapeurs ou liquides
inflammables dans le voisinage de cet
appareil ou de tout autre appareil.

Page 5
CISSELLDRYERWARRANTY
The Cissell Manufacturing Company (Cissell) warrants all new equipment (and the original parts thereof) to be free from
defects in material or workmanship for a period of three (3) years from the date of sale thereof to an original purchaser for
use, except as hereinafter provided. With respect to non-durable parts normally requiring replacement in less than three (3)
years due to normal wear and tear, and with respect to all new repair or replacement parts for Cissell equipment for which
the three (3) year warranty period has expired, or for all new repair or replacement parts for equipment other than Cissell
equipment,thewarrantyperiodislimitedtoninety(90)daysfromdateofsale.Thewarrantyperiodoneachnewreplacement
part furnished by Cissell in fulfillment of the warranty on new equipment or parts shall be for the unexpired portion of the
original warranty period on the part replaced.
With respect to electric motors, coin meters and other accessories furnished with the new equipment, but not manufactured
by Cissell, the warranty is limited to that provided by the respective manufacturer.
Cissell’s total liability arising out of the manufacture and sale of new equipment and parts, whether under the warranty or
caused by Cissell’s negligence or otherwise, shall be limited to Cissell repairing or replacing, at its option, any defective
equipment or part returned f.o.b. Cissell’s factory, transportation prepaid, within the applicable warranty period and found
by Cissell to have been defective, and in no event shall Cissell be liable for damages of any kind, whether for any injury to
persons or property or for any special or consequential damages. The liability of Cissell does not include furnishing (or
paying for) any labor such as that required to service, remove or install; to diagnose troubles; to adjust, remove or replace
defective equipment or a part; nor does it include any responsibility for transportation expense which is involved therein.
The warranty of Cissell is contingent upon installation and use of its equipment under normal operating conditions. The
warranty is void on equipment or parts; that have been subjected to misuse, accident, or negligent damage; operated under
loads, pressures, speeds, electrical connections, plumbing, or conditions other than those specified by Cissell; operated
or repaired with other than genuine Cissell replacement parts; damaged by fire, flood, vandalism, or such other causes
beyond the control of Cissell; altered or repaired in any way that effects the reliability or detracts from its performance,
or; which have had the identification plate, or serial number, altered, defaced, or removed.
No defective equipment or part may be returned to Cissell for repair or replacement without prior written authorization
from Cissell. Charges for unauthorized repairs will not be accepted or paid by Cissell.
CISSELLMAKESNOOTHEREXPRESSORIMPLIEDWARRANTY,STATUTORYOROTHERWISE,CONCERNING
THEEQUIPMENTORPARTSINCLUDING,WITHOUTLIMITATION,AWARRANTYOFFITNESSFORAPARTICULAR
PURPOSE,ORAWARRANTYOFMERCHANTABILITY.THEWARRANTIESGIVENABOVEAREEXPRESSLYIN
LIEUOFALLOTHERWARRANTIES,EXPRESSORIMPLIED.CISSELLNEITHERASSUMES,NORAUTHORIZES
ANY PERSON TO ASSUME FOR IT, ANY OTHER WARRANTY OR LIABILITY IN CONNECTION WITH THE
MANUFACTURE,USEORSALEOFITSEQUIPMENTORPARTS.
For warranty service, contact the Distributor from whom the Cissell equipment or part was purchased. If the Distributor
cannot be reached, contact Cissell.
IDENTIFICATIONNAMEPLATE
The Identification Nameplate is located on the rear wall of the dryer. It contains the dryer serial number, product number, model
number, electrical specifications and other important data that may be needed when servicing and ordering parts, wiring diagrams,
etc. Do not remove this nameplate.

Page 6
TABLEOFCONTENTS
75 LB. STACK LAUNDRY DRYER
PAGE
ModelNumbers &Company Address ......................................... 1
ImportantNotices ...................................................................... 2-4
Dryer Warranty............................................................................ 5
TableofContents ......................................................................... 6
Warnings,CautionaryNotesandSymbols ................................. 7-8
UnpackingandGeneralInstallation ......................................... 9-10
DryerOutlineDimensions(Illustration) ...................................... 11
GeneralSpecifications ................................................................ 12
MotorList................................................................................... 13
GeneralInformation.................................................................... 14
Gas Pipe Size Chart.................................................................... 15
GasPipingInformation ............................................................... 16
GasServiceInstallationInformation ........................................... 17
ExhaustInstallation-MultipleManifoldDuct ........................ 18-20
DryerMake-Up AirRequirements............................................. 21
ExhaustInstallationwithSeparateDucts.................................... 22
ExhaustandVenting................................................................... 23
Rules for Safe Operation of Dryer ............................................. 24
OperatingInstructions-TwoTimerModel ................................ 25
Service Savers............................................................................ 26
Troubleshooting ..................................................................... 27-30
DirectSparkIgnition(DSI)System ............................................ 31
PAGE
DirectSparkIgnitionFlowChart ................................................ 32
GeneralMaintenance ................................................................. 33
BasketAlignment-DoubleMotorModel ................................... 34
ShimmingtheBasketandSpiderAssembly ................................ 35
AirSwitchAdjustment ............................................................... 36
FanRotation ............................................................................... 37
Dryer - Front View ............................................................... 38-39
Dryer - Rear View ................................................................ 40-41
ThermostatAssembly............................................................ 42-43
Front Panel and Door Assembly - OPL ..................................... 44
Front Panel Asm. - OPL - Reed Switch..................................... 45
Front Panel Asm. - Coin - Reed Switch ..................................... 46
MotorControlBoxAssembly ..................................................... 47
ExhaustDuctAssembly ............................................................. 48
AirSwitchAssembly.................................................................. 49
GasHeatingUnit ........................................................................ 50
TimerControlPanelAssembly ................................................... 51
DMPCControlPanelAssembly ................................................. 52
DMPControlPanelAssembly ................................................... 53
DX3CControlPanelAssembly .................................................. 54
SmallGear ReducerAssembly -TM100 .................................... 55

Page 7
SYMBOLS
The following symbols are used in this manual and/or on the machine. The numbers between ()
refertothenumbersonthemachinesurveys.
Symbol Description Part/Measurement
NOTE!
on
marche
Ein
conectado
off
arrêt
Aus
desconectado
Hot! Do Not Touch
Heib! NichtBeruhren
Haute temperature! Ne pas toucher
Caliente! no tocar
Heet! Niet Aanraken
start
demarrage
Start
arranquedeunmovimiento
emission of heat in general
êmissiondechaleurengeneral
Warmeabgabeallgemein
emisióndecalor
cooling
refroidissement
Kuhlen
enfriamiento
dangerousvoltage
tensiondangereuse
GafahrlicheelektrischeSpannung
tension peligrosa

Page 8
SYMBOLS
The following symbols are used in this manual and/or on the machine.
Symbol Description
rotationintwodirections
rotation dans les deux sens
DrehbewigunginzweiRichtungen
movimientorotativoen losdossentidos
directionofrotation
sensdemouvementcontinude rotation
DrehbewegunginPfeilrichtung
movimientogiratorioorotatorio
en el sentido de la flecha
End of Cycle
caution
attention
Achtung
atencion;precaucion

Page 9
Unpacking/GeneralInstallation(AllDryers)
This dryer is packed in a large (heavy-duty) protective wooden crate.
Upon arrival of the equipment, any damage in shipment should be
reported to the carrier immediately.
Upon determining permanent location of a unit, care should be taken in
movement and placement of equipment. To move dryer through door
ways, you may need to remove the top of the machine. Follow instruc
tions for disassembling.
See outline clearance diagrams for correct dimensions.
Remove all packing material such as: tape, manuals, skid, etc.
Check voltage and amperes on rating plate before installing the dryer.
IMPORTANT
Beforeinstallingoroperatingthisdryer,thoroughlyreadthe
owner'smanualforcorrectinstructionsconcerningelectric
connections,exhaustducting,gaspiping,steamconnections,
make-upair, etc.
IMPORTANT
Readthewarningsinthismanual.
IMPORTANT
Do not install this dryer in an area where it will be exposed
to water and/or weather.
IMPORTANT
Failuretofollowtheseinstructionsandwarningsmay
create a safety hazard and may affect the warranty.
IMPORTANT
Followalllocalcodes.
IMPORTANT
Ifyou have anyinstallation questions,consult the factory
ServiceDepartment.
UNPACKING
GENERAL
INSTALLATION
(ALL DRYERS)

Page 10
GeneralInstallation(AllDryers)
Positiondryerfortheleastamountofexhaustpipingandelbows,
and allow free access to the rear of dryer for future servicing of belts,
pulleys and motors. Installation clearance from all combustable
materialforgasdryersis0”ceilingclearance,24”rearclearance,and
0”sideclearance. Installationclearancefromallcombustablematerial
forsteamdryersis0”ceilingclearance,24”rearclearance,and0”side
clearance.
Before operating dryer, open basket door and remove blocking
between front panel and basket. Read the instruction tags, owner's
manual,warnings,etc.
The dryer is so designed that when an operator opens the dryer
door, the basket and exhaust fan stop. Hot, dry air is properly and
effectivelymovedthroughthebasketandexhaustedthroughalinttrap
totheventingandeventuallytotheatmosphere. Thelintaccumulates
inthecollectorandshouldberemovedasneeded,minimumoncedaily.
IMPORTANT
Provideadequate clearance for air openingsinto the
combustionchamber.
Replacementpartsforthisdryerareavailablefromyourdistribu-
tororbycontactingthefactoryattheaddressorphonenumberprinted
on the cover of this manual.
WARNING Unit is heavy!
NOTE
Thegasinstallationmustconformwithlocalcodesor,in
the absence of local codes, with the National Fuel Gas Code,
ANSI Z223.1 or the CAN/CGA-B149, Installation Codes.
GENERAL
INSTALLATION
(ALL DRYERS)
GENERAL
IMPORTANT
REPLACEMENT
PARTS

Page 11
75 lb. STACK DRYER Outline Dimensions

Page 12
General Specifications
GENERAL
SPECIFICATIONSFOR
75lb.STACKLAUNDRY
DRYERS
GASFIREDMODEL
BasketLoad cket
Floor Space....................................... 87-1/2” (2223 mm) H x 54”
(1372 mm) W x 63-1/2”
(1613 mm) Deep
BasketSize........................................ 36” (915 mm) Diameter x
36” Deep—21cu.ft. (600 liter)
ExhaustDuct...................................... 12” Diameter (305 mm)
Motor Sizes ....................................... Fan—1/2HP;Basket—1HP
MaximumAirDisplacement.............. 2000 cfm (56.63m³/min.)
total(both pockets)
RecommendedOperating .................. 1576-1826cfm
Range (44.63 - 51.71 m³/min.)
total(both pockets)
NetWeight(approx.)......................... 1810 lbs. (821 kg.)
DomesticShippingWeight ................ 1960 lbs. (889 kg.)
(carton)
ExportShippingDimensions ............. 93” L (2363 mm) x 57” W
(1448 mm) x 76” H (1931 mm)
ExportCrating ................................... 233 cu. ft. (6.6 m³)
BasketRPM ...................................... Reversing—40
(3.2 reversals per minute)
Non-Reversing—40
GasSupply ........................................ 3/4”PipeConnection(26 mm)
Gas Pressure Regulator ..................... Setat3.5”
(Natural Gas) WaterColumn(8.7 mbar)
BTUInput(4burners) ....................... 360,000Btu/hr
(90,720 kcal/h)
(Natural Gas)
360,000Btu/hr
(90,720 kcal/h)
(LP Gases)
ElectronicIgnition............................. DirectSparkIgnition
DryingTime(approx.) ...................... 75 lbs. (35 kg) Dryweight
per pocket
(IndianHead Cloth)
70%MoistureRetention—
32minutes

Page 13
Motor List DOUBLE MOTOR MODELS
Motor No. Voltage Hz. Phase Basket/Fan HP Amps RPM
MTR303 200-240/460 60 3 B 1 3.2/1.6 1725
MTR303 220/380 60 3 B 1 3.2/1.6 1725
MTR301 115/200-240 50 1 B 1 9.0/4.9 1425
MTR303 200/346 50 3 B 1 3.2/1.6 1425
MTR303 220/380 50 3 B 1 3.2/1.6 1425
MTR303 240/415 50 3 B 1 3.2/1.6 1425
MTR101 575 60 3 B/F 1 1.7 1725
MTR300 115/200-240 60 1 F 1/2 6.2/3.1 1725
MTR302 200-240/460 60 3 F 1/2 1.8/0.9 1725
MTR302 220/380 60 3 F 1/2 1.8/0.9 1725
MTR300 115/200-240 50 1 F 1/2 6.2/3.1 1425
MTR302 200-220/346-380 50 3 F 1/2 1.8/0.9 1425
MTR184 240/415 50 3 F 1/3 1.6/.90 1425

Page 14
General Information
GENERAL
INFORMATION
ELECTRICAL
CONNECTIONS
Thedryerissodesignedthatwhenanoperatoropensthedryerdoor,the
basketstops. You can expectfastdrying from a laundrydryer.Hot, dry
airisproperlyand effectively moved through thebasketandexhausted
throughalinttraptotheatmosphere.Thedryercomesequippedwithan
inclined,self-cleaninglintscreen.Inthissystem,lintaccumulatesonthe
undersideofthescreenuntilablanketapproximately1/4” (7mm)thick
is formed. This blanket of lint will fall from the screen to the bottom of
thedryercabinetandshouldberemoveddaily,orasrequired,toprevent
anoveraccumulation.
DryersmustbeelectricallygroundedDryersmustbeelectricallygrounded
DryersmustbeelectricallygroundedDryersmustbeelectricallygrounded
Dryersmustbeelectricallygroundedbyaseparate#14orlargergreen
wirefrom the groundinggrounding
groundinggrounding
groundingterminalwithintheserviceconnectionboxto
a cold water pipe, or through the fourth green wire properly groundedgrounded
groundedgrounded
grounded
andconnectedtothe groundingterminalgroundingterminal
groundingterminalgroundingterminal
groundingterminal. Inallcases,thegroundingInallcases,thegrounding
Inallcases,thegroundingInallcases,thegrounding
Inallcases,thegrounding
methodmustcomplywithlocalelectricalcoderequirements;orinthemethodmustcomplywithlocalelectricalcoderequirements;orinthe
methodmustcomplywithlocalelectricalcoderequirements;orinthemethodmustcomplywithlocalelectricalcoderequirements;orinthe
methodmustcomplywithlocalelectricalcoderequirements;orinthe
absence of localabsence of local
absence of localabsence of local
absence of local codes, with thecodes, with the
codes, with thecodes, with the
codes, with the
National Electrical CodeNational Electrical Code
National Electrical CodeNational Electrical Code
National Electrical Code ,,,, ,ANSI/NFPAANSI/NFPA
ANSI/NFPAANSI/NFPA
ANSI/NFPA
7070
7070
70 or the Canadian Electrical Code, CA C22.1.or the Canadian Electrical Code, CA C22.1.
or the Canadian Electrical Code, CA C22.1.or the Canadian Electrical Code, CA C22.1.
or the Canadian Electrical Code, CA C22.1.
See wiring diagram furnished with dryer.See wiring diagram furnished with dryer.
See wiring diagram furnished with dryer.See wiring diagram furnished with dryer.
See wiring diagram furnished with dryer. Your dryer is completely
wiredatthefactoryanditisonlynecessaryfortheelectriciantoconnect
thepowerleadstothewireconnectorswithintheserviceconnectionbox
on the rear of the dryer. Do not change wiring without consultingDo not change wiring without consulting
Do not change wiring without consultingDo not change wiring without consulting
Do not change wiring without consulting
factory as you may void the factory warranty. Do not connect thefactory as you may void the factory warranty. Do not connect the
factory as you may void the factory warranty. Do not connect thefactory as you may void the factory warranty. Do not connect the
factory as you may void the factory warranty. Do not connect the
dryertoanyvoltageorcurrentotherthanthatspecifiedonthedryerdryertoanyvoltageorcurrentotherthanthatspecifiedonthedryer
dryertoanyvoltageorcurrentotherthanthatspecifiedonthedryerdryertoanyvoltageorcurrentotherthanthatspecifiedonthedryer
dryertoanyvoltageorcurrentotherthanthatspecifiedonthedryer
rating plate.rating plate.
rating plate.rating plate.
rating plate. (Wiring diagram is located on rear wall of dryer.)
«Attention. Lors des opérations d’entretien«Attention. Lors des opérations d’entretien
«Attention. Lors des opérations d’entretien«Attention. Lors des opérations d’entretien
«Attention. Lors des opérations d’entretien
des commandes, ètiqueter tous les fils avantdes commandes, ètiqueter tous les fils avant
des commandes, ètiqueter tous les fils avantdes commandes, ètiqueter tous les fils avant
des commandes, ètiqueter tous les fils avant
de les dèconnecter. Toute erreur de câblagede les dèconnecter. Toute erreur de câblage
de les dèconnecter. Toute erreur de câblagede les dèconnecter. Toute erreur de câblage
de les dèconnecter. Toute erreur de câblage
peut être une source de danger et de panne»peut être une source de danger et de panne»
peut être une source de danger et de panne»peut être une source de danger et de panne»
peut être une source de danger et de panne»

Page 15
Gas Pipe Size Chart
TOTAL BTU/HR
(for LP Gas correct
total BTU/HR below by
multiplying by .6)
TOTAL
KCAL
HOUR
GAS PIPE SIZE FOR 1000 BTU (250 KCAL) NATURAL GAS
AT 7” W.C. (17.5 MBAR) PRESSURE
In figuring total length of pipe, make allowance for tees and elbows. (150 ft.)
45,72 m
(125 ft.)
38,1 m
(100 ft.)
30,48 m
(75 ft.)
22,86 m
(50 ft.)
15,24 m
(25 ft.)
7,62 m
60,000
80,000
100,000
120,000
140,000
160,000
180,000
200,000
300,000
400,000
500,000
600,000
700,000
800,000
900,000
1,000,000
1,100,000
1,200,000
1,300,000
1,400,000
1,500,000
1,600,000
1,700,000
1,800,000
1,900,000
2,000,000
2,200,000
2,400,000
2,600,000
2,800,000
3,000,000
3,200,000
3,400,000
3,600,000
3,800,000
4,000,000
15000
20000
25200
30200
35200
40300
45300
50400
75600
100800
126000
151200
176400
202000
230000
250000
270000
300000
330000
350000
380000
400000
430000
450000
480000
504000
550000
605000
650000
705000
750000
806000
850000
907000
960000
1000000
3/4
3/4
3/4
3/4
3/4
3/4
1
1
1
1 1/4
1 1/4
1 1/2
1 1/2
1 1/2
2
2
2
2
2
2
2
2
2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
3
3
3
3
3
3/4
3/4
3/4
1
1
1
1
1
1 1/4
1 1/4
1 1/2
1 1/2
2
2
2
2
2
2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
3
3
3
3
3
3
3 1/2
3 1/2
3 1/2
3 1/2
3/4
3/4
1
1
1
1
1
1 1/4
1 1/4
1 1/2
1 1/2
2
2
2
2
2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
3
3
3
3
3
3
3
3 1/2
3 1/2
3 1/2
3 1/2
3 1/2
3 1/2
3/4
1
1
1
1
1 1/4
1 1/4
1 1/4
1 1/2
1 1/2
2
2
2
2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
3
3
3
3
3
3
3
3 1/2
3 1/2
3 1/2
3 1/2
3 1/2
3 1/2
4
4
3/4
1
1
1
1
1 1/4
1 1/4
1 1/4
1 1/2
1 1/2
2
2
2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
3
3
3
3
3
3
3
3 1/2
3 1/2
3 1/2
3 1/2
3 1/2
3 1/2
4
4
4
4
3/4
1
1
1
1 1/4
1 1/4
1 1/4
1 1/2
1 1/2
2
2
2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
3
3
3
3
3
3
3
3 1/2
3 1/2
3 1/2
3 1/2
3 1/2
4
4
4
4
4
4

Page 16
Gas Piping Information
Check gas rating plate for type of gas to equip the dryer.
Check for altitude elevation of the dryer.
Check utility for proper installation of gas supply line and gas
pressure.
NATURALGASONLY
Check the gas pressure inlet supply to dryer, 11 inches Water Column
Pressure (27.4mbar) maximum. Check themanifold pressure,
3.5inchesWaterColumnPressure (8.8 mbar)(NaturalGas).
LPGAS ONLY
11inchesWaterColumn Pressure (27.4 mbar) maximum.
CAUTION:Lowgaspressure andintermittentgaswill
causegasignitionproblems.Thiswillcauseinadequate
drying of the clothes load.
Thedryeranditsindividualshut-offvalvemustbedisconnected
fromthegassupplypipingsystemduringanypressuretestingof
that system at test pressures in excess of 1/2 psig (.04 bar).
Thedryermust beisolatedfrom thegassupply pipingsystemby
closingitsindividualmanualshut-offvalveduringanypressure
testing of the gas supply piping system at test pressures equal to
or less than 1/2 psig (.04 bar).
GASPIPING
NATURALGASONLY
LPGAS ONLY

Page 17
The size of the gas service pipe is dependant upon many variables,
such as tees, lengths, etc. Specific pipe size should be obtained from
the gas supplier. Refer to the Gas Pipe Size Chart in this manual for
general gas pipe size information.
CAUTION:Gaslooppipingmustbeinstalledas
illustratedtomaintainequalgaspressureforalldryers
connected to a single gas service.
Othergas-usingappliancesshouldbeconnectedupstream
fromtheloop.
WARNING:
LIQUIFIEDPETROLEUMGASESONLY
A Gas Pressure Regulator for Liquified Petroleum Gases is not
furnished on the gas heated clothes dryers. This regulator is normally
furnished by the installer. In accordance with American Gas
Association (AGA) standards, a Gas Pressure Regulator, when
installed indoors, must be equipped with a vent limiter or a vent line
must be installed from the Gas Pressure Regulator vent to the
outdoors.
Gas Service Installation Information
GENERAL
INSTALLATION
FORALLDRYERS

Page 18
12 17 21 24 27 30 32 34 36 38 40 42
Exhaust Installation—Multiple Manifold Duct
For Exhaust Duct less than 14 feet (5 m) and 2 elbows
equivalent and less than 0.3 inches (8 mm) static pressure.
30°- 45°
▲
AA
AA
A
A
)
▲
Air Flow to
Outside Building
DRYEREXHAUSTS
Area of section “A-A” must be equal to the sum of dryer exhaustpipes
enteringmultipleexhaust pipe. (See chart below.)
1 2 3 4 5 6 7 8 9 10 11 12
No. of Dryers
Duct Diameter
(in inches)
_ _ _ _
_ _ _ _
_ _ _ _
_ _ _ _
_ _ _ _
_ _ _ _
AA
AA
AUTUT
UTUT
UTOMAOMA
OMAOMA
OMATIC ELECTRICAL CONTRTIC ELECTRICAL CONTR
TIC ELECTRICAL CONTRTIC ELECTRICAL CONTR
TIC ELECTRICAL CONTROL FOR EXHAOL FOR EXHA
OL FOR EXHAOL FOR EXHA
OL FOR EXHAUST FUST F
UST FUST F
UST FANAN
ANAN
AN
For one or more dryers to start fan.
Exhaust
Booster Fan
Power Supply
to Fan
RelayCoils
Start and Stop
Switches on
Dryers
(relaysfurnishedbycustomers)

Page 19
Exhaust Installation—Multiple Manifold Duct
EXHAUST
INSTALLATION—
MULTIPLE
MANIFOLDDUCT
For Exhaust Duct more than 14 feet (5 m) and 2 elbows
equivalentand more than0.3 inches (8 mm) staticpressure.
(See illustration on next page.)
1. Make-upairfromoutsidebuildingmayenterenclosurefromtopor
side walls. (See Dryer Make-Up Air Requirements Chart)
2. Use constant diameter duct with area equal to the sum of dryer
duct areas.
EXAMPLE:3-12inch(305 mm) diameterduct=1-20.78inch
(528 mm) diameter duct in area. Use 21 inch (534 mm)
diameter duct or diameter to match tube-axial fan.
3. Enclosure (plenum) with service door. This separates the
dryer air from room comfort air.
4. Zero inches clearance to combustible material allowed on
sides and at points within 4 inches (102 mm) of front on top.
5. Heat loss into laundry room from dryer fronts only is about
60 Btu/hr per square foot.
6. Flangemounted,beltdriventube-axialfan.Fanmustrun
whenone or more dryersare running.See suggested
Automatic Electrical Control Wiring Diagram on previous
page. Must meet local electrical codes. Fan air flow (cfm) is
equal to sum of dryer air flows, but static pressure (SP) is
dependent on length of pipe and number of elbows.
7. Barometric Bypass Damper—Adjust to closed flutter
position with all dryers and exhaust fan running. Must be
locatedwithinenclosure.
CAUTION: Never install hot water heaters or other gas
appliancesinthe sameroomas dryers.Neverinstallcooling
exhaust fans in the same room as dryers.

Page 20
Exhaust Installation—Multiple Manifold Duct (Illustration)
