CJG PA5W060-0120500-ZU User manual

metal housing waterproof Power Supply PA5W Series
：A00
◆/ :Model PA5W060-0120500-ZU/ZG/ZC
1.  ℃/ ℃;
2. : ” 〞,
25±2 Test environment temperature : 25 ± 2
Ripple and noise measurement methods: terminal to parallel 47uF electrolytic capacity
and 0.1uF ceramic capacity, in 20 MHZ Bandwidth measurement.
      .47uf 0.1uf 20MHZ

Output
Characteristics
/ Rated Output Voltage
/ Rated Output Current
/ Rated Output Power 60W
/ Output Voltage Accuracy ±3%
&/ Output ripple & noise 3V

Input
Characteristics
/ Input Voltage Rage 176VAC 264VAC～
/ Input Frequency Rage 50 60HZ～
/ Input Current 0.5AMax
()/Inrush Current (cold start) ≤50A
Efficiency ≥88％ 230Vac

Protective
Characteristics
/ Over-Current Protection ■ YES NO□
/Short-Circuit Protection ■ YES NO□
/Over-Voltage Protection ■ YES NO□
/Over-Temperature Protection □ ■YES NO

Environmental
Characteristics
/ Working Temperature - ℃40 60～+
/ Working Humidity 20 95%RH, non-condensing～（ ）
/Storage Temperature -40 80～+ ℃
/Storage Humidity 10 95%RH～
/ IP Rating □ ■IP40 IP65 IP67 IP68□□
/ Vibration 10 500Hz minutes
for X Y Z each axis)
～，，
5G 30
(、、

Safety and EMC
/Safety Standard ENEC FCC CB CE RoHS、 、、、
()/ Dielectric Strength (Hi-Pot) 3.75KVAC/ 10mA/ 3S
/Insulation Resistance/ 100MOhm Min/ 500VDC/ 3S
/EMC E 55015N

Other sCharacteristic
/MTBF ≥℃)50000hrs. MIL-HDBK-217F(25
/Size 202*44*33mm(L*W*H)
/Weight 450g
/Remarks
◆/ :Applicable occasions
//Outdoor/Indoor
◆/ :Features
◆/ :Installation
◆/ :Warranty
55/ years
/Lock screw
1
2. Working temperature range -40 +60
3 Have OCP OVP.SCP function
4 UL/cUL.FCC.CB.CE Through the UL/cUL.FCC.CB.CE
.
/ ℃～ ℃
.../ .
. /
/ Constant voltage mode output
/Electrical Specification
IP68
LISTED
tel [email protected]:.. w. .|[phone] | ww cjglamps com
12V 24V
5A 2.5A
PA5W060-0240250-ZU/ZG/ZC
INPUT
L
N
Black
White
MODEL No:
EFFICIENCY>88% PF>0.95
Suitable for wet location
Constant
Voltage
Type
PA5W060-0120500-ZU/ZG/ZC
Po:60W
SELV
For LED Only
Input Voltage
Input Current
~50/60Hz
220-240V
0.5A
Max
Output Voltage
Output Current
12V
￣
﹍
5A
LED DRIVER
CAUTION:
2
3
1
.
.
.
Do not put the product closely to
heat source or flammable materials;
Right installation for easy heat conduction;
Do not touch the product when it’s working.
.
ta: 60℃
tc:
90℃
Five-years warranty
Made in China
Date Code:YYWW
OUTPUT
White
Black
“+”
“-”
IP68
G
Green

 /Profile Drawings/Lable
 /Profile Drawings  ：（/unit mm/inch)
tel [email protected]:.. w. .|[phone] | ww cjglamps com
/Lable
INPUT
L
N
Black
White
MODEL No:
EFFICIENCY>88% PF>0.95
Suitable for wet location
Constant
Voltage
Type
PA5W060-0120500-ZU/ZG/ZC
Po:60W
SELV
For LED Only
Input Voltage
Input Current
~ 50/60Hz
220-240V
0.5A
Max
Output Voltage
Output Current
12V
￣
﹍
5 A
LED DRIVER
CAUTION:
2
3
1
.
.
.
Do not put the product closely to
heat source or flammable materials;
Right installation for easy heat conduction;
Do not touch the product when it’s working.
.
ta: 60℃
tc:
90℃
Five-years warranty
Made in China
Date Code:YYWW
OUTPUT
White
Black
“+”
“-”
IP68
G
Green
INPUT
L
N
Black
White
MODEL No:
EFFICIENCY>88% PF>0.95
Suitable for wet location
Constant
Voltage
Type
PA5W060-0240250-ZU/ZG/ZC
Po:60W
SELV
For LED Only
Input Voltage
Input Current
~ 50/60Hz
220-240V
0.5A
Max
Output Voltage
Output Current
24V
￣
﹍
2.5 A
LED DRIVER
CAUTION:
2
3
1
.
.
.
Do not put the product closely to
heat source or flammable materials;
Right installation for easy heat conduction;
Do not touch the product when it’s working.
.
ta: 60℃
tc:
90℃
Five-years warranty
Made in China
Date Code:YYWW
OUTPUT
White
Black
“+”
“-”
IP68
G
Green
202
［］7.952
172
［］6.771
300
INPUT
［. ］ 11 811
OUTPUT
300
［. ］ 11 811
15 64.5
［］0.590 ［］2.539
SJTW 18AWGx3
SJTW 18AWGx2
33
［. ］1 299
［］ 1.732
44
AC/L(Black)
AC/N(White)
Vo+(White)
Vo-(Black)
(Green)
PE
Tc

PA5W060-0240250-ZG01
20 10.4Kg 390 265 220(mm)
/Packaging And Safety Information
 / Packaging diagram
1. ,,,！
2. ,,。
3. ,.,.
Prohibit hot-line work. Check and ensure the connection is correct before powering on.
Don't touch the exposed metal of the plastic casing power supply to avoid electric shock.
Do not attempt to repair privately. Please contact the supplier if you have any questions.
 /Warning
 / Cautious
 / Packaging Information

 ( /)pcs ( )Kg/ ( )Kg/  /Out carton
/Length /Width /Height
1. ,.
2.  !"#,$%&()*+,,-,./01.
3. 234,567./89.
Please make the power supply installed in a well-ventilated place, to ensure that the environment
temperature is appropriate.
To be installed by a certified electrician. Please read and follow the instructions carefully before installing.
Ensure all contact points are connected firmly.
Please pay special attention to the operating environment of the power supply, and ensure regular
check and maintenance to avoid hazard.
Qty pcs carton(/ )
Products code
Net Weight Gross Weight
22.92Ib
15.35 10.43 8.66(inch)
( )Product
:;Inner packing oxb
<()Outer carton
=>+?@,AB+CDE,FGH.
The actual packed quantity and weight may subject to change without prior notice.
tel [email protected]:.. w. .|[phone] | ww cjglamps com
13Kg
28.66Ib
PA5W060-0120500-ZG01
