SERVICE MANUAL
400W 2/1 CHANNEL POWER AMPLIFIER
DPX2250
- 1 - DPX2250
Clarion Co. Ltd.
50 Kamitoda, Toda-shi, Saitama 335-8511 Japan
Service Dept.: 5-66 Azuma , Kitamoto-shi, Saitama 364-0007 Japan
Tel: [phone] / 2432 FAX: [phone]
-------------------------------------------------------------------
Clarion Corporation of America
6200 Gateway Drive, Cypress, CA90630, USA
Phone: [phone]; Fax: [phone]
Website: Http://www.clarion.com
■FEATURE
■SPECIFICATION
lMaximum Power Output 150W x 2 @1%
lContinuous Rated Power 125W x 2
lPower in bridged Mode 400W
lPower in 2 Ohm load 210W x 2
lMono Power in 4 Ohm 400W
lChannel Separation 70dB
lFrequency Response 18 -30K
lInput Sensitivity 0.2 - 8V
lInput Impedance 22Kohm@line in;
470ohm@spkr
lNominal battery voltage 14.4 DCV
■TO ENGINEERS IN CHARGE OF
REPAIR OR INSPECTION OF OUR
PRODUCTS:
BEFORE REPAIR OR INSPECTION, MAKE SURE TO FOLLOW
THE INSTRUCTIONS SO THAT CUSTOMERS AND ENGINEERS
IN CHARGE OF REPAIR OR INSPECTION CAN AVOID
SUFFERING ANY RISK OR INJURY. REMODELING FOR WHICH
WE SHALL NOT BE LIABLE. THE ONUS OF PRODUCT LIABLITY
(PL) SHALL NOT BE OUR RESPONSIBILITY IN CASES WHERE
AN ACCIDENT OR FAILURE IS AS A RESULT OF UNSPECIFIED
PARTS BEING USED OR DUE TO NEGLIGENCE DURING
REPAIR.
1. USE SPECIFIED PARTS.
THE SYSTEM USES PARTS WITH SPECIAL SAFETY FEATURES
AGAINST FIRE AND VOLTAGE. USE ONLY PARTS WITH
EQUIVALENT CHARACTERISTICS WHEN REPLACING THEM.
2.PLACE THE PARTS AND WIRING BACK IN THEIR ORIGINAL
POSITIONS AFTER REPLACEMENT OR RE-WIRING.
FOR PROPER CIRCUIT CONSTRUCTION, USE OF INSULATION
TUBES, BONDING, GAPS TO PWB, ETC, IS INVOLVED. THE
WIRING CONNECTION AND ROUTING TO THE PWB ARE
SPECIALLY PLANNED USING CLAMPS TO KEEP AWAY FROM
HEATED AND HIGH VOLTAGE PARTS. ENSURE THAT THEY ARE
PLACED BACK IN THEIR ORIGINAL POSITIONS AFTER REPAIR
OR INSPECTION.
3.CHECK FOR SAFETY AFTER REPAIR.
CHECK THAT THE SCREWS, PARTS AND WIRES ARE PUT BACK
SECURELY IN THEIR ORIGINAL POSITION AFTER REPAIR.
ENSURE FOR SAFETY REASONS THERE IS NO POSSIBILITY OF
SECONDARY PROBLEMS AROUND THE REPAIRED SPOTS.
4.CAUTION IN REMOVAL AND MAKING WIRING CONNECTION TO
THE PARTS FOR THE AUTOMOBILE. DISCONNECT THE
BATTERY TERMINAL AFTER TURNING THE IGNITION KEY OFF.
IF WRONG WIRING CONNECTIONS ARE MADE WITH THE
BATTERY CONNECTED, A SHORT CIRCUIT AND/OR FIRE MAY
OCCUR.
5. CAUTIONS REGARDING CHIPS.
DO NOT REUSE REMOVED CHIPS EVEN WHEN NO
ABNORMALITY IS OBSERVED IN THEIR APPEARANCE. ALWAYS
REPLACE THEM WITH NEW ONES. (THE CHIP PARTS INCLUDE
RESISTORS, CAPACITORS, DIODES, TRANSISTORS, ETC). THE
NEGATIVE POLE OF TANTALUM CAPACITORS IS HIGHLY
SUSCEPTIBLE TO HEAT, SO USE SPECIAL CARE WHEN
REPLACING THEM AND HECK THE OPERATION AFTERWARDS.
6. CAUTIONS IN HANDLING FLEXIBLE PWB BEFORE WORKING
WITH A SOLDERING IRON MAKE SURE THAT THE IRON TIP
TEMPERATURE IS AROUND 270 ℃. TAKE CARE NOT TO APPLY
THE IRON TIP REPEATEDLY (MORE THAN THREE TIMES) TO
THE SAME PATTERNS. ALSO TAKE CARE NOT TO APPLY THE
TIP WITH FORCE.
7. TURN THE UNIT OFF DURING DISASSEMBLY AND PARTS
REPLACEMENT. RECHECK ALL WORK BEFORE YOU APPLY
POWER TO THE UNIT.
■CONTENT
NOTE: FOR FURTHER IMPROVEMENT, SPECIFICATIONS AND
DESIGN ARE SUBJECT TO CHANGE WITHOUT NOTICE.
l400 Watts of Maximum Music Power
l125W × 2 Into 4 Ohms, 20Hz-20kHz @ < 0.05%THD
l200W × 2 Into 2 Ohms, 20Hz-20kHz @ < 0.1%THD
lBridgeable, 400W × 1, 20Hz-20kHz @ < 0.2%THD
lInput Voltage Selector
lPrecise Frequency Selector
lVariable Bass Extender; 0-15dB @ 50Hz
lAdjustable -12db/Oct. High/Low Pass Crossover, 50-
250Hz Gold Plated Connectors; RCA/Speaker/Power
Speaker Level Input
lDimensions 13 1/4" × 12" × 2 7/8”
DESCRIPTION QTY
UB 61-AW30-0500 HI LEVEL INPUT CABLE 5PIN 300mm 1
UB 23-WR35-1211 EPE FOAM 350*123*115mm 1
UB TB-APX1300-02 C-TICK STICKER 1
UB 95-CPDPX1800 DPX1800 MAIN UNIT 1
UB GB-DPX1800 GIFT BOX 1
UB LS-FSDG-0524 SCREW φ5*24MM 4
UB PE-1280-06PE ZIPPER BAG 120*80*0.06mm 1
UB PE-2616-06PE PE BAG 260*160*0.06MM 1
UB PE-7040-06PE PE BAG 700*400*0.06mm 1
UB PE-7350-03GG-02 ZIPPER BAG 73*50*0.03MM 1
UB SMS-DPX2250 USER'S MANUAL 1
UB TB-DPX1800 MODEL LABEL 1
UB TB-DPX1800-01 S/N LABEL 1
UB TB-DPX1800-02 BARCODE LABEL 2
UB 23-WR35-1211-01 EPE FOAM (RIGHT) 1
UB DPX1800-08 REMOTE CONTROL 1
PART NO

■TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
LOW OR NO REMOTE TURN-ON VOLTAGE CHECK REMOTE CONNECTIONS AT AMPLIFIER AND SOURCE UNIT.
BLOWN AMPLIFIER FUSE REPLACE WITH NEW FAST-BLOW FUSE (SAME RATING).
POWER WIRES NOT CONNECTED CHECK BATTERY AND GROUND WIRING AT AMPLIFIER; ALSO CHECK
BATTERY CONNECTIONS.
SPEAKER LEADS SHORTED CHECK SPEAKER CONTINUITY TO GROUND, IT SHOULD NOT SHOW
A COMMON GROUND.
NO AUDIO
SPEAKERS NOT CONNECTED OR ARE
BLOWN
CHECK SPEAKER CONNECTIONS AT AMPLIFIER, MEASURE COIL
IMPEDANCE.
AUDIO CYCLES ON
AND OFF
THERMAL PROTECTION CIRCUITS ARE
SHUTTING AMPLIFIER OFF
CHECK LOCATION FOR ADEQUATE VENTILATION; CONSULT AN
AUTHORIZED CLARION AUDIO DEALER.
DISTORTED AUDIO. GAIN IS NOT SET PROPERLY, OR
DAMAGED SPEAKER CONES
REVIEW SETTING GAIN; INSPECT EACH SPEAKER CONE FOR SIGNS
OF DAMAGE (I.E., FROZEN CONE, BURNING SMELL, ETC.)
AMPLIFIER FUSE
KEEPS BLOWING
INCORRECT WIRING OR SHORT CIRCUIT REVIEW INSTALLATION AND CHECK ALL WIRING CONNECTION.
WHINING OR TICKING
NOISE IN THE AUDIO
WITH ENGINE ON.
AMPLIFIER IS PICKING UP ALTERNATION
NOISE OR RADIATED NOISE
TURN DOWN INPUT GAIN AND MOVE AUDIO CABLES AWAY FROM
POWER WIRES. CHECK POWER AND GROUND CONNECTIONS ON
AMPLIFIER AND INSTALL AN IN-LINE NOISE FILTER ON SOURCE
UNIT’S POWER WIRE. ALSO CHECK THE ALTERNATOR AND /OR
VOLTAGE. TEST FOR WEAK BATTERY OR ADD WATER TO
BATTERY.
■EXPLODED VIEW / PARTS LIST
- 2 - DPX2250
REF D e s c rip tio n S p e c i fi c a ti o n Un it
1 UB 9 3 -D B 3 0 -0 0 0 0 H E AT S IN K AL 6 0 6 3 L = 3 0 4 .8 m m B L A C K PCS
2 UB 9 3 -D B 3 8 -0 0 0 0 S U B H E A T S IN K AL 6 0 6 3 L = 3 8 m m B L A C K PCS
3 UB 2 9 -0 1 0 0 - 0 0 0 0 -P D -0 1 B AC K L IG H T E D P AP E R W H IT E 0 .1 m m PCS
4 UB 2 9 -1 6 0 2 - 0 5 0 0 -P D F IB E R P AP E R 1 6 * 2 * 0 .5 m m PCS
5 UB P C B -1 0 2 0 -1 0 H B L E D P C B A S S E M B Y 1 0 6 * 2 0 * 1 .0 t/m m 9 4 V0 B L U E PCS
6 UB P C B -2 9 1 5 -1 6 H B - 0 3 P C B 2 9 7 * 1 5 3 * 1 .6 m m B l u e F R 4 D O U B L E PCS
7 UB M M -3 2 6 4 -7 9 0 0 S P AC E B AR Φ 3 .2 * Φ 6 .4 * H 7 .9 M M PCS
8 UB J J -F B 2 4 - 1 0 0 1 C L IP 1 * 1 0 .2 * 2 4 .2 M M B L AC K PCS
9 UB M G - D P X2 2 5 0 -L F R O N T P AN N E L B L AC K PCS
1 0 UB M G - D P X2 2 5 0 -R R E AR P AN N E L B L AC K PC S
1 1 UB M M -D P X2 2 5 0 - 0 1 S ID E R IN G ( L E F T ) AB S B L AC K PCS
1 2 UB M M -D P X2 2 5 0 - 0 2 S ID E R IN G ( R IG H T ) AB S B L AC K PCS
1 3 UB M G - D P X2 2 5 0 -0 3 AC R YL IC B O AR D P C T R AN S P AR E N T PCS
1 4 UB 2 9 -1 0 1 1 -0 1 0 0 -P D T IN F O IL 1 0 6 * 1 1 T AK 0 .1 m m PCS
1 5 UB M G - D P X2 2 5 0 -0 4 L O G O B AD G E P C PCS
1 6 UB M G - D P X2 2 5 0 -0 5 B AD G E R IN G P C S IL VE R PCS
1 7 UB M G - D P X2 2 5 0 -0 2 T O P C O VE R AL U M I PCS
1 8 UB M G - D P X2 2 5 0 T O P C O VE R - L O G O AL U MI, 3 0 4 .8 M M PCS
1 9 UB M G - D P X2 2 5 0 -0 1 T O P C O VE R - M O D E L AL U MI, 3 0 4 .8 M M PCS
2 0 UB M M -D P X2 2 5 0 B O T T O M C O VE R B L AC K PCS
2 1 UB 2 9 -1 8 1 0 -0 4 0 0 -E D E VA 1 8 * 1 0 * 4 M M PCS
2 2 UB 2 9 -3 0 0 8 - 0 5 0 0 -D A B O T T O M P AD 3 0 0 * 8 * 0 .5 m m PCS
2 3 UB P C -0 8 0 5 -0 3 G W E V A F O AM 8 * 5 m m , 3 m m ,E VA PCS
2 4 UB 2 9 -P H 0 0 -0 0 1 A P L AS T IC P AD P H -1 A PCS
2 5 UB 0 4 -0 8 0 9 - 0 0 G G VR C A P Φ 8 .5 * 9 .0 m m B L AC K AB S PCS
2 6 UB T IN - AM IT 2 -0 1 8 M IK A 2 0 * 2 5 * 0 .1 M M PCS
2 7 UB T IN - AM 1 T 2 -0 1 7 M IK A 1 8 .5 * 1 3 * 0 .1 M M PCS
2 8 UB P C B -5 7 2 6 -1 6 F R P C B 5 7 * 2 6 * 1 .6 /m m B L U E F R -4 PCS
S 1 UB L S -F B L O -0 4 0 6 S C R E W 4 * 6 m m H E X B L AC K PCS
S 2 UB L S -F B D G -0 2 1 0 -0 1 S C R E W P H IL IP P S Φ 2 * 1 0 M M B L AC K PC S
S 3 UB L S -F B L O -0 3 0 8 S C R E W 3 * 8 m m H E X B L AC K PCS
S 4 UB L S -F B D O -0 3 1 4 S C R E W P H IL IP P S M 3 * 1 4 m m B L A C K PCS
S 5 UB L S -F S D O -0 3 0 6 -0 1 S C R E W P H IL IP P S Φ 3 * 6 M M PCS
S 6 UB L S -F B D O -0 3 1 7 S C R E W P H IL IP P S W /W AS H E R M 3 * 1 7 m m B L AC K PC S
S 7 UB L S -F S G G -0 2 0 5 S C R E W M 2 * 5 m m P H IL IP P S PC S
S 8 UB L S -F B C G -0 3 0 6 S C R E W P H IL IP P S Φ 3 * 6 M M B L AC K PCS
P a rt N o

- 3 - DPX2250

■ELECTRICAL PART LIST
- 4 - DPX2250
DESCRIPTION SPEC QTY LOCATION REF.
UB 40-LG20-0020 JUMPER 1*20mm 3 JP1 JP2 JP14
UB 40-LG40-0020 JUMPER 1*40mm 1 JP6
UB 40-LH10-0100 JUMPER 1*100mm 1 JP9
UB 40-LH10-0100-02 JUMPER Φ2.0mm L100mm H13mm 1 JMP4
UB 40-LH10-0217 JUMPER Φ2.0*100mm H=17mm 1 JMP3
UB 40-LH14-0200-01 JUMPER ψ2.0mm L=140mm H=17mm 2 JMP1 JMP2
UB 40-LH25-0200-01 JUMPER Φ2*25mm H=5mm 1 JP5
UB 40-LH25-0201 JUMPER L=25mm H=7.7MM, 1MM 2 JP11 JP4
UB 40-LH30-0100 JUMPER 1*30mm 1 JP3
UB 40-LH30-0200-02 JUMPER Φ2*30mm H=5mm 1 JP7
UB 40-LH40-0200-02 JUMPER Φ2*40mm H=5mm 1 JP10
UB 40-LH50-0100 JUMPER 1*50mm 1 JP15
UB 40-LH70-0100 JUMPER 1*70mm 2 JP12 JP16
UB 40-LH80-0200-01 JUMPER Φ2*80mm H=13mm 1 JMP5
UB 40-LHA0-0200-03 JUMPER Φ2*110mm H=17mm 2 JP8 JP13
UB 61-B080-0100-02 CABLE BLACK Φ6.5mm AWG1007 16# L=80mm 1 GND
UB 61-BW10-0500 CABLE 5PIN CABLE AWG1007 22＃ 110mm 1 HI LEVEL IN
UB 61-CC20-0300 CABLE 3PIN L=300mm 26# 1 CON101
UB 61-RB13-0200 CABLE 2P CABLE AWG1007 26# 135mm 1 THERMISTOR
UB BYQ-0406-4700 TRANSFORMER Φ47mm4:6:6 1.0mm*8*4TS SEC(1.0*4*6) 1 T1
UB CCL-101J2AOAT-UB C/CAPACITOR 100P/100V 8 C60 C61 C62 C63 RC3 RC6 RC12 RC15
UB CCL-104J2AOAT-UB C/CAPACITOR 104/100V "J" PRITCH:5mm 21
C43 C44 C45 C46 C47 C48 C49 C50 C410
C415 C414 C4 20 C421 C425 C426 C431
C432 RC24 RC25 RC26 RC27
UB CCL-151J2AOAT-UB C/CAPACITOR 151/100V PITCH:5mm 2 C30 C32
UB CCL-221J2AOAT-UB C/CAPACITOR 220P/100V "J" AI 5mm 6 RC1 RC10 RC18 RC19 RC20 RC21
UB CCL-271J2AOAT-UB C/CAPACITOR 271/100V PITCH:5mm 4 C27 C29 C34 C55
UB CCL-470J2AOAT-UB C/CAPACITOR 47/100V PITCH:5mm 8 C5 C6 C10 C18 C19 C23 RC22 RC23
UB CCL-681J2EOAT-UB C/CAPACITOR 681/250V 1 RC28
UB CEN105J1HYRAT-UB NP CAPACITOR 1uF/50V"M"105 AI Φ4*7mm5mm 4 C3 C4 C16 C17
UB CEN107J1HYRAT-UB NP CAPACITOR 100uF/25V105℃ Φ8*12 BLACK 1 C64
UB CEN226J1HYRAT-UB NP CAPACITOR 22uF/50V105℃ BLACK Φ6.3*11mm 2 RC4 RC13
UB CEP104J1HHR5T-UB E/ CAPACITOR 0.1UF/50V 105℃Φ5*11mm 2 C8 C21
UB CEP106J1CYR5T-UB E/ CAPACITOR SMT 10UF/16V D=5mm L=5.4mm "M" 105℃1 C405
UB CEP107EHRAP-01 E/ CAPACITOR 100UF/63V 105℃ Φ10*16mm LOW ESR 2 C26 C28
UB CEP107J1CHR5T-UB E/ CAPACITOR SMT 100UF/16V D=5mm L=5.4mm "M" 105℃2 C433 C26
UB CEP107J1EHR6T-01UB E/ CAPACITOR 100uF/25V "M"105 AI Ф6.3*11mm5mm 5 C427 C428 C429 C430 RC9
UB CEP225J1HHR5T-UB E/ CAPACITOR 2U2/50V 105℃Φ5*11mm 2 C2 C15
UB CEP227J1EHRAT-UB E/ CAPACITOR 220uF/25V105℃ BLACK 4 C53 C59 C39 C51
UB CEP228J1HHRAP-01 E/ CAPACITOR 2200UF/50V 105℃ Φ18*25mm 4 C41 C56 C57 C58
UB CEP228J1VHRAP-03 E/ CAPACITOR 2200uF/35V 105℃ LOW ESR 3 C13 C35 C37
UB CEP474J1HHR5T-UB E/ CAPACITOR 0.47UF/50V 105℃ Φ5*11mm 2 C9 C22
UB CEP475J1EHR5T-UB E/ CAPACITOR SMT 4U7/25V D=4mm L=5.4mm "M" 105℃2 C434 C437
UB CEP475J1HHR5T-01UB E/ CAPACITOR 4U7/50V 105℃ BLACK Φ5*11 6 C7 C20 RC8 RC17 RC2 RC11
UB CML-104J2AOAP-03 CAPACITOR 104J/100V 4 RC5 RC7 RC14 RC16
UB CML-104J2AOAP-05 CAPACITOR 104 0805M 50V 2 C401 C13
UB CML-224J1JOAP-02 CAPACITOR 224/63V 4 C31 C33 C52 C54
UB CML-472J2AOAP-04 CAPACITOR 472 0805J50V 1 C402
UB CML-563J1JOAT-UB CAPACITOR 563/63V PITCH:5mm 4 C11 C12 C24 C25
UB DPX2250-03 MINIBOARD DPX2250 ZM-MK494 1
UB DR-D0IN4001-T-02 DIODE IN4001 SMT 1 D407
UB DR-DO2502CC-T DIODE C25-02C TO-220AB 2 D2 D21
UB DR-DO2502CN-T DIODE C25-02N TO-220AB 6 D1 D20 D25 D26 D28 D30
UB DS-D0IN4148-T-02 DIODE IN4148 3 D401 D410 D412
UB DS-D0IN5402-T-01 DIODE IN5402 1 D406
UB DS-DOIN4148-T-01 DIODE IN4148 20
D3 D4 D5 D6 D7 D8 D9 D10 D13 D22 D23
D24 D29 D32 D33 D34 D402 D403 D404
D405
UB DZ-015S35CW2T-01 ZENER DIODE 5.1V1/2W 1 Z5
UB DZ-047S17BW2T ZENER DIODE 4.7VSMT1/2W 1 Z1
UB DZ-082S29AW2T-01 ZENER DIODE 8.2V 1/2W 4 Z2 Z4 Z7 Z9
UB DZ-120S1CAW2T-02 ZENER DIODE SMT 12V1/2W 1 Z5
UB DZ-120S1CAW2T-03 ZENER DIODE 12V 1/2W 4 Z1 Z3 Z6 Z8
UB DZ-150S21501T-01 ZENER DIODE 15V/1W 2 Z403 Z404
UB DZ-390S239W5T ZENER DIODE 39V/0.5W DO-35 2 Z401 Z402
UB FUSE-HDP-006 FUSE HOLDER BLACK (BXS-01E) 3 F401 F1 F2
UB FUSE-R250E20H-01 FUSE 20A*3 UL 3 F401 F1 F2
PART NO.

- 5 - DPX2250
DESCRIPTION SPEC QTY LOCATION REF.
UB IA-0000PC817H IC PC817 DIP4 1 U7
UB IA-00TL074CNH-01 IC TL074 DIP14 4 U2 U4 U5 U6
UB IA-00TL494CNH IC SMT TL494CN 1 U401
UB JP-12XV3-001B CONNECTER 3PIN 2.0mm 1 CON101
UB JR-12CVA-002Z RCA 2P RED/WHITE 2-HOLE AV2-8.4-13A 1 RCA1
UB LC-GG25-0023 INDUCTOR 2.5uH Φ23 1.2*5*5.5Tmm 1 L401
UB LD-R0G10-001D LED HOLDER 10*8.2*4.3mm 1 LED2
UB LD-R0U30-008E-01 LED 3.2*1.8mm BLUE 8 LED1 LED2 LED3 LED4 LED5 LED6 LED7
LED8
UB LD-ROU30-005R LED ψ3* 4.8mm RED 1 LED2 RED
UB LD-ROU30-011E LED ψ3*4.8mm BLUE 1 LED2 BLUE
UB PB-00RN-03-10 TERMINAL BLOCK 3P(JSE3A-25PC) BLACK 1 J2
UB PB-00RN-04-12 TERMINAL BLOCK 4P(JSE4A-23PC) BLACK 1 CON3
UB PB-12RN-01 CONNECTER 2.54mm 12PIN 90 DEGREE FEET 1 CON1
UB PCB-1020-10HB LED BOARD 106*20*1.0t/mm 94V0 BLUE 1
UB PCB-2915-16HB-03 PCB 297*153*1.6mm Blue FR4 DOUBLE 1
UB PCB-5726-16FR PCB 57*26*1.6/mm BLUE FR-4 1
UB RC-100J01-MLT-01 RESISTORS 10Ω 1W 2 RR34 RR75
UB RC-100JW8-MLT-01 RESISTORS 10R 1/8W 5% 6 R24 R25 R26 R57 R58 R59
UB RC-101JW8-MLT-01 RESISTORS 100Ω1/8W 8 R11 R44 R68 R75 R77 R95 R101 R103
UB RC-102FWA-S1T RESISTORS 1K0805 1% 2 R66 R89
UB RC-102J01-MLT-01 RESISTORS 1K 1W 3 R67 R74 R422
UB RC-102JW4-MLT-01 RESISTORS 1K/1/4W 1 R110
UB RC-102JW8-MLT-01 RESISTORS 1K/1/8W 16
R70 R90 R97 R413 R414 R415 R416 RR3
RR11 RR13 RR40 RR43 RR44 RR52 RR54
RR81
UB RC-103FWA-S1T RESISTORS 10K0805 1% 5 R425 R427 R428 R402 R90
UB RC-103JW8-MLT-01 RESISTORS 10K/1/8W 4 R12 R45 RR5 RR41
UB RC-104FWA-S1T RESISTORS 100K0805 1% 2 R426 R91
UB RC-104JW8-MLT-01 RESISTORS 100K/1/8W 4 R73 R80 R100 R106
UB RC-112JW8-MLT-01 RESISTORS 1K1 1/8W 5% 2 R17 R50
UB RC-122JW8-MLT-01 RESISTORS 1K21/8W 8 R79 R105 R69 R76 R81 R96 R102 R107
UB RC-124JW8-MLT-01 RESISTORS 120K 1/8W 5% 2 RR37 RR78
UB RC-152JW8-MLT-01 RESISTORS 1K51/8W 5% 4 R72 R78 R99 R104
UB RC-153FWA-S1T RESISTORS 15K08051% 1 R67
UB RC-155FWA-S1T RESISTORS 1M5 0805 1% 1 R439
UB RC-182JW4-MLT-01 RESISTORS 1.8K 1/4W 2 RR19 RR60
UB RC-183JW8-MLT-01 RESISTORS 18K1/8W 2 R18 R51
UB RC-205FWA-S1T RESISTORS 2M 0805 1% 1 R407
UB RC-220J01-MLT RESISTORS 22R 1W 1 RR86
UB RC-221JW4-MLT-01 RESISTORS 220R/1/4W 5% 2 RR26 RR67
UB RC-222JW8-MLT-01 RESISTORS 2.2K/1/8W 2 RR16 RR57
UB RC-223JW8-MLT-01 RESISTORS 22K 1/8W 19
R2 R20 R22 R23 R30 R35 R53 R55 R56 R63
R325 R326 RR15 RR33 RR56 RR74 RR77
RR89 R91
UB RC-244JW8-MLT RESISTORS 240K1/8W5% 1 RR42
UB RC-271JW4-MLT-01 RESISTORS 270Ω 1/4W 5% 2 RR1 RR97
UB RC-272JW8-MLT-01 RESISTORS 2.7K/1/8W 4 R93 R94 R108 R109
UB RC-273JW8-MLT-01 RESISTORS 27K1/85% 2 R111 R112
UB RC-302FWA-S1T RESISTORS 3K 0805 1% 1 R401
UB RC-302JW8-MLT-01 RESISTORS 3K/1/8W 2 R71 R98
UB RC-330JW8-MLT-01 RESISTORS 33Ω/1/8W 8RR7 RR8 RR9 RR10 RR48 RR49 RR50
RR51
UB RC-331JW8-MLT-01 RESISTORS 330Ω1/8W 5% 4 RR4 RR39 RR45 RR80
UB RC-332FWA-S1T RESISTORS 3K3 0805 1% 3 R437 R438 R39
UB RC-334JW8-MLT-01 RESISTORS 330K 1/8W 5% 2 R19 R52
UB RC-362JW4-MLT RESISTORS 3.6K1/4W5% 2 RR18 RR59
UB RC-362JW8-MLT-01 RESISTORS 3K61/8W 4 R21 R54 R83 R84
UB RC-392JW4-MLT-01 RESISTORS 3K9 1/4W 2 R430 R431
UB RC-3R0JW8-MLT-01 RESISTORS 3Ω 1/8W 8RR22 RR23 RR29 RR30 RR63 RR70 RR82
RR85
UB RC-432JW8-MLT-01 RESISTORS 4.3K1/8W 2 RR17 RR58
UB RC-470J01-MLT RESISTORS 472W 2 R429 R432
UB RC-470JW4-MLT-01 RESISTORS 47Ω/1/4W 4 RR20 RR31 RR61 RR72
UB RC-470JW8-MLT-01 RESISTORS 47Ω/1/8W 10 R6 R39 R417 R418 R419 R420 RR12 RR14
RR53 RR55
UB RC-471J02-MLT RESISTORS 470Ω/1W 2 R3 R36
PART NO.

- 6 - DPX2250
DESCRIPTION SPEC QTY LOCATION REF.
UB RC-472FWA-S1T RESISTORS 4K708051% 3 R406 R424 R423
UB RC-472JW8-MLT-01 RESISTORS 4.7K/1/8W 7 R33 R85 R88 R92 RR38 RR79 R115
UB RC-473FWA-S1T RESISTORS 47K08051% 1 R68
UB RC-473JW8-MLT-01 RESISTORS 47K1/85% 1 R114
UB RC-562JW8-MLT-01 RESISTORS 5K6 1/8W 5 RR6 R29 R62 R61 R28
UB RC-563JW8-MLT-01 RESISTORS 56K/1/8W 4 RR21 RR32 RR62 RR73
UB RC-682JW8-MLT-01 RESISTORS 6.8K/1/8W 4 R82 R86 R27 R60
UB RC-822JW8-MLT-01 RESISTORS 8K21/8W 1 R87
UB RN1000JW8-MLT-03 RESISTORS 100R 1/8W 1% 2 R16 R49
UB RN1001JW8-MLT-03 RESISTORS 1K 1/8W 1% 4 R14 R47 R66 R89
UB RN1002JW8-MLT-03 RESISTORS 1K2 1/8W 1% 3 R31 R64 R113
UB RN1502JW8-MLT-01 RESISTORS 15K 1/8W 1% 4 R9 R10 R42 R43
UB RN2002JW8-MLT-02 RESISTORS 20K 1/8W 1% 2 R32 R65
UB RN2400JW8-MLT RESISTORS 240K 1/8W 1% 2 R13 R46
UB RN2702JW8-MLT-01 RESISTORS 27K 1/8W 1% 4 R7 R8 R40 R41
UB RN4701JW8-MLT-01 RESISTORS 4.7K 1/8W 4 R4 R5 R37 R38
UB RN7500JW8-MLT-01 RESISTORS 750R 1/8W 1% 2 R15 R48
UB RSG-0801-WT SILICON TUBE Φ1.0*8mm 4 QR7 QR25
UB RSG-1001-WT SILICON TUBE Φ1.0*10mm WHITE 36 MOSFET FRR
UB RSG-1525-BR SILICON TUBE Φ1.5*25mm UL 2 RT1
UB RSG-2006-WG SILICON TUBE Φ2.0*6MM 16 TRANSISTOR
UB RW-R15J03-QPP-01 CEMENT RESISTORS 0.15ohm 3W 8 RR24 RR25 RR27 RR28 RR65 RR68 RR83
RR84
UB ST1-00B647H-01 TRIODO B647 TO-92 7 Q2 Q5 Q9 Q12 Q414 QR6 QR24
UB ST1-00D667T-01 TRIODO D667 TO-92M 3 QR8 Q415 QR26
UB ST1-050N 06H-01 MOS 50N06 TO-220AB 10 Q1 Q4 Q6 Q7 Q8 Q11 Q406 Q407 Q408 Q409
UB ST1-0B649AH-01 TRIODO B649ATO-126M 2 QR9 QR27
UB ST1-0D669A-01 TRIODO D669ATO-126M 4 QR7 QR12 QR25 QR30
UB ST1-2N5401H TRIODO 2N5401 TO-92 8 Q404 Q405 QR1 QR2 QR5 QR19 QR21 QR23
UB ST1-2N5401H-01 TRIODO SMD 2N5401 TO-23"F" 2 Q410 Q416
UB ST1-2N5551H-01 TRIODO 2N5551TO-92 15 Q3 Q10 Q13 QR3 QR4 QR15 QR16 QR17
QR18 QR20 QR22 QR33 QR34 Q14 Q15
UB ST1-2N5551H-03 TRIODO SMD 2N5551TO-23"F" 1 Q412
UB ST1-TIP35CH TRANSISTOR TIP35CTO-218 4 QR13 QR14 QR31 QR38
UB ST1-TIP36CH TRANSISTOR TIP36CTO-218 4 QR10 QR11 QR28 QR37
UB SW -DPX2250 LED PLATE 1
UB SW -PL23X-009 SWITCH 2P3T L=9mm 3 SW1 SW4 SW 5
UB TMS-PID103-002 THER MISTOR -10K 10% 1 RT1
UB VR-R1C503-04-01 VR C50K 41 L=15mm2.5dB 1 VR4
UB VR-R2A203 VR 20K 2 L=15mm 2.5dB 1 VR1
UB VR-R2B203-019 VR B20K*2 L=15mm 1 VR2
PART NO.

- 7 -
■BLOCK DIAGRAM
DPX2250
Rectifying
Circuit
Rectifying
Circuit
High/Low Voltage
Conversion (L)
High/Low Voltage
Conversion (R)
In phase
Out of phase
LOW/HIGH PASS
LOW/HIGH PASS
FILTER OFF
HPF
LPF
OFF
HPF
LPF
LPF HPF
FREQUENCY
CONTROL
FREQUENCY
CONTROL
FREQUENCY
CONTROL
FREQUENCY
CONTROL
BASSBOOST
GAIN
VOL
L
R
RCA IN
+ - + -
L
R
HILGIN

- 8 -
■CIRCUIT DIAGRAM
DPX2250

- 9 - DPX2250

- 10 - DPX2250

- 11 - DPX2250

- 12 - DPX2250

■PRINTED WIRING BOARD:
- 13 - DPX2250

- 14 - DPX2250
1. RCA input jacks 8.
2. Input Voltage Selector 9.
Output mode switch
3. P recise Frequency Selector 10.
Crossover function switch
4.
Bass Boost Control 11.
5. Speaker Level Inputs 12.
6. Gain control 13.
7. 14.
1 26 4 3
910
5
Left
rear speaker output
Remote
turn-on connection
Right
rear speaker output
Ground
connection
Fuses
Battery 12V connection
14
12
7
11 13
8
■CONTROL AND CONNECTION:

- 15 - DPX2250
■LED BOARD:
