Clarion UNGO PRO SECURITY K20 User manual

MMooddeellKK2200
➤
OOwwnneerr’’ssGGuuiiddee

i
© 2006 directed electronics, inc.
lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy
This Ungo Pro Security system is warranted against defects in material and workmanship.
The main unit is covered by this limited lifetime warranty. This Limited Lifetime
Warranty applies to Ungo Pro Security systems that have been installed by an authorized
Ungo Pro Security dealer. This warranty is to the Original Purchaser ("Owner") and to
the original vehicle in which it was installed into. This warranty is not transferable to any
subsequent owner(s) of the product(s).
WWaarrrraannttyyPPrrooggrraamm::
Main Unit Limited Lifetime
Remote Controls One year from date of purchase
Siren One year from date of purchase
Shock Sensor One year from date of purchase
LED One year from date of purchase
Override Switch One year from date of purchase
The Warranty does not cover batteries or products deemed damaged through alterations
or installation. It also does not cover products mishandled, misused, neglected, abused,
water damaged, or with removed/altered serial numbers.
PROOF OF PURCHASE WILL BE REQUIRED FOR WARRANTY SERVICE OF
THIS PRODUCT.
This warranty does not cover the costs incurred for removal or reinstallation of the main
unit and/or any damage to the vehicle or the vehicle's electrical system.
The sole responsibility of Clarion Corporation of America ("Clarion") under this
Warranty shall be limited to the repair or replacement of the product, at the sole discre-
tion of Clarion.
If it becomes necessary to send the product or any defective part to Clarion, the product
must be shipped in its original carton or equivalent carton, fully insured, with shipping
charges prepaid. Clarion will not assume any responsibility for any loss or damage
incurred in shipping.
ALL IMPLIED WARRANTIES EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW SHALL HAVE NO GREATER DURATION THAN THE
WARRANTY PERIOD SET FORTH ABOVE. UNDER NO CIRCUMSTANCES
SHALL CLARION CORPORATION BE LIABLE FOR ANY LOSS OR DAMAGE,
DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE OR INABILITY
TO USE OF THE PRODUCT. BECAUSE SOME STATES DO NOT ALLOW LIMI-

ii © 2006 directed electronics, inc.
TATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR EXCLUSIONS
OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, THE
ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE THE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
Should you have any difficulties with the performance of this product during warranty,
please call: 1-800-GO-CLARION or visit your local Ungo Pro Security dealer. You may
also contact the National Service Manager at the following address below for additional
service help you may need.
Clarion Corporation of America
Attn: National Service Manager
661 W. Redondo Beach Blvd.
Gardena, Ca 90247

1
© 2006 directed electronics, inc.
ttaabblleeooffccoonntteennttss
lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy...................................................................
.............ii
wwhhaattiissiinncclluuddeedd.....................................................................
.......................................22
iimmppoorrttaannttiinnffoorrmmaattiioonn......................................
............................................................22
system maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
your warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
fcc/id notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ttrraannssmmiitttteerrffuunnccttiioonnss...............
.....................................................................................44
standard configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
uussiinnggyyoouurrs
syysstteemm........................................................................................................66
locking/arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
unlocking/disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
disabling the system without a transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
audible mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
valet mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
panic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
rraappiiddrreessuummeellooggiicc....................................................................
....................................99
pprrooggrraammmmiinnggooppttiioonnss...........................................
.....................................................1100
gglloossssaarryyoofftteerrmmss...........................
.............................................................................1111
sseeccuurriittyy&&ccoonnvveenniieen
ncceeeexxppaannssiioonnss............................................................................1122

2© 2006 directed electronics, inc.
wwhhaattiissiinncclluuddeedd
➤The control module
➤A pair of four-button transmitters
➤A status LED indicator light
➤A push-button Valet®switch
iimmppoorrttaannttiinnffoorrmmaattiioonn
Congratulations on the purchase of your keyless entry system.
Due to the complexity of this system, it must be installed by an
authorized dealer only. Installation of this product by anyone
other than an authorized dealer voids the warranty.
By carefully reading this Owner's Guide prior to using your
system, you will maximize the use of this system and its features.
You can print additional or replacement copies of this manual by
accessing the Clarion web site at www.clarion.com.
system maintenance
The system requires no specific maintenance. Your remote is
powered by a small, lightweight 3-volt lithium battery that will
last approximately one year under normal use. When the battery
begins to weaken, operating range will be reduced and the LED
on the remote will dim.
➜

3
© 2006 directed electronics, inc.
your warranty
It is necessary to keep your proof of purchase, which reflects that
the product was installed by an authorized dealer.
fcc/id notice
This device complies with Part 15 of FCC rules. Operation is
subject to the following conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesirable operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate this device.
412 Series
➜
➜

4© 2006 directed electronics, inc.
ttrraannssmmiitttteerrffuunnccttiioonnss
The receiver uses a computer-based learn routine to learn the
transmitter buttons. This makes it possible to assign any specific
transmitter button, or combination of buttons, to any receiver
function. The transmitter initially comes programmed with the
Standard Configuration, but may also be customized by an
authorized dealer. The transmitter buttons indicated in all of the
instructions in this manual correspond to a Standard
Configuration transmitter.
ssttaannddaarrddttrraannssmmiitttteerrccoonnffiigguurraattiioonn
controls the AArrmmfunction.
controls the DDiissaarrmmfunction.
controls AAuuxxiilliiaarryyOOuuttppuuttand an AAuuddiibblleeMMooddee.
controls the PPaanniiccfunction.
and pressed together control an AAuuxxiilliiaarryyOOuuttppuutt.

5
© 2006 directed electronics, inc.
standard configuration
Button
The locking/arming function is controlled by pressing this
button for one second. Pressing a 2nd time (within 5
seconds) after arming will honk the horn (if connected).
Button
The unlocking/disarming function is controlled by pressing this
button for one second. Pressing a 2nd time (within 5
seconds) after disarming will unlock the remaining doors (if
progressive door unlocking is configured).
Button
An optional auxiliary function are controlled by this button. (An
optional auxiliary function, such as trunk release, can be
controlled by pressing this button for 1.5 seconds.)
The auxiliary output controls __________________________.
Button
The panic feature is controlled by pressing this button for one
second.
and Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls_________________________.
➜

6© 2006 directed electronics, inc.
uussiinnggyyoouurrssyysstteemm
locking/arming
Pressing for one second arms the system by activating the
starter kill (optional) and locking the doors (if connected). The
horn will honk (if connected and in audible mode) and the
parking lights will flash once to confirm arming of the system.
While the system is armed, the status LED will flash once per
second. The Failsafe®Starter Kill (if installed) will also prevent
the vehicle’s starter from cranking.
The system can also be programmed to arm the optional
Failsafe®Starter Kill automatically (called Passive Mode). If the
system has been programmed for Passive Mode, the Failsafe®
Starter Kill will automatically activate 30 seconds after the igni-
tion has been turned off. After the ignition has been turned off,
the status LED will flash rapidly to indicate that the system is in
Passive Mode.
If Passive Mode has been programmed on, then it is also possible
to program the system for Passive Locking. With Passive
Locking, the vehicle doors lock automatically at the same time that
the Failsafe®Starter Kill is activated. If Passive Locking is
programmed on, care must be taken to prevent the keys from
being locked in the vehicle.
note: Manually locking the vehicle does not arm the sys-
tem; it will only lock the doors.
➜

7
© 2006 directed electronics, inc.
unlocking/disarming
Pressing for one second disarms the system and unlocks the
doors (if connected). The horn will honk twice (if connected and
in audible mode) and the parking lights will flash twice to confirm
disarming of the system. The optional Failsafe®Starter Kill will be
deactivated. The status LED will turn off, unless the system is pro-
grammed for Passive Mode. In Passive Mode, the status LED will
flash rapidly when the system is disarmed. This indicates that the
system will re-engage the starter kill and re-lock the doors (if
Passive Locking has been programmed) in 30 seconds unless the
ignition is turned on.
disabling the system without a transmitter
If your remote transmitter is lost or damaged, you can manually
override the system. To do this, you must have the vehicle's igni-
tion key and know where the Valet®switch is located. Be sure to
check with the installer for the location of the Valet®switch.
➜
note: If the system has been armed with the remote trans-
mitter, you must use the transmitter or the Valet switch
to disarm the system and deactivate the starter kill.
Manually unlocking the vehicle does not disarm the sys-
tem; it will only unlock the doors.
➜
note: For Passive Mode to be effective, the Failsafe®
Starter Kill relay must be installed.

8© 2006 directed electronics, inc.
To disarm the security system,
turn the ignition to the ON posi-
tion. Press and release the Valet
switch within 10 seconds. The
status LED will stop flashing and
the vehicle should start. If the
vehicle does not start, you may
have waited too long; turn the
ignition off and repeat the process.
Location of Valet Button_________________________________
audible mode
To temporarily turn on the arm or disarm horn honk(s), simply
press for less than one second before arming or disarming,
and the confirmation honk(s) will be present for that one opera-
tion only.
valet mode
You can prevent your system from automatically activating the
Failsafe®Starter Kill (optional, not included) and locking the
doors by using Valet®Mode. This is very useful when washing the
vehicle or having it serviced. In Valet®Mode, the starter kill
cannot be activated, even with the transmitter, but all conve-
nience functions (door locks, trunk release, etc.) will continue to
work normally.
To enter or exit Valet®Mode:
➜
➜
DRW-35

9
© 2006 directed electronics, inc.
1. Turn the ignition on.
2. Turn the ignition off.
3. Press and release the Valet®
switch within 10 seconds.
The status LED will light steadily if you are entering Valet®Mode
and will turn off if you are exiting Valet®Mode.
panic mode
If you are threatened in or near your vehicle, you can attract
attention by triggering the system with your transmitter. Just
press for two seconds to enter Panic Mode. In Panic Mode,
the horn will honk (if connected) and the parking lights will flash
for 30 seconds. To stop Panic Mode at any time, press on the
transmitter again.
rraappiiddrreessuummeellooggiicc
This Pro Security system will store its current state to non-volatile
memory. If power is lost and then reconnected, the system will
recall the stored state from memory. This means if the unit is in
Valet Mode and the battery is disconnected for any reason, such
note: In order for Panic Mode to be effective, the vehicle’s
horn (or optional siren) as well as the vehicle's parking
lights must be connected.
➜
DRW-35

10 © 2006 directed electronics, inc.
as servicing the car, when the battery is reconnected the unit will
still be in Valet Mode. This applies to all states of the system
including arm, disarm, and panic mode.
pprrooggrraammmmiinnggooppttiioonnss
Programming options control your system's normal, operational
set-up. Most options do not require additional parts, but some may
require additional installation labor. This system's programming
options are listed below, with the factory default settings in bboolldd:
➤Ignition switch-controlled door-locking oonnor off. With this
feature on, the doors will lock 3 seconds after the ignition key
is turned on, and unlock when the ignition key is turned off.
➤Comfort Closure ooffffor on. This option is not available for
all vehicles. When programmed on, and pressing on the
remote, the vehicle will lock and close the windows/sunroof.
See your dealer to see if this is available for your vehicle.

11
© 2006 directed electronics, inc.
gglloossssaarryyoofftteerrmmss
Control Unit: The “brain” of your system. Usually hidden under
the dash area of the vehicle. It houses the microprocessor that
monitors your vehicle and controls all system functions.
LED: A light mounted at a discretionary location inside the
vehicle. It is used to indicate the status of your system.
Starter Interrupt: An automatic switch controlled by your system
which prevents the vehicle’s starter from cranking whenever the
system is armed. The vehicle is never prevented from cranking
when the system is disarmed, in Valet Mode, or if the starter
interrupt switch itself fails. Your system has feature-ready
circuitry for the starter interrupt, however installation may
require additional labor.
Transmitter: A hand-held, remote control which operates the
various functions of your system.
Valet Switch: A small button mounted at a discretionary location
inside the vehicle. It is used to override the system when a trans-
mitter is lost or damaged, or to enter or exit Valet Mode.

12 © 2006 directed electronics, inc.
sseeccuurriittyy&&ccoonnvveenniieenncceeeexxppaannssiioonnss
Listed below are some of the many expansion options available
for use with your system. Some options may require additional
parts and/or labor. Please consult with your dealer for a complete
list of options available for use with this system.
Domelight Supervision: The domelight will illuminate for 30
seconds each time the system is disarmed using the remote. This
is useful for seeing inside the vehicle at night prior to entering it.
Power Door Lock Control: Your system is capable of controlling
many types of power door lock systems; however, some door lock
systems may require extra parts. Consult with your dealer to
determine which type of locks your vehicle uses. If power locks
are connected, the system can be programmed to lock the doors
automatically 30 seconds after the ignition has been turned off.
The system can also be programmed to lock the doors when the
ignition is turned on and to unlock them when the ignition is
turned off.
Power Trunk Release: The system’s auxiliary output can be
programmed to operate a factory power release for the vehicle's
trunk or hatch. If the factory release is not power-activated,
Directed®'s 522T trunk-release solenoid can often be added.

13
© 2006 directed electronics, inc.
Power Window Control: Power window control is provided with
Directed®'s 529T or 530T systems. The 529T system will roll up
two windows automatically when the system is armed, or roll two
windows down by using the transmitter. The 530T will roll two
windows both up and down. The 530T also provides one touch
switch operation.
Progressive Door Unlocking: For added security, your system can
be configured to unlock the driver’s door only, leaving the
passenger doors locked. Pressing the unlock button an additional
time will unlock the passenger doors. This option requires addi-
tional parts and labor.

14 © 2006 directed electronics, inc.

15
© 2006 directed electronics, inc.
QQUUIICCKKRREEFFEERREENNCCEEGGUUIIDDEE
To lock/arm using your remote
➤To arm the system press for one second. The doors will lock (if
connected). The LED will begin to flash. The Failsafe® Starter Kill will
prevent the vehicle’s starter from cranking if it has been installed. The vehi-
cle’s horn (if connected) will honk (in audible mode) and the parking lights
will flash once to confirm arming of the system.
To unlock/disarm using your remote
➤To disarm the system press for one second. The doors will unlock (if
connected). The Failsafe®Starter Kill will be deactivated and the vehicle’s
horn (if connected) will honk twice (in audible mode) and the parking lights
will flash twice.
To enter or exit Valet
®
Mode
➤Turn the ignition to the ON position. Turn the ignition back off. Press and
release the Valet®switch within 10 seconds. The status LED will light steadily
if you have entered Valet®Mode. To exit Valet®Mode, repeat the steps above.
The LED will turn off when exiting Valet®Mode.
To activate Panic Mode
➤Press and hold for 2 seconds.
To exit Panic Mode
➤Press on the transmitter.
Location of Valet Switch___________________________________
Cut along dotted line and fold for a quick and easy reference to keep in your purse or wallet.
✂
✂

Get Started
Get Protected
Ungo Pro Security
661 W. Redondo Beach Blvd.
Gardena, Ca. 90247
800-GO-CLARION
© 2005 Directed Electronics, Inc. - All rights reserved GS660 02-05
