Clarion NX501E Repair manual





































NX501E
N Z 501E
Owner’s manual & Installation manual
Mode d’emploi et manuel d’installation
Benutzerhandbuch und Montageanleitung
Manuale dell’utente e manuale di installazione
Gebruikershandleiding en installatiehandleiding
Manual de instrucciones y de instalación
Bruksanvisning och installationsanvisning
Podręcznik użytkownika i podręcznik instalacyjny
Εγχειρίδιο λειτουργίας & Εγχειρίδιο εγκατάστασης
Downloaded from Caradio-Manual.com Manuals

3NX501E/NZ501E
English
English Owner’s Manual
Contents
1. FEATURES ...........................................................................................................5
Expanding Systems ..............................................................................................5
2. PRECAUTIONS....................................................................................................6
3. CAUTIONS ON HANDLING.................................................................................8
Operation Panel ....................................................................................................8
USB Port...............................................................................................................8
Cleaning................................................................................................................8
Handling Discs......................................................................................................9
4. PANEL CONTROLS...........................................................................................10
NX501E Functions of Buttons.............................................................................10
NZ501E Functions of Buttons.............................................................................11
5. REMOTE CONTROL..........................................................................................13
Functions of Remote Control Buttons ................................................................14
6. MAIN MENU OPERATIONS ..............................................................................16
Front Zone Source ..............................................................................................16
Rear Zone Source...............................................................................................16
7. DVD SYSTEM ....................................................................................................17
DVD Video Features............................................................................................17
Discs ...................................................................................................................17
About the registered marks, etc. ........................................................................18
8. DVD VIDEO PLAYER OPERATIONS.................................................................19
Change DVD System Settings............................................................................19
Watching to a disc ..............................................................................................20
Operate the DVD Player menu............................................................................20
Operate the Video files Player menu...................................................................23
9. DVD AUDIO PLAYER OPERATIONS ................................................................24
Showing CD Player mode screen.......................................................................24
Operate the CD Player menu..............................................................................24
Listening To MP3/WMA ......................................................................................25
10. USB AUDIO OPERATIONS .............................................................................28
Notes on using USB memories...........................................................................28
Select USB Audio mode .....................................................................................28
Playing MP3/WMA files in USB memory ............................................................29
11. USB VIDEO OPERATIONS..............................................................................31
Notes on using USB memories...........................................................................31
Select USB Video mode .....................................................................................31
Playing video files in USB memory.....................................................................31
USB Video Menu Operations..............................................................................32
12. iPod/iPhone OPERATIONS.............................................................................33
Notes on using Apple iPod/iPhone.....................................................................33
Controlling the iPod/iPhone................................................................................33
Selecting the iPod Video mode...........................................................................35
13. Bluetooth AUDIO PLAYER OPERATIONS .....................................................37
Selecting the Bluetooth Audio mode..................................................................37
Bluetooth audio player settings ..........................................................................37
Registering your Bluetooth audio player (Pairing)...............................................37
Selecting the Bluetooth audio player..................................................................38
Controlling the Bluetooth audio player ...............................................................38
Downloaded from Caradio-Manual.com Manuals

4 NX501E/NZ501E
English Owner’s Manual
14. Bluetooth TELEPHONE OPERATIONS ............................................................39
Select the BT Phone mode.................................................................................39
Bluetooth Telephone settings .............................................................................39
Register your cellular phone (Pairing) .................................................................40
Select the cellular phone ....................................................................................41
Obtaining the Phone Book data .........................................................................41
Telephone operations..........................................................................................41
15. RADIO OPERATIONS......................................................................................43
16. RDS OPERATIONS .........................................................................................44
17. DVB-T OPERATIONS ......................................................................................47
18. AUX 1 / AUX 2 OPERATIONS .........................................................................48
19. CAMERA OPERATIONS..................................................................................48
20. REAR SOURCE OPERATIONS .......................................................................49
DVD Video in Rear ..............................................................................................49
AUX 1 in Rear......................................................................................................50
AUX 2 in Rear......................................................................................................50
iPod Video in Rear ..............................................................................................50
21. SETTING OPERATIONS ..................................................................................51
General Setup Menu...........................................................................................51
Video Setup Menu ..............................................................................................51
Audio Setup Menu ..............................................................................................51
Navigation Setup Menu ......................................................................................52
Others Setup Menu.............................................................................................52
Set the Anti-Theft code.......................................................................................52
22. MONITOR OFF ................................................................................................53
23. TROUBLESHOOTING .....................................................................................54
GENERAL............................................................................................................54
DVD PLAYER ......................................................................................................54
USB DEVICE.......................................................................................................55
Bluetooth ............................................................................................................55
TV/VTR (When connecting an optional TV tuner, etc.)........................................56
24. ERROR DISPLAY.............................................................................................56
25. SPECIFICATIONS............................................................................................57
INSTALLATION / WIRE CONNECTION GUIDE....................................................59
Downloaded from Caradio-Manual.com Manuals

5NX501E/NZ501E
English
English Owner’s Manual
1. FEATURES
Double Din 6.2” Touch Panel Control
(NX501E)
Motorized 7” Touch Panel Control
(NZ501E)
DVD Video/CD-DA/MP3/WMA
Playback Capability
Built-In Bluetooth
®
OEM Steering Wheel Remote Ready
Compatible with iPod
®
/ iPhone
®
via
USB
Expanding Systems
NOTE:
The items listed outside the frames are the commercial products generally sold.
Expanding visual features
Rear Monitor
iPod
Rear Vision Camera
Expanding audio features
External Power
Amplifier
iPhone
USB
Memory
Bluetooth
Telephone
DVB-T Tuner (DTX501E)
Green
White
Red
Video In
Audio/L
Audio/R
Steering Wheel
Remote Control Terminal
Yellow
RearZone
Monitor
Yellow
Yellow
GPS
Antenna
External
Microphone
Connection
Radio Antenna
Gray
Black
Black
Black
Black
Video Out
4-Channel Amplifier
Subwoofer 1
Subwoofer 2
Line Out
Rear R
Line Out
Rear L
Line Out
Front R
Line Out
Front L
Purple
Gray
Black
White
Red
White
Red
White
Red
CAMERA
VISUAL IN
SWI
VIDEO OUT
DTV
2 ZONE OUT
Black
Red
White
Red
EX MIC
DVB-T Tuner (DTX501E)
iPod/iPhone
CCA-748 (sold separately)
Video Out Rear Vision Camera
SUB WOOFER
AUX IN 2
Expanding DVB-T tuner features
Downloaded from Caradio-Manual.com Manuals

6 NX501E/NZ501E
English Owner’s Manual
2. PRECAUTIONS
• Foryoursafety,thedrivershouldnotwatchanyvideosourcesand/oroperatethecontrolswhiledriving.Please
note that watching and operating any video sources while driving are prohibited by law in some countries. Also,
while driving, keep the volume to a level at which external sounds can be heard.
• Whenusingthenavigationsystem,followtheprecautionslistedbelow.Afterreadingthismanual,besureto
keep it in a handy place (such as the glove box of your car).
• Thisnavigationsystemshouldnotbeusedtoreplaceyourownjudgment.Noitinerarysuggestedbythis
navigationsystemshouldeveroverrideanyhighwayregulations,yourownjudgment,oraknowledgeofsafe
driving practices. Do not follow the navigation system’s suggested itinerary if it would cause you to perform a
dangerous or illegal act, place you in a dangerous situation, or take you into an area you consider unsafe.
• Theadviceprovidedbythenavigationsystemistoberegardedasasuggestiononly.Theremaybetimeswhen
the navigation system displays the vehicle’s location incorrectly, fails to suggest the shortest route, or fails to
directyoutoyourdesireddestination.Insuchinstances,relyonyourowndrivingjudgment,takingintoaccount
the driving conditions at the time.
• Donotusethenavigationsystemtolocateemergencyservices.Thedatabasedoesnotcontainacomplete
listing of emergency services such as police stations, fire halls, hospitals and walk-in clinics. Please show
discretion and ask for directions in such instances.
• Asthedriver,youaloneareresponsibleforyourdrivingsafety.
• Inordertoavoidatrafcaccident,donotoperatethesystemwhiledriving.
• Inordertoavoidatrafcaccident,operatethesystemonlywhenthevehicleisstoppedatasafeplaceandthe
parking brake is on.
• Inordertoavoidatrafcaccidentortrafcoffense,rememberthatactualroadconditionsandtrafcregulations
take precedence over the information contained on the navigation system.
• Thesoftwaremaycontaininaccurateorincompleteinformationduetothepassageoftime,changing
circumstances, and the sources of information used. Please respect current traffic conditions and regulations at
all times while driving.
• Whereactualroadconditionsandhighwayregulationsdifferfromtheinformationcontainedonthenavigation
system, abide by the highway regulations.
• Keeptheamountoftimespentviewingthescreenwhiledrivingtoastrictminimum.
• Thenavigationsystemdoesnotprovide,norrepresentinanywayinformationon:trafcandhighway
regulations; technical aspects of the vehicle including weight, height, width, load and speed limits; road
conditions including grade, percentage of incline and surface conditions; obstacles such as the height and
widthofbridgesandtunnels;andothercurrentdrivingorroadconditions.Alwaysrelyonyourownjudgment
when driving a car, taking into account current driving conditions.
• Donotdisassembleormodifythisunit.Itmaycauseanaccident,re,orelectricshock.
• Donotusethisunitwhenatroubleexists,suchasnoscreencontentappearsornosoundisaudible.Itmay
cause an accident, fire, or electric shock. For that case, consult your authorized dealer or a nearest Clarion
service center.
• Incaseofaproblem,suchasanymaterialhasbeenenteredintheunit,theunitgetswet,orsmokeorstrange
smells come out of the unit, etc., stop using this unit immediately, and consult your authorized dealer or a
nearest Clarion service center.
Using it in that condition may cause an accident, fire, or electric shock.
• Useafusewiththesamespecicationonlywhenreplacingthefuse.
Using a fuse with a different specification may causes a fire.
• Fortheinstallationofthisunitorachangeintheinstallation,askyourauthorizeddealeroranearestClarion
service center for safety. Professional skills and experiences are required to do so.
WARNING
Downloaded from Caradio-Manual.com Manuals

7NX501E/NZ501E
English
English Owner’s Manual
1. When the inside of the car is very cold and the
player is used soon after switching on the heater,
moisture may form on the disc (DVD/CD) or the
optical parts of the player and proper playback may
not be possible. If moisture forms on the disc (DVD/
CD), wipe it off with a soft cloth. If moisture forms
on the optical parts of the player, do not use the
player for about one hour. The condensation will
disappear naturally allowing normal operation.
2. Driving on extremely bumpy roads which cause
severe vibration may cause the sound to skip.
3. This unit uses a precision mechanism. Even in the
event that trouble arises, never open the case,
disassemble the unit, or lubricate the rotating parts.
CAUTIONS:
This appliance contains a laser system and is
classified as a “CLASS 1 LASER PRODUCT”.
To use this model properly, read this owner's
Manual carefully and keep this manual for
your future reference. In case of any trouble
with this player, please contact your nearest
“AUTHORIZED service station”. To prevent
direct exposure to the laser beam, do not try to
open the enclosure.
S=1/1
NZ501E
NX501E
CNE-8121B-CL
1:1
机身大贴纸
技术说明：
1、大小65x75mm,红色外框线为刀模线。
2、材质，80g铜版纸,过哑胶。
3、内容印刷黑色:PANTONE Black C。
4、要求内容印刷正确、清晰，贴纸表面干净、整洁，不得有脏污、斑点、折痕；
切边务必整齐,不得歪斜。
7-8121-1002-00-00
Downloaded from Caradio-Manual.com Manuals

8 NX501E/NZ501E
English Owner’s Manual
3. CAUTIONS ON HANDLING
Operation Panel
For a longer service life, be sure to read the following cautions.
• Theoperationpanelwilloperateproperlyina
temperature range of 0˚ to 60˚ C.
• Donotallowanyliquidsonthesetfromdrinks,
umbrellas etc. Doing so may damage the internal
circuitry.
• Donotdisassembleormodifythesetinanyway.
Doing so may result in damage.
• Subjectingtheoperationpaneltoshocksmayresult
in breakage, deformation or other damage.
• Donotletcigarettesburnthedisplay.
• Ifaproblemshouldoccur,havethesetinspectedat
your store of purchase.
• Donotinsertobjectsorpokeinthespacebetween
the operation panel and the main unit when the
panel is tilted.
• Theremotecontrolunitmaynotworkiftheremote
control sensor is exposed to direct sunlight.
• Inextremelycoldweather,thedisplaymovement
may slow down and the display may darken, but this
is not a malfunction. The display will work normally
when the e temperature increases.
• Smallblackandshinyspotsinsidetheliquidcrystal
panel are normal for LCD products.
USB Port
• TheUSBmemorystickmaystickoutwheninserted,
so it may cause danger during driving. In such
cases, you can use a commercial USB extension
cable, etc., but use it safely under your own
judgment.
• TheUSBmemorysticksmustberecognizedas
“USB mass storage class” to work properly. Some
models may not operate correctly.
When the memorized data is lost or damaged by any
chance, Clarion shall not be liable for any damage.
When using an USB memory stick, we recommend
that you backup your data stored on it before by
using a personal computer etc.
• DatalesmaybebrokenwhenusingUSBmemory
sticksinthefollowingsituation:
When disconnecting the USB memory stick or
turning the power off during writing or reading data.
When affected by static electricity or electric noise.
Connect/disconnect the USB memory stick when it
is not accessed.
• SomeUSBmemorystickscannotbeinsertedtothe
main unit because of their shape. In such cases, use
a commercial USB extension cable to connect them.
• Connectingwiththecomputerisnotcovered.
• Musicles(MP3,WMA,etc.)storedintheUSB
memory stick can be played back.
Cleaning
• Cleaningthecabinet
Use a soft, dry cloth and gently wipe off the dirt. For
tough dirt, apply some neutral detergent diluted in
water to a soft cloth, wipe off the dirt gently, then
wipe again with a dry cloth.
Do not use benzene, thinner, car cleaner, etc., as
these substances may damage the cabinet or cause
the paint to peel. Also, leaving rubber or plastic
products in contact with the cabinet for long periods
of time may cause stains.
• Cleaningtheliquidcrystalpanel
The liquid crystal panel tends to collect dust, so
wipe it off occasionally with a soft cloth. The surface
is easily scratched, so do not rub it with hard
objects.
Downloaded from Caradio-Manual.com Manuals

9NX501E/NZ501E
English
English Owner’s Manual
Handling
• Newdiscsmayhavesomeroughnessaroundthe
edges. If such discs are used, the player may not
work or the sound may skip. Use a ball-point pen or
the like to remove any roughness from the edge of
the disc.
Ball-point pen
Roughness
• Neversticklabelsonthesurfaceofthediscormark
the surface with a pencil or pen.
• Neverplayadiscwithanycellophanetapeorother
glue on it or with peeling off marks. If you try to play
such a disc, you may not be able to get it back out
of the DVD player or it may damage the DVD player.
• Donotusediscsthathavelargescratches,are
misshapen, cracked, etc. Use of such discs may
cause misoperation or damage.
• Toremoveadiscfromitsstoragecase,pressdown
on the center of the case and lift the disc out,
holding it carefully by the edges.
• Donotusecommerciallyavailablediscprotection
sheets or discs equipped with stabilizers, etc. These
may damage the disc or cause breakdown of the
internal mechanism.
Storage
• Donotexposediscstodirectsunlightoranyheat
source.
• Donotexposediscstoexcesshumidityordust.
• Donotexposediscstodirectheatfromheaters.
Cleaning
• Toremovengermarksanddust,useasoftcloth
and wipe in a straight line from the center of the disc
to the circumference.
• Donotuseanysolvents,suchascommercially
available cleaners, anti-static spray, or thinner to
clean discs.
• Afterusingspecialdisccleaner,letthediscdryoff
well before playing it.
On Discs
• Exerciseagoodprecautionwhenloadingadisc.The
operation panel will close automatically when leaving
it open for a while.
• Neverturnoffthepowerandremovetheunitfrom
the car with a disc loaded.
CAUTION
For your safety, the driver should not
insert or eject a disc, opening the
operation panel while driving.
Handling Discs
Downloaded from Caradio-Manual.com Manuals

10 NX501E/NZ501E
English Owner’s Manual
4. PANEL CONTROLS
NX501E Functions of Buttons
Note: Be sure to read this chapter while referring to front
diagram “PANEL CONTROLS”.
[PWR/VOL]Knob
• Pressthiskeytopoweronthesysteminpoweroff
mode.
•Whenthepowerisalreadyon,itmovestothe
Navigation mode. If Navigation mode is displayed, it
moves to the Navigation menu.
• Keeppressingthiskeymorethan2secondtoturn
off the system when system is in power on mode.
• Rotatetheknobtoincreaseordecreasethevolume.
[NAVI/AV] Button
• Pressthisbuttontoenternavigationmode;press
again to return current source.
• Pressandholdthisbuttonfor3secondstodisplay
the brightness setting panel.
[ ]Eject
• Presstoejectdiscfromunit.
[MENU] Button
• Pressthisbuttontodisplaymainmenu,pressagain
to return current source.
• Pressandholdthisbuttonfor3secondstoturnoff
the monitor. Press any place of the screen to turn on
the monitor again.
[RESET] Button
• Pressthisbuttontohardwareresettheunit.
Note: When the [RESET] button is pressed, frequencies
of radio stations, titles, etc. stored in memory are
cleared.
[microSD]
• InsertamicroSDinthis.
Note: The microSD card is only for navigation. Please
don’t remove it, otherwise, the navigation function will
be disabled.
[AUX IN]
AUX 1 Connector.
[Microphone]
• InternalmicrophoneforuseduringBluetoothphone
calls.SensitivitycanbeadjustedfromtheSettings
menu.
[IR] SENSOR
• Receiverfortheremotecontrolunit(operating
range:30degreeinalldirections).
[ ]
[Microphone]
[MENU]
[NAVI/AV]
[PWR/VOL]
[RESET]
[microSD]
[AUX IN]
[IR]
Downloaded from Caradio-Manual.com Manuals

11NX501E/NZ501E
English
English Owner’s Manual
NZ501E Functions of Buttons
Note: Be sure to read this chapter while referring to front
diagram “PANEL CONTROLS”.
[MENU/PWR] button
• Pressthiskeytopoweronthesysteminpoweroff
mode.
• Keeppressingthiskeymorethan2secondtoturn
off the system when system is in power on mode.
• Pressthisbuttontodisplaymainmenu,pressagain
to return current source when system is in power on
mode.
[NAVI/AV] Button
• Pressthisbuttontoenternavigationmode;press
again to return current source.
• Pressandholdthisbuttonfor3secondstodisplay
the brightness setting panel.
•PressthiskeytochangedisplayofsubLCDwhen
panel is closed.
[ ]Eject
• Presstoejectdiscfromunit.
[Microphone]
• InternalmicrophoneforuseduringBluetoothphone
calls.SensitivitycanbeadjustedfromtheSettings
menu.
[RESET] Button
• Pressthisbuttontohardwareresettheunit.
Note: When the [RESET] button is pressed, frequencies
of radio stations, titles, etc. stored in memory are
cleared.
[microSD]
• InsertamicroSDinthis.
Note: The microSD card is only for navigation. Please
don’t remove it, otherwise, the navigation function will
be disabled.
[AUX IN]
AUX 1 Connector.
[OPEN]
[TA/SEND]
[ / ]
[-]
[+]
[IR]
[ ]
[ ]
[ ]
[BND/END PS]
[NAVI/AV]
[Microphone]
[RESET]
[AUX IN]
[MENU/PWR]
[microSD]
Downloaded from Caradio-Manual.com Manuals

12 NX501E/NZ501E
English Owner’s Manual
[ , ] Buttons
• Presstosearchpreviousornextstationorchannel
in Tuner modes.
• PressandholdtoentermanualseekstatusinTuner
mode, then press briefly to seek station by step.
• Presstosearchpreviousornexttrackorchapterin
CD, MP3/WMA, iPod and DVD video modes.
• Pressandholdtofastforwardorfastbackwardby
2x, 4x, 8x or 16x step in CD, MP3/WMA and DVD
video mode.
• Pressandholdtofastforwardorfastbackwardin
iPod music.
[ ] Button
•Presstoplay,pauseaudioorvideo.
•Pressandholdtostopaudioorvideo.
•PressthiskeytomutewheninTunermode.
[+][-] Buttons
• PresstoIncreaseanddecreasevolume.
[OPEN] Button
•Usethisbuttontoopen/closeTFTpanel.
•PressandholdtoenterTFTpanelanglesetting
options.
[BND/END PS] Button
•presstochangebandsbetweenFM1,FM2,FM3,
AM bands.
•Pressandholdtostartpresetscan.Pressagainto
stop.
END Function:
Only be available when a call incoming or in telephone
talking.
•Presstorejectcallwhenacallincoming.
•Presstoendacallwhenintelephonetalking.
[TA/SEND] Button
•Pressthisbuttontoturnon/offtheTA(Trafc
Announcement) standby mode.
SENDFunction:
Only be available when there is a coming call.
•Presstoacceptthecomingcall.
•Presstoswitchtoprivatemodewhenintalking.
[IR] SENSOR
• Receiverfortheremotecontrolunit(operating
range:30degreeinalldirections).
Downloaded from Caradio-Manual.com Manuals

13NX501E/NZ501E
English
English Owner’s Manual
5. REMOTE CONTROL
Replacing the batteries
1. Press the retention tab and pull out the battery tray
and remove the old battery.
2. Insert the new CR2025 battery and slide the battery
tray back in the remote control the same direction
that you removed it.
Please ensure the tray is inserted in the correct
direction.
Note:
Using batteries improperly can cause them to explode.
Take note of the following points:
•Whenreplacingbatteries,replacebothbatterieswith
new ones.
•Donotshort-circuit,disassembleorheatbatteries.
•Donotdisposeofbatteriesintoreorames.
•Disposeofspentbatteriesproperly.
WARNING
Lithium (CR) battery contain
Perchlorate
Dispose of discharged batteries properly.
Signal transmitter
Operatingrange:30°inalldirections
[ / ]
[0-9]
[SRCH]
[BACK]
[ , , , ]
[TITLE]
[ ], [ ]
[ZOOM]
[MUTE]
[AUDIO]
[POWER / SRC]
[VOLUME]
[SET]
[PIC]
[TA]
[RPT]
[ ], [ ]
[SUB.T]
[OPEN]
[ANGLE]
[NAVI / AV]
[MENU]
[BAND]
[ROOT]
[ENT]
Downloaded from Caradio-Manual.com Manuals

14 NX501E/NZ501E
English Owner’s Manual
[ / ] Button
• Pressthisbuttontoplayorpausevideoandaudio
media.
• Pressthisbuttonmorethan1secondtostopvideo
and audio media.
[MUTE] Button
• MuteorUnmutethespeaker.
• Thesymbol on upper right area of the screen
indicates that speaker is muted.
[POWER/SRC] Button
• Pressthisbuttontomovethefocustonextavailable
source item on main menu.
• Pressthisbuttontopoweronwhentheunitis
power off.
• Pressthisbuttonmorethan1secondtopoweroff
when the unit is power on.
Note: While panel is closed position, you cannot select
any souce. (NZ501E Only)
[0 - 9] Buttons
• UseintheKeyPadscreentoselecttheradioor
DVB-T channels.
• Usetoselectthetrackinthetracklistscreen.
• PresstoenterDVDvideochapters/titlesintheKey
Pad screen.
[VOLUME] Buttons
• Increaseanddecreasevolume.
[NAVI/AV] Button
• Pressthisbuttontoswitchbetweencurrentsource
and current position on navigation map.
[SRCH] Button
• Pressthisbuttontoopenchapterortitlesearch
window while playing DVD.
[BAND] Button
• Switchtonextbandalternately.
[SET] Button
• PressthisbuttontoopentheAudiosettingmenuin
any mode.
[BACK] Button
• Pressthisbuttontoquitmainmenuifcurrentscreen
is main menu.
[ ], [ ], [ ], [ ] Buttons
• Pressthisbuttonforcursormovementinmainmenu
or Setting mode.
• Fromthemainmenu,youcanselectyourdesired
source or change your settings.
[MENU] Button
• PressthisbuttontoentertheMAINMENUorreturn
current resource.
[PIC] Button
•Pressandholdthisbuttontochangeyourmonitor
brightness.
[ENT] Button
• PresstoxtheentereddataintheKeyPadscreen
or enter the item the cursor is on.
[TA] Button
• PresstoTAOn/Off.
[TITLE] Button
• PresstogotothetitlemenuontheDVD.
[ROOT] Button
• PresstogototherootmenuontheDVD.
[RPT] Button
• Presstoperformchapterrepeat/titlerepeat/
repeat off while playing DVD mode.
• Presstoperformtrackrepeat/repeatoffwhile
playing CD.
• Presstoperformrepeattrack/repeatfolder/repeat
off while playing MP3/WMA, or video files on disc.
• Presstoperformrepeattrack/repeatfolder/repeat
off while playing MP3/WMA, or video files in USB
memory.
• PressforAFOn/Off.
[ ], [ ] Buttons
• Presstoseekthenextavailablehigherorlower
station in Tuner mode.
• Presstoselectthenexthigherorlowerchapter
number in DVD video mode.
• PresstoselectthenexthigherorlowertrackinDVD
Audio, USB Video, USB Audio mode.
• Pressformovementofbackgroundsourcein
Navigation mode.
Functions of Remote Control Buttons
You can use the remote control unit to control the NX501E and NZ501E.
Note:
• Thewirelessremotecontroloperationmaynotbeoptimalindirectsunlight.
Downloaded from Caradio-Manual.com Manuals

15NX501E/NZ501E
English
English Owner’s Manual
Functions of Remote Control Buttons
[ ], [ ] Buttons
• Presstomanuallyselectthenexthigherorlower
station in Tuner modes.
• Presstoperformfast-forwardorfast-backward
searching. Press again to change the speed to 2x,
4x, 8x or 16x.
• Pressformovementofbackgroundsourcein
Navigation mode.
[ZOOM] Button
• PresstoturnonandzoominwhileplayingDVD.You
can zoom in up to 3x. (No all DVD disc supports this
function).
[AUDIO] Button
• PresstoswitchtheAUDIOchannelofthediscwhile
playing DVD.
[SUB-T] Button
• Presstoswitchnextavailablesubtitlewhileplaying
DVD.
• PresstodisplayVideomenuiniPodmode.
[ANGLE] Button
• PresstoswitchthedifferentANGLEwhileplaying
DVD. (No all DVD disc supports this function)
• PresstodisplayAudiomenuiniPodmode.
[OPEN] Button
• PressthisbuttontoOPENorCLOSEthemotorized
screen. Please ensure there are no obstructions
before starting the operation. (NZ501E only)
Downloaded from Caradio-Manual.com Manuals

16 NX501E/NZ501E
English Owner’s Manual
Front Zone Source
[Tuner]-Press the button to display the Tuner mode.
[Disc Audio]-Press the button to display the Disc
Audio mode.
[Bluetooth Audio]-Press the button to display the
Bluetooth Audio mode.
[USB Audio]-Press the button to display the USB
Audio mode.
[AUX 1]- Press the button to display the AUX 1 mode.
[iPod Audio]-Press the button to display the iPod
Audio mode.
[DVB-T]-Press the button to display the DVB-T mode.
[Disc Video]-Press the button to display the Disc
Video mode.
[Camera]-Press the button to display the Camera
mode.
[USB Video]-Press the button to display the USB
Video mode.
[AUX 2]-Press the button to display the AUX 2 mode.
[iPod Video]-Press the button to display the iPod
Video mode.
[Navigation]-Press the button to display the
Navigation mode.
[Telephone]-Press the button to display the Telephone
mode.
[Rear Button]-Press the button to display the rear
menu.
[Setting Button]-Press the button to display the
setting menu.
Rear Zone Source
[Rear Disc Video]-Press the button to display the
Rear Disc Video mode.
[Rear AUX 1]-Press the button to display the Rear
AUX 1 mode
[Rear iPod Video]-Press the button to display the
Rear iPod Video mode.
[Rear AUX 2]-Press the button to display the rear AUX
2 mode.
[2-Zone Off]-Press the button to closed the rear
activity.
[Front Button]-Press the button to display the front
main menu.
[Setting Button]-Press the button to display the
setting menu.
6. MAIN MENU OPERATIONS
Scrolling the menu
Press screen and scrolling to right or left it will
switch to next or previous page of mainmenu.
Moving the menu position
1. Press any quadrate icon on mainmenu more than
2seconds,theiconwilloatonmainmenu.
2.Scrollingtheoatingicontoanypositionyouwant.
Downloaded from Caradio-Manual.com Manuals

17NX501E/NZ501E
English
English Owner’s Manual
DVD Video Features
This unit provides the following functions in addition to
the high image quality and sound quality of DVD video.
Note:
•Thefunctionsdescribedinthissection,forexample,
the recorded language,subtitles, angles, etc. differ
depending on the DVD video disc.
Refer to the instructions provided with the DVD video.
•Somediscfunctionsmayoperatedifferentlyfrom
described in this manual.
Multi-sound function
DVD video can store up to 8 languages for one film;
select the language of your preference.
• Thelanguagesstoredonthediscareindicatedby
the icon shown below.
Multi-angle function
A DVD video that is filmed from multiple angles allows
you to select the angle of choice.
• Thenumberofrecordedanglesareindicatedbythe
icon shown below.
Subpicture (subtitles) function
A DVD video can record subtitles for up to 32
languages and you can select the language of the
subtitles you wish to see.
• Thenumberofrecordedsubtitlelanguagesare
indicated by the icon shown below.
Multi-story function
When a DVD video contains more than one story for
alm,youcanselectthestoryyouwishtoenjoy.
The operation procedures vary with the disc; observe
the instructions for selecting a story provided during
playback.
Menu screens
Menu can be called up during DVD video playback to
perform menu setting.
• Exampleshowingmenudisplay
Discs
Playable discs
This DVD video player can play the following discs.
Playable discs
CD TEXTDVD video discs Audio CDs
Playable media files
MP3/WMA
About CD Extra discs
A CD Extra disc is a disc in which a total of two
sessions have been recorded. The first session is
Audio session and the second session is Data session.
Your personally-created CDs with more than second
data sessions recorded cannot be played on this DVD
video player.
Note:
•WhenyouplayaCDExtradisc,onlytherstsession
will be recognized.
About playing a CD-R/CD-RW disc (MP3, WMA)
This player can play CD-R/CD-RW discs previously
recorded in music CD format (MP3, WMA).
7. DVD SYSTEM
DVD video is a high-quality digital video source that provides crisp and clear images. One 12 cm disc contains
either one film or four hours of music.
Downloaded from Caradio-Manual.com Manuals

18 NX501E/NZ501E
English Owner’s Manual
About playing a DVD-R/RW or DVD+R/RW disc
This player cannot play DVD-R/RW and DVD+R/ RW
discs previously recorded in video CD format.
However, MP3/WMA files recorded on DVD-R/ RW and
DVD+R/RW discs can be played.
Discs that cannot be played back
This DVD video player cannot play back DVD-Audio,
DVD-RAM, Photo CDs, etc.
Note:
•ItmayalsonotbepossibletoplaybackCDsrecorded
onaCD-RunitandCD-RWunit.(Cause:disc
characteristics, cracks, dust/dirt, dust/dirt on player’s
lens, etc.)
•IfaCD-RorCD-RWdiscthathasnotbeennalizedis
played, it will take a long time to start playing. Also, it
may not be possible to play depending on its recording
conditions.
•YoucannotplaySuperAudioCDsPlaybackoftheCD
player is not supported even if it is a hybrid disc.
About MP3/WMA playback
This unit can play back CD-R/CD-RW, DVD-R/ RW
and DVD+R/RW discs on which MP3/WMA music data
have been recorded.
For a detailed information, see the section entitled
“Listening to MP3/WMA”.
Note on region numbers
The DVD video system assigns a region number to
DVD video players and DVD discs by sales area.
DVD video players sold in the Europe can play back
DVD discs with the region number “ALL”, “2” or any
combination of numbers that also incorporate a “2”.
The DVD video region number is marked on the disc
jacketasshownbelow.
ALL
4
6
2
2
• Thisproductincorporatescopyrightprotection
technology that is protected by U.S. patents
and other intellectual property rights. Use of
this copyright protection technology must be
authorized by Rovi Corporation, and is intended for
home and other limited viewing uses only unless
otherwise authorized by Rovi Corporation. Reverse
engineering or disassembly is prohibited.
• ManufacturedunderlicensefromDolby
Laboratories.“Dolby”, “Pro Logic” and the double-D
symbol are trademarks of Dolby Laboratories.
• “MadeforiPod,”and“MadeforiPhone”mean
that an electronic accessory has been designed to
connect specifically to iPod, or iPhone, respectively,
and has been certified by the developer to meet
Apple performance standards.
Apple is not responsible for the operation of this
device or its compliance with safety and regulatory
standards. Please note that the use of this
accessory with iPod or iPhone may affect wireless
performance. iPhone and iPod are trademarks
of Apple Inc., registered in the U.S. and other
countries.
• TheBluetooth
®
word mark and logos are owned
by the Bluetooth
®
SIG, Inc. and any use of such
marks by Clarion Co., Ltd. is under license. Other
trademarks and trade names are those of their
respective owners.
About the registered marks, etc.
Downloaded from Caradio-Manual.com Manuals

19NX501E/NZ501E
English
English Owner’s Manual
Change DVD System Settings
Note:Ifthesetupoperationisperformedinthe
middle of DVD video play, the disc will restart from the
beginning.
Selecting DVD Set Up Menu
1. Press the [Setting] button on the Main Menu to
access the Video set up menu.
2. Press [Video] button. The video menu is displayed.
Setting up the Screen Size
Press the [DVD Wide Screen Mode] button to turn on
or turn off the DVD wide screen mode.
The factory default setting is “On”.
Note: Not all DVD disc supports this function.
DVDWideScreenModeOn
DVDWideScreenModeOff
Setting up the password for parental level
control
The factory default pass code is “0000”.
1. In Main Menu press [Setting] button. Press
[Others] button on the display. Touch the [Set
Password] ---- and a numerical key pad will appear.
Input the old password,and touch the [OK] key,or
input “4356” to reset password.
Input a new password,and touch the [OK] key.
Input the same new password again, and touch the
[OK] key.
Note: When a disc with view restrictions is inserted, you
will be prompted to input this password. The disc will not
be viewable until the correct password is entered.
Set rating for parental level control
1. Select Others screen while in Setting mode. Press
[Parental Control] button. Press the desired rating
for level control. Use this table to set the parental
level.
KidSafe KidSafe
G General Audiences
PG Parental Guidance Suggested
PG-13 Parents Strongly Cautioned
PG-R Parental Guidance Restricted
R Restricted
NC-17 No One 17 And Under Admitted
Adult Only Adult
• Thecontentsthattheparentallevelrestrictsvary
with the country code.
Note: The rating can be selected only under the
password unlocked status, and the limits can be set only
under the password locked status.
8. DVD VIDEO PLAYER OPERATIONS
Downloaded from Caradio-Manual.com Manuals

20 NX501E/NZ501E
English Owner’s Manual
Watching to a disc
1.Toloadadisc:
Insert the disc into the center of the insertion slot the
label side facing up.
CAUTION
For your safety, the driver should not
insert or eject a disc, opening the
operation panel while driving.
Note:
•Neverinsertforeignobjectsintothediscinsertionslot.
•Ifthediscisnotinsertedeasily,theremaybeanother
disc in the mechanism or the unit may require service.
•8cm(singleplay)discscannotbeused.
2. Disc starts playing automatically.
WARNING
Some videos may be recorded at higher
than desired volume levels. Increase the
volume gradually from the minimal setting
after the video has started.
Ejecting a disc
1.Toejectadiscpresseject[ ] button. The play
mode then switches to the Tuner mode.
 Ifthediscisleftintheejectedpositionfor15
seconds, the disc is automatically reloaded. In this
case, the play mode will remain in the Tuner mode.
Note:Ifyouforceadiscintobeforeautoreloading,it
may damage a disc.
Showing DVD Player mode screen
After disc is loaded, the play mode is automatically
engaged.
Touch any place of the screen to display DVD Video
menu touch the screen again to return the playback
screen. The display will return to the playback screen,
if you do not touch the screen for 10 seconds.
1 2 3 4 5 6 7 8
9
1011
12 13 14 15 16 17
1 - Next page Buttons
2 - Previous Track /Fast Backward Button
3 - Play/Pause Button
4 - Next Track/Fast Forward Button
5 - Elapsed playing time
6 - Seek bar
7 - Total time
8 - Top Menu Button
9 - System time
10 - Bluetooth status
11 - DVD playback info
12 - Previous page Button
13 - Repeat switching Button
14 - Audio Channel switching Button
15 - Subtitle switching Button
16 - INFO Button
17 - Direct chapter or title searching Button
Operate the DVD Player menu
You can select the button items displayed in the DVD
menu by directly touching it.
Play/Pause Playback
1. Touch [ ] button to pause during playback.
2. Touch [ ] button again to resume playback.
Skip (Search) a Chapter
1. Press [ ] or [ ] button during playback.
Chapters are skipped down or up from current
locations, as many times as the button is pressed, and
playback starts.
Skip use seek bar
Press the triangle [ ] on seek bar and drag it to any
position where you want to start playback.
Downloaded from Caradio-Manual.com Manuals

21NX501E/NZ501E
English
English Owner’s Manual
Fast Forward/Fast Backward
1. Press [ ] or [ ] button and hold 2 seconds to
start fast backward or fast forward during playback.
The playback speed starts at 2x, then will increase
to 4x, 8x, and 16x. Release the button will continue
playing with normal speed.
2. [ ] or [ ] button on remote control can also be
used to start fast backward or fast forward during
playback.
Note:
•Noaudioisreproducedduringfastforwardandfast
backward operation.
•Thefastforwardandfastbackwardspeedmaydiffer
depending on the disc.
Stop Playback
1. Press the [ ] button on remote control more than
1 second. Playback is stopped.
2. To resume playback, press the [ ] button.
Playback resumes from start of the disc.
Search with a Chapter/Title Number
You can locate the beginning of a scene using the
chapter numbers or title numbers recorded on the
DVD Video disc.
1. Showing the DVD Video menu, touch [ ] button.
TheKeyPadscreenappearswiththechapter/Title
number input mode.
Touching [ ]buttonturnstheKeyPadtothe
chapter number input mode.
Touching [ ]buttonturnstheKeyPadtothetitle
number input mode.
•Title
A large segment to divide the data area of the disc.
•Chapter
A small segment to divide the data area of the disc.
2. Input the number of the title/chapter that you want
to play with the [0] to [9] key.
3. Touch the [ ] button.
Playback starts from the scene of the input title
number or chapter number.
Note:
Iftheinputtitle/chapternumberdoesnotexistor
searching with a title/chapter number is not allowed, the
screen image will not change.
4. Touch [ ] button to close the key pad.
Repeat Playback
This operation plays back chapters recorded on the
DVD-Video repeatedly.
1. Showing the DVD Video menu, touch [ ] button.
2. Touch [ ] button once for Chapter Repeat, again
for Title Repeat.
3. Press [ ] button again to turn off the repeat
playback.
Using the Title Menu
On DVD discs containing two or more titles, you can
select from the title menu for playback.
1. Showing the DVD Video menu, touch [ ]
button during playback.
The title menu screen appears.
* Depending on the disc, the title menu may not be
called.
2. Touch the title menu screen.
3. Select the items in the title menu screen by
directional buttons.
* Depending on the disc, items may not be selected
with the directional buttons.
4. Touch [ ] button to fix on the selected item.
5. Touch [ ] button.
Downloaded from Caradio-Manual.com Manuals
