Clarion NP401 Repair manual
NP401
Owner’s manual & Installation manual
Mode d’emploi et manuel d’installation
Manual de instrucciones y de instalación
FLASH MEMORY NAVIGATION SYSTEM
SISTEMA DE NAVEGACIÓN MEMORIA FLASH
SYSTÈME DE NAVIGATION À MÉMOIRE FLASH
®
NP401 OM_100920_EN.indd 1 2011-1-6 16:10:50
English
Owner’s
Manual
2 NP401
Thank you for choosing the Clarion NP401 as your in-car navigator. This document is the detailed
description of the software.
You can easily discover Clarion Mobile Map while you are using it; however, we still recommend that you
read this manual to understand the screens and the features of Clarion Mobile Map.
Copyright note
The product and the information contained herein is subject to change without prior notification.
This manual may not, in whole or in part, be reproduced or transmitted in any form either electronically or
mechanically, including photocopying and recording, without the express written consent of Clarion.
© 2010– Clarion.
Data Source © 2006 Tele Atlas N.V.
All rights reserved.
CLARION PRODUCT REGISTRATION INFORMATION
For USA and Canada only
www.clarion.com
Dear Customer:
Congratulations on your purchase of a Clarion mobile electronic product. We are confident that
you’ll enjoy your Clarion experience.
There are many benefits to registering your product. We invite you to visit our website at
www.clarion.com to register your Clarion product. We have made product registration simple
with our easy to use website.
The registration form is short and easy to complete. Once you’re registered, we can keep you
informed of important product information.
Register at www.clarion.com - it’s easy to keep your Clarion product up to date.
NP401 OM_100920_EN.indd 2 2011-1-6 16:10:50
English
Owner’s
Manual
NP401 3
1. PRECAUTIONS
•Foryoursafety,thedrivershouldnotwatchanyvideosourcesand/oroperatethecontrolswhiledriving.Pleasenotethatwatchingand
operating any video sources while driving are prohibited by law in some countries. Also, while driving, keep the volume to a level at which
external sounds can be heard.
•Whenusingthenavigationsystem,followtheprecautionslistedbelow.Afterreadingthismanual,besuretokeepitina
handy place (such as the glove box of your car).
•Thisnavigationsystemshouldnotbeusedtoreplaceyourownjudgment.Noitinerarysuggestedbythisnavigationsystem
should ever override any highway regulations, your own judgment, or a knowledge of safe driving practices. Do not follow
the navigation system’s suggested itinerary if it would cause you to perform a dangerous or illegal act, place you in a
dangerous situation, or take you into an area you consider unsafe.
•Theadviceprovidedbythenavigationsystemistoberegardedasasuggestiononly.Theremaybetimeswhenthenavigation
system displays the vehicle’s location incorrectly, fails to suggest the shortest route, or fails to direct you to your desired
destination. In such instances, rely on your own driving judgment, taking into account the driving conditions at the time.
•Donotusethenavigationsystemtolocateemergencyservices.Thedatabasedoesnotcontainacompletelistingof
emergency services such as police stations, fire halls, hospitals and walk-in clinics. Please show discretion and ask for
directions in such instances.
•Asthedriver,youaloneareresponsibleforyourdrivingsafety.
•Inordertoavoidatrafcaccident,donotoperatethesystemwhiledriving.
•Inordertoavoidatrafcaccident,operatethesystemonlywhenthevehicleisstoppedatasafeplaceandtheparking
brake is on.
•Inordertoavoidatrafcaccidentortrafcoffense,rememberthatactualroadconditionsandtrafcregulationstake
precedence over the information contained on the navigation system.
•Thesoftwaremaycontaininaccurateorincompleteinformationduetothepassageoftime,changingcircumstances,and
the sources of information used. Please respect current traffic conditions and regulations at all times while driving.
•Whereactualroadconditionsandhighwayregulationsdifferfromtheinformationcontainedonthenavigationsystem,
abide by the highway regulations.
•Keeptheamountoftimespentviewingthescreenwhiledrivingtoastrictminimum.
•Thenavigationsystemdoesnotprovide,norrepresentinanywayinformationon:trafcandhighwayregulations;technical
aspects of the vehicle including weight, height, width, load and speed limits; road conditions including grade, percentage of
incline and surface conditions; obstacles such as the height and width of bridges and tunnels; and other current driving or
road conditions. Always rely on your own judgment when driving a car, taking into account current driving conditions.
•Donotdisassembleormodifythisunit.Itmaycauseanaccident,re,orelectricshock.
•Donotusethisunitwhenatroubleexists,suchasnoscreencontentappearsornosoundisaudible.Itmaycausean
accident, fire, or electric shock. For that case, consult your authorized dealer or a nearest Clarion service center.
•Incaseofaproblem,suchasforeignmaterialshaveenteredintheunit,theunitgetswet,orsmokeorstrangesmellscome
out of the unit, etc., stop using this unit immediately, and consult your authorized dealer or a nearest Clarion service center.
Using it in that condition may cause an accident, fire, or electric shock.
•Useafusewiththesamespecicationonlywhenreplacingthefuse.
Using a fuse with a different specification may causes a fire.
•Fortheinstallationofthisunitorachangeintheinstallation,askyourauthorizeddealeroranearestClarionservicecenter
for safety. Professional skills and experiences are required to do so.
WARNING
NP401 OM_100920_EN.indd 3 2011-1-6 16:10:50
English
Owner’s
Manual
4 NP401
1. Even in the event that trouble arises, never open the case,
disassemble the unit, or lubricate the rotating parts.
2. This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to consult the dealer
oranexperiencedradio/TVtechnicianforhelp.
INFORMATION FOR USERS:
CHANGES OR MODIFICATIONS TO THIS
PRODUCT NOT APPROVED BY THE
MANUFACTURER WILL VOID THE WARRANTY
AND WILL VIOLATE FCC APPROVAL
2. CAUTIONS ON HANDLING
Navigation System
• Topreventdischargeofthecarbattery,usethissystem
with the engine of the vehicle running as much as
possible.
• Thehousingofthisunitmaybecomehotbecausethisunit
has a high-speed CPU. Be careful to handle the unit during
navigating or immediately after turning the power off.
• Turnoffthepowerofthevehiclewhenconnectingor
disconnecting wires. Doing this while the power of the
vehicle is turned on, may cause a trouble or malfunction.
Note:
•
When using this unit first time after purchasing, or not
used for long periods of time, it might take about 5
to 15 minutes until the current location is determined
using GPS. Moreover, even when using it often, it may
take about 2 to 3 minutes until the current location is
determined according to the GPS measuring situation.
•
When the route (path) cannot be calculated, move
desired destination to a nearby main road and perform
calculation again. It may be impossible to find a route
in case the car location is too close to the desired
destination.
•
For vehicles equipped with an intelligent key, do
not bring the intelligent key close to the unit of the
navigation system. The navigation system may not
operate correctly.
•
If an electrical equipment that generates a strong
electrical noise is used near this unit, the screen may
be disturbed and noise may be generated. In this case,
keep away such an electrical equipment or refrain from
using it.
NP401 OM_100920_EN.indd 4 2011-1-6 16:10:51
English
Owner’s
Manual
NP401 5
Cleaning
• Cleaningthecabinet
Use a soft, dry cloth and gently wipe off the dirt. For
tough dirt, apply some neutral detergent diluted in water
to a soft cloth, wipe off the dirt gently, then wipe again
with a dry cloth. Do not use benzene, thinner, car cleaner,
etc., as these substances may damage the cabinet or
cause the paint to peel. Also, leaving rubber or plastic
products in contact with the cabinet for long periods of
time may cause stains.
• Datasavedtotheashmemorymayget lost in case of a
breakdown, malfunction, or other trouble of this unit.
• Operationofthenavigationsystemmaybelimitedto
protect the unit if the temperature is extremely high or low.
In such a case, please wait until temperature becomes
normal again.
NP401 OM_100920_EN.indd 5 2011-1-6 16:10:51
English
Owner’s
Manual
6 NP401
CONTENTS
1. PRECAUTIONS .............................................................................................................................3
2. CAUTIONS ON HANDLING ..........................................................................................................4
3. Warnings and Safety information..................................................................................................8
4. Getting started with Clarion Mobile Map......................................................................................9
4.1 Simple and Advanced modes...............................................................................................11
4.2 Buttons and other controls on the screen ............................................................................12
4.2.1 Using keyboards ..........................................................................................................13
4.3 Using the map.......................................................................................................................13
4.3.1 Checking the details of a map location .......................................................................14
4.3.2 Manipulating the map ..................................................................................................14
4.3.3 Lane information and Signposts..................................................................................17
4.3.4 Status information and hidden controls on the map ...................................................18
4.3.5 Using the Cursor (the selected map location)..............................................................21
4.4 Clarion Mobile Map concepts...............................................................................................22
4.4.1 Smart Zoom .................................................................................................................22
4.4.2 Position markers ..........................................................................................................23
4.4.3 Daytime and night color profiles ..................................................................................24
4.4.4 Color scheme in tunnels ..............................................................................................24
4.4.5 Route calculation and recalculation.............................................................................24
4.4.6 Itinerary.........................................................................................................................24
4.4.7 Track Logs....................................................................................................................25
4.4.8 Route demonstration ...................................................................................................25
4.4.9 POI (Points of Interest) .................................................................................................25
4.4.10 Road Safety Cameras................................................................................................26
4.4.11 Speed limit warning ...................................................................................................28
5. Navigating with Clarion Mobile Map...........................................................................................29
5.1 Selecting the destination of a route ......................................................................................29
5.1.1 Selecting the Cursor as the destination.......................................................................29
5.1.2 Entering an address or part of an address ..................................................................29
5.1.3 Selecting the destination from your Favorites .............................................................35
5.1.4 Selecting the destination from the POIs ......................................................................35
5.1.5 Selecting the destination with saved POI search criteria ............................................36
5.1.6 Selecting the destination from the History...................................................................36
5.1.7 Selecting the destination by entering its coordinates..................................................37
5.2 Creating a multi-point route (inserting a via point)................................................................37
5.3 Creating a multi-point route (appending a new destination).................................................38
5.4 Editing the route....................................................................................................................38
5.5 Viewing the entire route on the map (Fit-to-Screen).............................................................39
5.6 Watching the simulation of the route ....................................................................................39
5.7 Enabling Safety Mode...........................................................................................................39
NP401 OM_100920_EN.indd 6 2011-1-6 16:10:51
English
Owner’s
Manual
NP401 7
5.8 Pausing the active route........................................................................................................39
5.9 Deleting the next via point from the route.............................................................................40
5.10 Deleting the active route .....................................................................................................40
5.11 Using Track Logs ................................................................................................................40
5.12 Saving the active route........................................................................................................41
5.13 Loading a saved route.........................................................................................................41
6. Reference Guide (Advanced mode)............................................................................................42
6.1 Map screen ...........................................................................................................................42
6.1.1 Icons on the map .........................................................................................................45
6.1.2 Objects on the map......................................................................................................47
6.1.3 Detour menu ................................................................................................................49
6.1.4 Cursor menu.................................................................................................................49
6.1.5 Position menu ..............................................................................................................51
6.1.6 Route Information screen.............................................................................................52
6.1.7 Trip Information screen ................................................................................................53
6.1.8 Quick menu..................................................................................................................55
6.1.9 GPS Data screen..........................................................................................................57
6.2 Find menu .............................................................................................................................58
6.3 Route menu...........................................................................................................................58
6.4 Manage menu .......................................................................................................................59
6.4.1 Manage Saved Routes.................................................................................................60
6.4.2 Manage History............................................................................................................60
6.4.3 Manage Track Logs......................................................................................................60
6.4.4 Manage Favorites.........................................................................................................61
6.4.5 Manage POIs................................................................................................................61
6.4.6 Manage Saved Search Criteria ....................................................................................62
6.4.7 User Data Management...............................................................................................62
6.5 Settings menu .......................................................................................................................63
6.5.1 Map Screen settings ....................................................................................................64
6.5.2 Sound settings .............................................................................................................65
6.5.3 Route Planning options................................................................................................65
6.5.4 Regional settings..........................................................................................................67
6.5.5 Navigation settings.......................................................................................................68
6.5.6 Warning settings ..........................................................................................................69
6.5.7 Menu settings...............................................................................................................70
6.5.8 Device settings.............................................................................................................71
6.5.9 Track Log settings........................................................................................................71
7. Glossary ......................................................................................................................................72
8. End User License Agreement .....................................................................................................73
9. Troubleshooting...........................................................................................................................77
10. Specifications............................................................................................................................78
11.Installation/Wireconnectionguide..........................................................................................78
NP401 OM_100920_EN.indd 7 2011-1-6 16:10:51
English
Owner’s
Manual
8 NP401
3. Warnings and Safety information
Clarion Mobile Map is a navigation system that helps you find your way to your destination with its GPS
receiver. Clarion Mobile Map does not transmit your GPS position; others cannot track you.
It is important that you look at the display only when it is safe to do so. If you are the driver of the vehicle,
we recommend that you operate Clarion Mobile Map before you start your journey. Plan the route before
your departure and stop if you need to change something in the route.
Clarion Mobile Map has a Safety Mode: if you turn on Safety Mode, you cannot change anything in Clarion
MobileMapwhilethevehicleismovingataspeedof10km/h(6mph)orhigher.Unlessonlypassengers
operate Clarion Mobile Map, we strongly encourage you to turn on Safety Mode.
You must obey the traffic signs and follow the road geometry. If you deviate from the route that Clarion
Mobile Map recommended, Clarion Mobile Map changes the instructions accordingly.
Never place any part of the navigation system where it obstructs the driver's view, where it is in the
deployment zone of an airbag or where it might cause injuries in an accident.
For more information, consult the End User License Agreement (page 73).
NP401 OM_100920_EN.indd 8 2011-1-6 16:10:51
English
Owner’s
Manual
NP401 9
4. Getting started with Clarion Mobile Map
Clarion Mobile Map is optimized for in-car use. You can use it easily by tapping the screen buttons and the
map with your fingertips.
Clarion Mobile Map can plan routes throughout the whole installed map set; you do not need to change
maps or switch to a poorly detailed general map to navigate between map segments or countries.
Tasks Instructions
Double tapping the
screen
You do not need to tap the screen twice for any action. With buttons and controls, a
single tap is enough.
Tapping and
holding the screen
You do not need this to access the basic navigation functions. Tap and keep pressing
the following buttons to reach extra functions:
•Tapandhold on the Map screen: you can set the minimum and maximum zoom
level of Smart Zoom.
•Tapandholdanyofthe buttons on the Map screen: you
can set or reset the zoom value of the button (2D map).
•Tapandholdanyofthe buttons on the Map screen: you
can set or reset the tilt and zoom values of the button (3D map).
•Tapandhold on list and menu screens: the Navigation menu appears.
•Tapandholdanyofthe , , , , , and buttons on the Map
screen: you can rotate, tilt or scale the map continuously.
•Tapandhold on keyboard screens: you can delete several characters quickly.
•Tapandhold or in long lists: you can scroll pages continuously.
•TapandholdthebuttonsintheQuickmenutoopenscreensrelatedwiththe
function of the button from the Manage menu or the Settings menu.
StartusingClarionMobileMap
When Clarion Mobile Map is started the first time, you need to do the following:
1. Select the written language of the application interface. Later you can change it in Settings (page 68).
NP401 OM_100920_EN.indd 9 2011-1-6 16:10:51
English
Owner’s
Manual
10 NP401
2. Select the language and speaker used for voice guidance messages. Later you can change it in Settings
(page 67).
3. Read and accept the End User License Agreement (page 73).
4. Select whether to start the program in Simple mode or in Advanced mode. Later you can switch between
the two operating modes in Settings.
5. Read and accept the road safety warning.
After this, the Navigation menu appears and you can start using Clarion Mobile Map.
The Navigation menu in Simple mode: The Navigation menu in Advanced mode:
The typical way of using Clarion Mobile Map is to select a destination, and start navigating. You can select
your destination in the following ways (not all of them are available in):
•Usetheselectedlocationonthemap(theCursor)(page29).
•Enterafulladdressorapartofanaddress,forexampleastreetnamewithoutahousenumberorthe
names of two intersecting streets (page 29).
•EnteranaddresswithZIPcode(page34).Thiswayyoudonotneedtoselectthenameofthecityandthe
search for street names might be faster as well
•Useacoordinate(page37)
•Useasavedlocation:
•aFavorite(page35)
•aPOI(page35)
•theHistoryofpreviouslysetdestinationsandwaypoints(page36)
NP401 OM_100920_EN.indd 10 2011-1-6 16:10:52
English
Owner’s
Manual
NP401 11
4.1SimpleandAdvancedmodes
The two operating modes of Clarion Mobile Map mainly differ in the menu structure and the number of
available features. The controls and screen layouts are the same.
•Simplemode:youhaveeasyaccesstothemostimportantnavigationfunctionsandthebasicsettings
only. The rest of the settings are set to values that are optimal for typical use.
•Advancedmode:youhaveaccesstothefullfunctionalityofClarionMobileMap.
To switch from Simple mode to Advanced mode: on the startup screen (Navigation Menu), tap ,
.
To switch from Advanced mode to Simple mode: on the startup screen (Navigation Menu), tap ,
.
The features and settings available in each mode are as follows:
Type of action Available in
Simple mode
Available in
Advanced mode Explanation
Navigating to a selected map point Yes Yes See page 29
Navigating to a street address Yes Yes See page 30
Navigating to an incomplete address Yes Yes See page 32
Navigating to an intersection Yes Yes See page 32
Navigating to recent destinations (History) Yes Yes See page 36
Navigating to Favorites Yes Yes See page 35
Navigating to a POI Yes Yes See page 35
Navigating to coordinates No Yes See page 36
Creating a multi-point route No Yes See page 37
Saving a map point as a Favorite destination Yes Yes See page 23
Saving a map point as a POI No Yes See page 23
Saving a map point as a location of a Road
Safety Camera
No Yes See page 23
Mark a map point with a Pin No Yes See page 23
Saving the active route No Yes See page 40
Saving Track Logs No Yes See page 40
NP401 OM_100920_EN.indd 11 2011-1-6 16:10:52
English
Owner’s
Manual
12 NP401
Type of action Available in
Simple mode
Available in
Advanced mode Explanation
Map Screen settings Only
color profiles
(from Quick Menu) Yes See page 64
Menu settings Only background picture Yes See page 70
Sound settings Yes (from Quick Menu) Yes See page 65
Route Planning options Yes Yes See page 66
Regional settings Only language selection Yes See page 67
Warnings No Yes See page 69
4.2Buttonsandothercontrolsonthescreen
When you are using Clarion Mobile Map, you usually tap buttons on the touch screen.
You only need to confirm selections or changes in Clarion Mobile Map if the application needs to restart, it
needs to perform a major reconfiguration, or you are about to lose some of your data or settings. Otherwise,
Clarion Mobile Map saves your selections and applies the new settings without confirmation as soon as you
use the controls.
Type Example Description How to use it
Button
Tap it to initiate a function, to
open a new screen, or to set a
parameter.
Tap it once.
Icon Shows status information. Some icons also function as a
button. Tap them once.
List
When you need to select from
several options, they appear in
a list.
Move between pages with the
and buttons and tap the
value that you want.1
Slider
When a feature has several
different unnamed values,
Clarion Mobile Map shows
an indicator on a gauge that
displays and sets a value from
a range.
Drag the handle to move the
slider to its new position.
Tap the slider where you want
the handle to appear; the thumb
jumps there.
NP401 OM_100920_EN.indd 12 2011-1-6 16:10:52
English
Owner’s
Manual
NP401 13
Type Example Description How to use it
Switch
When there are only two
choices, a checkmark shows
whether the feature is enabled.
Tap it to turn the switch on or off.
Virtual
keyboard
Alphabetic and alphanumeric
keyboards to enter text and
numbers.
Each key is a touch screen
button.
4.2.1Usingkeyboards
You only need to enter letters or numbers in Clarion Mobile Map when you cannot avoid it. You can type
with your fingertips on the full-screen keyboards and you can switch between various keyboard layouts, for
example ABC, QWERTY, or numerical.
Task Details
Switching to another keyboard
layout, for example from an English
QWERTY keyboard to a Greek
keyboard
Tap , and select from the list of available keyboard types.
Clarion Mobile Map remembers your last keyboard choice and offers it the next time
you need to enter data.
Correcting your entry on the
keyboard
Tap to remove the unneeded character(s).
Tap and hold the button to delete the entire input string.
Entering a space, for example
between a first name and a family
name or in multi-word street names
Tap .
Entering lowercase or capital letters Tap to cycle through entering lowercase letters, initial capitals or all capitals.
Entering symbols Tap to switch to a keyboard offering symbol characters.
Finalising the keyboard entry Tap .
4.3Usingthemap
The map screen is the most frequently used screen of Clarion Mobile Map. It can be accessed from the
Navigation menu by tapping .
NP401 OM_100920_EN.indd 13 2011-1-6 16:10:52
English
Owner’s
Manual
14 NP401
For further information about the map screen, see page 41.
4.3.1Checkingthedetailsofamaplocation
•Ifyouareinterestedinthedetailsofyourcurrentpositionduringnavigation:
1. Check the bottom line of the map. It shows the current street and house number information.
2. For further details, tap to open the Position menu.
3. Tap . The address, the coordinate and the list of nearby POIs will be displayed.
•Youcancheckthedetailsofanyotherlocationbyselectingitonthemap:
1. Tap the map anywhere to open the map control buttons.
2. Tap the desired location on the map. The Cursor ( ) appears there. The address of the location is
displayed at the bottom of the map.
3. For further details, tap to open the Cursor menu.
4. Tap . The address, the coordinate and the list of nearby POIs will be displayed.
5. It is even easier if you select the desired point in the Find menu. Then the Cursor menu opens
automatically. You only need to tap the button.
4.3.2Manipulatingthemap
Position markers on the map:
•CurrentGPSposition: (page 23)
•Selectedlocation(Cursor): (page 23)
The following controls help you modify the map view to suit your actual needs the best. Most of these
controls appear only if you tap the map once, and disappear after a few seconds of inactivity.
NP401 OM_100920_EN.indd 14 2011-1-6 16:10:52
English
Owner’s
Manual
NP401 15
Action Button(s) Description
Moving the
map No buttons
You can move the map into any direction. Tap the map at any desired
location. The point you hit on the map moves to the center of the
screen.
If GPS position is available and you have moved the map, the
button appears. Tap this button to return to the GPS position.
Opening/
closing map
control buttons
Tap this button to show or hide the following map control buttons:
•Zoomin/out
•Rotateleft/right(3Dmaponly)
•Tiltup/down(3Dmaponly)
•Zoompresetbuttons(2Dmaponly)
•Tiltandzoompresetbuttons(3Dmaponly)
•ReturntoGPSpositionbutton
•SmartZoombutton
Zooming in
and out ,
Changes how much of the map is displayed on the screen.
Clarion Mobile Map uses high-quality vector maps that let you see the
map at various zoom levels, always with optimized content. It always
displays street names and other text with the same font size, never
upside-down, and you only see the streets and objects that you need.
Map scaling has different limits in 2D and in 3D map view modes.
Tilting up and
down , Changes the vertical view angle of the map in 3D mode.
Rotating left
and right ,
Changes the horizontal view angle of the map in 3D mode or in rotated
2D mode.
When GPS position is available, Clarion Mobile Map always rotates
the map so its top faces your direction of travel (Track-Up orientation).
You can turn away from Track-Up with these buttons.
If GPS position is available and you have rotated the map, the
button appears. Tap this button to re-enable the automatic map
rotation.
NP401 OM_100920_EN.indd 15 2011-1-6 16:10:52
English
Owner’s
Manual
16 NP401
Action Button(s) Description
Viewing modes , ,
Gives you the following map perspectives in Clarion Mobile Map:
•classictop-downview(2D),thetopofthemapalwaysfacesNorth
•top-downview(2D),thetopofthemapalwayspointsinthecurrent
driving direction
•perspectiveview(3D),thetopofthemapalwayspointsinthe
current driving direction
The icon always shows the mode the button switches to: If you are in
3D mode, you can see the button and you need to tap it to switch
to 2D mode.
Smart Zoom
Clarion Mobile Map can automatically rotate, scale and tilt the map
and give you the optimal view:
•Whenyouareapproachingaturn,ClarionMobileMapzoomsinand
raises the view angle to let you easily recognize your maneuver at
the next junction.
•Ifthenextturnisatadistance,ClarionMobileMapzoomsoutand
lowers the view angle to show you the road in front of you.
Tap this button once to enable Smart Zoom.
Tap&hold the button to set the zoom limits of Smart Zoom.
Returning
to normal
navigation
(back to the
GPS position
with automatic
map rotation)
Tap this button to move the map back to the current GPS position. If
the map has been rotated, automatic map rotation is also re-enabled.
Zoom preset
buttons
(available in
Advanced
mode only)
Tap one of the preset buttons to set the zoom level to a fix, predefined
value. Smart Zoom is disabled. These buttons are available in 2D mode.
Tap&hold any of the buttons to set its value to the current zoom level,
or to reset it to its original value.
NP401 OM_100920_EN.indd 16 2011-1-6 16:10:52
English
Owner’s
Manual
NP401 17
Action Button(s) Description
Tilt and zoom
preset buttons
(available in
Advanced
mode only)
Tap one of the preset buttons to set the tilt and zoom levels to fix,
predefined values. Smart Zoom is disabled. These buttons are
available in 3D mode.
Tap&hold any of the buttons to set its value to the current tilt and zoom
levels, or to reset it to its original value.
Map scale Clarion Mobile Map shows the scale of the map in 2D mode.
Fit-to-screen
This button does not appear on the Map screen. It is available on the
following screens:
•PlanonMapscreen:Whenyouhaveanactiveroute,youcandisplay
it in its full length on the map.
•TrackInformationscreen:Atracklogcanbedisplayedinitsfull
length on the map.
End Call This button is displayed only during a phone call. Tap the button to
hang up.
Repeat Voice
Instruction
Tap this button to repeat the current voice instruction. The distance is
updated to always describe the current situation.
4.3.3LaneinformationandSignposts
When navigating on multilane roads, it is important to take the appropriate lane in order to follow the
recommended route. If lane information is available in the map data, Clarion Mobile Map displays the lanes
and their directions using small arrows either at the bottom or at the top of the map (the position of these
arrows can be modified in Map Screen settings). Arrows in yellow represent the lanes you need to take.
Where there is additional information available, signposts substitute arrows. Signposts are always displayed
at the top of the map. The color and style of the signposts are similar to the real ones you can see above
road or by the roadside. They show the available destinations and the number of the road the lane leads to.
All signposts look similar when cruising (when there is no recommended route). When navigating a route, only
that signpost is displayed in vivid colors that points to the lane(s) to be taken; all others are darkened out.
NP401 OM_100920_EN.indd 17 2011-1-6 16:10:53
English
Owner’s
Manual
18 NP401
4.3.4Statusinformationandhiddencontrolsonthemap
The following information appears in the rounded field in the top left corner, the Turn Preview field. When
tapping this area, the result depends on the information currently shown.
Icon Information Details Action
There is no active
route in Simple mode
If there is no route to be navigated in
Simple mode, this icon appears in the
Turn Preview field.
Tap this area to open
Find Address.
There is no active route
in Advanced mode
If there is no route to be navigated in
Advanced mode, this icon appears in
the Turn Preview field.
Tap this area to open Find.
, There is no valid
GPS position
If an active route exists, and there is no
valid GPS position, the view of the sky
above you is shown with colored dots
for each satellite. Some dots need to
turn green to be able to navigate.
Tap this area to open the
Route Information screen.
If the icon is a static
picture, route calculation
is needed
GPS position and an active route are
available, but automatic off-route
recalculation is switched off, and you
deviated from the route.
Tap this area to
make Clarion Mobile
Map recalculate the
recommended route.
If the icon is animated,
route calculation is in
progress
Clarion Mobile Map is calculating or
recalculating the route.
Nothing happens if you tap
this area of the screen.
, Next route event (next
maneuver)
GPS position and an active route
are available, and you navigate the
recommended route. This area gives
you information about the type and
distance of the next route event.
Tap this area to open the
Route Information screen.
NP401 OM_100920_EN.indd 18 2011-1-6 16:10:53
English
Owner’s
Manual
NP401 19
The following area appears next to the above described rounded area. When tapping this area, the result
depends on the information currently shown.
Icon Information Details Action
There is no valid
GPS position
If there is no valid GPS position,
this symbol appears here.
Tap this area to open the GPS
Data screen to check the signal
status or the connection settings.
Traffic restriction
When GPS position is available but
there is no route to be navigated,
the traffic restriction of the
upcoming intersection is shown
here if there is any.
Nothing happens if you tap this
area of the screen.
,
Second route event
(maneuver after the
next maneuver)
When GPS position and an active
route are both available, this field
shows the route event that follows
the next route event shown in the
above described area.
Tap this area to open the Itinerary
screen with the turn by turn
guidance instructions.
Approaching
a Road Safety
Camera
This icon appears when you
are approaching a Road Safety
Camera, and the warning for
cameras is enabled in Settings.
Tap this area to suppress the
audible camera warning.
Tap again to display the second
route event with the possibility to
open the Itinerary.
Stops the running
simulation
This icon appears during Route Fly
Over, Route Simulation, and Track
Log playback.
Tap this area to stop the
simulation.
Route recalculation
progress
During route recalculation, this field
shows the recalculation progress
between 0% and 100%.
Nothing happens if you tap this
area of the screen.
Indicator strip
-soundsmuted/enabled
- Track Log recording
- Bluetooth status
Tap this area to open the Itinerary
screen with the turn by turn
guidance instructions.
NP401 OM_100920_EN.indd 19 2011-1-6 16:10:53
English
Owner’s
Manual
20 NP401
The following symbols appear in the Indicator strip:
Icon Color Description
Icon Description
The sound output of Clarion Mobile Map
is muted.
The sound output of Clarion Mobile Map
is enabled.
Clarion Mobile Map records a Track log
when GPS position is available.
Track log recording is disabled.
The Bluetooth radio is switched off.
The Bluetooth radio is turned on but no,
telephone is connected.
There is an error in the Bluetoothconnection.
Clarion Mobile Map is connected to a telephone
as a handsfree set via Bluetooth.
A phone call is in progress over the Bluetooth
color
White
White
Redblinking
Red
Red
Gray
Purple
Green
Blue
White Thesound output of Clarion Mobile Map is muted.
Icon Description
The sound output of Clarion Mobile Map
is muted.
The sound output of Clarion Mobile Map
is enabled.
Clarion Mobile Map records a Track log
when GPS position is available.
Track log recording is disabled.
The Bluetooth radio is switched off.
The Bluetooth radio is turned on but no,
telephone is connected.
There is an error in the Bluetooth connection.
Clarion Mobile Map is connected to a telephone
as a handsfree set via Bluetooth.
A phone call is in progress over the Bluetooth
color
White
White
Redblinking
Red
Red
Gray
Purple
Green
Blue
White Thesound output of Clarion Mobile Map is enabled.
Icon Description
The sound output of Clarion Mobile Map
is muted.
The sound output of Clarion Mobile Map
is enabled.
Clarion Mobile Map records a Track log
when GPS position is available.
Track log recording is disabled.
The Bluetooth radio is switched off.
The Bluetooth radio is turned on but no,
telephone is connected.
There is an error in the Bluetooth connection.
Clarion Mobile Map is connected to a telephone
as a handsfree set via Bluetooth.
A phone call is in progress over the Bluetooth
color
White
White
Redblinking
Red
Red
Gray
Purple
Green
Blue
Red blinking Clarion Mobile Map recordsaTrack logwhen GPS position is available.
Icon Description
The sound output of Clarion Mobile Map
is muted.
The sound output of Clarion Mobile Map
is enabled.
Clarion Mobile Map records a Track log
when GPS position is available.
Track log recording is disabled.
The Bluetooth radio is switched off.
The Bluetooth radio is turned on but no,
telephone is connected.
There is an error in the Bluetooth connection.
Clarion Mobile Map is connected to a telephone
as a handsfree set via Bluetooth.
A phone call is in progress over the Bluetooth
color
White
White
Redblinking
Red
Red
Gray
Purple
Green
Blue
Red Tracklog recording isdisabled.
Icon Description
The sound output of Clarion Mobile Map
is muted.
The sound output of Clarion Mobile Map
is enabled.
Clarion Mobile Map records a Track log
when GPS position is available.
Track log recording is disabled.
The Bluetooth radio is switched off.
The Bluetooth radio is turned on but no,
telephone is connected.
There is an error in the Bluetooth connection.
Clarion Mobile Map is connected to a telephone
as a handsfree set via Bluetooth.
A phone call is in progress over the Bluetooth
color
White
White
Redblinking
Red
Red
Gray
Purple
Green
Blue
Gray TheBluetooth radio is switched off.
Icon Description
The sound output of Clarion Mobile Map
is muted.
The sound output of Clarion Mobile Map
is enabled.
Clarion Mobile Map records a Track log
when GPS position is available.
Track log recording is disabled.
The Bluetooth radio is switched off.
The Bluetooth radio is turned on but no,
telephone is connected.
There is an error in the Bluetooth connection.
Clarion Mobile Map is connected to a telephone
as a handsfree set via Bluetooth.
A phone call is in progress over the Bluetooth
color
White
White
Redblinking
Red
Red
Gray
Purple
Green
Blue
Purple TheBluetooth radio is turnedon but no telephone isconnected.
Icon Description
The sound output of Clarion Mobile Map
is muted.
The sound output of Clarion Mobile Map
is enabled.
Clarion Mobile Map records a Track log
when GPS position is available.
Track log recording is disabled.
The Bluetooth radio is switched off.
The Bluetooth radio is turned on but no,
telephone is connected.
There is an error in the Bluetooth connection.
Clarion Mobile Map is connected to a telephone
as a handsfree set via Bluetooth.
A phone call is in progress over the Bluetooth
color
White
White
Redblinking
Red
Red
Gray
Purple
Green
Blue
Red There isan error in theBluetooth connection.
Icon Description
The sound output of Clarion Mobile Map
is muted.
The sound output of Clarion Mobile Map
is enabled.
Clarion Mobile Map records a Track log
when GPS position is available.
Track log recording is disabled.
The Bluetooth radio is switched off.
The Bluetooth radio is turned on but no,
telephone is connected.
There is an error in the Bluetooth connection.
Clarion Mobile Map is connected to a telephone
as a handsfree set via Bluetooth.
A phone call is in progress over the Bluetooth
color
White
White
Redblinking
Red
Red
Gray
Purple
Green
Blue
Green Clarion Mobile Map is connected to a telephone as a handsfree set via
Bluetooth
Icon Description
The sound output of Clarion Mobile Map
is muted.
The sound output of Clarion Mobile Map
is enabled.
Clarion Mobile Map records a Track log
when GPS position is available.
Track log recording is disabled.
The Bluetooth radio is switched off.
The Bluetooth radio is turned on but no,
telephone is connected.
There is an error in the Bluetoothconnection.
Clarion Mobile Map is connected to a telephone
as a handsfree set via Bluetooth.
A phone call is in progress over the Bluetooth
color
White
White
Redblinking
Red
Red
Gray
Purple
Green
Blue
Blue A phone call is in progress over theBluetooth connection.
The following information can be seen in the three data fields shown on the map screen. Tap this area to
open the Trip Information screen where you can select which values to be shown in these three fields.
When there is no active route, these fields show the following information: current speed, compass and the
current time of day.
Icon Type More information
Compass
Shows the direction of your heading both when the map
is automatically rotated (3D) and when the map is always
facing North (2D).
Speed information
There are speed values that can be shown:
•Currentspeed
•Speedlimitonthecurrentroad
NP401 OM_100920_EN.indd 20 2011-1-6 16:10:53
