Clarion NX404 User manual

DVD MULTIMEDIA STATION WITH BUILT-IN NAVIGATION &
6.2’’ TOUCH PANEL CONTROL
NX404
Owner’s manual

1
NX404
English
English Owner’s Manual English Owner’s Manual
CLARION PRODUCT REGISTRATION INFORMATION
INFORMATIONS DE L’ENREGISTREMENT DE PRODUITS CLARION
INFORMACIÓN DEL REGISTRO DE PRODUCT O DE CLARION
For USA and Canada only
www.clarion.com
Pour les Étas Unis et le Canada seulement
www.clarion.com
Para USA y Canada nomas
www.clarion.com
Dear Customer:
Congratulations on your purchase of a Clarion mobile electronic product. We are
confident that you’ll enjoy your Clarion experience.
There are many benefits to registering your product. We invite you to visit our website
at www.clarion.com to register your Clarion product.
We have made product registration simple with our easy to use website.
The registration form is short and easy to complete. Once you’re registered, we can
keep you informed of important product information.
Register at www.clarion.com - it’s easy to keep your Clarion product up to date.
Cher client:
Nous vous remercions d’avoir acheté ce produit électronique mobile Clarion. Nous
sommes confiants que vous apprécierez votre expérience Clarion.
Il y a beaucoup d’avantage à enregistrer votre produits. Nous vous invitons à visiter
notre site Web www.clarion.com pour enregistrer votre produit Clarion.
Nous avons facilité la tache d’enregistrement de produit simple et facile grâce à notre
site Web.Le formulaire d’enregistrement est court et facile à compléter. Lorsque vous
êtes enregistrer, nous pouvons vous tenir informé des informations important de
produits. Enregistrer à www.clarion.com - c’est facile de mettre à jour votre produit
Clarion.
Querido Cliente:
Felicitaciones por su compra de producto electrónico móvil de Clarion. Estamos
seguros que usted gozará de su experiencia con el producto de Clarion.
Hay muchas ventajas al registrar su producto. Le invitamos a que visite nuestro sitio
en internet www.clarion.com para registrar su producto de Clarion.
Hemos hecho el registro de producto fácil en nuestro sitio. La forma de registro es
corta y fácil de completar. Una vez que lo registre, podremos proporcionarle la infor-
mación de su producto.
Registrese en www.clarion.com - es fácil mantener su producto de Clarion actual-
izado.
Under Industry Canada regulations, this radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry
Canada. To reduce potential radio interference to other users, the antenna type and its
gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that necessary for successful communication.
Conformément à la réglementation d’Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d’un type et d’un gain maximal (ou inférieur) approuvé pour
l’émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioé-
lectrique
à l’intention des autres utilisateurs, il faut choisir le type d’antenne et son gain de sorte
que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l’intensité néces-
saire à l’établissement d’une communication satisfaisante.

2NX404
English
English Owner’s Manual English Owner’s Manual
Contents
Thank you for purchasing this Clarion product.
• Please fully read this owner’s manual before operating this equipment.
•Check the contents of the enclosed warranty card and store it in a safe place with this manual.
1. FEATURES...........................................................................................................4
Expanding Systems ..............................................................................................4
2. PRECAUTIONS....................................................................................................5
3. CAUTIONS ON HANDLING.................................................................................8
Operation Panel ....................................................................................................8
USB Port...............................................................................................................8
Cleaning................................................................................................................8
Handling Discs......................................................................................................9
4.OPERATIONAL PANEL ......................................................................................11
Functions of Buttons...........................................................................................11
5. REMOTE CONTROL..........................................................................................12
Remote Control Function....................................................................................13
6. MAIN MENU.......................................................................................................15
7. DVD VIDEO PLAYER OPERATIONS ...............................................................16
Discs ...................................................................................................................16
Change DVD System Settings............................................................................17
Watching to a disc ..............................................................................................17
Operate the DVD Player menu............................................................................18
Operate the Video files Player menu...................................................................20
Switching Subtitles .............................................................................................20
Video files list......................................................................................................20
Play DivX Video-On-Demand file........................................................................20
Playable disc video files......................................................................................21
8. CD PLAYER OPERATIONS...............................................................................22
Listening to a disc/Ejecting a disc ......................................................................22
Showing CD Player mode screen.......................................................................22
Operate the CD Player menu..............................................................................22
Listening to compressed audio ..........................................................................23
Tag display function............................................................................................23
9. USB AUDIO OPERATIONS ...............................................................................25
Notes on using USB memories...........................................................................25
Select USB Audio mode .....................................................................................25
Playing Audio files in USB memory ....................................................................26
10. USB VIDEO OPERATIONS..............................................................................27
Notes on using USB memories...........................................................................27
Select USB Video mode .....................................................................................27
Playing video files in USB memory.....................................................................27
Playable Video file...............................................................................................27
11. iPod OPERATIONS..........................................................................................29
Notes on using Apple iPod/iPhone.....................................................................29
iPod Audio ID3 Info.............................................................................................29
iPod audio playlist mode screen.........................................................................30
iPod Video Menu Operations..............................................................................31
iPod Video ID3 mode screen ..............................................................................31
iPod Video List mode screen..............................................................................32
iPod Video Simple Control Mode Screen ...........................................................32
iPod Video play mode screen.............................................................................32
iPod Audio Bluetooth mode................................................................................33
12. Pandora®OPERATIONS.................................................................................34

3
NX404
English
English Owner’s Manual English Owner’s Manual
Selecting the Pandora mode ..............................................................................34
Pandora Bluetooth mode....................................................................................35
13. Bluetooth®AUDIO PLAYER OPERATIONS ..................................................36
Selecting the Bluetooth Audio mode..................................................................36
Bluetooth audio player settings ..........................................................................36
Registering your Bluetooth audio player (Pairing)...............................................36
Selecting the Bluetooth audio player..................................................................37
Controlling the Bluetooth audio player ...............................................................37
14. Bluetooth® TELEPHONE OPERATIONS..........................................................38
Select the BT Phone mode.................................................................................38
Bluetooth Telephone settings.............................................................................38
Registering your cellular phone (Pairing) ............................................................39
Select the cellular phone ....................................................................................39
Obtaining the Phone Book data .........................................................................39
Telephone operations .........................................................................................39
15. TUNER OPERATIONS.....................................................................................41
16. HDMI MODE ....................................................................................................42
Wire connection of HDMI mode .........................................................................42
Select HDMI source ...........................................................................................43
HDMI Mode.........................................................................................................43
17. AUX .................................................................................................................44
18. CAMERA INPUT OPERATIONS .....................................................................44
19. REAR SOURCE OPERATIONS.......................................................................45
DVD Video in Rear ..............................................................................................45
DVD Video Rear Source Control Info mode. ......................................................45
DVD Video Rear Source Control Direct mode. ..................................................45
iPod Video in Rear ..............................................................................................46
iPod Video Rear Source Control Play Mode.......................................................46
iPod Video Rear Source ID3 Mode.....................................................................46
20. SETTING OPERATIONS..................................................................................47
General Setup Menu...........................................................................................47
Video Setup Menu ..............................................................................................47
Audio Setup Menu ..............................................................................................48
Navigation Setup Menu ......................................................................................48
Others Setup Menu.............................................................................................48
Set the Anti-Theft code.......................................................................................49
21. TROUBLESHOOTING .....................................................................................50
GENERAL............................................................................................................50
DVD PLAYER ......................................................................................................50
USB DEVICE.......................................................................................................51
Bluetooth ............................................................................................................51
TFT screen ..........................................................................................................52
22. ERROR DISPLAY.............................................................................................53
DVD PLAYER ......................................................................................................53
23. SPECIFICATIONS............................................................................................54
24. WIRE CONNECTION GUIDE...........................................................................56

4NX404
English
English Owner’s Manual English Owner’s Manual
1. FEATURES
Expanding Systems
NOTE:
• The items listed outside of the frames are the commercial products generally sold.
• CCA-750,CCA-770,CCA-771:Sold separately.
FLAC(Free Lossless Audio Codec) Compatible with ID3-TAG Display
Built-in Bluetooth
®
Handsfree (HFP) and Audio Streaming (A2DP &
AVRCP)
Front-Panel Auxiliary Input and 6ch RCA Output with Subwoofer Control
iPod
®
Expanding visual features
Rear monitor Rear Vision Camera
Expanding audio features
External Power
Amplier
iPhone
®
USB
Memory
Bluetooth
Telephone
(Connect via CCA-750)
(Connect via CCA-750)
(Connect via CCA-770,CCA-771)
iPhone
®
/ Smartphone via HDMI

5
NX404
English
English Owner’s Manual English Owner’s Manual
2. PRECAUTIONS
• For your safety, the driver should not watch any video sources and/or operate the controls while driving.
Please note that watching and operating any video sources while driving are prohibited by law in some
countries. Also, while driving, keep the volume to a level at which external sounds can be heard.
• Do not disassemble or modify this unit. It may cause an accident, re, or electric shock.
• Do not use this unit when a trouble exists, such as no screen content appears or no sound is
audible. It may cause an accident, fire, or electric shock. For that case, consult your authorized
dealer or a nearest Clarion service center.
• In case of a problem, such as any material has been entered in the unit, the unit gets wet, or
smoke or strange smells come out of the unit, etc., stop using this unit immediately, and consult
your authorized dealer or a nearest Clarion service center.
Using it in that condition may cause an accident, fire, or electric shock.
• Use a fuse with the same specication only when replacing the fuse.
Using a fuse with a different specification may causes a fire.
• For the installation of this unit or a change in the installation, ask your authorized dealer or a
nearest Clarion service center for safety. Professional skills and experiences are required to do
so.
• This navigation system should not be used to replace your own judgment. No itinerary suggested
by this navigation system should ever override any highway regulations, your own judgment, or a
knowledge of safe driving practices. Do not follow the navigation system’s suggested itinerary if it
would cause you to perform a dangerous or illegal act, place you in a dangerous situation, or take
you into an area you consider unsafe.
• The advice provided by the navigation system is to be regarded as a suggestion only. There may
be times when the navigation system displays the vehicle’s location incorrectly, fails to suggest
the shortest route, or fails to direct you to your desired destination. In such instances, rely on your
own driving judgment, taking into account the driving conditions at the time.
• Do not use the navigation system to locate emergency services. The database does not contain
a complete listing of emergency services such as police stations, fire halls, hospitals and walk-in
clinics. Please show discretion and ask for directions in such instances.
• As the driver, you alone are responsible for your driving safety.
• In order to avoid a trafc accident, do not operate the system while driving.
• In order to avoid a trafc accident, operate the system only when the vehicle is stopped at a safe
place and the parking brake is on.
• In order to avoid a trafc accident or trafc offense, remember that actual road conditions and
traffic regulations take precedence over the information contained on the navigation system.
• The software may contain inaccurate or incomplete information due to the passage of time,
changing circumstances, and the sources of information used. Please respect current traffic
conditions and regulations at all times while driving.
• Where actual road conditions and highway regulations differ from the information contained on
the navigation system, abide by the highway regulations.
• Keep the amount of time spent viewing the screen while driving to a strict minimum.
• The navigation system does not provide, nor represent in any way information on: trafc and
highway regulations; technical aspects of the vehicle including weight, height, width, load and
WARNING

6NX404
English
English Owner’s Manual English Owner’s Manual
speed limits; road conditions including grade, percentage of incline and surface conditions;
obstacles such as the height and width of bridges and tunnels; and other current driving or road
conditions. Always rely on your own judgment when driving a car, taking into account current
driving conditions.
• This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation.This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications.However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interfrence to radio reception, which
can be determined by turning the equipment off and on, the user is encourage to consult the
dealer or an experienced radio technician for help.

7
NX404
English
English Owner’s Manual English Owner’s Manual
1.When the inside of the car is very cold and
the player is used soon after switching on the
heater, moisture may form on the disc (DVD/
CD) or the optical parts of the player and
proper playback may not be possible. If
moisture forms on the disc (DVD/CD), wipe it
o with a soft cloth. If moisture forms on the
optical parts of the player, do not use the
player for about one hour. The condensation
will disappear naturally allowing normal
operation.
2.Driving on extremely bumpy roads which
cause severe vibration may cause the sound
to skip.
3.This unit uses a precision mechanism. Even
in the event that trouble arises, never open
the case, disassemble the unit, or lubricate
the rotating parts.
Changes or modications to this product
unapproved by the manufacturer will void the
warranty and will violate FCC approval.
NX404
CNE-8239D-CL
1:1
机身大贴纸
吕崇垚
20140102
技术说明：
1、大小65x75mm,红色外框线为刀模线。
2、材质，80g铜版纸,过哑胶。
3、内容印刷黑色:PANTONE Black C。
4、要求内容印刷正确、清晰，贴纸表面干净、整洁，不得有脏污、斑点、折痕；
切边务必整齐,不得歪斜。
5B
V8VCNE8239DCL
8614A-CNE8239DCL
7-8239-1014-00-01
INFORMATION FOR USERS:

8NX404
English
English Owner’s Manual English Owner’s Manual
3. CAUTIONS ON HANDLING
Operation Panel
• The operation panel will operate properly in a
temperature range of 0˚ to 60˚ C.
• Do not allow any liquids on the set from
drinks, umbrellas etc. Doing so may damage
the internal circuitry.
• Do not disassemble or modify the set in any
way. Doing so may result in damage.
• Subjecting the operation panel to shocks
may result in breakage, deformation or other
damage.
• Do not let cigarettes burn the display.
• If a problem should occur, have the set
inspected at your store of purchase.
• The remote control unit may not work if the
remote control sensor is exposed to direct
sunlight.
• In extremely cold weather, the display
movement may slow down and the display
may darken, but this is not a malfunction.
The display will work normally when the
temperature increases.
• Small black and shiny spots inside the liquid
crystal panel are normal for LCD products.
For a longer service life, be sure to read the following cautions.
Cleaning
• Cleaningthecabinet
Use a soft, dry cloth and gently wipe off
the dirt. For tough dirt, apply some neutral
detergent diluted in water to a soft cloth, wipe
off the dirt gently, then wipe again with a dry
cloth.
Do not use benzene, thinner, car cleaner, etc.,
as these substances may damage the cabinet
or cause the paint to peel. Also, leaving rubber
or plastic products in contact with the cabinet
for long periods of time may cause stains.
• Cleaningtheliquidcrystalpanel
The liquid crystal panel tends to collect dust,
so wipe it off occasionally with a soft cloth.
The surface is easily scratched, so do not rub
it with hard objects.
USB Port
• The USB memory sticks must be recognized
as “USB mass storage class” to work
properly. Some models may not operate
correctly.
When the memorized data is lost or
damaged by any chance, Clarion shall not
be liable for any damage.
When using an USB memory stick, we
recommend that you backup your data stored
on it before by using a personal computer etc.
• Data les may be broken when using USB
memory sticks in the following situation:
When disconnecting the USB memory stick or
turning the power off during writing or reading
data. When affected by static electricity or
electric noise. Connect/disconnect the USB
memory stick when it is not accessed.
• Connecting with the computer is not covered.

9
NX404
English
English Owner’s Manual English Owner’s Manual
Handling Discs
Handling
• New discs may have some roughness
around the edges. If such discs are used,
the player may not work or the sound
may skip. Use a ball-point pen or the like
to remove any roughness from the edge
of the disc.
Ball-point pen
Roughness
Never stick labels on the surface of the
disc or mark the surface with a pencil or
pen.
• Never play a disc with any cellophane
tape or other glue on it or with peeling off
marks. If you try to play such a disc, you
may not be able to get it back out of the
DVD player or it may damage the DVD
player.
• Do not use discs that have large
scratches, are misshapen, cracked,
etc. Use of such discs may cause
missoperation or damage.
• To remove a disc from its storage case,
press down on the center of the case
and lift the disc out, holding it carefully
by the edges.
• Do not use commercially available disc
protection sheets or discs equipped with
stabilizers, etc. These may damage the
disc or cause breakdown of the internal
mechanism.
Storage
• Do not expose discs to direct sunlight or
any heat source.
• Do not expose discs to excess humidity
or dust.
• Do not expose discs to direct heat from
heaters.
Cleaning
• To remove ngermarks and dust, use
a soft cloth and wipe in a straight
line from the center of the disc to the
circumference.
• Do not use any solvents, such as
commercially available cleaners, anti-
static spray, or thinner to clean discs.
• After using special disc cleaner, let the
disc dry off well before playing it.
On Discs
• Never turn off the power and remove the
unit from the car with a disc loaded.
CAUTION
For your safety, the driver should not
insert or eject a disc, opening the
operation panel while driving.
