Clarion PU-2426A-A User manual

-1- PU-2426A-A
Published by Service Dept.
Printed in Japan
Clarion Co., Ltd.
50Kamitoda,Toda-shi,Saitama335-8511Japan
ServiceDept.: 5-66Azuma,Kitamoto-shi,Saitama364-0007Japan
Tel:[phone] FAX: [phone]
298-6033-00 Dec.2002 P
Service Manual
Model
SAAB Automobile Genuine
6-Disc CD Changer
PU-2426A-A
(Genuine No.12799475)
SPECIFICATIONS
CD section
Disc: Compact disc (8 cm / 12 cm)
Separation: More than 60 dB (at 20 kHz LPF)
S/N ratio: More than 70 dB (at 20 kHz LPF JIS-A)
Distortion: Less than 0.05 % (at 20 kHz LPF)
General
Optical output power: -10 to -1.5 dBm
Power supply voltage: DC13.5 V
Negative ground
Current consumption: Less than 5A
CAUTIONS
Use of controls,adjustment or performance of procedures
other than those specified herein,may result in hazardous
radiation exposure.
The COMPACT DISC player should not be adjusted or
repaired by anyone except properly qualified service per-
sonnel.
This appliance contains a laser system and is classified as
a "CLASS 1 LASER PRODUCT".
To use this model properly,read this Owner's Manual care-
fully and kep this manual for your future reference.
To engineers in charge of repair or
inspection of our products.
Before repair or inspection, make sure to follow the
instructions so that customers and Engineers in
charge of repair or inspection can avoid suffering
any risk or injury.
1. Use specified parts.
The system uses parts with special safety features against
fire and voltage. Use only parts with equivalent character-
istics when replacing them.
The use of unspecified parts shall be regarded as remod-
eling for which we shall not be liable. The onus of product
liability (PL) shall not be our responsibility in cases where
an accident or failure is as a result of unspecified parts
being used.
2. Place the parts and wiring back in their original positions
after replacement or re-wiring.
For proper circuit construction, use of insulation tubes,
bonding, gaps to PWB, etc, is involved. The wiring con-
nection and routing to the PWB are specially planned us-
ing clamps to keep away from heated and high voltage
parts. Ensure that they are placed back in their original
positions after repair or inspection.
If extended damage is caused due to negligence during
repair, the legal responsibility shall be with the repairing
company.
In case of any trouble with this player,please contact your
nearest"AUTHORIZED service station".To prevent direct
exposure to the laser beam,do not to open the enclosure.
12799475
1 2 V NEG. GND.
YS9475
PU- 2426A 286- 9929- 14
H/ W 12799487
S/ W 12799488
CL AS S 1 LA SER P RODUCT
MANUFACTURED:
TH I S PRODUCT I ON COMPL I ES WI T H DHHS RUL E S
21 CF R SUBCHAPT ER J APPL I CABL E AT DATE OF
MA N UF AC T UR E .
CL AR I ON CO. , LT D.
50 KAMI TODA. T ODA- SHI . SAI T AMA- KEN. J APAN
T HI S DE VI CE COMP L I ES WI T H PA RT 1 5 OF T HE F CC RUL ES OPE RAT I ON I S SUBJ ECT T O THE F OL L OWI NG T WO
CONDI TI ONS: ( 1 ) T HI S DEVI CE MAY NOT CAUSE HARMFUL I NTERF ERENCE , AN D ( 2) THI S DE VI CE MUST A CCEPT
ANY I NT ERF ERENCE RE CEI VE D, I NCL UDI NG I NTERF E RENCEANY I NT ERF ERENCE RE CEI VE D, I NCL UDI NG I NTERF E RENCE THA T MAY CAUSE UNDESI RED OPE RATI ON.
MA D E I N J A P A N
XX
Dimensions(mm): 179 (W) x 51.5 (H) x 180.7 (D)
NOTE
We cannot supply PWB with component parts in principle.
When a circuit on PWB has failure , please repair it by com-
ponent parts base. Parts which are not mentioned in ser-
vice manual are not supplied.
Specifications and design arevsubject to change without
notice for further improvement.
COMPONENTS
PU-2426A-A

-2-
PU-2426A-A
3. Check for safety after repair.
Check that the screws, parts and wires are put back se-
curely in their original position after repair. Ensure for
safety reasons there is no possibility of secondary ploblems
around the repaired spots.
If extended damage is caused due to negligence of repair,
the legal responsibility shall be with the repairing company.
4. Caution in removal and making wiring connection to the
parts for the automobile.
Disconnect the battery terminal after turning the ignition
key off. If wrong wiring connections are made with the bat-
tery connected, a short circuit and/or fire may occur. If ex-
tensive damage is caused due to negligence of repair, the
legal responsibility shall be with the repairing company.
5. Cautions regarding chips.
Do not reuse removed chips even when no abnormality is
observed in their appearance. Always replace them with
new ones. (The chip parts include resistors, capacitors,
diodes, transistors, etc). The negative pole of tantalum
capacitors is highly susceptible to heat, so use special care
when replacing them and check the operation afterwards.
6. Cautions in handling flexible PWB
Before working with a soldering iron, make sure that the
iron tip temperature is around 270 . Take care not to ap-
ply the iron tip repeatedly(more than three times)to the
same patterns. Also take care not to apply the tip with
force.
7. Turn the unit OFF during disassembly and parts replace-
ment. Recheck all work before you apply power to the unit.
8. Cautions in checking that the optical pickup lights up.
The laser is focused on the disc reflection surface through
the lens of the optical pickup. When checking that the la-
ser optical diode lights up, keep your eyes more than
30cms away from the lens. Prolonged viewing of the laser
within 30cms may damage your eyesight.
9. Cautions in handling the optical pickup
The laser diode of the optical pickup can be damaged by
electrostatic charge caused by your clothes and body. Make
sure to avoid electrostatic charges on your clothes or body,
or discharge static electricity before handling the optical
pickup.
9-1. Laser diode
The laser diode terminals are shorted for transporta-
tion in order to prevent electrostatic damage.
After replacement, open the shorted circuit. When
removing the pickup from the mechanism, short the
terminals by soldering them to prevent this damage.
9-2. Actuator
The actuator has a powerful magnetic circuit. If a
magnetic material is put close to it. Its character-
istics will change. Ensure that no foreign substances
enter through the ventilation slots in the cover.
9-3. Cleaning the lens
Dust on the optical lens affects performance. To
clean the lens, apply a small amount of isopropyl
alcohol to lens paper and wipe the lens gently.
SYSTEM CONTROL
M30624FGAGP
IC101
BUFFER
TC74LCX07FT
IC103
BUFFER
SN74AHCT08PW
IC102
KEY
MATRIX
NJU3715G
IC401
MOST-IC
OS8104
IC202
PIGTAIL
P201
POWER SUPPLY CD Changer
mechanism
IX-6
OSC IC
NJU6391
IC203 IC302,IC305,IC501
IC502,Q301,Q305
Q306
EXPLANATION OF IC
052-0311-00 M30624FGAGP Microcomputer without programs
<NOTE.>Never use this Microcomputer without writing the program.
Because this Microcomputer does not have any program.
Please ask the detail to the service section of Clarion Tokyo.

-3- PU-2426A-A
EXPLODED VIEW : PARTS LIST
Main section
23
1
30
30
2
3
5
4
14
26
12
26
27
19
20
29
29
24
9
8
15
10
25
16
28
26
26
31
26
13
26
11
26
26
26
6
22
19
20
27
17
7
19
20
29
29
26
18
21

-4-
PU-2426A-A
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
1 940-8002-01 ESCUTCHEON-ASSY 1
2 345-8712-01 RUBBER SWITCH 1
3 335-6864-00 SPACER 4
4 039-2155-01 SWITCH PWB 1
(WITHOUT COMPONENT)
5 716-0778-10 WAVE SCREW(phi2 x 6) 7
6 039-2154-01 MAIN PWB 1
(WITHOUT COMPONENT)
7 856-0004-00 OPT-DIGIT-CABLE 1
8 039-2156-01 CONNECT-PWB 1
(WITHOUT COMPONENT)
9 074-1293-00 OUTLET SOCKET 1
10 331-3386-00 TR-HOLDER 1
11 305-0320-01 SIDE-CVR 1
12 305-0321-00 SIDE-CVR 1
13 310-1756-01 UPPER CASE 1
14 311-1855-01 LOWER CASE 1
15 313-1859-00 HEAT SINK 1
16 331-3384-00 CONNECT-HOLDER 1
17 331-3403-02 PWB HOLDER 1
18 347-6619-00 INSULATOR 1
19 620-1086-00 DAMPER-H-PLT 4
20 629-0083-01 DAMPER 4
21 039-1957-01 FPC(WITHOUT COMPONENT) 1
22 816-2586-00 FLAT WIRE 1
23 ----------- CD-CHANGER-MECHANISM 1
(001810)
24 714-2608-81 MACHINE SCREW(M2.6 x 8) 2
25 716-1494-00 IT SCREW(M2.6 x 6) 1
26 716-1716-00 SCREW(M2 x 3) 20
27 716-3450-00 SCREW(M1.7 x 2) 4
28 716-3484-00 SCREW(M2 x 5) 1
29 750-3491-00 FL-SPRING 4
30 780-2604-00 IT SCREW(M2.6 x 4) 2
31 286-9929-14 SETPLATE 1

-5- PU-2426A-A
CD changer mechanism section 1/3

-6-
PU-2426A-A
CD changer mechanism section 2/3

-7- PU-2426A-A
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
1 HBS-511-100 LOADING UNIT 1
(WITHOUT MOTOR)
2 SMA-186-100 LOADING MOTOR ASSY 1
3 HBS-512-100 MOTOR PLATE SUB ASSY 1
4 HBS-513-101 DRIVE UNIT 1
5 039-1951-00 CD PWB 1
(WITHOUT COMPONENT)
6 039-1953-00 DRIVER PWB 1
(WITHOUT COMPONENT)
7 966-0597-23 CHASSIS ASSY 1
8 966-0600-21 LOCK-P-RE-ASSY 1
9 966-0601-21 M-GEAR-P-ASSY 1
10 966-0602-23 DR-LINK-ASSY 1
11 966-0603-20 MODE-P-ASSY 1
12 966-0604-22 LOCK-PF-ASSY 1
13 966-0605-20 SHIFT-P-ASSY 1
14 966-0606-22 HLC-PLATE-ASSY 1
15 966-0607-23 COV-PLATE-ASSY 1
16 966-0610-05 TOP-PLATE-ASSY 1
17 966-0611-06 DR-BASE-P-ASSY 1
18 966-0615-01 LOCK-L-RF-ASSY 1
19 966-0616-20 LOCK-L-LF-ASSY 1
20 966-0618-21 EJECT-B-ASSY 1
21 966-0624-23 DISC-HOL-ASSY 1
22 001-7042-00 DIODE (GL4800) 4
23 013-7414-50 DETECTOR SWITCH 1
24 039-1954-00 LED-L-PWB 1
(WITHOUT COMPONENT)
25 039-1955-00 LED-R-PWB 1
(WITHOUT COMPONENT)
26 039-1956-00 SENSOR PWB 1
(WITHOUT COMPONENT)
27 039-2009-00 PIM FPC 1
28 039-2010-00 RIV-FOC 1
29 039-2011-00 LED-FPC 1
30 039-2012-00 SENSOR-FPC 1
31 039-2013-00 MOS-FPC 1
32 039-2014-00 L-MOTOR-FPC 1
(WITHOUT COMPONENT)
33 051-5806-01 IC (GPIS93) 1
34 051-5806-02 IC (GPIS95) 1
35 060-0252-01 PHOTO-TR 4
36 347-6657-01 LO-COVER SHEET 1
37 620-1041-23 GEAR PLATE 1
38 620-1042-20 M-GEAR-H 1
39 620-1056-21 HLR-PLATE-L 1
40 620-1057-21 HLR-PLATE-R 1
41 620-1063-20 LO-MOTOR-PLT 1
42 620-1066-10 LOCK LINK-LR 1
43 620-1067-01 SLIDE PLATE-L 1
44 620-1068-22 SLIDE PLATE-R 1
45 620-1071-11 EJECT ARM 1
46 620-1072-10 EJECT PLATE 1
47 620-1073-10 FRONT PLATE 1
48 620-1083-10 FPC-PLATE 1
49 620-1090-20 GAP PLATE 1
50 620-1568-20 RATTLE PLATE-F 2
51 621-0640-20 V-GEAR-G 1
52 621-0641-21 PI-HOLDER-M 1
53 621-0656-21 PI-HOLDER-V 1
54 622-1622-00 SL-G-ROLLER 2
55 622-1623-00 SL-G-ROLLER-R 2
56 622-1648-02 DU-STP-SLEEVE 1
57 622-1650-02 COV-PLATE PIN-B 2
58 622-1651-00 LOCK-RE-ROLLER 1
59 622-1652-00 LOCK-PF-ROLLER 1
60 716-1866-00 SCREW (M1.7 x 3) 4
61 716-1873-00 SCREW (M2 x 1.6) 1
62 716-3449-00 SCREW (M2 x 3) 15
63 716-3450-00 SCREW (M1.7 x 2) 4
64 716-3451-00 SCREW (M1.7 x 2.5) 4
65 716-3459-00 SCREW (M1.7 x 5) 1
66 716-3466-02 SCREW 1
67 738-1420-17 PRECISION SCREW 2
68 743-1200-20 E-RING 2
69 743-1500-10 E-RING 13
70 746-0624-00 WASHER 1
71 746-0712-03 WASHER 1
72 746-0761-00 WASHER 1
73 750-3478-01 TOP-P-SP-L 2
74 750-3479-01 TOP-P-SP-R 1
75 750-3480-01 DR-LOCK-SP 1
76 750-3483-00 EJECT-A-SPRING 1
77 750-3484-01 DR-BASE-SPRING 1
78 750-3485-01 TENSION-SP-L 1
79 750-3486-01 LO-TENSION-SP 1
80 750-3489-00 DRIVE-P-SPRING 1
81 750-3496-00 GAP-P-SPRING R 1
82 750-3497-00 GAP-P-SPRING L 1
83 750-6711-01 DU-STP-SPRING 1
84 750-6712-01 DR-LOCK-SP-B 1

-8-
PU-2426A-A
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
1 HBS-514-100 CLAMPER SUB ASSY 1
2 SMA-185-100 SPINDLE MOTOR ASSY 1
3 SMA-184-100 SLED MOTOR ASSY 1
4 HBS-515-101 LS-ASSY 1
5 620-1587-00 SH-SPRING 1
6 966-0622-22 D-SHIFT-P-ASSY 1
7 969-0009-00 PICK UP-ASSY 1
8 013-7414-50 DETECT SWITCH 1
9 039-2015-01 P/U-FPC 1
10 039-2016-01 M/S-FPC 1
11 347-6632-00 PU-SHEET 1
12 620-1078-20 PUSH PLATE 1
13 620-1080-21 PU-GUIDE PLATE 1
14 620-1081-20 SCREW PUSH-PLT 1
15 620-1082-22 SPRING PLATE 1
16 620-1588-20 SCREW-HOL-PLT 1
17 621-0670-20 LS-HOLDER-L 1
18 621-0673-20 D-GEAR A 1
19 621-0674-20 D-GEAR B 1
20 621-0675-20 D-GEAR C 1
21 621-0683-21 DU-STOPPER 1
22 716-3460-00 SCREW (M1.4 x 1.8) 2
23 716-3470-00 SCREW (M1.7 x 3) 5
24 738-1722-17 PRECISION SCREW 2
25 738-2025-17 PRECISION SCREW 2
26 716-3474-00 SCREW (M1.7 x 3) 2
27 743-1500-20 E-RING 1
28 750-3487-00 SHIFT-P-SPRING 1
29 750-3504-00 CLAMP-A-SPRING 1
30 966-0619-25 DRIVE PLT-ASSY 1
31 745-0807-00 WASHER 1
32 745-0808-00 WASHER 1
CD changer mechanism section 3/3 : Drive unit

-9- PU-2426A-A
ELECTRICAL PARTS LIST
Main PWB(B1) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Note) Severaldifferentpartsofthesamereferencenumberarealternativeparts.
Oneofthosepartsisusedintheset.
C101 046-1032-78 0.01uF
C102 046-1032-78 0.01uF
C103 046-1032-78 0.01uF
C104 046-1032-78 0.01uF
C105 046-1032-78 0.01uF
C201 046-1032-78 0.01uF
C202 042-0595-62 16V10uF
C203 046-1032-78 0.01uF
C204 046-1032-78 0.01uF
C205 042-0595-62 16V10uF
C206 046-1032-78 0.01uF
C207 168-1042-78 16V 0.1uF
C209 042-0595-62 16V10uF
C210 046-1032-78 0.01uF
C212 168-1042-78 16V 0.1uF
C213 046-1022-58 1000pF
C214 045-1201-50 12pF
C215 046-1032-78 0.01uF
C216 045-2201-50 22pF
C217 045-2201-50 22pF
C225 163-1073-15 6.3V100uF
C226 046-1032-78 0.01uF
C227 163-1073-15 6.3V100uF
C228 046-1032-78 0.01uF
C301 046-1032-78 0.01uF
C302 046-1032-78 0.01uF
C304 046-1032-78 0.01uF
C305 046-1032-78 0.01uF
C306 042-0427-94 16V47uF TAN
C307 046-1032-78 0.01uF
C308 046-1032-78 0.01uF
C309 163-1073-35 16V100uF
C310 046-1032-78 0.01uF
C311 046-1032-78 0.01uF
C312 168-2245-79 0.22uF
C313 163-2273-25 10V 220uF
C315 163-1063-35 16V10uF
C316 163-1073-15 6.3V100uF
C318 163-4763-35 16V47uF
D301 001-0529-33 MA8056-H
D302 001-2403-90 M1F60
D303 001-0516-90 MA111
D304 001-0516-90 MA111
D305 001-0516-90 MA111
D306 001-0516-90 MA111
D307 001-0516-90 MA111
FIL201 010-3024-50 BLM11A221
IC101 052-xxxx-xx CAUTION
IC102 051-7239-38 SN74AHCT08PWR
IC103 051-7511-38 TC74LCX07
IC201 051-9402-58 BR93LC56
IC202 051-6632-08 OS8104
IC203 051-6919-08 NJU6391PE
IC302 051-3279-90 BA033LBSG-TR
IC304 051-1556-09 S-80840CNUA
IC305 051-3298-90 TDA3664/N
IC306 051-5413-09 S-80824KNUA
IC306 051-5413-09 S-80824KNUA
J101 074-1189-95 45P
J401 074-1201-70 20P
J401 074-1100-70 52746-2090 FPC
L201 010-2285-62 BLM11A601SPB
L208 010-2285-62 BLM11A601SPB
L209 010-2285-62 BLM11A601SPB
P101 076-0313-10 10P
P202 076-0485-18 18P
Q201 192-2712-00 2SC2712
Q202 125-0002-92 RN2402
Q203 125-2004-92 RN1402
Q301 193-1758-00 2SD1758TK-P,Q,R
Q302 125-0014-92 DTA114EK
Q303 125-2004-92 RN1402
Q305 125-0014-92 DTA114EK
Q306 125-2004-92 RN1402
Q308 190-1162-00 2SA1162
Q309 125-2004-92 RN1402
R101 033-4721-15 1/16W 4.7k ohm
R102 033-1011-15 1/16W 100 ohm
R103 033-4721-15 1/16W 4.7k ohm
R104 033-4721-15 1/16W 4.7k ohm
R105 033-4731-15 1/16W 47k ohm
R106 033-4731-15 1/16W 47k ohm
R107 033-4731-15 1/16W 47k ohm
R108 033-1041-15 1/16W 100k ohm
R109 033-1041-15 1/16W 100k ohm
R110 033-1041-15 1/16W 100k ohm
R111 033-1041-15 1/16W 100k ohm
R112 033-1041-15 1/16W 100k ohm
R113 033-4731-15 1/16W 47k ohm
R114 033-4731-15 1/16W 47k ohm
R115 033-1011-15 1/16W 100 ohm
R116 033-0000-05 1/16W 0 ohm
R118 033-2241-15 220k ohm
R119 033-2241-15 220k ohm
R120 033-2241-15 220k ohm
R121 033-4731-15 1/16W 47k ohm
R122 033-2241-15 220k ohm
R123 033-4731-15 1/16W 47k ohm
R124 033-1041-15 1/16W 100k ohm
R125 033-3321-15 1/16W 3.3k ohm
R126 033-3321-15 1/16W 3.3k ohm
R127 033-3321-15 1/16W 3.3k ohm
R128 033-3321-15 1/16W 3.3k ohm
R129 033-3321-15 1/16W 3.3k ohm
R130 033-3321-15 1/16W 3.3k ohm
R201 033-4721-15 1/16W 4.7k ohm
R202 033-1011-15 1/16W 100 ohm
R203 033-4721-15 1/16W 4.7k ohm
R204 033-1011-15 1/16W 100 ohm
R205 033-0000-05 1/16W 0 ohm
R206 033-1031-15 1/16W 10k ohm
R207 033-4731-15 1/16W 47k ohm
R208 033-1031-15 1/16W 10k ohm
R209 033-2221-15 1/16W 2.2k ohm
R210 033-3941-15 390k ohm
R211 033-1031-15 1/16W 10k ohm
R212 033-0000-05 1/16W 0 ohm
R213 033-1001-15 1/16W 10 ohm
R214 033-1011-15 1/16W 100 ohm
R220 033-3331-15 1/16W 33k ohm
R221 033-3331-15 1/16W 33k ohm
R301 033-3341-15 330k ohm
R302 033-5641-15 560k ohm
R303 116-1511-15 1/8W 150 ohm
R304 116-2291-15 1/8W 2.2 ohm
R305 033-2241-15 220k ohm
R308 033-2241-15 220k ohm
R313 032-0092-92 1/10W 220k ohm F
R314 032-0092-36 1/10W 470k ohm F
R315 033-8241-15 820k ohm
R316 033-8241-15 820k ohm
X101 060-1511-90 CSTCV16.00MXJ0
X201 061-3038-00 HC49 16.9344MHz
Switch PWB(B2) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C401 168-1042-78 16V 0.1uF
D401 001-7065-90 GREEN
D402 001-7065-90 GREEN
D403 001-7065-90 GREEN
D404 001-7065-90 GREEN
D405 001-7065-90 GREEN
D406 001-7065-90 GREEN
D407 001-7065-90 GREEN
D413 001-2601-90 MA728-TX
D414 001-2601-90 MA728-TX
D415 001-2601-90 MA728-TX
D416 001-2601-90 MA728-TX
D417 001-2601-90 MA728-TX
D418 001-0529-31 MA8056-L
D419 001-0529-31 MA8056-L
D420 001-0529-31 MA8056-L
D421 001-0529-31 MA8056-L
D422 001-0529-31 MA8056-L
D423 001-0529-31 MA8056-L
IC401 051-6617-08 NJU3715G-TE2
J401 074-1201-70 20P
J401 074-1100-70 52746-2090 FPC
Q401 190-1298-00 2SA1298
Q402 125-2004-92 RN1402
Q405 125-2004-92 RN1402
R401 119-4711-15 1/16W 470 ohm
R402 119-4711-15 1/16W 470 ohm
R403 119-4711-15 1/16W 470 ohm
R404 119-4711-15 1/16W 470 ohm
R405 119-4711-15 1/16W 470 ohm
R406 119-4711-15 1/16W 470 ohm
R407 119-4711-15 1/16W 470 ohm
R408 119-4711-15 1/16W 470 ohm
R409 119-4711-15 1/16W 470 ohm
R410 119-4711-15 1/16W 470 ohm
R411 119-4711-15 1/16W 470 ohm
R412 119-4711-15 1/16W 470 ohm
R413 119-8211-15 1/16W 820 ohm
R414 119-8211-15 1/16W 820 ohm
R415 033-5621-15 1/16W 5.6k ohm
R416 033-5621-15 1/16W 5.6k ohm
R417 033-5621-15 1/16W 5.6k ohm
R418 033-5621-15 1/16W 5.6k ohm
R419 033-4731-15 1/16W 47k ohm
R420 033-5611-15 1/16W 560 ohm
R423 033-1031-15 1/16W 10k ohm
R424 033-0000-05 1/16W 0 ohm
S401 013-7415-50 DETECTOR
SWITCH
TM401 073-0766-90 OG-503040
TM402 073-0766-90 OG-503040
TM403 073-0766-90 OG-503040
TM404 073-0766-90 OG-503040
TM405 073-0766-90 OG-503040

-10-
PU-2426A-A
CONNECT-PWB(B3) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C501 172-1041-11 0.1uF
C502 184-3383-31 16V3300uF
C503 163-2273-25 10V 220uF
C504 178-3342-78 0.33uF
C505 168-1042-78 16V 0.1uF
C506 163-2273-25 10V 220uF
C507 178-3342-78 0.33uF
C508 168-1042-78 16V 0.1uF
D501 001-2015-00 RL253
IC501 051-3260-00 BA05ST
IC502 051-3289-00 BA09ST
J501 074-1293-00 PIN HEADER
J502 074-1297-18 18P
T501 009-9006-60 CHOKE
TM1 073-0762-90 TERMINAL
TR501 010-3401-90 SBS9080-5
CD changer maechanism section
CD PWB(B4) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C1 045-1201-50 12pF
C2 046-1022-58 1000pF
C3 168-1042-78 16V0.1uF
C4 042-0636-54 4V220uF
C5 168-1042-78 16V0.1uF
C6 046-1032-78 0.01uF
C7 168-1042-78 16V0.1uF
C8 178-4742-78 0.47uF
C9 178-2242-78 0.22uF
C10 168-1042-78 16V0.1uF
C11 168-1042-78 16V0.1uF
C12 168-1042-78 16V0.1uF
C13 046-2232-78 0.022uF
C14 168-5612-55 560pF
C15 168-1042-78 16V0.1uF
C16 046-2212-58 220pF
C17 046-2212-58 220pF
C18 168-1222-55 1200pF
C19 046-3322-58 3300pF
C20 168-3932-78 0.039uF
C21 168-3932-78 0.039uF
C22 042-0416-52 10V10uF TAN
C23 045-1201-50 12pF
C25 178-1052-78 1uF
C26 042-0472-91 16V47uF
C27 178-3342-78 0.33uF
C29 168-2732-55 16V0.027uF
C30 042-0416-58 4V100uF
C31 042-0636-52 4V47uF
C32 046-1022-58 1000pF
C33 046-6822-58 6800pF
C34 168-2732-55 16V0.027uF
C35 178-2742-78 0.27uF
C36 178-1052-78 1uF
C37 168-1042-78 16V0.1uF
C38 042-0472-91 16V47uF
C39 042-0636-50 6.3V100uF
C40 045-1211-50 120pF
C41 045-5601-50 56pF
C42 168-1042-78 16V0.1uF
C43 042-0636-52 4V47uF
C50 168-1042-78 16V0.1uF
C51 168-1042-78 16V0.1uF
C60 168-5612-55 560pF
C61 045-1201-50 12pF
D1 001-0516-90 MA111
IC1 051-6365-00 MN662785TBUC
IC2 051-9318-00 MSM51V17400D
IC3 051-6060-08 BD7961FM-E2
IC4 051-5711-90 AN8882SB-E1
J1 074-1189-95 45P
J4 074-1138-56 6P
J5 074-1201-65 15P
J6 074-1059-76 26P
L2 010-2155-93 10uH
Q2 131-1188-00 2SB1188
Q3 131-1188-00 2SB1188
R1 033-0000-05 0 ohm JW
R2 033-1041-15 1/16W 100k ohm
R3 033-3311-15 1/16W 330 ohm
R4 033-6811-15 1/16W 680 ohm
R5 033-1041-15 1/16W 100k ohm
R6 033-3931-15 1/16W 39k ohm
R7 033-1041-15 1/16W 100k ohm
R10 033-1011-15 1/16W 100 ohm
R11 033-3911-15 1/16W 390 ohm
R12 033-2221-15 1/16W 2.2k ohm
R13 033-6831-15 1/16W 68k ohm
R14 033-5621-15 1/16W 5.6k ohm
R15 033-1021-15 1/16W 1k ohm
R16 033-5631-15 1/16W 56k ohm
R17 033-1031-15 1/16W 10k ohm
R18 033-1031-15 1/16W 10k ohm
R19 033-5621-15 1/16W 5.6k ohm
R20 033-6831-15 1/16W 68k ohm
R21 033-5621-15 1/16W 5.6k ohm
R22 033-1031-15 1/16W 10k ohm
R23 033-1031-15 1/16W 10k ohm
R24 033-4731-15 1/16W 47k ohm
R25 033-3931-15 1/16W 39k ohm
R26 033-6831-15 1/16W 68k ohm
R27 033-6831-15 1/16W 68k ohm
R28 033-1031-15 1/16W 10k ohm
R29 033-2201-15 1/16W 22 ohm
R31 033-8211-15 1/16W 820 ohm
R32 033-5631-15 1/16W 56k ohm
R33 033-6831-15 1/16W 68k ohm
R34 033-3331-15 1/16W 33k ohm
R35 033-6831-15 1/16W 68k ohm
R38 033-3931-15 1/16W 39k ohm
R39 033-1831-15 1/16W 18k ohm
R40 117-1001-15 1/10W 10 ohm
R41 033-6821-15 1/16W 6.8k ohm
R42 033-6821-15 1/16W 6.8k ohm
R43 033-1241-15 1/16W 120k ohm
R44 033-6831-15 1/16W 68k ohm
R45 116-4711-15 1/8W 470 ohm
R46 117-1811-15 1/10W 180 ohm
R47 116-4711-15 1/8W 470 ohm
R48 033-1031-15 1/16W 10k ohm
R49 033-1011-15 1/16W 100 ohm
R60 033-1031-15 1/16W 10k ohm
TM1 073-0768-90 TERMIMAL
Sensor PWB(B5) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
PT3 060-0252-01 PT4850F
PT4 060-0252-01 PT4850F
PT5 060-0252-01 PT4850F
PT6 060-0252-01 PT4850F
S1 013-7414-50 SPVG22 IC5 051-5806-02 GPIS95
Driver PWB(B7) section
PIM-FPC(B6) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C1 168-1045-56 0.1uF
C2 163-1073-35 16V100uF
D1 001-0529-32 MA8056-M
IC1 051-6044-18 BA6920FP-Y
J1 074-1239-76 26P
J2 074-1100-59 9P
R1 033-1021-15 1/16W 1k ohm
R2 032-0104-59 1/4W 2.2 ohm
R3 032-0104-59 1/4W 2.2 ohm
S1 013-7412-50 SPVG21
PIV-FPC(B8) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
IC6 051-5806-01 GPIS93
LED-L-PWB(B9) section
LED3 001-7042-00 GL4800
LED4 001-7042-00 GL4800
LED-R-PWB(B10) section
LED5 001-7042-00 GL4800
LED6 001-7042-00 GL4800
L-Motor-FPC(B11) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
M1 SMA-186-100 LOADING
M/S-FPC(B12) section
M2 SMA-185-100 SPINDLE
M3 SMA-184-100 SLED
S2 013-7414-50 SPVG22
