Clarion CMR-L1 User manual

CMR-L1
RGB LED Lighting Controlle r
wi th remote
Controleurd'eclairage LED RGB avec telecornmande
Controlador de iluminaci6n LED RGB con control remote
RGB LED -Beleuchtungssteuerung mit Fernbedienung
Dispositivo di controllo illuminazione LED RGB con telecomando
clariofi
~
MARINE AUDIO
©2021 Clarion Marine Aud io

General Connections
-
....I
I
~
~
c.;)
OO • fNDC)
NOTES
( Ro / 0
: iJ. . LED
...
GN
0
~cf; LED
@0
:o ·- LED
...
YL
0
~cl: LED
Yl
RO
Red
18AW G / 0.75 mm
2
•
Black
18 AW G / 0.75 mm
2
Red
22 AW G / 0. 34 mm
2
Green
22 AWG / 0.34 mm
2
Blue
22 AW G / 0.34 mm
2
Yellow
22 AW G I 0.34 mm2
-: 9 :- LED s 2A@ 14 . 4V DC
•: «• LEDx ( MAX ) s 2A@1 4.4V DC
• Install in a dry, well-ventilated location; do not install in an engine compartment
or ot her areas of extreme heat Do not installwhere it will be directly exposed
to the elements.
• To opt imize performance, avoidconfined installation locations or areas
surrounded by metal; maintain at least 25 cm (10 1n) of separation from any audio
signal cables.
• Makesure the to tal amperagedemands of all connected LED circuits does not
ex ceed the output capacity of the controller
• *Install a fuse (not included)at the main +12V power wire (Red) connection point
that 1s appropriate for the total current draw of all LED circuits (up to 10A)
• Forshort-circuitprotection, we recommend installing a fuse (not included)
at EACH speaker's + 12V LED connection lead Refer to yourspeaker's LED
specifications for ind1v1dual fuse values.

Control
I F . I
unction
I
(9
Power: On/Off
Demo Mode: On/Off
88
Dynamic Mode: Select from 20 modes
8 Dynamic Speed: Select from 10 levels
I Fixed Color: Select from 20 colors
C Brightness: Select from 8 levels
0
ooe Preset Color: Select from 7 colors
---
The dev,ce has been evaluated to meet general RF exposure requirements
The device can be used m portable exposure conditions,
compliance with exposure requirements
FCC Compliance Statement
This equipment has been tested and found to comply with the limits of Pan 15 of t he
FCC Ru l es These limits are designed to provide reasonable pro t ection against harmful
interference in a residential installation . This equipment generates, uses and can radiate
radio frequency energy and, 1f not installed in accordance with the instructions, may
cause harmful interference to radio commun ications However, there Is no guarantee
that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, the user 1s encouraged to try to
correct the interference by one or more of the following measures.
• Reorient or relocate the receiving antenna
Increase separation between the equipment and the receiver
- Connect the equipmen t to an out le t on a circuit different from that to which the
receiver 1s connected .
Consu lt the dealer or an experienced radio/TV technician for help.
Any changes or modifications no t expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment

Specifications
Dynamic Mod es 20
Dynamic Speed Levels 10
Static Colors
20
Direct Preset Colors 7
Br ightness Levels 8
Operating Voltage 10-15V DC
Operating Temp R ange
-4 °F to +158 °F
(-20 °C to + 70 °C)
Operating Frequency 433.92
MH z
Operating Range* Up to 15 m (49.2 ft)
Output Capacity 2 A (maximum)
Recommended Fuse Value 10A (maximum)
Transmitter Battery CR2025 (3V)
Dimensions 3.37 in x 1.57 in x 0.28 in
(Transmitter) 85.5 mm x40 mm x 7 mm
Dimensions 1.38 in x 0.51 in x 0.24 in
(Receive r) 35 mm x 13 mm x 6 mm
*Individual operating range will vary based on transmitter
battery level and installation conditions.
