Owner's Manual
PP-4360

1
Table of contents
1. System Overview ����������������������������������������������������� 2
Control of This Unit ���������������������������������������������������� 2
Steering Remote Control �������������������������������������������������� 3
Silver box to supply power and simulate some signals ��������������������������������� 4
2. Common Operations ��������������������������������������������������� 5
Home Menu ��������������������������������������������������������� 5
Audio Source Switch ���������������������������������������������������� 5
Displays ����������������������������������������������������������� 6
Settings ���������������������������������������������������������� 6
Connections �������������������������������������������������������� 7
Informations ��������������������������������������������������������� 7
3. Bluetooth Operations ��������������������������������������������������� 8
Bluetooth Settings ����������������������������������������������������� 8
Phone Settings ������������������������������������������������������ 9
Bluetooth Phone Operations ����������������������������������������������� 11
Bluetooth Audio Operations ����������������������������������������������� 15
4. iPod Operations ���������������������������������������������������� 17
iPod Connection ����������������������������������������������������� 17
iPod Mode Selection ��������������������������������������������������� 17
5. Using Apple CarPlay ������������������������������������������������� 18
6. Using Siri ��������������������������������������������������������� 19
7. Using Android Auto ��������������������������������������������������� 19
8. Declaration of conformity ����������������������������������������������� 20
English

2
English
1. System Overview
Control of This Unit
54
32
1
6
9
8
7
(Fig 1-1)
1
[POWER] button: press to turn audio playback on/off.
[VOLUME] knob: rotate to turn volume up/down.
2
[Day/Night] button: (short) change night mode;
(long) display OFF
3
[x]: track / folder down;
[v] button: track / folder up.
4
[MENU] button: press to enter the home menu screen.
5
[AUDIO] button: press to enter the audio source or
audio playback screen.
6
[TEL] button: press to switch to the Bluetooth phone
menu screen.
7
[CAMERA] button: open camera setting.
8
[BACK] button: press to return to the previous screen.
9
[TUNE]/[SCROLL] knob: rotate to tune up/down, track
up/down; press to switch sound.

3
English
Steering Remote Control
1
2
3 4 5 7 8
6
1
[+] button: volume up.
2
[-] button: volume down.
3
[x]: track / folder down
4
[v] button: track / folder up.
5
[BACK] button: press to return to the previous screen.
6
[OK] button: press to enter the audio source or audio playback screen.
7
[VR] button: start Siri.
8
[ ] button: press to switch to the Bluetooth phone menu screen or press to
hang up the calling.

4
English
Silver box to supply power and simulate some signals
NOT USE
the INPUT of +14V
NOT USE
NOT USE
Speed Knob
NOT USE
+B Switch, ACC Switch
and IGN Switch
These LEDS lights when each
switchs(+B, ACC, IGN) become
to turn on
PKB Switch and Navion Switch
NOT USE. Please make usre
to turn off these test switches.
Turning on+B and ACC switch is
as same as key position is ACC
Turning on+B and ACC and IGN switch
is as same as key position is on

5
English
2. Common Operations
Home Menu
1
Press the [MENU] button to enter
the main menu screen.
(Fig 2-1-1)
For the CarPlay Audio, Bluetooth
Audio and iPod touchkeys, you
shoud customize the home menu.
■Customize Home Menu
In the home munu screen ((Fig
2-1-1) page 5), please touch
Customize Home Menu to customize the
home menu.
1
(Fig 2-1-2)
(Next page)
1 2
(Fig 2-1-3)
1
widget icons
2
function icons
Drag an icon from the top area to the
bottom area.
Audio Source Switch
1
While in the audio playback
screen, press [AUDIO] button to
enter the audio source screen.
This unit supports AM/FM,
SiriusXM, USB/iPod, Bluetoot
Audio, Apple CarPlay and Android
Auto audio source plackback.
(Fig 2-2-1)

6
English
Displays
The audio source playback can be
displayed in the main display, home
menu widget display and the meter
display.
■Main display
(Fig 2-3-1)
■Home Menu Widget Display
For the widget display, please go to
the customized home menu ((Fig
2-1-2) page 5) to customize the
widget display.
(Fig 2-3-2)
(Fig 2-3-3)
■Meter Display
Some information is displayed in this
area.
Bluetooth audio playback, iPod ,
Apple CarPlay music or Bluetooth
phone call information is displayed,
too.
1
Please press the [X] or [V] button
of the steering remote control to
switch the menu item.
(Fig 2-3-4)
Settings
1
Press to enter the settings
screen.
(Fig 2-4-1)
(Fig 2-4-2)
■Sound Settings
1
In the settings screen((Fig 2-4-1)
page 6), please touch Sound to
enter the sound settings screen.

7
English
(Fig 2-4-3)
■Language Settings
1
In the settings screen((Fig 2-4-2)
page 6), touch Others and then
Language to enter the language set-
tings screen.
Connections
1
In the settings screen((Fig 2-4-
1) page 6), please touch
Connections to enter the connections
screen.
(Fig 2-5-1)
GBluetooth : touch to pair, connect or
delete Bluetooth device.
GWi-Fi : touch to connect Wi-Fi.
GUSB : touch to view the information
of connected USB.
GApps : touch to view the
information of connected Apps.
Informations
1
In the settings screen((Fig 2-4-1)
page 6), please touch Info to
enter the information screen.
(Fig 2-6-1)
2
Touch System Information to check the
system information.
(Fig 2-6-2)

8
English
3. Bluetooth Operations
Bluetooth Settings
3
In the settings screen((Fig 2-4-
1) page 6), please touch
Connections to enter Bluetooth
connections screen.
(Fig 3-1-2)
4
Touch to enter the Bluetooth
settings screen.
(Fig 3-1-3)
GBluetooth : Bluetooth on or off.
GAllow 2 Phones Simultaneously : allow
connect 2 phones with this unit
simultaneously.
GFavorite Phone : give top priority to
connect to this phone.
GFavorite Audio : give top priority to
connect to this audio device.
GDevice Name : edit the device name
of this unit.
GPIN : edit the PIN code.
■Pairing Bluetooth Device
Please turn Bluetooth of this unit to
be on before pairing.
1
On the Bluetooth connections
screen ((Fig 3-1-2) page 8),
touch Add New .
(Fig 3-1-4)
2
Look for this unit’s device name
from your Bluetooth device.
(Default device name: MYCAR)
3
According the prompt message,
please enter or confirm PIN
to pairing from your Bluetooth
device.
4
After successful pairing, it
will return to the Bluetooth
connections screen ((Fig 3-1-2)
page 8) and your Bluetooth
device is displayed in the paired
list. “Connected” is displayed
below the device name. And the
corresponding icons and
are lit.
■Connect , Disconnect or Delete a
Paired Bluetooth Device
On the Bluetooth connections screen
((Fig 3-1-2) page 8):
zTouch a paired Bluetooth device
to connect or disconnect to the
device.
zTouch to connect or
disconnect as a phone object.
zTouch to connect or
disconnect as a audio object.

9
English
zTouch to enter the device
information screen.
(Fig 3-1-5)
You can check the available
features of the device, including
Call, Phonebook, Send Text,
Receive Text, Audio Streaming.
Touch Delete to delete the paired
device.
Phone Settings
1
In the settings screen ((Fig 2-4-1)
page 6), touch Phone to enter
the phone setting screen.
(Fig 3-2-1)
GConnections : enter the Bluetooth
connections screen ((Fig 3-1-3)
page 8).
GAutomatic Hold : when there is a
coming call whether put the call
on hold or not automatically.
■Adding or Editing Quick Dial
1
In the phone setting screen ((Fig
3-2-1) page 9), touch Quick Dial
to enter the quick dial screen.
(Fig 3-2-2)
GDelete All : delete all of the quick
dial list.
2
Touch Edit to enter the quick dial
list screen.
(Fig 3-2-3)
G{Quick Dial List} : touch to edit or
delete the quick dial list.
3
Touch Add New to enter the adding
new list screen.

10
English
(Fig 3-2-4)
GCopy from Call History : copy from call
history as a quick dial.
GCopy from Phonebook : copy from
phonebook as a quick dial.
GEnter Number by Keypad : enter phone
nuber by keypad as a quick dial.
4
After copying or inputing, it enter
the quick dial register screen.
(Fig 3-2-5)
GEntry # : select another quick dial
as the new quick dial.
GName : change the quick name.
GNumber : input new number as
quick dial.
GType : change quick dial type
including Mobile, Main, Home,
Office and Other.
5
Touch OK to register the number
or list as a quick dial.
■Phonebook Settings
1
In the phone setting screen ((Fig
3-2-1) page 9), touch Phonebook
to enter the phonebook setting
screen.
(Fig 3-2-6)
GDownload Entire Phonebok : download
the entire phonebook from the
connecting phone manually.
GAuto Downloaded : while pairing or
connecting a Bluetooth device
the phonebook and call history
will be downloaded automatically.
GSort Phonebook by : switch sorting
method of phone book by first
name or last name.
■Text Message Settings
1
In the phone setting screen
((Fig 3-2-1) page 9), touch
Text Message to enter the text
message setting screen.
(Fig 3-2-7)
GText Message : turn the text message
function on or off.
GText Message Ringtone : whether there
is a ringtone notification when
receiving a text message.
GSignature : when this function setting
ON, when sending a texmessage,
the text message will be added a
signature “Sent from XXX”. “ XXX”
is the vehicle name of factory
configuration.
GAuto Reply : when this function
setting ON, reply the pre-set fixed
text message to the received new
mail. Auto reply only once, do not
reply if failed.

11
English
GAuto Reply Text Message : you can set
the fixed or customized message
as the auto reply text message.
GEdit Custome Text : add, edit or delete
the customized message for auto
replying.
■Notifications Settings
1
In the phone setting screen
((Fig 3-2-1) page 9), touch
Notifications to enter the notificitions
settings screen.
(Fig 3-2-7)
GDriver Only : while setting On, when
there is an incoming call or a new
text message, the incoming call
screen or the new text message
is not displayed in this unit's
displayer, and there is no ringtone
notification.
GRingtone : while setting On, when
there is an incoming call or a new
text message, there is ringtone
notification.
Bluetooth Phone Operations
Before operate the Bluetooth Phone
you must pair the mobile phone with
this unit. Refer to “Pairing Bluetooth
Device” on Page 8.
1
Press the [ ] button to enter the
phone menu screen.
If there is no phone connected,
besides the Connections , the other
keys are unavailable.
(Fig 3-3-1)
■Multipoint phone
This unit allow you connect 2 phones
with this unit simulataneously. You
can view the call history, phonebook,
text message and so on of the 2
connected phones. The device name
will appear the corresponding screen,
and you can switch the device in
some screens.

12
English
Take Phonebook for example. While
2 phones connected, you can change
the device.
■Download Call History,
Phonebook and Text Message
The call history, phonebook and text
message of the Bluetooth phone can
be downloaded to this unit.
While the “Auto Downloaded”
(Phonebook Settings page 8)and
“Text Message” (Text Message
Settings page 10) are set to ON,
when a Bluetooth phone is paired
connected with this unit at first time,
The call history, phonebook and
text message will be downloaded
automaticly.
Note:
GText message downloading is only
valid for the phones that support
text message downloaded.
1
While the “Auto Downloaded”
(Phonebook Settings page
10)and “Text Message” (Text
Message Settings page 10) are
set to ON, touch Phonebook ,
Call History or Text Message on the
phone menu screen ((Fig 3-3-
1) page 11) to enter the
call history, phonebook or text
message screen.
2
Touch Yes to go to the Phonebook,
Call History or Text Message list
screen.
If the call history, phonebook and
text message have already been
downloaded, they will be updated.
Please accept downloading when
the Bluetooth phone receives a
request.
3
After downloading is successful,
the call history, phonebook and
text message will be displayed on
the screen.
Note:
GThe phonebook and call history
will be downloaded or updated at
the same time.
■Make Outgoing Call
There are 5 ways to make outgoing
call.
(Fig 3-3-2)
Enter Numbers to Dial
1
In the phone menu screen
((Fig 3-3-1) page 11), Touch
Dial Number to enter the Dial
Number screen.
(Fig 3-3-3)
2
After finish entering the phone
numbers, touch OK to make

13
English
calling.
Call from Phonebook
1
In the phone menu screen ((Fig
3-3-1) page 11), touch Phonebook
to enter the phonebook screen .
(Fig 3-3-5)
2
Touch to select a contact to
display the details.
(Fig 3-3-6)
3
Touch to select a phone number
to call.
Call from Call History
1
In the phone menu screen ((Fig
3-3-1) page 11), touch Call History
to enter the call history screen.
(Fig 3-3-7)
2
Touch to select a call list to make
outgoing call.
Call from Text Message
1
Enter the text message screen
((Fig 3-3-12) page 14)
2
Touch Call to make outgoing call.
Call by Quick Dial
After adding quick dial list (Adding or
Editing Quick Dial page 9), you
can make outgoing call by quick dial.
1
In the phone menu screen(Fig
3-2-1), touch Quick Dial to enter the
quick dial screen.
(Fig 3-3-9)
GEdit : Touch to answer the call.
2
Touch a quick dial list to make
outgoing call.
■Incoming call
1
The following screen will be
displayed when there is an
incoming call.
(Fig 3-3-10)
GAnswer : Touch to answer the call.
GDecline : Touch to decline the call.
GHold Call : Touch to put the call on
hold.
■During a telephone call

14
English
1
The following screen is displayed
during a telephone call.
(Fig 3-3-11)
For 2 phones connected, the
Device Name is displayed.
GHang up : Touch to hang up the
phone to hang up the call.
GMute : You may touch if you do not
want other party to hear the call
under special circumstances.
Touch again to make the call
output from the vehicle speakers.
GDial Number : Open the number pad
if you need to enter PIN or code
for some special calls, or if you
want to make another outgoing
call.
GUse Handset : Touch to use your
phone to answer the call.
GSwitch Call : When you make
another outgoing call or there is
another incoming during calling,
touch to switch between the two
calls.
■Reading and Text Message
1
In the phone menu screen
((Fig 3-3-1) page 11), touch
Text Message to enter the Text
Message screen.
(Fig 3-3-12)
2
Touch to select a text message to
display the detailed text message.
(Fig 3-3-13)
GPrev. : switch to the previous text
message.
GNext : switch to the next text
message.
GCall : make outgoing call.
GReply : reply the text message.
■Volume setting
1
In the phone menu screen ((Fig
3-3-1) page 11), touch Volume to
enter the volume setting screen.
(Fig 3-3-14)
2
Touch + or - to adjust the ringtone
or outgoing call volume.

15
English
Bluetooth Audio Operations
This unit only supports the playing
of audio files instead of images or
videos.
Notes:
GBefore operate the Bluetooth
Audio you must pair this unit with
Bluetooth device which support
audio file playing.
GThe functions of some devices
may vary due to different types of
devices.
■Select Bluetooth Audio mode
1
Touch Bluetooth Audio on the audio
source screen ((Fig 2-4-1) page
6) to enter the Bluetooth Audio
playback screen.
(Fig 3-4-1)
If connected with the device which
support AVRCP 1.3, repeat and
random are unavailable; the
BT Menu is displayed as Connections ,
and touch it to enter the Bluetooth
connections screen ((Fig 3-1-2)
page 8).
If the playing track has an album
artwork, the upper right icon
will be displayed as the track's
album artwork.
■Track up / down
1
Touch x / vto go to the
previous or next track.
■Fast Forward / Fast Reverse
1
Long press x / vfor fast
reverse or fast forward.
■Pause / Play
1
Touch to pause.
2
Touch to resume playing.
■Repeat Play
1
Touch to switch the repeat play
mode.
: play one track repeatly.
: play all tracks repeatly.
: repeat off.
■Shuffle Play
1
Touch to switch the shuffle play
mode.
: play all tracks in random.
: random off.
■Bluetooth Menu
1
In the Bluetoothe audio playback
screen, touch BT Menu to enter the
Bluetooth menu screen.
(Fig 3-4-2)
GNow Playing : return to the playing
screen.
GCurrent List : go to the current list
screen.
GConnections : go to the Bluetooth
connection screen ((Fig 3-1-2)
page 8).
G{Folder List} : enter the folder to

16
English
select a track.

17
English
4. iPod Operations
This unit can play audio files stored
in an iPod. You can use it as an audio
device by simply copying desired
audio files into it.
iPod Connection
Connect iPod device to USB port.
When connecting iPod, this unit will
read the files automatically. The track
information display on the screen
once playback start.
iPod Mode Selection
1
Touch iPod in the audio source
screen ((Fig 2-4-1) page 6) to
enter the iPod playback screen.
(Fig 4-1-1)
If the playing track has an album
artwork, the upper right icon
will be displayed as the track's
album artwork.
■Track up / down
1
Touch x / vto go to the
previous or next track.
■Fast Forward / Fast Reverse
1
Long press x / vfor fast
reverse or fast forward.
■Pause / Play
1
Touch to pause.
2
Touch to resume playing.
■Repeat Play
1
Touch to switch the repeat play
mode.
: play one track repeatly.
: play all tracks repeatly.
: repeat off.
■Shuffle Play
1
Touch to switch the shuffle play
mode.
: play all tracks in random.
: random off.
■iPod Menu
1
In the iPod playback screen((Fig
4-1-1) page 17), touch iPod Menu
to enter the iPod menu screen.
And the category list is displayed.
{Category List}
(Fig 4-1-2)
GNow Playing : return to the playing
screen.
GCurrent List : go to the current list
screen.
GAlbum Artwork : set the album artwork
of the playing track is diaplayed
or not in the playbak screen ((Fig
4-1-1) page 17).
G{Category List} : enter the category
list to select a track.

18
English
5. Using Apple CarPlay
Just connect your iPhone to this unit,
you can use Apple CarPlay, and the
iPhone screens are displayed on the
display and operated.
Various functions such as destination
guidance, call incoming / outgoing,
text message sending / receiving,
audio playback, etc. can be used.
zSupported iPhones: iPhone 5
above
zSupported OS: iOS 7.0 above
Please use the supported iPhones,
otherwise the Apple CarPlay
functions will not be used abnormally.
Request:
GWhen you use the Apple CarPlay
function, iPhone communication
fee will be charged. The
communication fee will be borne
by the subscriber of the used
iPhone.
GDepending on how you use it,
the charge from mobile phone
company may be expensive.
Please check the price plan
and usage of your mobile
phone company in advance.
Depending on usage frequency,
we recommend using the optimum
rate plan such as flat rate data
plan.
Notes:
GApple CarPlay's operations may
be restricted while driving.
GIf the radio wave condition of the
iPhone is bad, the operations of
Apple CarPlay may be restricted.
GOperations such as audio
playback may be restricted due
to restrictions of Apple CarPlay
application.
GApple CarPlay's operations may be
restricted depending on the model
and state of the iPhone.
■Starting Apple CarPlay
1
Please connect your iPhone to
the unit’s USB port with the Apple
lightning cable supplied with your
iPhone.
The first time you connect, a
prompt screen will appear.
Touch OK .
(Fig 5-1-1)
2
Touch Ye s to use Apple CarPlay.
(Fig 5-1-2)
3
Press the [ ] button, it will enter
the CarPlay phone screen;
press the [AUDIO] button, it will

19
English
enter the audio souce screen ((Fig
2-4-1) page 6), and touch
Apple CarPlay to enter the CarPlay
music playck screen.
Note:
GAfter starting Apple CarPlay, the
Bluetooth connection with the
iPhone will be disconnected.
■To end the Apple CarPlay
Disconnect the iPhone from the USB
port of this unit.
6. Using Siri
During Bluetooth connection with
iPhone, you can use iPhone’s voice
assistant “Siri”.
zPush and hold [VR] button on
steering switch.
7. Using Android Auto
■Preparation and Connection
1
Use the Google Play store in
your Android smartphone to
download and install Android Auto
application.
2
Connect the Android smartphone
to the USB interface by the data
cable supplied with Android
smartphone.
3
When the connection prompt
screen appears, touch [OK] to
establish the connection.
