Phaeton Series Tank Lights
STORAGE and HANDLING
Jacoby-Tarbox Phaeton Series Tank Lights
meet or exceed all applicable specifications when
they are shipped from the factory. Even thought
this unit is called a tank light, it may be installed
on sight flow indicators also.
All units should be inspected upon receipt to
ensure that no damage has been incurred during
transit. If there has been, a claim should be filed
with the carrier immediately. Units should be
stored in an area protected from the elements
and corrosive fumes, in a secure manner where
they can neither fall, nor be struck by other
objects. Care should be taken to protect the
window and the end connections from damage.
Avoid placing any objects directly on the light at
any time.
COMPONENTS
There are three main components that make up
the Phaeton Series light, the light ring, the power
supply, and the cable connecting these two main
pieces. The cable may have more than one piece
depending on the required distance between the
light ring and the power supply.
INSTALLATION
CAUTION: All lights are taggedwith
the service conditions for that particular unit.
These specifications are located on the
Jacoby-Tarbox tag on the power supply
housing, and are contained in the
“Specifications”section of this manual. Do
not use or refer to specifications listed on red
label on the power supply housing. They are
specification for generic use. Review the
ratings prior to installation and again prior
to start-up, to ensure proper operation in the
installed environment. Should there be any
doubt as to the applicability of a unit for the
installed environment, consult the factory
before placing the unit into service.
Note: All installation steps should be
performed by a qualified technician and
should be executed in accordance with all
applicable national and local codes.
The light and power supply should be
checked to ensure that they contain no foreign
matter, and that the end connections are clean,
undamaged, and in line with existing conduit.
Step by step instructions:
1) Place the light ring directly on to the
desired window.
2) Hold the ring in place and pull the
mounting bracket beyond the perimeter of
the window’s retaining flange. The
opening in the bracket should allow it to
slip over the retaining flange. The
thumbscrew should be pointing, away
from the window. Repeat this step for the
other two mounting brackets.
3) Once all three brackets are in place,
tighten the thumbscrews to secure the light
ring.
4) Remove the cap in the ½” NPT conduit
connection. Open the housing. The
power supply has a pluggable, 2-position
terminal block ready to connect to the
customer’s power. All electrical
specifications must comply with NEC
guidelines. After connecting the power,
close the housing.
5) IMPORTANT: The customer must
have a sealing fitting in the conduit
supplying power to the light’s power
supply within 18” of the power supply.
Section: T500
Bulletin: T500.6
Date:
08/03
Supersedes: 07/03
INSTALLATION, OPERATING
& MAINTENANCE
INSTRUCTIONS
NORTHEAST CONTROLS INCORPORATED
TEL: [phone] | FAX: [phone]
www.nciweb.com
NORTHEAST CONTROLS INCORPORATED
TEL: [phone] | FAX: [phone]
[email protected]

2
CAUTION: Prior to starting step 6, verify
that the area is free of flammables.
6) Remove the cover on the power supply
once the power has been turned on. An
LED will be lit if it is wired correctly.
7) If the LED in the power supply is not lit,
check the power source and the
connection before continuing.
8) If the LED in the power supply is lit,
replace the cover on the power supply, and
connect the light ring to the power supply
using only the cable supplied.
9) If the cable will not reach the power
supply, contact your local representative
for the required extension cable.
OPERATION
Phaeton tank lights run continuously. The
operating life of the LED’s is 100,000 hours
under normal conditions.
Customers may install a switch or timer if
desired. Any additional components must be
installed prior to the customer’s sealing fitting.
ROUTINE MAINTENANCE
Keep window on the front of the light clean
using commercial glass cleaners, such as
Windex®or similar. Never use harsh abrasives,
wire brushes, metal scrapers, or any material that
could scratch the window. The window may be
cleaned while the unit is in operation.
The light may be removed while the unit is
in operation during inspection or maintenance of
the customer’s sight window or sight flow
indicator. The light ring may also be
disconnected from the power supply, if desired.
Disconnect the cord at the supplied screw
connector adjacent to the power supply. The
plant power going to the power supply does not
need to be disconnected.
Figure 1: Typical Phaeton Installation in Hazardous Environment
SPECIFICATIONS
Power Supply: 120 or 240 VAC @ 50-60 Hz
24V DC (600 mA)
Power <1.0 Amp @120 VAC
Consumption: <0.5 Amp @ 240 VAC
Est. Life: 100,000 Hours (continuous)
Agency Approvals: FM and CSA
Ratings:
Class I, Div 1, Grps. B, C,
& D
Class II, Div 1, Grps. E, F, & G
Cenelec Rated to:
Eexd _________
Eexia, and IP 66 per IEC 529
Wire Size: Min 18 AWG / Max 12 AWG
Max dist. from 90’ (27.5 M)
power supply to light:
Standard Cable = 8’ (2.5M)
