Clarke Strong-Arm CFSR360 Instruction Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
LS1219 ISS 1
ORIGINAL INSTRUCTIONS
360KG STEEL MESH FOLDING RAMP
MODEL NO: CFSR360
PART NO: 7610198

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
The CLARKE CFSR360 Steel Mesh Folding Ramp provides a safe and simple
solution to loading and unloading in-line narrow vehicles, wheelbarrows or
bikes from vans or trailers.
This ramp also includes an adjustable strap with hook to ensure the ramp is
secure when loading or unloading.
Before attempting to use this product, it is essential that you read this manual
thoroughly and carefully follow all instructions given. In doing so you can look
forward to the product giving you long and satisfactory service.
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of
12 months from the date of purchase. Please keep your receipt as proof of
purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
SAFETY PRECAUTIONS
1. Never overload the ramps. Maximum capacity for your ramp is 800 lbs
(360kg) per ramp; 1600 lbs (720 kg) per pair (all loads must be evenly
distributed).
2. Always use the safety strap to securely fasten the ramp to the vehicle or
trailer. This prevents the ramp from slipping off of the tailgate.
3. Carefully roll or winch equipment up or down the ramp. Never drive or ride
your equipment while loading or unloading.
4. Make sure the ramp is aligned with the wheels of any vehicle being loaded
or unloaded.
5. Always load or unload on a solid, level and stable surface with the vehicle
in gear, the parking/emergency brake on and the engine off.
6. Use as loading ramp only.
7. Ramp surfaces must be clean, dry and free from oil or grease or water.
8. Maximum recommended height of the tailgate that the ramp attaches to
should be no greater than 30 inches (76 cm).
9. Inspect the ramp before each use. Replace the safety strap if the webbing
is frayed or worn. Do not attempt to use a ramp that is damaged in any
way. Do not modify or alter the ramp in any way. Proper care of the ramp
is essential to safety.
10. Proper use of this product is critical to safety. Improper use may result in
personal or property damage which is not covered by your warranty.
11. During use, keep bystanders away from the ramp and load.
12. Maintain a secure footing and do not overreach.
WARNING: TO AVOID PERSONAL INJURY AND/OR PROPERTY DAMAGE,
PLEASE READ AND FOLLOW ALL OF THESE INSTRUCTIONS BEFORE USE.

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SETTING UP
1. Make sure you are loading on a hard, level surface.
2. Turn the engine off, place the vehicle in gear and set the hand brake on.
FITTING THE SECURING STRAP TO THE RAMP
1. Unfold and lay the ramp upside
down.
2. Slide the strap (with a loop) under
one of the cross members and
pass the free end through the
loop as shown.
3. Slide the free end of the strap into
the buckle on the second strap.
• Only pass a few inches through,
so you can tighten this up later.
4. Unfold and place the edge of the
ramp on the bed or tailgate of the
van.
• The tailgate should not be
more than 30" (76 cm) in height
or the ramp will be too steep.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
SECURING THE RAMP
5. Secure the ramp to the vehicle using the hook on the second strap.
6. Tighten the strap.
• After the strap is secure, test the
ramp by pulling backwards.
Make sure it does not slide
back or disengage from the
loading surface of the vehicle.
7. Once the ramp is secure and the
area is safe, proceed with
loading.
• During use, make sure that the
ramp does not bow from excessive weight.
AFTER USE
1. Loosen and unhook the strap and
fold the ramp.
2. Store in a clean, dry environment.

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SPECIFICATIONS
Please note that details and specifications contained herein, are correct at the time of
publishing. We reserve the right to change specifications at any time without prior
notice.
Model Number CFSR360
Maximum Load 800lb / 360 kg
Extended Dimensions (L x W x H) 2054 x 280 x 41 mm
Folded Dimensions (L x W x H) 1055 x 280 x 101 mm
Maximum Recommended Height Of The Tailgate 30 inches (76 cm)
Weight 11.5 kg
