Clarke PG6500ADVES Instruction Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
LS1216
5.5KVA PETROL GENERATOR
MODEL NO: PG6500ADVES
PART NO: 8857856

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE 5.5KVA Petrol Generator.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
ENVIRONMENTAL RECYCLING POLICY
Through purchase of this product, the customer is taking on the
obligation to deal with the WEEE in accordance with the WEEE
regulations in relation to the treatment, recycling & recovery and
environmentally sound disposal of the WEEE.
In effect, this means that this product must not be disposed of with general
household waste. It must be disposed of according to the laws governing
Waste Electrical and Electronic Equipment (WEEE) at a recognised disposal
facility.

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
GENERAL SAFETY RULES
WORK AREA
•Always use in a well ventilated area.
• Always position the exhaust outlet away from people.
• Never use indoors or in a confined space.
• Read these safety instructions before using the equipment.
• Keep children away from the generator.
POSITIONING THE GENERATOR
1. Always leave a least a 1m gap between the generator and any
surrounding building or structures.
2. Always ensure the generator is on a solid, flat surface.
3. Always ensure the surrounding area is free from any material that could
burn or be damaged by heat.
4. Never move or tilt the generator whilst it is switched on.
FIRE PREVENTION
1. Always switch the engine OFF when refuelling.
2. Always refuel away from any source of heat.
3. Always refuel in a well ventilated area.
4. Only use standard unleaded petrol.
5. Never overfill the tank, fill to the level specified (See “Checking the fuel
level” on page 11.).
6. Never smoke whilst refuelling and avoid smoking or using a naked flame
near the generator.
7. Never start the engine if there is spilled fuel. Any spillage must be wiped
clean and the generator allowed to dry before attempting to start the
engine.
WARNING: EXHAUST FUMES CAN BE EXTREMELY DANGEROUS IF INHALED

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PREVENTION OF ELECTRIC SHOCK
1. Never use the generator in wet conditions unless it is well protected/
covered. Under these conditions, adequate ventilation MUST be provided.
2. Never operate the generator with wet hands.
3. Never use water or any other liquids to clean the generator.
ADDITIONAL SAFETY RULES FOR GENERATORS
1. Always ensure the applied load does not exceed the generator rating.
Overloading the generator is dangerous and could cause serious
damage.
2. Always disconnect the generator when carrying out any maintenance.
3. Always ensure the generator reaches operating speed before connecting
a load.
4. Never allow the generator to run out of fuel when a load is connected.
5. Never transport the generator with fuel in the tank.
6. Do Not connect to a commercial or residential power supply; e.g. ring
main.
7. Never allow the generator air vents to become blocked.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SAFETY SYMBOLS
Caution - The user
should be aware of a
general hazard
Hot Surface - Do not
touch
Dangerous voltage Poisonous fumes - Do
not use the generator
in an enclosed space.
Flammable Read Instruction
manual before use

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
GENERATOR OVERVIEW
NO DESCRIPTION NO DESCRIPTION
1 Handles 8 Battery
2 Fuel Supply Valve 9 Wheel
3 Ignition Switch 10 Dipstick
4 Fuel Tank Cap 11 Starting Handle
5 Fuel Level Gauge 12 Air Filter
6Frame 13ChokeLever
7 Control Panel 14 Earth Point

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
UNPACKING AND ASSEMBLY
Unpack your generator and check to ensure the following items are present.
Should there be any deficiency or damage caused during transit contact
your CLARKE dealer immediately.
BEFORE USING THE GENERATOR
Attach a suitable earth lead to a good earthing point - water pipe, ground
spike etc., whenever you use this generator.
Before using your generator check that:
• The generator is in good condition and free from any damage.
• The generator is clean and free from fuel or oil spillage.
• The generator is correctly located for use (See page 3).
• The fuel system is intact and there is no leakage.
NOTE: Always use a funnel to fill the fuel tank to avoid accidental
spillage of fuel. If fuel is spilled it must be cleaned up before use.
1 x 5kW Petrol Generator 2 x Handle c/w fixings
1 x Axle c/w nuts & washers 1 x Spark Plug Box Spanner
2 x Wheel 1 x Tommy Bar
2 x Axle Brackets c/w fixings 1 x Pair of Ignition keys
2 x Foot Assembly c/w fixings 1 x Lead Acid Battery
WARNING: ENSURE THERE IS ADEQUATE FUEL IN THE TANK WHEN USING
THE GENERATOR. RUNNING OUT OF FUEL OR STOPPING THE ENGINE
SUDDENLY WITH A LOAD CONNECTED COULD CAUSE SERIOUS DAMAGE.
WARNING: ALWAYS CHECK THE OIL LEVEL BEFORE STARTING SEE
PAGE 10, FAILURE TO MAINTAIN THE CORRECT OIL LEVEL MAY SERIOUSLY
DAMAGE THE ENGINE.

8
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
FITTING THE WHEELS/FEET
1. Lay the generator on its front and
attach the 2 feet to the frame
using 4 x short bolts, 4 x washers, 4
x spring washers and 4 x nuts.
2. Slide both wheels on to the axle.
3. Secure the wheel to the axle using
the nut provided.
4. Place the axle against the frame
on the generator as shown.
5. Fix the axle to the frame using
2 x long bolts, 2 x washers, 2 x
spring washers and 2 x nuts.
6. Carefully place the generator
onto its wheels/feet.
FITTING THE HANDLES
1. Place the handle into position as
shown.
NOTE: The generator has not been
shown in the image for clarity
2. Secure the handle using the
flanged nut and bolt supplied
• Making sure that the 2 plastic
washers are inserted between
the handle and frame as
shown.

9
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
CONNECTING THE BATTERY
• Connect the negative wire
to the negative terminal on
the battery as shown on
the right.
• Connect the positive wire
to the positive terminal on
the battery.
• Ensure both terminals are
covered by the plastic
covers as shown.
EARTH POINT
1. Ground the generator by
connecting a suitable grounding
wire to the earth point.
NOTE: Connect the other end of the
grounding wire to a copper or
brass grounding rod that is driven
into the earth.
WARNING: FAILURE TO PROPERLY GROUND THE GENERATOR CAN RESULT
IN ELECTROCUTION

10
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
CHECKING THE ENGINE OIL LEVEL
1. Turn the dipstick anti-clockwise
and remove from the oil fill tube.
2. Wipe the dipstick with a clean
cloth.
3. Insert the dipstick back into the oil
fill tube and then remove it again.
Do not screw in the oil filler cap/
dipstick when doing this.
4. If the oil level is at or below the ‘L’
mark on the dipstick, add oil to
the crankcase.
• Fill until the oil reaches the
threads in the oil fill tube.
• Oil capacity (See page 21).
• We recommend the use of
SAE15W40 oil in this generator.
available from your CLARKE
dealer.
5. Replace the oil filler cap.
WARNING: TO CARRY OUT THIS CHECK, PLACE THE GENERATOR ON LEVEL
GROUND WITH THE ENGINE SWITCHED OFF.
WARNING: TAKE CARE NOT TO TOUCH ANY HOT PARTS OF THE
GENERATOR WHEN CHECKING THE OIL LEVEL.

11
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
CHECKING THE FUEL LEVEL
RECOMMENDED FUEL
Only use standard unleaded petrol.
1. Check the fuel level on the fuel
gauge.
The fuel gauge will show as red
when you have fuel in the tank
turning white as the fuel level
decreases
Empty Full
.
2. To add fuel, open the fuel filler
cap.
3.
Fuel filter
Just inside the fuel tank is a fuel
filter which catches any
contaminants as you refuel.
4. Slowly add fuel to the fuel tank
(maximum 25L) watching the fuel
level gauge as you do so.
NOTE: Do not overfill the fuel tank.
5. Replace the fuel filler cap securely.
WARNING: ALWAYS REFUEL IN A WELL VENTILATED AREA AWAY FROM
ANY HEAT SOURCES.
WARNING: ALLOW THE UNIT TO COOL DOWN BEFORE REFUELLING.
WARNING: DO NOT LEAVE FUEL WITHIN THE REACH OF CHILDREN.

12
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
USING YOUR GENERATOR
STARTING THE ENGINE
1. Remove all connections from the
AC sockets.
2. Set the fuel valve to the ON
position as shown.
3.
4. Move the choke lever to the
‘Choke’ position.
5. Insert the key into the ignition.
6. Turn and hold the key in the START
position.
7. Once the engine starts to run turn
the key back to the RUN position.
8. Once the engine has warmed up,
set the choke lever to the Run
position.

13
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
BACKUP STARTING PROCEDURE
If for any reason the engine will not start using the above procedure, you can
start your generator manually by carrying out the following.
1. Follow steps 1-4 in the previous
section.
2. Set the ignition key to the ON
position.
3. Hold the generator steady and
pull the starting handle lightly until
you start to feel resistance.
Then pull sharply to start the
engine.
• You may have to do this more
than once.
4. Once the engine has warmed up,
move the choke lever to the “run”
position.
WARNING: ONCE THE GENERATOR HAS STARTED, RELEASE THE STARTING
HANDLE SLOWLY TO AVOID INJURY/DAMAGE AS IT RECOILS.

14
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
CONNECTING ELECTRICAL DEVICES
The generator can supply both 230V AC and 115V AC.
The sockets are laid out in the
following order: (from left to right):
• 1 x 32amp 230v (Blue),
• 1 x 32amp 115v (Large Yellow)
• 1 x 16amp 115v (Small Yellow).
1. Connect the appliance to the
generator starting with the device
that draws the most current.
2. Select the voltage that you
require using the voltage selector
switch.
AC BREAKER
The AC Breaker will activate if the
generator is overloaded. If the AC
Breaker activates,
1. Remove any connected devices
from the generator.
2. Wait for a few minutes.
3. Set the AC breaker to the ON (up)
position.
4. Reconnect the devices to the generator, making sure you do not exceed
the maximum capacity of the generator.
CAUTION: MAKE SURE THAT THE APPLIANCE BEING CONNECTED IS IN
GOOD WORKING ORDER, IF IT BEGINS TO ACT ABNORMALLY OR STOPS
SUDDENLY, DISCONNECT IT FROM THE GENERATOR
CAUTION: MAKE SURE THE APPLIANCE DOES NOT EXCEED THE MAXIMUM
RATED LOAD FOR THE GENERATOR.
CAUTION: ANY DEVICE WHICH CONTAINS AN INDUCTIVE LOAD E.G.
DEVICES THAT CONTAIN A MOTOR MAY REQUIRE MORE CURRENT ON
STARTUP.

15
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SHUTTING DOWN THE GENERATOR
To stop the generator in an emergency simply set the engine switch to ‘OFF’.
NOTE: Turn off any electric devices.
1. Disconnect any electric devices.
2. Make sure that the AC breaker is
set to the off (down) position.
3. Turn the ignition key to the OFF
position.
4. Turn the fuel valve to “OFF”.

16
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
MAINTENANCE
CHANGING THE ENGINE OIL
1. Unscrew and remove the oil filler
cap/dipstick.
2. Place an oil collection tray under
the drain plug.
3. Place an oil collection tray under
the drain plug.
4. Unscrew the drain plug and allow
the used engine oil to drain from
the crankcase into the oil
collection tray.
NOTE: Drain the engine oil when the
engine is warm, this will ensure
the oil flows out faster.
5. Replace the drain plug.
6. Fill the crankcase with engine oil.
• Fill until the oil reaches the threads in the oil fill tube.
•Oil capacity (See page 21.).
• We recommend the use of SAE15W40 oil in this generator, available
from your CLARKE dealer.
7. Replace the oil filler cap/dipstick.
ENVIRONMENTAL PROTECTION
One of the most damaging sources of pollution is oil, Do not throw away used
engine oil in with your domestic rubbish or pour it down drains or sinks. Place it
in a leak proof container and take it to your local waste disposal site.
CAUTION: PROLONGED EXPOSURE TO USED ENGINE OIL IS HARMFUL,
ALWAYS WASH YOUR HANDS THOROUGHLY AFTER HANDLING USED
ENGINE OIL.

17
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
CHANGING THE SPARK PLUG
1. Remove the Side Panel bolts and
remove the side panel
2. Remove the spark plug cap from
the spark plug.
3.
Add pic
Use the spark plug spanner
supplied to remove the spark
plug.
4. Remove any carbon that has
accumulated around the
electrode.
5. Check the spark plug gap (a), it
should be between 0.7 and 0.8
mm, adjust if necessary.
6. Check the overall condition of the
spark plug for erosion or pitting
and replace if necessary.
7. Reinstall the spark plug and
replace the spark plug cap.
CAUTION: ALLOW THE ENGINE TO COOL BEFORE REMOVING THE SPARK
PLUG.

18
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
CHECKING THE AIR FILTER
1. Unclip and remove the air filter
cover.
2. Remove the air filter element.
3. Make sure that the air filter is
clean and not damaged.
•If the air filter is damaged
contact CLARKE spare parts
department for a replacement.
• If the filter is dirty, wash in a
solution of warm water and
mild detergent and rinse
thoroughly. Leave the filter to
dry completely, once it is dry immerse in clean engine oil and
squeeze to remove excess oil.
4. Replace the filter to its original position and replace the air filter cover.
CAUTION: DO NOT USE THE GENERATOR WITHOUT THE AIR FILTER FITTED,
THIS CAN DAMAGE THE GENERATOR.
WARNING: DO NOT USE INFLAMMABLE SOLVENTS OR PETROL TO CLEAN
THE AIR FILTER.

19
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
CLEANING THE FUEL VALVE FILTER / DRAINING THE FUEL TANK
1. Set the fuel supply valve to OFF.
2. U
VALVE FILTER
‘O’ RING
CUP
nscrew and remove the cup,
then remove the valve filter and
‘O’ ring.
3. Wash these parts in a non-
inflammable solvent. Make sure
that the valve filter is not
damaged.
4. Place an approved petrol storage
container under the fuel valve
and set the fuel supply valve to
‘ON’.
• The fuel in the tank will drain
into the container.
5. Replace the ‘O’ ring and valve
filter and tighten the cup as far as
possible.

20
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
The generator fails
to start
Ignition switch is off Set the ignition switch to ‘on’
Not enough oil in the generator Add more oil, See page 10
No fuel Add more fuel, See page 11
Spark plug not working correctly Change the spark plug, See
page 17
The generator fails
to generate elec-
tricity
The device you are trying to
power is faulty
Make sure the device you want
to power is working properly
The AC breaker is switched off Switch the AC breaker on
The generator is
difficult to start
The air filter is dirty Clean the air filter, See page 18
The fuel filter is blocked Clean the fuel filter, See page 19
If this does not solve your problem, please contact the CLARKE service
department.
OPTIONAL ACCESSORIES
A wide range of optional accessories are available from your CLARKE dealer
including:
