Classic Cantabile DP-60 User manual

000
22171/00023425/00023428
Version 01/2012
Classic Cantabile
DP
-
60
Users manual

2
Important Notes
Your piano will give you years of playing
pleasure if you follow the simple rules given
below:
Location
Do not expose the unit to the following
conditions to avoid deformation,
discoloration, or more serious damage.
Direct sunlight.
High temperature (near a heat source,
or inside a car under long exposure of
Sunlight.
Excessive humidity
Excessive dust
Strong vibration
Power Supply
Make sure to use the suitable AC
adaptor, and the AC outlet voltage at
your country matches the input voltage
specified on the AC adaptor s label.
Turn the power switch OFF when the
instrument is not in use.
An AC adaptor should be unplugged from
the AC outlet if the instrument is not
going to be used for an extended period
of time.
Unplug the AC adaptor during electric
storms.
Avoid plugging the AC adaptor into the
same AC outlets as appliances with high
power consumption, such as electric
heaters or ovens. Also avoid using multi-
plug adaptors since this could reduce
sound quality, causes operation errors
and damages.
'
's
Turn Power OFF When Making
Connections
To avoid damages, turn off the power
switches before you connect the unit to
the related devices or disconnect the
related devices from the unit.
Handling and Transporting
Never apply excessive force to the
controls, connectors or other parts of the
instrument.
Always unplug cables by gripping the
plug firmly, but not pulling the cables.
Disconnect all cables before moving the
instrument.
Physical shocks caused by dropping,
bumping, or placing heavy objects on the
instrument could result in scratches or
even severe damages.
Cleaning
Clean the unit with a soft dry cloth.
A slightly damp cloth may remove
stubborn grime and dirt.
Never use cleaners such as alcohol or
thinner.
Avoid placing vinyl object on top of the
unit (vinyl might discolor and stick to the
surface).
Electrical Interference
This instrument contains electric circuitry
and may cause interference if it is placed
too close to radio or television receivers.
If this occurs, move the instrument
further away from the receivers.

Summarize
Main Features
Keyboard:
88 touch keyboard with 3 touch levels.
Operation:
Use the [+/YES] & the [-/NO] button or direct select button to select desired function & parameters.
Voice:
20 voices in total with 10 select buttons.
Voice demo :
It helps you to get an idea of what the voice selected is capable of doing.
Style:
20 piano styles in total, use the [+/YES] & the [-/NO] button to select.
Song:
60 songs in total, each one has self-learning mode.
Song learning:
Use the [TRACK1/SONG MELODY OFF] button to enter.
Record:
1 user song, include 2 track tracks.
SD card:
Play midi files, save recorded data.
Style control buttons:
START/STOP, ACC VOL, FILL A/FILL B.
Others function buttons:
DUAL, SPLIT, REVERB/CHORUS, METRO, TRANSPOSE +/-, TOUCH, etc.
Buttons with indicator:
FILL A/FILL B, RECORD, PLAY/STOP, ACC VOL, SPLIT, DUAL, REVERB/CHORUS, TOUCH, METRO,
(SD)STORE, (SD)PLAY/STOP, TRACK 1/SONG MELODY OFF, TRACK2, SCALE.
Pedal:
Sustain pedal, soft pedal, sostenuto pedal.
Interface:
MIDI IN/OUT, USB, HEADPHONE, AUX.OUT
This piano is an easy to use digital piano. It has advanced functions especially in midi controler.
This piano elaborated 20 beautiful voices, you can select them directly by using 10 Direct Select Button.
This piano provide with SD card function, you can choose your favorate MIDI song to play;
You can also backup your recording setting to SD card.
This piano still has the MIDI port to help the user to create their own music.
You are recommended to study this manual carefully before using the unit.
3
NOTE:
Pressing [+] and [-] buttons together when turning on the piano, will put all values back to default setting.

4
Conent
Set-up Guide
General Guide
The Connectors
- Using the AC power jack
- Using Headphones
- Using the AUX.OUT jack
- Using the Foot Pedals
- Using the MIDI IN/OUT jack
- Using the USB jack
Operation
- Power on & Master Volume
- Song
- Voices and Effects
- Metronome
- Style Control
- Record
- Lesson
- SD Function
MIDI
- What is MIDI
- MIDI Connection Method
- Major Application
Specifications
Voice List
Style List
Song List
MIDI Implementation Chart
5-7
8-9
10-11
10
10
10
11
11
11
12-22
12
12-13
13-17
18
18-19
20-21
21
21-22
23
23
23
23
24
25
25
26
27

Open the package, and check whether the following parts are available:
1. Piano body
2. Music stand
3. Left leg component
4. Left front leg
5. Right leg component
6. Right front leg
7. Foot pedal unit
8. Back panel skirt
5
9. Left metal strip
10. Right metal strip
11. Hand screws(4pcs)
12. Screws 6x45 (2pcs)
13. Screws 6x18 (6pcs)
14. Screws 6x35(4pcs)
15. Screws 6x12(2pcs)
16. Screws 4x15(4pcs)
17. Power cable stabling hook(2pcs)
Set-up Guide
3
9
4
5
7
11 12 13 14 15 16 17
8
6
10
1、

6
Set-up Guide
Follow the illustration below and finish off the set-up procedures.
6x45 1PC
6x45 1PC
6x35 2PCS
6x18 2PCS
6x18 2PCS
6x35 2PCS
A. Please use the screws( 6x45) fixed the front legs to correspond legs components,
as follow guide:
B. Please use the screws( 6x18) fixed the metal strips to correspond legs components,
as follow guide:
C. Put the foot pedal unit in between the left and right legs components, use 4 pieces of
screws ( 6x35, 2PCS on each side) to stable the legs onto the foot pedal unit.
2、

7
E. Put the piano body on the top of the assembly in part D. Use 4 pieces of hand
screws and 2 pieces the screws ( 6x18) to stable afterward.
finished
F. After the initial set-up, connect pedal cable in the foot pedal unit to
and stick the cable stabling hook on the internal side of the leg component to fix the pedal
cable.(See the below illustration for reference).
the rear-panel PEDAL jack,
D. Use 2 pieces the screws( 6x12) and 4 pieces the screws ( 4x15) to stable the back
panel skirt onto the assembly finished in PART C.
Set-up Guide
4x15 4PCS
Hand screws 4PCS
6x12 2PCS
Cable stabling hook
6X18 2PC

Top View
Rear View
Front View 5
Control Panel
Pedal Jack
MIDI IN/OUT Jack
AUX. OUT Jack
Special Pedal Clog
Headphones Jack
1
2
3
4
5
6
Soft Pedal
Sostenuto Pedal
Sustain Pedal
Music Stand
Piano Keyboard
USB Jack
7
8
9
10
11
12
8
General Guide
12

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
POWER SWITCH
MASTER VOLUME
BRILLIANCE
START/STOP
FILL A/FILL B
ACC.VOL
TRANSPOSE +/-
TEMPO +/-
RECORD
TRACK 1/SONG MELODY OFF
TRACK 2
PLAY/STOP
METRO
BEAT LED INDICATOR
LED DISPLAY
- VOICE
- STYLE
- SONG
16
+/YES & -/NO
STYLE
VOICE
SONG
VOICE DIRECT SELECT BUTTONS
VOICE DEMO
SCALE
REVERB/CHORUS
DUAL
SPLIT
TOUCH
SD CONTROL
- PLAY/STOP
- STORE
SD SLOT
17
18
19
20
21
22
23
24
25
26
27
28
9
VOLUME
I
- +
SONG
STYLE VOICE GRD.PIANO
BRT.PIANO
E.PIANO 1
E.PIANO 2
HARPSICD
VIBES
DRAWBAR
CHR.ORGAN
ACCORDION
HARMONICA
ST.GUITAR
STR.TRIO
STRING
SLOW.STR
TRUMPET
BRASS
FOLKSAX
OBOE
JZ.FLUTE
PANFLUTE
SCALE
TOUCH
SD CONTROL
DUAL
REVERB/
CHORUS
VOICE
DEMO
SPLIT
METRORECORD TRACK 1 TRACK 2 PLAY / STOP
- TEMPO +
START/STOP FILL A/FILL B ACC VOL
BRILLIANCE
I
MELLOW BRIGHT
POWER
ON
OFF
VOIC E STY LE SONG
+ / YES
- / NO
BEAT
- TRANSPOSE +
SONG
MELODY OFF
STORE
PLAY/
STOP
21
15 16
17 18 20
24
10 11 12 13 14
19
22
25
23
26 27 28
Control Panel
General Guide

10
The Connectors
There are two headphones jacks on the left underneath
the piano body.
When an optional set of stereo headphones is connected
with the headphones jack 2, the sound from speakers will
switch off automatically resulting in only the sound from
headphone to be heard.
When jack 1 is connected with the stereo headphones,
the sound can be heard from both headphones and
speakers of the piano.
Connect two pairs of headphones to jack1 and jack2,it
helps the user play with the teacher or friend in a quiet
surrounding.
Headphones
Jack 1
Headphones
Jack 2
1、
2、
3、
Using headphones jacks
Never use the headphone with high volume, as it may hurt your sense of hearing.
To prevent the damage of the speakers, ensure that the volume is set to the
minimum level before connecting the power and other devices.
Ensure the piano is turned
off when connecting and
disconnectiong the power.
1、Turn the volume switch
anti-clockwise to reach
the minimum volume
level.
2、
3、4、If you have done the
above procedures you
are now safe to turn
on the piano.
Using the AC power jack
Plug the power cord into
an AC power outlet.
Set volume to minimum
Turn the power switch off
Turn the power switch on
NOTE:
When the piano is not in use or in the time of thunder-
storm, please disconnect the power for safety sake.
VOLUME
POWER
ON
OFF
POWER
ON
OFF
Connect the rear-panel AUX.OUT jack to amplified
speakers, amplifiers or domestic hi-fi-units for external
amplification.
NOTE:
Connect both left(L) and right(R) channels for the
stereo effect.
If you only connect either one of the channels, the
connected channel will only take effect.
Using the AUX.OUT jacks

Connect the plug of the foot pedal unit to the pedal
jack on the rear panel.
You will experience the sustain/soft/sostenuto effect.
MIDI stand for Musical Instrument Digital Interface.
MIDI is a world wide standard that makes it possible
for various electronic musical instruments and other
devices.
MIDI IN:
MIDI OUT:
Data transmitted from other MIDI instrument via MIDI
is received at this terminal.
Data produced by the Digital Piano is transmitted to
other MIDI instruments via MIDI from this terminal.
11
The connector
Using the Foot Pedals
NOTE:
Step on the sustain pedal ,all notes played on the
keyboard have a longer sustain.
Step on the sostenuto pedal, the notes played before
you step on have a sustain effect.
Step on the soft pedal , all notes played on the
keyboard have a soft effect.
Soft pedal Sostenuto
pedal
Sustain
pedal
Using the MIDI IN/OUT Jack
Using the USB Jack
1、
1、
2、
2、
Connect PC or other USB host devices that support
USB audio.
For devices with USB cable, you can simply connect
the MIDI/USB converter to your USB connector on the
devices and plug the MIDI in or MIDI out cables into the
piano, after the driver is installed and initialization
is finished, you can choose USB Audio Device in the
device menu of the software to transfer midi data.

Turn the [POWER] switch to on. The LED display
lightens up.
Rotate the volume control knob to adjust the volume
to your desired level.
Press the [+/YES] and the [-/NO] button synchronously,
and then power on the piano, it can reset all the setting
to the default value and erase the record data.
12
Operation
Power on & Master Volume
Song
Turn the power switch on
Turn the power switch on
Press first to stop playing the song,
press again to play current song repeatedly.
POWER
POWER
ON
OFF
ON
OFF
The level decreases The level increases
VOLUME
NOTE:
If the LED display has not lightened up after you power on the piano, please check the power supply.
If the piano is silent, the volume may be adjusted to its minimum level.
Although Mains switch is in OFF position, the piano is not disconnected from the power supply completely!
VOICE
VOICE
VOICE
STYLE
STYLE
STYLE
SONG
SONG
SONG
+ / YES
- / NO
BEAT
Press together
1、
1、
2、
3、
There are 60 songs in total. (See Appendix 3 ).
PLAY a song:
Press the [SONG] button to enter the song mode, the
SONG flag on LED is lightened. It will play all songs
repeatedly in a cycle.
Press the [START/STOP] button to stop playing the song,
but it will not quit the song mode. The 2nd time you start
playing the song by pressing the [START/STOP] button,
it will play current song repeatedly.
STYLE
SONG
VOICE
Enter the song mode
and play all songs circlely.
Song flag
is lightened
START/STOP FILL A/FILL B ACC VOL

SONG
MELODY OFF
Operation
SELECT a song:
Use the [+/YES] or [-/NO] button to select the song you
want. If you select the new song, LED will display its
number at first and then display introductory beat and
the measure count.
INTRODUCTORY BEAT:
After pressing [START/STOP] , the measure count begins
from negative value to 1, and then begins to play the song.
Press the [TRACK1/SONG MELODY OFF] button to
enter self-learning mode, and turn on/off the main melody
of the song.
While the song stop playing, you can press the [VOICE],
[STYLE], [DUAL] or [SPLIT] button to exit.
VOICE
VOICE
STYLE
STYLE
SONG
SONG
+ / YES
+ / YES
- / NO
- / NO
BEAT
Select a song
Display the measure count
The beat LED indicators
are lightened in turn.
The LED indicator is lightened.
START/STOP
DUAL
DUAL
FILL A/FILL B
SPLIT
SPLIT
ACC VOL
TOUCH
TOUCH
METRORECORD TRACK 1 TRACK 2 PLAY / STOP
STYLE
STYLE
SONG
SONG
VOICE
VOICE
Exit the song mode
2、
2、
3、
3、
4、
4、
5、
Voices and Effects
There are 20 voices in total (See Appendix 1).
Voice Select
When power is on, LED lightens the VOICE flag and
displays the 001 voice number.
Press the [VOICE] button to enter the voice mode, LED
displays the VOICE R1 number.
Press the [DUAL] button to enter the dual voice mode,
LED displays the VOICE R2 number.
you can select other voice by pressing the [+/YES] and
the [-/NO] or voice Direct Select buttons.
VOICE
VOICE
STYLE
STYLE
SONG
SONG
Display VOICE R1
Display VOICE R2
Select a voice
Press the first time to
select GRD.PIANO
Press the second time
to select BRT.PIANO
Use Direct Select buttons to select
There are 10 voices Direct Select buttons to select 20
voices. Each Direct Select button can be used to choose
2 different voices.
Press the first time to select upper layer voice , press the
second time to select the lower layer voice.
When you select the upper layer voice, the upper layer
indicator turns on;
when you select the lower layer voice, the lower layer
indicator turns on and the upper layer indicator turns off.
1、
13

Operation
VOICE
Each demo song demonstrate one voice which is
selected.
In the voice/style status:
When playing the VOICE DEMO, press [VOICE DEMO]
again to exit the demo mode.
If you change the voice , and it will exit the demo mode.
DEMO
VOICE STYLE SONG
Voice status
Turn off the button to play VOICE R1 demo
Turn on the button to play VOICE R2 demo
DUAL
DUAL
SPLIT
SPLIT
TOUCH
TOUCH
VOICE
DEMO SCALE
REVERB/
CHORUS
REVERB/
CHORUS
VOICE
DEMO SCALE
Turn on the DUAL voice
The indicator goes off.
DUAL
DUAL
SPLIT
SPLIT
TOUCH
TOUCH
+ / YES
- / NO
Change a voice
and exit the demo.
Press it again to
exit the demo.
2、
2、
3、
3、
4、
4、
1、
1、
In VOICE R1 mode, press [VOICE DEMO] button to
play the demo song which is programmed with the
current R1 voice.
In DUAL mode, press [VOICE DEMO] button to play
the demo song which is programmed with the current
R2 voice.
Press the [DUAL] button to turn on the DUAL mode,
the VOICE flag on the LED and the indicator are both
lightened. The dual voice number is also displayed on
the LED.
Then, you can get two different sounds at the same time
when you press one key on the keyboard.
Use the [+/YES] / [-/NO] button and voice Direct Select
buttons to select your desired voice. The default voice
number is 007.
Press the [DUAL] button again to turn off the DUAL mode,
the indicator goes off.
NOTE:
While the keyboard is in split mode, only the right hand
area can respond the dual voice, the left hand below
split point would respond.
VOICE STYLE SONG
+ / YES
- / NO
BEAT
Select a dual voice
VOICE STYLE SONG
Voice flag is lightened
Two voices will sound
at the same time.
Eg. Piano
Eg. Cello
DUAL
The piano has dual voice. You can create the new sound through this function for richer and punchier
sounds. You can get two different sounds at the same time when pressing one key in the right area in
the keyboard.
14

BRILLIANCE
When the piano is power on, rotate BRILLIANCE knob
clockwise, it sounds brighter ; rotate BRILLIANCE
knob anti-clockwise,it sounds more gloomy.
You can change the piano brilliance as your wish.
This function allows you to change the tonality of the
sound.
Rotate to adjust the brilliance
BRILLIANCE
I
MELLOW BRIGHT
For a mellower sound For a brighter sound
Operation
VOICE STYLE SONG
Display touch value
Select touch response type
2、
3、
1、
TOUCH
This function allows you to turn on the dynamic level
when playing the keyboard.
When power is on , the TOUCH indicator lightened.
Press the [TOUCH] button continuously to select the
touch response type, the TOUCH indicator flashes and
displays touch response type 00X temporarily on LED.
There are 4 touch response types. Press [TOUCH] button
repeatedly to select, the default is 002.
If the type is set as OFF, it means no touch response to
keyboard, the TOUCH indicator goes off.
NOTE:
If you don't press any button for 2 seconds in touch
response type select mode, it will quit this mode
automatically.
The indicator flashes
DUAL SPLIT TOUCH
VOICE
VOICE
STYLE
STYLE
SONG
SONG
+ / YES
- / NO
BEAT
15
2、
3、
1、
VOICE STYLE SONG
Display split parameter
Change split point
The indicator is flashing.
DUAL SPLIT TOUCH
VOICE STYLE SONG
+ / YES
- / NO
BEAT
Melody
area
Chord
area
Default split
point F#3
SPLIT POINT
You can split the keyboard to melody and chord area
by this function.
Press the [SPLIT] button, LED displays the current split
parameter XXX .
Use the [+/YES] / [-/NO] button or keyboard to change it,
after exit the setting mode the new value becomes to the
new split point, the split default value is 34.
The new split point belongs to the left area of the keyboard.
NOTE:
The volume level will be increased/decreased slightly
when rotating the [BRILLIANCE] to the BRIGHT/MELLOW.

Operation
REVERB/CHORUS effect will make the keyboard
sound much more fully and widely.
When power is on, the REVERB/CHORUS indicator is on.
Press the [REVERB/CHORUS] button to switch the DSP
response setting.
Press [REVERB/CHORUS] repeatedly to switch to reverb
or chorus setting mode.
There are 32 level to be selected by pressing [+/YES]
and [-/NO] button. The default chorus level is 00, the
default reverb level is 08.
VOICE
DEMO SCALE
REVERB/
CHORUS
VOICE STYLE SONG
VOICE STYLE SONG
REVERB/CHORUS
2、
3、
4、
1、
VOICE
VOICE
STYLE
STYLE
SONG
SONG
+ / YES
+ / YES
- / NO
- / NO
BEAT
BEAT
16
TRANSPOSE
You can change the pitch of the entire keyboard by
semitone steps with TRANSPOSE function.
Press the [TRANSPOSE +] or [TRANSPOSE -] button
for the first time, LED displays current transpose value
temporarily.
Press [TRANSPOSE +] to increase the value and
Press [TRANSPOSE -] to decrease the value, the
maximal range to be adjusted is from -012 to +012
semitones, the default value is 000.
In TRANSPOSE setting , press the [TRANSPOSE +]
and [TRANSPOSE -] button simultaneously to set the
value to default.
NOTE:
If you don't press any button for 2 seconds in transpose
setting mode, it will quit this mode automatically.
- TRANSPOSE +
- TRANSPOSE +
- TRANSPOSE +
- TEMPO +
- TEMPO +
- TEMPO +
VOICE
VOICE
STYLE
STYLE
SONG
SONG
Display current transpose value
Display default transpose value
increase the value Decrease the value
- TRANSPOSE + - TEMPO +
2、
3、
4、
1、

Operation
SCALE
This function allows you to experience different scales
when you play certain genres of music that is not comp-
osed based on twelve equal interval.
Press [SCALE] button to enter into scale mode and the
button indicator lights up; The default scale is 001
Pythagor.
There are 6 types of scale to select:
Pythagor, Major, Minor, Meantone, Werckmei, kirnberg.
Press [SCALE] button again to exit scale mode and the
button indicator goes off.
Hold and press [SCALE] for 2 seconds to enter into SCALE
select status. The scale now flashes and the scale number
displayed on LED.
Use [+/YES] or [-/NO] to select the scale type, play the
key from C7~B7 to select scale root.
VOICE
DEMO SCALE
REVERB/
CHORUS
VOICE
VOICE
STYLE
STYLE
SONG
SONG
Enter scale mode and
the indicator lights up.
Press and hold the button for
2 seconds to enter scale select
status. The indicator is flashing.
Display scale type.
Display scale root.Press the G7 key
C7 B7
VOICE
DEMO SCALE
REVERB/
CHORUS
Press the button again to exit scale
mode. The indicator goes off.
VOICE
DEMO SCALE
REVERB/
CHORUS
Number Name Number Name
1 Pythagor
2 Major
3 Minor
4 MeanTone
5 Werckmei
6 Kirnberg
Types of scal e :
Select the scale type
VOICE STYLE SONG
+ / YES
- / NO
BEAT
2、
3、
4、
5、
1、
For example, to select the scale named"Minor"
and set the root key to "G",keep pressing [+/YES]
till "003 " displayed temporarily on the LED,
then press the G7 key to set the root, LED displays
"G","G" stands for "Scale Root".
PEDAL
1、
SUSTAIN Pedal
When you step on the sustain pedal, all notes
played on the keyboard have a lingering effect.
3、
SOFT Pedal
when you step on the soft pedal, all notes played
on the keyboard have a soft effect. The volume is
reduced slightly
2、
SOSTENUTO Pedal
When you step on the pedal, the first note you play
has a sustain effect, but all subsequent notes will
not sustain. Soft
Pedal
Sostenuto
Pedal
Sustain
Pedal
17

Metronome
Style Control
Operation
Press the [METRO] button to turn on the metronome and
the metronome sound will be played.
Press the button again to turn off the metronome.
When the style stops to play, the beat type follows 4/4
after turning on the metronome.
When the style begins to play, the beat type follows the
current style.
Metronome can be turned on together with the style.
If the style plays at first, then to turn on the metronome,
the metronome will respond next measure.
If the metronome plays at first, then to start to play the
style, the metronome responds at once to the first beat
of the style.
VOICE
VOICE
STYLE
STYLE
SONG
SONG
+ / YES
+ / YES
- / NO
- / NO
BEAT
BEAT
SONG
MELODY OFF
The LED indicator is lightened.
Metronome can be turned on
together with the style.
METRORECORD TRACK 1 TRACK 2 PLAY / STOP
The beat LED indicators
are lightened in turn.
The beat LED indicators are flashing at the same time.
2、
2、
2、
3、
4、
1、
1、
1、
STYLE SELECT
Press the [STYLE] button to enter style mode, the style
number and style flag on the LED are both lightened.
You can use the [+/YES] / [-/NO] button to select the
style you want.
START/STOP THE STYLE
When the style is not playing, you can press the
[START/STOP] button to enter SYNC START
mode, the beat point are flashing at the same time,
now the style will be start with A.B.C. on if you press
the key in the chord area on keyboard.
Press the [START/STOP] button again to stop style play
and turn off the A.B.C. function at the same time.
" "
There are 20 styles in total. (See APPENDIX 2). STYLE
SONG
VOICE
VOICE STYLE SONG
Style flag Style number
Select the style
VOICE STYLE SONG
+ / YES
- / NO
BEAT
START/STOP FILL A/FILL B ACC VOL
Enter " SYNC START " mode
Chord area
18

Operation
FILL IN A/B
In NORMAL mode, press the [FILL A/FILL B] button to
insert 1 measure fill and the FILL A/FILL B indicator is
flashing, after one measure is over, the style enters
variation mode.
In VARIATION mode, press the [FILL A/FILL B] button
to insert 1 measure fill and the FILL A/FILL B indicator
is flashing, after one measure is over, NORMAL style
will be returned.
When power is on, the preset style mode is NORMAL
mode.
ACCOMP VOLUME
Press the [ACC VOL] button, LED displays the current
volume temporarily.
You can use the [+/YES] / [-/NO] button to adjust the
volume from 0 ~ 31. (Default Accomp Value is 24)
The ACC VOL indicator is flashing at the same time.
When power is on, the ACC VOL indicator is on.
In ACC VOL mode, press the [+/YES] and [-/NO]
buttons synchronously can mute the accompaniment,
the ACC VOL indicator goes off at the same time;
If you press the [+/YES] and [-/NO] buttons again
synchronously can open the accompaniment, the
ACC VOL indicator is lightened at the same time.
START/STOP
START/STOP
START/STOP
START/STOP
START/STOP
START/STOP
START/STOP
START/STOP
START/STOP
FILL A/FILL B
FILL A/FILL B
FILL A/FILL B
FILL A/FILL B
FILL A/FILL B
FILL A/FILL B
FILL A/FILL B
FILL A/FILL B
FILL A/FILL B
ACC VOL
ACC VOL
ACC VOL
ACC VOL
ACC VOL
ACC VOL
ACC VOL
ACC VOL
ACC VOL
Preset style mode is NORMAL
mode, the indicator is off.
Style is not playing:
Style is playing:
The indicator is flashing, after a
measure is over, the indicator is
on, enter VARIATION mode.
The indicator is flashing, after a
measure is over, the indicator is
off, enter NORMAL mode.
Press and enter VARIATION
mode, the indicator is on.
VOICE STYLE SONG
The indicator is on.
The indicator
is flashing.
The indicator
goes off.
Display current volume.
Adjust the
volume
Press them
together.
Press them
together.
VOICE
VOICE
STYLE
STYLE
SONG
SONG
+ / YES
+ / YES
- / NO
- / NO
BEAT
BEAT
- TRANSPOSE + - TEMPO +
VOICE STYLE SONG
Display default tempo.
- TRANSPOSE + - TEMPO +
VOICE STYLE SONG
Display current tempoAdjust the tempo from 30~280.
Use the [TEMPO+] or [TEMPO-] button to adjust the
tempo from 30 to 280.
Press the [TEMPO+] and [TEMPO-] synchronously to
set to the default tempo.
When the style is not playing, it will take out the default
tempo of the style if you select the style.
When the style is playing, it will keep the current tempo
once you change the style.
2、
2、
2、
3、
3、
3、
4、
1、
1、
1、
19
TEMPO

Record
Operation
There is one user song can be recorded, include 2
Melody Tracks.
RECORD SONG
Waiting for recording:
Press the [RECORD] button for the first time to enter
the record mode.
The RECORD indicator flashes, four beats flashes
synchronously to indicate waiting for recording.
At the same time an empty track will be selected to be
recorded automatically and relative track flag flashes
(the selection order is Track1,Track2, the Track1 will be
selected while neither the tracks is empty )
You also can press the [TRACK 1/SONG MELODY OFF]
or [TRACK 2] button to select the track you want to record.
Start recording:
When 4 beats flashes, you can play the keyboard directly
to start recording, the RECORD indicator and the track
flag that you select both flashes.
When 4 beats flashes, you can also press the [START/
STOP] button, open the A.B.C. and start record.
Press the key in the left area and sync start style, then
style data are recorded to the correspond track.
If the two tracks all have style data, it will be overwrited
by the new data.
Stop recording:
Press the [RECORD] button for the second time to stop
recording. LED display and indicator get back to the
previous mode.
If the capacity is full while recording, the recording will
be stopped automatically with the FUL display on LED.
SONG
MELODY OFF
SONG
MELODY OFF
SONG
MELODY OFF
Enter the record mode,
the indicator is flashing.
The indicator turns on.
The indicator is off.
Play the keyboard to start recording.
Select the record track,
the indicator will flash.
The indicator will still flash.
The indicator turns on.
Get back to previous mode.
METRO
METRO
METRO
RECORD
RECORD
RECORD
TRACK 1
TRACK 1
TRACK 1
TRACK 2
TRACK 2
TRACK 2
PLAY / STOP
PLAY / STOP
PLAY / STOP
Four beats flashes synchronously
to indicate waiting for recording.
VOICE STYLE SONG
+ / YES
- / NO
BEAT
NOTE:
The recorded data will not be lost when you turn off the
power.
Hold on the [+/YES] and [-/NO] button together and
power on the piano, it will erase all the recorded data.
START/STOP FILL A/FILL B ACC VOL
Open A.B.C. and start record
Chord area
NOTE:
when entering record mode, the old data of the selected
track will lost.
VOICE STYLE SONG
VOICE STYLE SONG
2、
3、
1、
20
