SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
VK-1302 10’x10’ Display
Plan View
10ft
10ft

© 2017
www.classicexhibits.com
Order #XXXXX General Information
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
Part Identification - Numbering
Spline Connection Base Plate & Extrusion Connection
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all setscrews
and locks during disassembly
7A
Hex Tool - Essential for Assembly
Extrusion & Lock Connection Engaged Lock
LADDERS OR LIFTS
MAY BE REQUIRED

© 2017
www.classicexhibits.com
Order #XXXXX General Information
Graphic Removal
To remove the graphic from
the frame, locate the fabric
pull tab.Gently pull up on the
tab to remove the fabric.
Step 1
Insert corner A. Turn edge of
graphic so silicon welt is
perpendicular to face of
graphic. Insert narrow side
of welt with fabric to outside
into the channel. Repeat for
other side of this corner.
Step 2
Repeat Step 1 for opposite
corner C, then insert corner
B, followed by corner D, to
complete the installation of
the corners.
Step 3
Once all corners are inserted,
press one silicon edge into
channel from corners and
work toward the center.
Make sure welt is fully inserted
into channel. Continue until
all sides are done. Smooth
out edges of graphic.
SEG Graphic Installation
It is important to first insert
graphic into each alternate
corner then to the sides of
the frame. If this is not done,
graphic will not fit into the
frame correctly.
Corner A
Corner D
Corner B
Corner C

© 2017
www.classicexhibits.com
Order #XXXXX
Step 1 of 2
Backwall Assembly
Light Connection
Attach Lights to
Backwall where
desired and tighten
in place.
When desired location
is found, tighten
set screw to secure.
Tighten plastic knob
to secure
wing in place.
Slide connector on back
of A10 clamp into groove
of extrusion.
A10 Clamp Attachment
(If Removed)
Attach connector piece to rack
as shown. Then connect
assembled literature
rack to vertical extrusion.
Literature Rack Attachment
Tighten Lock
to Secure
*

© 2017
www.classicexhibits.com
Order #XXXXX
Step 2 of 2
Canopy Assembly
Connections are made by holding the button
down and sliding the red tube into opposing
tube until the connection is made. To disassemble
push button and pull or twist extrusions apart.
Push-Button
Push-Button
66
6
6
Numbered Label
Using Your Setup Instructions
The Aero Overhead Sign Setup Instructions are created specically for your conguration. They include an
exploded view of the frame which is sequentially numbered. We encourage you to study the instructions
before attempting to assemble your exhibit.
Connections are kept very simple: no tools. Everything assembles with push-button
connectors and pre-connected horizontal sections.
Cleaning and Packing Your Display
1) Use care when cleaning aluminum extrusion or acrylic inserts. Use only non-abrasive cleaners.
2) Retain all packing material. It will make re-packing much easier and will reduce the likelihood
of shipping damage.
Steps:
1) Connect canopy pieces together as shown.
2) Apply pillow case graphic to assembled canopy
A
A
B
B
D
D
CC
Push-Button
Push button then rotate
for packing purposes
