Classique CLPP52SD User manual

User Manual for your Classique
CLPP52SD 52 cm
Canopy Hood
1
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
JW 02/11/12

2
Contents Page
Environmentalnote 3
IMPORTANT SAFETY INFORMATION 4 – 6
Specifications of your cooker hood 7
Dimensions 7
Productdetails 7
Using your cooker hood 8 - 9
Beforefirstuse 8
To use your cooker hood 8 - 9
Cleaning your cooker hood 9 - 10
Generalcleaning 9
The grease filter 10
Maintenance 10 – 13
Removing and cleaning the grease filter 10 - 11
Changingalightbulb 11-12
Fitting the carbon filters 12 - 13
Installation 13 - 17
Electrical connection 13 - 14
Before beginning installation 14 - 15
Installing your cooker hood 15 - 16
Connecting to external ducting 17
Completing the installation 17
Extraction mode or recirculation mode? 18
Troubleshooting 19 - 20
Warrantycard 21 – 22
Contact Details 24

ENVIRONMENTAL NOTE
Note: Before discarding an old appliance, switch off and
disconnect it from the power supply. Cut off and render any
plug useless. Cut the cable off directly behind the appliance to
prevent misuse. This should be undertaken by a competent
person.
oThe packaging materials that we use are environmentally
friendly and can be recycled.
oPlease discard all packaging material with due regard for the
environment.
3

IMPORTANT SAFETY INFORMATION
Your safety is of the utmost importance to us. Please
make sure that you read this instruction booklet
before attempting to install or use the appliance. If
you are unsure of any of the information contained in
this booklet, please contact the Retailer where you
purchased your unit from.
IMPORTANT: Any installation work must be
carried out by a qualified electrician or
competent person.
oThe hood must be installed in accordance with the installation
instructions and all measurements followed.
oIf the cooker hood is installed for use above a gas appliance then
the provision for ventilation must be in accordance with Gas
Safety Codes of Practice and local regulations
oIt is dangerous to alter the specifications or to modify this
product. Do not tamper with it or attempt to modify the
appliance in any way.
oWhen installing the hood, ensure that the following
recommended distances are observed between the highest point
on the hob top (including the burners) and the bottom of the
cooker hood:
Electric cookers: 700 mm
Gas cookers: 700 mm
Coal/ oil cookers: 800 mm
IMPORTANT: DO NOT SET YOUR COOKER HOOD LESS
THAN 700mm ABOVE YOUR COOKER.
oWhen installed between adjoining wall cabinets, the cabinets
must not overhang the hob.
oThe edges of the cooker hood are sharp – be mindful of this as
you handle your appliance, especially during installation and
cleaning. DO NOT CLEAN IN BEHIND THE GREASE FILTERS!
4

oIf the room where the cooker hood is to be used contains a fuel
burning appliance such as a central heating boiler then its flue
must be of the sealed or balanced flue type.
oIf other types of flue or appliances are fitted, ensure that there is
an adequate supply of air in the room.
oWhen the hood is being used in its extractor function, ensure
that the ducting is fire retardant and that there are no bends
sharper than 90 degrees as this will reduce the efficiency of the
hood.
oEnsure the ducting for the extractor function has the same
diameter as the outlet hole all the way through.
oKeep young children from using, playing with or
tampering with the cooker hood. Older children
and infirm persons should be supervised if they are
using the cooker hood.
oYour cooker hood is for domestic use only.
5
oPlease dispose of the packing material carefully –
children are especially vulnerable to it.
oDirty oil is an even greater fire risk.
oAlways put lids on pots and pans when cooking
on a gas cooker.
oThe manufacturer refuses to accept any responsibility for
damages arising to the hood or it catching on fire, from a failure
to observe the fire safety advice contained in this instruction
booklet.
oRemember that when in extraction mode, your cooker hood is
removing air from your room. Ensure that proper ventilation
measures are being observed.

oNote that it removes odours from your room, not steam.
oWarning - Always ensure that the cooker
hood has been disconnected from the power
supply before carrying out any work on the
hood, including replacing light bulbs.
oDo not connect the ducting system of this appliance to any
existing ventilation system which is being used for any other
purpose.
oDo not install above a cooker with a high level grill.
oNever leave frying pans unattended during use as
overheated fats and oils might catch fire.
oThe cooker hood should not be exposed to a direct heat source
from the cooking device underneath it, i.e. naked flame from a
gas burner or heat from electric hob zones without a pan on
them.
oDo not attempt to use the cooker hood if it is damaged in any
way. Never attempt to use it without the grease filter fitted or if
the filter is excessively greasy!
oNever flambé cook under this cooker hood.
oThe lights on this appliance should only be used during operation
of the cooker hood. They should not be left on permanently and
used as a lighting source.
THE MANUFACTURER DECLINES ALL
RESPONSIBILITY IN THE EVENT OF FAILURE TO
OBSERVE THE INSTRUCTIONS GIVEN HERE, FOR
INSTALLATION, MAINTENANCE AND SUITABLE
USE OF THE HOOD.
6

Specifications of your cooker hood
Product dimensions
Height: 162 mm
Width: 520 mm
Depth: 296 mm
Your canopy hood is fitted with:
oSlider control operation
oIntegrated axial motor
o3 speeds
o1 washable aluminium grease filter
o2 halogen lights
oNoise level: 62 / 57 / 52 dB
Extraction capacity: 350 m³ / hr
Standard Accessories: - Non-return airflow flap
Optional extras: - 1 pair S2 carbon filters for air recirculation mode
- DK5 1 metre length ducting kit 125 mm Ø
- DK10 3 metre length ducting kit 125 mm Ø with flat
channelling included.
7

Using your cooker hood
Before first use
IMPORTANT: THIS PROCESS MUST BE FOLLOWED
BEFORE THE COOKER HOOD IS USED FOR THE FIRST
TIME.
oYou should use a good quality stainless steel cleaner on ALL of
the stainless steel areas of your cooker hood, before it is used
for the first time.
oThis will help to leave a silicone water-resistant film to protect
the stainless steel surfaces.
To use your cooker hood
oMake sure that it has been installed by a suitably qualified
person, as per the information contained in the manufacturer’s
installation instructions.
oFind the control panel, which is located at the front right of the
canopy.
oThere are two sliders on the control panel, which perform
separate functions.
1) Light control. The light can be used even when the motor is OFF.
0 = Light OFF
I = Light ON
2) Motor speed control.
= Low speed
= Medium speed
= High speed
8

IMPORTANT: IDEALLY YOU SHOULD SWITCH ON
YOUR HOOD TEN MINUTES BEFORE YOU START TO
COOK, OR AT THE VERY LEAST WHEN YOU BEGIN
COOKING. YOU SHOULD ALSO RUN YOUR HOOD FOR
TEN MINUTES AFTER YOU HAVE FINISHED COOKING.
Cleaning your cooker hood
IMPORTANT: BEFORE CLEANING, ALWAYS ENSURE
THAT YOU HAVE SWITCHED YOUR COOKER HOOD
OFF AT THE OMNI-POLAR SWITCH, SET AT THE
WALL FROM THE CABLE.
Cleaning
oClean the external parts of your cooker hood with mild liquid
detergent and a new damp cloth.
oNever use abrasive powder, corrosive solvents or brushes.
oNever insert pointed objects into the motor’s protective grid.
oOnly clean the control panel and grease filter grill with mild liquid
detergents and a new damp cloth.
oIf you are using the appliance in recirculation mode, then be
sure to replace the carbon filters at the recommended interval
(see section on “Fitting the carbon filter”). A build up of grease
could cause a fire hazard.
oNever attempt to clean the area above the grease filter.
oIMPORTANT: You should regularly use a good quality
stainless steel cleaner to maintain the shine and finish on
the stainless steel areas of your cooker hood.
oThis will help to leave a silicone water-resistant film to protect
the stainless steel surfaces and keep them in good condition for
the life of the product.
9

The grease filter
oYour cooker hood includes a grease filter which helps to absorb
grease particles to protect your kitchen and furniture from
greasy residues.
oThe aluminium filter may become flammable if it becomes
saturated with greasy residue.
oTo prevent this fire hazard, the filter should be cleaned regularly.
Depending on use, this should be done every 10-15 days or at
least once a month, using hot water and normal washing-up
detergent.
oDO NOT WASH THE GREASE FILTER IN A DISHWASHER.
Maintenance
Removing and cleaning the grease filter
oFirst remove the grease filter
by pulling down on the
handle and pulling it away
from the cooker hood.
oSoak the grease filter in hot water and washing up liquid for
about an hour.
oRinse it off thoroughly with hot water.
10
oRepeat the process if required.

oRefit the grease filter once it
has dried.
oIMPORTANT: Let the
grease filter dry
thoroughly before
refitting it in the cooker
hood.
Changing a light bulb
IMPORTANT: BEFORE ATTEMPTING TO CHANGE
A LIGHT BULB, YOU MUST ENSURE THAT YOU
HAVE DISCONNECTED THE COOKER HOOD FROM
YOUR MAINS SUPPLY.
11
oRemove the grease filter (as
described on page 10).
oPrior to touching the light bulbs
ensure that they have cooled
down.
oFind the bulb that requires
replacement, you will find it
located in the light fixture which
is inside the exposed section of
the canopy.
oPress gently on the underside of the bulb that needs to be
replaced and twist anticlockwise to release.

oInsert a new identical 40W (max) bulb.
oIMPORTANT: Defective bulbs should be replaced immediately.
oIf the lights still do not work, make sure that the bulbs are fitted
properly into their housings before you call for technical
assistance. oRefit the grease filter.
Fitting the carbon filter
If the appliance is going to be used in recirculation mode then it is
necessary to a fit a carbon filter. This will help to absorb unpleasant
odours caused by cooking.
IMPORTANT: BEFORE ATTEMPTING TO FIT OR
REMOVE THE CARBON FILTERS, YOU MUST
ENSURE THAT YOU HAVE DISCONNECTED THE
COOKER HOOD FROM YOUR MAINS SUPPLY.
1) Remove the grease filter.
2) Press the carbon filter against
one end of the motor, the fixing
point is in the centre of the
carbon filter.
3) Turn the carbon filter
clockwise, until you feel it click
into place.
12

oRepeat this process for the second carbon filter. You need to
place a carbon filter at either end of the motor.
oRefit the grease filters.
oThe carbon filters should be replaced every 3 - 6 months or if
they show signs of damage.
Installation
IMPORTANT: Before installation read all the
instructions and make sure that the voltage (V)
and the frequency (Hz) indicated on the rating
plate are exactly the same as the voltage and
frequency in your home. The rating plate can be
found behind the grease filter.
The manufacturer declines all responsibility in the event of the installer
failing to observe all the accident prevention regulations in force,
which are necessary for normal use and the regular operation of the
electric system.
Electrical connection
13
YOUR COOKER HOOD IS INTENDED FOR FITTED AND
PERMANENT INSTALLATION.
oThe cooker hood’s power cable must be fitted upstream from the
electrical connection, using an omni-polar switch with a contact
distance of at least 3 mm. THE FUSE MUST BE RATED AT 3
AMPS.
WARNING: THIS APPLIANCE MUST BE EARTHED. It
should only be connected by a competent person, using
fixed wiring via a double pole switched fused spur outlet.

We recommend that the appliance is connected by a qualified
electrician, who will comply with the local regulations. The wires in the
mains lead are coloured in accordance with the following UK code:
Blue = Neutral, Brown = Live, Green/Yellow = Ground
If you only find two wires in the main’s lead (blue and brown),
then neither must be connected to the earth terminal.
oAs the colours of the wires in the appliance’s mains lead may not
correspond with the coloured markings identifying the terminals
in your spur box, please proceed as follows:
oThe blue wire must be connected to the
terminal marked “N” (neutral), or coloured
black.
oThe brown wire must be connected to the
terminal marked “L” (live), or coloured red.
IMPORTANT: If your supply cord is damaged, it must be
replaced by the manufacturer, its service agent, or similarly
qualified persons to avoid any hazard.
Before beginning installation
oCheck that the product purchased is of a suitable size for the
chosen installation area. In addition check whether there is an
electrical socket available that will be accessible once the hood is
mounted. If the product is going to be used in extraction mode,
then there should also be space to connect a ducting hose to the
outside.
oCarry out all necessary masonry work prior to the fitting of the
cooker hood.
oEnsure that all electrical connections are carried out by a suitably
qualified person.
oBefore commencing installation of the cooker hood the grease
filter should be removed.
oCheck inside the product and ensure that there is no transit
packaging or any other materials, such as packets of screws,
guarantees etc. These should be removed and kept for future
use.
14

oIf possible, disconnect and move freestanding or slot-in cookers
from their position, to provide easier access to the rear wall and
ceiling. If this is not possible, then a thick, protective covering
should be placed over the worktop, hob top or cooker. This will
help to protect these surfaces from damage and debris.
oSelect a flat surface for assembling the cooker hood. Cover that
surface with a protective covering and place all cooker hood
parts and fittings on it.
oDo not tile, grout or silicone this appliance to the wall or
cabinetry. This appliance is designed to be surface mounted
only.
Installing your cooker hood
IMPORTANT: YOU WILL HAVE TO DECIDE BEFORE
INSTALLING YOUR COOKER HOOD WHETHER TO USE
IT IN EXTRACTION MODE OR RECIRCULATION
MODE. PLEASE TURN TO PAGE 21-22 NOW TO
UNDERSTAND THE DIFFERENCES BETWEEN THESE
TWO MODES.
oWe recommend that two people install this hood.
oYour cooker hood should only be fitted into the underside of a
kitchen unit.
oIt must be positioned at least 700 mm above the hob
underneath it. You cannot fit this product by securing it between
two cupboards.
IMPORTANT: YOUR COOKER HOOD SHOULD BE CONNECTED
TO YOUR MAINS SUPPLY AFTER THE REST OF THE
INSTALLATION PROCESS HAS BEEN COMPLETED.
15

1) Remove the metal grease filter (A).
2) Create an opening in the underneath of the kitchen unit; the cut-
out must be of the dimensions shown in the drawing below.
16
17).
oIMPORTANT: If you are going
to connect your cooker hood to
external ducting, then you must
complete the steps listed in the
“Connecting to external ducting”
section before carrying on with
the rest of the installation (this
information can be found on
page
3) Make a hole in the inside of the kitchen unit for the electrical cable
to feed through. Remove the screws securing the extractor frame (B)
to the hood and unscrew the 2 lights. Ensure that the two support clips
on either side of the hood are set to accommodate the thickness of the
mounting surface, by adjusting the clip via the screw.
4) Lift the cooker hood towards the cut-out that you made in step 2.
Feed the electrical cable through the hole that you made in step 3.
IMPORTANT: Do not connect the electrical cable to the mains supply
at this stage.
5) Lift the cooker hood fully into the cut out that you made in step 2.
If you are connecting the cooker hood to external ducting, then secure
the ducting hose to the coupling on the appliance.
oOne person should support the hood. The other person should fully
tighten the support screws through the pre-drilled holes in the outer
frame of the hood, into the kitchen unit. Then replace the extractor
frame using the screws (B) and reattach the 2 lights.
oRefit the grease filter.

Connecting to external ducting
oConnect the coupling to the top of the cooker hood, using two of
the smaller screws provided.
oConnect a Ø125 mm ducting hose to a discharge outlet that is
suitable for cooking vapours.
oThe discharge outlet should have a cross section of at least 150
cm² (please note that the ducting hose is not supplied with the
appliance but one can be obtained from the Spares Department).
oThe maximum distance between the coupling and your discharge
outlet should be 3 metres, with one 90 degree bend. For each
additional 90 degree bend, the maximum distance is reduced by
a further metre.
oBefore fixing the cooker hood into the kitchen unit, you should
connect the other end of the ducting hose to the coupling in the
top of the cooker hood.
Completing the installation
oIf you are setting the appliance to recirculation mode, then you
should now fit the two carbon filters. See the “Fitting the carbon
filters” section on pages 12-13.
oThe electrical connection must correspond to the electrical
requirement noted on the rating plate, which is placed inside the
cooker hood. The appliance should now be connected to the
electrical supply. See pages 13-14 for detailed information on
the electrical connection.
oRefit the grease filter and then switch on the mains
supply to the appliance. Check that the appliance is
operating correctly by selecting each speed and
switching the light bulbs on and off.
17

Extraction mode or recirculation mode?
IMPORTANT: YOU WILL HAVE TO DECIDE BEFORE
INSTALLING YOUR COOKER HOOD WHETHER TO USE
IT IN EXTRACTION MODE OR RECIRCULATION
MODE.
What is the difference between extraction and recirculation
modes?
In extraction mode, the stale air will be taken via the grease filter and
out of the room via external ducting.
In recirculation mode stale air is taken via the grease filter, and passed
through a charcoal filter for purification. The air then re-enters the
kitchen via an opening in the hood.
For optimum performance, we recommend that the cooker hood is
used in extraction mode and connected to external ducting.
Unfortunately if you live in a flat or the hood is too far from an outside
wall, this may not be possible. The only alternative is to recirculate the
air.
Recirculation: Extraction:
18
Do I need a charcoal filter?
a grease filter but if you are using your cookerAll cooker hoods have
hood in recirculation mode, then charcoal filters must be fitted in
ddition to the grease filter.a

Troubleshooting
MPORTANT: If your cooI
pker hood appears not to be operating y before contacting an Authorised Service Agent, please
Check that the hood is connected to the power supply and
e
If the hood is set up for extraction mode, check that the ducting
s
roperl
refer to
,
the table below.
My cooker hood will not start.
owh
ther you have selected any of the fan speeds.
My cooker hood is not working effectively.
oCheck that fan speed is set to an appropriate setting.
oCheck that the grease filter is not dirty and if it requires
cleaning.
oIf the hood is set up for recirculation mode, check that the
carbon filters do not need to be replaced.
oho
e and discharge outlet are not blocked.
My cooker hood is noisy and/or vibrating.
oCheck whether the installation has been completed as per the
instruction booklet.
oIt is normal to get a certain amount of noise and vibration, due
to the extraction capacity of the cooker hood.
DO NOT MAKE ANY ATTEMPT TO REPAIR THE APPLIANCE
YOURSELF. IF THE APPLIANCE IS STILL NOT OPERATING
CORRECTLY, PLEASE CONTACT AN AUTHORISED SERVICE
AGENT BY VISITING WWW.CLASSIQUE.CO.NZ
19

20
cMy applian e isn’t working correctly
IMPORTANT: If your appliance appears not to be
operating correctly, then you should disconnect it
from your mains supply and then contact an
Authorised Service Agent. Log onto
www.classique.co.nz to locate your nearest
guarantee and finds that the problem is not the result of an
engineer is concerned that damage will be
appliance, like plinths. Or any installation other
ates a policy of continuous
provement and reserves the right to adjust and modify its
roducts without prior notification.
Service Agent.
DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF.
Please note that if a service agent is asked to attend whilst the product
underis
appliance fault, then you may be liable for the cost of the call out
charge.
The appliance must be accessible for the service agent to
perform any necessary repair. If your appliance is installed in
uch a way that ans
caused to the appliance or your kitchen, then they will not
complete a repair.
This includes situations where appliances have been tiled in,
sealed in with sealant, have wooden obstructions placed in
ront of thef
than the one specified by the manufacturer has been
completed.
Please refer to the conditions of guarantee that appear on the
warranty card that you receive with the appliance.
MPORTANT: The manufacturer operI
im
p
