Adexa SSCH1A User manual

Range hood
Instruction Manual
Model:SSCH1A/SSCH3A

(1) NOTICE
1. Thank you for choosing our cooker hood. Please read the instruction manual
carefully before use.
2. The installation work must be undertaken by a qualified and competent fitter.
3. The manufacturer disclaims all liability for any damage or injury caused as a
result of not following instructions for installation contained in the following
text.
The cooker hood is used on AC220-240V, 50Hz.
(2)FEATURE
1. The cooker hood uses high quality materials, and is made with a streamlined
design.
2. Equipped with a large power low noise electric motor and centrifugal leaf, it
produces strong suction, low noise, non stick grease filter and easy to clean.
3. With the isolated low voltage circuit board control, 12vDC input, the lights are
therefore safer.
4. Special wind tunnel construction and oil collector design, free dirt will be
absorbed in a second.

(3) .Installation
●Clamps and hooks for installation
inner chimney holder
outer chimney holder
Wall hook
>> Pyramid range hood:
3. 1 The cooker hood should be placed at a distance of 65-75cm(26-30inch)from the cooking surface for the
best effect.See the Pic 1.
3.2 Install the hook on a suitable place once the installation height is
fixed,and keep it in line.The fixed position of the inside chimney bracket
is the place of chimney.
3.3 Fix the outside chimney bracket on the outside chimney,and be sure
that the inside chimney can be adjusted the height in in freely as well as
fixing the extensible pipe.Afterwards,install the extensible pipe and
chimney on the cooker hood.See Pic 3.
3.4 Put the cooker hood on the hook.See Pic 4.
3.5 Adjust the height of the inside chimney to the position of the inside chimney bracket and fix on it by
screw,after adjusting the position,fix the body with safety screw,See Pic 5.
Note:The two safety vents are positioned on the back casing,with diameter of 6mm

>>T shape range hood:
3.1The cooker hood should be placed at a distance of 65-75cm(26-
30inch)from the cooking surface for the best effect.See the Pic 1.
3.2 Install the hook on a suitable place once the installation height
is fixed,and keep it in line.The fixed position of the inside chimney
bracket is the place of chimney.
3.3 Fix the outside chimney bracket on the outside chimney,and be
sure that the inside chimney can be adjusted the height in in freely
as well as fixing the extensible pipe.After wards install the
extensible pipe and chimney on the cooker hood. See Pic 3.
3.4 Put the cooker hood on the hook.See Pic 4.
Adjust the height of the inside chimney to the position of the inside chimney bracket and fix on it by
screw,after adjusting the position,fix the body with safety screw^See Pic 5. Note:The two safety vents are
positioned on the back casing,with diameter of 6mm.
---- Warning: Failure to install the screws or fixing device in accordance with
these instructions may result in electrical hazards.

(5) NOTICE OF INSTALLATION
1. Before installation, please ensure the area is clean to avoid suction of
the remaining bits of broken wood and dust.
2. It cannot share the same air ventilation tube with other appliance such as
gas tube, warmer tube, and hot wind tube.
3. The bending of ventilation tube should be≥120°, parallel or above the
start point and should be connected to the external wall.
4. After installation, make sure that the extractor is level to avoid grease
collection at one end.

(6) SAFETY WARNING
Never let the children operate the machine.
The cooker hood is for home use only, not suitable for barbecue, roast shop and other commercial
purpose.
The cooker hood and its filter should be clean regularly in order to keep in good working condition.
Clean the cooker hood according to the instruction manual and keep the unit from danger of burning.
Forbid the direct baking from the gas cooker.
Please keep the kitchen room a good convection.
Before connecting this appliance check that the power supply cord is not damaged. A damage supply
cord must be replaced by qualified service personnel only.
There shall be adequate ventilation of the room when the range hood is used at the same time as
appliances burning gas or other fuels
The air must not be discharged into a flue that is used for exhausting fumes from appliances burning
gas or other fuels
Regulations concerning the discharge of air have to be fulfilled.
Do not flame under the range hood.
The range hood is not intended to be installed over a hob having more than four hob elements
This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
The air must not be discharged into a flue that is used for exhausting fumes from appliances burning
gas or other fuels.
When the range hood and appliances supplied with energy other than electricity are simultaneously
in operation, the negative pressure in the room must not exceed 4 Pa (4 x 10-5 bar).
CAUTION: Accessible parts may become hot when used with cooking appliances.
Electrical Shock Hazard
Only plug this unit into a properly earthed outlet. If in doubt seek advice from a suitably qualified
engineer.
Failure to follow these instructions can result in death, fire, or electrical shock.

(7) USE (Speed adjustment .See pictures)
>>>Push button
pi c6 C
1. Push stop button, and the motor will stop.
2 . Push the Low button, the buzzer will buzz once, and the motor runs at low speed.
3. Push the high button, the buzzer will buzz once, and the motor runs at mid speed.
4 . Push the High button, the buzzer will buzz once, and the motor runs at high speed.
5. Push the light button and the two lights will come on. Push it again and the light
will turn off.
Light
High Mid Low
Stop

(8) MAINTENANCE
8.1 The cleaning of the grease filter mesh
The filter mesh is made of high-density aluminum. Please do not use the corrosive
detergent on it. Keeping this filter clean will keep the appliance running correctly.
Please strictly follow the guidelines below.
Method 1: Put the mesh into 40-50 c clean water, pour on detergent, and soak for 2-3
mins. Wear gloves and clean with a soft brush. Please do not apply too much pressure,
as the mesh is delicate and will damage easy.
Method 2: If instructed to do so, it can be put into a dishwasher.

8.3 Notice of cleaning cooker hood
A. To protect the main body from corrosion over a long period of time, the
cooker hood should be cleaned with hot water plus non corrosive detergent
every two months.
B. Please do not use abrasive detergent for it will damage the body.
C. Keep the motor and other spare parts free from water, as this will cause
damage to the appliance.
D. Before cleaning the appliance please remember to cut offpower
E. The carbon filter shouldn’t be exposed to heat.
F. Please don’t tear open the fixed bar around the carbon filter
G. If the plug or cord is damaged, please replace it with special soft cord.
(9). Abnormity and Solution
Fault
Cause
Solution
Light on, but motor does
not work
The leaf blocked
Get rid of the blocking
The capacitor damaged
Replace capacitor
The motor jammed bearing damaged
Replace motor
The internal with of motor off or a bad
smell from the motor
Replace motor
Light does not work, motor
does not work
Beside the above mentioned, check the following:
Light damaged
Replace lights
Power cord looses
Connect the wires as per the
electric diagram
Oil drops from the metal
grease filter
Heavily fouled filter
Immediately clean or replace the
metal grease filter
Shake of the body
The leaf damaged and causes
shaking
Replace the leaf
The motor is not tightly hanged
Lock the motor tightly
The body is not tightly hanged
Fixed the body tightly
Insufficient suction
The distance between the body and
the gas top too long
Readjust the distance
Too much ventilation from open
doors or windows
Choose a new place and
resemble the machine
The machine inclines
The fixing screw not tight enough
Tighten the hanging screw and
make it horizontal
The hanging screw not tight enough
Tighten the hanging screw and
make it horizontal

Environment Protection
According to the European waste regulation 2012/ 19/EU this symbol on the product or on its packaging
indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate
collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment and human health, which
could otherwise be caused by inappropriate waste handling of this product. For more detailed information
about recycling of this product, please check with your Local Authority or retailer for recycling advice.
