CLD CLDPCHB Configuration guide

SKU# CLDPCHB / CLDPRHB / CLDPCFG / CLDPRFG / CLDPCFGY / CLDPRFGY / CLDPCFL CLDLED.COM
1
WHAT’S INCLUDED:
1 X LED Pod
1 X U Mount Bracket
Mounting Hardware
STREET LEGAL
3" CUBE POD LIGHT
CLDPCHB
CLDPRHB
CLDPCFG
CLDPRFG
CLDPCFGY
CLDPRFGY
CLDPCFL
FEATURES & SPECIFICATIONS:
Light Output: 620-1,434 Lumens
Power: 20W @ 13.6V DC
Current: 1.5A @ 13.6V DC
Voltage: 10 - 36V DC
Beam Pattern & Compliance:
Cube / Round Auxiliary High Beam (SAE J581)
Cube / Round Fog Light (SAE J583)
Cube / Round Fog Light, Yellow Lens
Cube Flood Beam
MOUNTING BRACKET INSTALL INSTRUCTION
Dimensions: mm

SKU# CLDPCHB / CLDPRHB / CLDPCFG / CLDPRFG / CLDPCFGY / CLDPRFGY / CLDPCFL CLDLED.COM
2
HARNESS INSTALL INSTRUCTION
Wiring Harness sold separately
1. Determine and suitable mounting locations to install the LED Pods, wiring harness and switch. Once
all mounting locations are confirmed, connect the wires as shown above. Proper insulation at
connections is required.
2. Connect positive wire and negative wire properly. Press the switch to test if the lights are
functioning properly.
3. Adjust the light to the desired angle and then secure by tightening all mounting screws.
