WHAT’S INCLUDED:
1 X LED Work Light
2 X Bottom Mount Brackets
Mounting Hardware
6" SLIM LED LIGHT
FLOOD BEAM
CLDMPD6
FEATURES & SPECIFICATIONS:
Light Output: 772 Lumens
Power: 18W @ 13.6V DC
Current: 1.3A @ 13.6V DC
Voltage: 10 - 36V DC
Beam Pattern: Flood Beam
MOUNTING BRACKET INSTALL INSTRUCTION

SKU# CLDMPD6 CLDLED.COM
2
HARNESS INSTALL INSTRUCTION
Wiring Harness sold separately
1. Determine and suitable mounting locations to install the LED work lights, wiring harness and switch.
Once all mounting locations are confirmed, connect the wires as shown above. Proper insulation at
connections is required.
2. Connect positive wire and negative wire properly. Press the switch to test if the lights are
functioning properly.
3. Adjust the light to the desired angle and then secure by tightening all mounting screws.
