User instructions
ArcSource 1 MC Short
The module generate colored light by means of RGBW LED multichip.The product was designed for exterior
use and it is ideal for locations where signaling,directional or e󰀨ect lighting is required.
1.Attention
Consider the respective national norms during the installation!
Do not install the unit near naked ames
Avoid using the unit in locations subject to possible impacts
Do not attempt to dismantle or modify the unit
2.Installation
The ArcSource unit has to be connected to the power source of type of LVLE acording to the specications
stated in the chapter "Technical specications".
CAUTION!
Avoid looking directly into the LED light beam at close range!
3. Connection
ArcSource 1 MC Short

Adapter cable Chogori/ RJ45 betwen xture and LED driver
4.Technical specications
Max. power consumption: 4.4W
Max input current per colour: 350 mA
Max. input voltage: 48V
Operating ambient temp.range: -20°C/+40°C
Cooling : convection
LED device: Cree MC-E RGBW multichip
Typical Lumen maintenance: 70%@ 60,000 hours
Led life expectancy: minimum 60,000 hours
Available beam angles: 27°, 35°
Transparent cover: 6 mm clear at tempered glass (24°beam angle)
Construction: stainless steel top ange
brass housing
Weight: 0.2 kg
IK rating: IK 07
Protection factor: Suitable for wet location
Power /data plug: Chogori 08BMMA-SL8001
Power /data cable Flamar LiYY 8xAWG22 UL Style 2517/CSA O.D. 6,70mm
(0.5 m length)
5.Dimensions
(All dimensions are in mm)
"OSF" version (Oversized ange)
6. Accessories
1 x Splitter (No. 13050690)
1 x Connector Chogori CGRBDU-08BFFA (female)
7. Optional Accessories
Adapter cable CGRBDU-08BFFA/RJ4 RJ45, L=3m (No. 13051630)
Adapter cable CGRBDU-08BFFA/RJ4 RJ45, L=7m (No. 13051631)
Adapter cable CGRBDU-08BFFA/RJ4 RJ45, L=15m (No. 13051682)
T-connector Chogori 8-pin (No. 13051938)

Specications are subject to change without notice.
Version 1.8 US
May 2, 2017
8. ArcSource 1 MC Short with spring clips
This version of the ArcSource 1 MC Short allows to place the ArcSource 1 MC Short into a hole in a at surface
(e.g. lower ceiling). The ArcSource unit is xed in the right position by means of the two springs. Prepare the
hole (37-40mm) in a lower ceiling, bend up both clips and pull the ArcSource unit throw the hole.
