Clean Island Breathing 1500/3000 Portable Air Filtration System Manual 2014
Portable
Air Filtration
Systems
Instruction Manual
Models 1500 & 3000
Read and
keep this manual for
reference purposes

Clean Island Breathing 1500/3000 Portable Air Filtration System Manual 2014
Specications (all models)
CLASSIFICATION
• Portable HEPA (High Efciency Particulate Air)
100% Sealed Air Cleaning Device
• C.S.A. approved
MATERIALS: 24 gauge cold rolled steel
FINISH: Powder coated baked enamel
COLOR: Sandstone
INTAKE (Upper Section)
Perforated steel enclosure surrounding a three-
stage lter assembly.
OUTFLOW (Lower Section)
Encloses motor/fan.
MOTOR/FAN
• Thermally protected Class “B” insulated motor
• Designed for continuous operation
• Run tested for 50,000 hours
• Service: 120 Volt, 60 Hz.
CONTROL: 3 Speed Electronic Control
Model 1500
DIMENSIONS: 16” W, 13.5”H
WEIGHT: 15 lbs.
AIR FLOW (C.F.M.): 50-175
POWER USAGE: 41-84 Watts
Model 3000
DIMENSIONS: 16” W 23”H
WEIGHT: 22 lbs.
AIR FLOW (C.F.M.): 50-225
POWER USAGE: 41-84 Watts
Thank you for purchasing a Clean Island Breathing portable air filtration system. With
proper care and maintenance, your Clean Island Breathing system will provide many
years of reliable service, improving the quality of your air.
ABOUT FILTERS AND SERVICE LIFE
The life spans of the individual lters are:
STAGE 1 PREFILTER: 3 to 6 months
STAGE 2 HEPA FILTER: 2 to 5 years
STAGE 3 V.O.C. BLANKET: 6 to 8 months
OPTIONAL V.O.C. CANISTER: 6 to 12 months
The useful service life of the lters is directly related to the volume of air passed through the
system and the amount of contaminants in the air. If your indoor air contains abnormally
high levels of airborne contaminants (such as cigarette smoke) the life of the lters may be
shortened. The HEPA lter’s particulate removal efciency actually improves with use as it
loads up with particulates. However, as it loads up it also becomes more difcult to move air
through the system. If you notice a signicant drop in air ow from the unit, the HEPA lter
should be replaced.
THREE-STAGE FILTRATION
STAGE 1: Prelter
Removes large particulates and odors. Extends the life of the
HEPA lter.
STAGE 2: HEPA Filter
99.97% efcient @ 0.3 microns. Removes dust, pollen,
bacteria, animal dander, attached viruses, cigarette smoke,
radon daughters and more.
STAGE 3: V.O.C. Blanket
Removes odors and hazardous chemicals that may off-gas
from cleaners, paints, solvents, carpets, furniture and other
items containing synthetic materials.
OPTIONAL V.O.C. Canister
For heavy-duty removal of gases and odors.

Clean Island Breathing 1500/3000 Portable Air Filtration System Manual 2014
Clean Island Breathing L.L.C.
Questions? Comments? Email us at: [email protected]
P.O. Box 10271, Lahaina, HI 96761
Clean Island Breathing reserves the right to change or modify any specications without notice.
Visit our website at: www.cleanislandbreathing.com
REPLACEMENT PARTS
Item Item Number
US
1500
Replacement HEPA Cartridge - 8” ET 90012206
Annual Filter Kit: Standard - 8” ET 94012011
Annual Filter Kit: Plus - 8” ET 94012231
Motor 99011150
3000
Replacement HEPA Cartridge - 16” ET 90015406
Annual Filter Kit: Standard - 16” ET 94015011
Annual Filter Kit: Plus - 16” ET 94015231
Motor 99011150

Clean Island Breathing 1500/3000 Portable Air Filtration System Manual 2014
Opening the cabinet
1. Turn the unit off and unplug it.
2. Unscrew the 5 lid screws. Once all ve
screws are out, remove the metal cover.
3. Bracing the unit so
it does not move,
turn the HEPA
cartridge counter-
clockwise and lift/
pull out.
Pre-lter
1. Pull the pre-lter
up and off the unit.
NOTE: The pre-fiter may contain
contaminants, remove it slowly to avoid
releasing particles back into the air.
2. Foam pre-lters can be washed several
times, wash by hand in warm water. Let it
dry completely before placing it back onto
the HEPA cartridge.
3. If replacing the lter,
remove plastic shrink
wrap from the new pre-
lter.
4. Stretch the new/washed
lter around the top of
the HEPA cartridge and
slide it down into place
HEPA lter
1. Place the HEPA cartridge gently into the
unit.
2. When the HEPA cartridge is in place,
brace the unit, press down and gently
turn it clockwise to lock it into place. If too
much force is used, the cartridge may be
difcult to remove!
3. If replacing the HEPA lter with a new
lter, discard old HEPA lter and use new
when replacing the HEPA lter into the
unit.
4. With each annual lter replacement kit,
a new ‘o’ ring is provided. The old one
is removed by pinching it between two
ngers and pulling it off the collar on the
blower deck.
5. Discard old ‘o’ ring.
6. Place the new ‘o’ ring onto the collar and
slide it down to the base of the blower
deck.
Inner Carbon Filter Replacement
1. Look inside the HEPA cartridge to locate
the two ends of the inner carbon lter.
2. Pull one end of the old inner carbon lter
in and bend it into a loose roll so it can be
removed.
3. Remove the inner carbon lter from the
HEPA cartridge.
4. Remove plastic shrink wrap from the new
inner carbon lter.
5. Unroll the inner carbon lter and roll it
up in the opposite direction (this makes
the lter follow a more contoured prole
against the inner HEPA
lter surfaces and helps
keep it in place), place the
rolled inner carbon lter
inside the HEPA cartridge
and gently unroll it until the
ends ‘butt’ together and the
lter is snug against the
HEPA lter.
V.O.C. Canister (OPTIONAL)
1. Remove old Carbon Filter by pulling it out
from the inside of the HEPA lter.
2. Remove the plastic shrink wrap from the
new carbon canister.
3. Place the carbon canister inside the Air
Filtration System, smaller end rst.
4. Slide the HEPA Filter over the V.O.C.
Canister and down into the Air Filteration
System.
5. Gently, turn the HEPA Filter until it locks
into place.
Closing the cabinet
1. Position the top cover on the unit with the
centered screw hole at the rear of the unit.
2. To replace the lid screws, apply rm
pressure to the top cover to align the
holes and then insert and fasten screws.
3. Plug the unit in and turn it on.
MAINTENANCE: FILTER REPLACEMENT INSTRUCTIONS
When a red LED lter light is ashing...
HEPA Filter Replacement
As the HEPAfilter captures particulates, it
will darken over time. Replace the HEPA
filter when it darkens to example D.
A. New B. Used C. Used D. Replace

Clean Island Breathing 1500/3000 Portable Air Filtration System Manual 2014
OPERATING YOUR CLEAN ISLAND BREATHING
HEPA AIR FILTRATION SYSTEM
OPERATION
1. Place the unit in the area where you want the cleanest air.
2. Plug the electrical cord provided into a compatible grounded outlet.
3. To operate, select the desired speed by pressing firmly on one of the buttons marked
“HIGH”, “MEDIUM” or “SILENT”. The appropriate green LED light will illuminate and 3
red LED lights will indicate active stage filtration.
4. To stop the unit operation, press firmly on the button marked “OFF”.
FILTER LIGHT INDICATORS
Your HEPA system is equipped with an electronic filter timer. This timer monitors the life
expectancy of each filter in the unit. By default, the Pre-Filter, HEPA Filter and V.O.C.
Blanket lights will turn on when the unit is powered on.
If you have upgraded your V.O.C. Blanket to a V.O.C. Canister, you must activate the
corresponding timer.
- Press and hold the V.O.C. Canister button until the light comes on. The V.O.C. Blanket
light will automatically go off. The control panel will now monitor the life expectancy of
the V.O.C. Canister.
If you are switching your V.O.C. Canister to a V.O.C. Blanket, you must
activate the corresponding timer.
- Press and hold the V.O.C. Blanket button until the light comes on. The V.O.C. Canister
light will automatically go off.
The control panel will now monitor the life expectancy of the V.O.C. Blanket.
When a filter indicator light flashes, it is time to check and replace that filter.
- Turn the unit off and see instructions for “filter removal” to determine if filter replacement
is needed. See ‘Maintenance” on next page.
Once the filters have been checked or replaced, turn the unit back on and reset the
control panel.
- To reset, press and hold the flashing filter button until the light is constant.
CAUTION
1. Make sure the cord is not in the path of people walking or where anything can be rolled
over it.
2. Do not place any objects on top of the unit or allow anyone to sit on it.
3. NEVER place any liquids or plants on the unit. Moisture could leak into the unit and
damage the filter media or electrical components.
4. The air ltration system discharges the cleaned air through the vents near the bottom
on four of the six sides. On “HIGH” the velocity of the air coming out is high to enhance
circulation throughout the area being cleaned. If the airow is bothersome or creates a
draft, turn the unit until the air is directed toward an unoccupied area of the room.

Clean Island Breathing 1500/3000 Portable Air Filtration System Manual 2014
CLEAN ISLAND BREATHING LIMITED WARRANTY
Clean Island Breathing L.L.C. warrants Clean Island Breathing HEPA Air Filtration
Systems to the original retail purchaser as follows:
1. The motor/fan part is warranted for ve (5) years from the date of purchase under the
following conditions:
2. All other component parts (except lters) are warranted for one (1) year from the date of
purchase under the following conditions:
i. The Clean Island Breathing HEPA Air Filtration System has failed under normal use,
due to defects in material or workmanship.
ii. The Clean Island Breathing HEPA Air Filtration System has been operated according to
the manufacturers recommendations.
iii. The Clean Island Breathing HEPA Air Filtration System has been operated in compliance
with the voltages specied on the product.
iv. An authorized Clean Island Breathing dealer or a service provider agreed upon by both
the consumer and the manufacturer has performed an inspection.
v. There have been no attempts to modify the Clean Island Breathing HEPA Air Filtration
System from its original condition.
Actions contrary to the above will void the Clean Island Breathing warranty.
Clean Island Breathing HEPA Air Filtration Systems that have qualied for warranty and
met all of the above conditions will, at the discretion of the manufacturer, have the failing
components repaired or replaced or, at the option of the manufacturer, be replaced with a
new system.
MAKING A WARRANTY CLAIM
The consumer may make a warranty claim by contacting the any authorized Clean Island
Breathing dealer. The dealer will then contact the manufacturer, Clean Island Breathing
L.L.C., to obtain a Repair Return Authorization.
If the consumer is unable to contact an authorized dealer in their area, they should directly
contact the manufacturer, Clean Island Breathing L.L.C., at 1 808 298 9771 or info@
cleanislandbreathing.com to obtain a Repair Return Authorization.
To obtain a Repair Return Authorization, a valid serial number and/or original proof of
purchase must be presented to the manufacturer.
RETURNING THE SYSTEM FOR WARRANTY INSPECTION AND/OR REPAIR
Prior to returning any product for warranty repair, the consumer must remove all lter
components.
In the interest of consumer and employee safety, Clean Island Breathing L.L.C. will not
receive any lter media that has left the manufacturers premises. Any Systems returned for
inspection and/or repair with the lters included will not be received by Clean Island Breathing
L.L.C. and will be returned to the consumer/dealer at the consumer/dealer’s expense.
Excluding the lters, the consumer is required to return all original product components,
including adaptors if applicable.
