ClearCube A1410 User manual

Quick Start Guide
ClearCube Technology 8834 Capital of Texas Hwy N Austin, Texas 78759 voice 512 652 3500 www.clearcube.com
USB 1.1 Ports
Power Indicator Link Indicator Power Button
ClearCube® I9420 I/Ports connect to ClearCube A1410 and R1350
PC blades to provide the following features:
• Support for one or two independently–configurable monitors
• PC–over–IP™ (PCoIP™) processors, delivering PC video and
audio over your IP network
• Four USB 1.1 ports
• Audio in and audio out
I9420 I/Port Overview
In typical ClearCube environments, A1410 and R1350 PC blades
are centrally–located in data centers. Each blade user has an I9420
I/Port on their desk, which is connected to a PC blade over an IP
network. The I9420 provides the interface to the blade. That is, the
user can connect monitors, pointing devices, and other peripherals
to the I9420 to receive peripheral data sent from a blade and to
send USB data to the blade.
Setting up Your I9420 I/Port
1. Place your I9420 on a desk or use the included mounting bracket to
mount the I9420, for example, under a desk or behind a monitor.
2. Connect the following to the I9420:
– USB keyboard and pointing device using the USB ports on
the front or the rear of the I9420.
– CAT5 or CAT6 Ethernet cable to the RJ-45 jack on the rear of the
I9420.
– Monitor cable to each DVI-I port on the rear of the I9420.
– Power adapter supplied with the I9420
3. Ensure that you have connected the power cable and AC adaptor
provided with your I9420. Connect the AC adapter to the I9420,
and then connect the power cable to a power outlet. Press the
power button to power on the I9420.
I9420 I/Port Indicators
The I9420 has the following indicators on the front panel:
• Blue power indicator—Illuminated when the I9420 is powered
on.
• Link LED—Shows when a connection, or link, is established
between the I9420 and a blade.
– Green LED—I/Port and blade are connected.
– Red LED—I/Port and blade are not connected (for
example, the I9420 Ethernet cable is disconnected).
I9420 I/Port
Rear USB 1.1
Ports
Audio Out Audio In
DVI–I
Port 1
DVI–I
Port 2
Power
Connector
RJ-45
I9420 I/Port
Keyboard Pointing Device
Monitor
Network Switch
Chassis and Blades

ClearCube Technology 8834 Capital of Texas Hwy N Austin, Texas 78759 voice 512 652 3500 www.clearcube.com
G0200102 Rev A
Additional Steps
I9420 I/Ports and dual–monitor blades contain PCoIP
processors that enable dual monitor displays. You must
provision the PCoIP processors on your I9420s and on your
blades when deploying them. See User Port Guide at
support.clearcube.com for information about provisioning
PCoIP processors on your I9420.
Email: [email protected]
Web site: support.clearcube.com
Toll-free: [phone]
Phone: [phone]
RoHS
WEEE Disposal Guidelines
In the European Union, this electronic
product falls under the European Directive
(2002/96/EC) WEEE. When it reaches the
end of its useful life or is no longer wanted,
do not discard with conventional waste, but
disposed of at an approved designated
recycling or treatment facility.
Check with your local authorities for proper
disposal instructions.
For assistance, contact ClearCube at
[email protected]
